UCTRONICS Gigabit PoE Splier 802.3af Micro USB
(Model: U515902)
1. INTRODUCTION
Thank you for choosing UCTRONICS.
This Gigabit PoE splier
receives a 44-56V PoE signal from a
PoE switch or PoE injector, and then
separate the data and power onto
two different lines. The data output
is up to 1000Mbps in an RJ45 port,
and the power output is a 5V 2A
direct current (up to 2.5A) in a Micro
USB port.
It provides an ideal soluon for
delivering power and data to non-
PoE devices like Raspberry Pi, IP
cameras and so on.
2.CONNECTION
Plug-and-play with deployed PoE switches or injectors.
UCTRONICS

This PoE splier is supposed to work fine with non-PoE devices that need a
5V 2-2.5A input without any extra configuraon, provided that you have
already deployed your PoE switches or injectors.
Step 1: Connect the Micro USB male port of the splier to the female port
on the target device.
Step 2: Connect the RJ45 male port of the splier to the female port on the
target device.
Step 3: Use an Ethernet cable to connect the PoE splier to a PoE switch or
PoE injector through the RJ45 female port.
3.INDICATOR LIGHT
An indicator light beside the RJ45 input port informs you of its status.
Indicator light Status
ON Powering and transferring data to your target device
BLINKS Data transfer established without powering your target device
OFF Not powering or transferring data to your target device
4.CONTACT US
You are always welcome to throw us quesons, feedback, and advice.
UCTRONICS is an online wholesale company that aims at delivering the best
electronic component modules and open source hardware to every customer.
If you encounter any problem while using our product, please let us know.
Our professional technical team will help you solve it. Please do not hesitate
to contact us if you need any technical support on your UCTRONICS products,
and you are always welcome to send us any feedback or advice.
Website: hp://www.uctronics.com
Email: [e-mail]
