HELLER WFC5 User manual

USER MANUAL
Water Filter Cooler
Model Number: WFC5
READ AND SAVE THESE INSTRUCTIONS

BEFORE FIRST USE
Read and follow all the instructions in this User Manual even if you feel you are familiar with the product, and
find a place to keep it handy for future reference.
For your convenience record the complete model number (located on the product identification plate) and the
date you received the product, together with your purchase receipt and attach to the warranty and service
information. Retain in the event that warranty service is required.
NOTE: The rating of this product (as marked on the product identification plate) is based on specific loading
tests. Normal use or the use of other recommended attachments may draw significantly less power.
IMPORTANT SAFEGUARDS
When using any electrically powered product, basic safety precautions should always be followed,
including the following:
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE PRODUCT.
WARNING - to reduce the risk of fire, electrical shock or injury to persons or property:
Always operate the product from a power source of the same voltage, frequency and rating as indicated on
the product identification plate.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
The appliance must be used and rested on a stable and level surface;
The appliance is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking.
Do not operate any product with a damaged cord or plug, or after the product malfunctions, or is dropped
or appears damaged in any way. Return the complete product to the place of purchase for inspection,
repair or replacement.
To reduce the risk of electric shock, do not immerse or expose the product or flexible cord to rain, moisture
or any liquid other than those necessary for correct operation of the product.
This product should not be used in the immediate vicinity of water, such as bathtub, washbowls, swimming
pool etc. where the likelihood of immersion or splashing could occur.
Switch off and unplug from outlet when not in use, before assembling or disassembling parts and before
cleaning. Remove by grasping the plug - do not pull on the cord.
In order to avoid any dangerous overheating, we recommend fully unwinding the power cord.
Do not use the appliance for other than its intended use.
Do not immerse the appliance exposed to the weather (rain, sun, etc).
Never operate the appliance with wet or damp hands.
Do not place objects on the product or allow objects to obstruct the inlet or outlet openings, or operate in
close proximity to walls or curtains, etc.
The use of attachments or accessories not recommended or sold by the product distributor may cause
personal or property hazards or injuries.
Do not use your appliance with an extension cord unless this cord has been checked and tested by your
electricity supplier or qualified technician.
If the appliance is not working normally, disconnect from the power supply and contact the nearest
authorized service agent.
This product is intended for normal domestic/household use only.
This water filter must only be used with municipally treated tap water. Do not attempt to filter untreated, raw
water or water of unknown quality.

Filter replacement is essential for the product to perform as represented. It must be replaced at least every
3 months.
This appliance has been designed to be used continuously.
FEATURES
1. Drip Tray
2. Body
3. Chilled Water Tap
4. Indicator Light
5. Filtered Water Chamber
6. Unfiltered Water Chamber
7. Filter Cartridge
8. Lid
9. Filter Replacement Indicator
BEFORE FIRST USE
Clean the appliance and its accessories:
Unpack the gift box and check if all components and accessories are included.
Wash the lid, two water tanks and all the accessories with warm soapy water then rinse thoroughly and
dry.
Wipe the appliance body over with a damp clean cloth or paper towel.
Put the filter in cold tap water, maker sure the whole filter is immersed in water for about 30 minutes.
9
8
7
6
5
4
3
2
1

Flushing the dispensing system:
It is important to rinse out the dispensing system before starting to use your appliance:
1. Put the base water tank onto the water cooler; ensure that the tank sits into the slots located in top of
the water cooler.
2. Combine two tablespoons of Baking Soda; bicarbonate soda, with 2 Litres of lukewarm water into a
separate jug or container and set aside.
3. Remove the unfiltered water chamber from the cooler.
4. Pour the bicarbonate mixture into the filtered water chamber.
5. Hold the Chilled Water Tap in until water flows out from the tap. This ensures the mixture has entered
from the internal water tank.
6. Cycle the bicarbonate mixture through the front and re-pour back into the top reservoir. Repeat this
process a couple of times.
7. Switch power “ON” and allow the solution to sit in the cooler for a minimum of 4 hours (ideally leave
overnight).
8. Drain all the bicarbonate mixture out through the Chilled Water Tap until you can no longer drain any
water.
9. Remove the Drain Plug from underneath the unit to drain any excess water in the cooling tank. This is
important to ensure all of the mixture is removed from the cooler.
10. While the Drain Plug is open, pour 2 Litres of water through to remove any excess bicarbonate mixture
from the system. Reinstate drain cap and Unfiltered Water Chamber.
11. Flush clean water through the unit and drain out via taps. Tilt the unit back and forth to remove trapped
water from unit. Repeat process to ensure there is no residual taste.
Filter life:
The life of your filter will be affected by the quality of your tap water. When you
notice that the water begins to flow very slowly from the spout it is time to
change the filter. This can be any time from one month to three months
depending on the area where you live.
However, it must be replaced at least every three months. The Date Indicator
for Filter Replacement on the filter will help you to remember when this is.
Example: if the filter was installed in January, turn the dial to show 1 (indicating
1st month of the year). The ‘Change’ window will show 3 (indicating Filter
replacement is due in March, 3rd Month of the year) (See Figure 1).
FIGURE 1
NOTE: During the flushing process, the appliance may splutter as the air inside the filter is replaced by
water. You will notice a change in the filtering noise when the water tank is almost empty.
NOTE: Do not fill the water tank too quickly; because when you fill the upper water tank, the water will go
through the filter and enter into the base water tank and the water chiller. When the top of the filter is
immersed in water, please wait a couple of seconds to allow the water to enter into the base water tank.

OPERATIONS
Using your Water Cooler:
1. Remove Filter Cartridge from plastic; make sure not to lose the Filter Cartridge O-Ring. Immerse Filter
Cartridge in ambient water for 20 minutes. Shake filter underwater to remove any excess black carbon
particles and trapped air.
2. Before plugging unit in, it is recommended that the filter bottle parts (except Filter Cartridge) is washed
with warm water and detergent and is rinsed thoroughly.
3. Ensure Drain Plug (underneath unit) is secure on the unit and tighten in place.
4. Place Unfiltered Water Chamber into the Filtered Water Chamber.
5. Place Filter Cartridge into the Filtered Water Chamber. Make sure Filter Cartridge is firmly in place.
6. Place lid on top of filter bottle.
7. Turn the switch to “ON” at the back of the unit.
8. Pour water into the Unfiltered Water Chamber; allow water to filter through to the Filtered Water
Chamber.
9. Once the Filtered Water Chamber is full of water, push and hold the tap down until water runs out of the
tap.
10. Once the unit is set up and plugged into mains power, the indicator light will turn red when the unit is in
cooling mode. When cooling is complete the indicator light will turn blue.
\
Replacing the filter:
1. Removing the old filter:
Switch off and unplug the appliance.
Ensure the top tank is empty
Remove and discard the old filter.
If O-ring seal remains inside the appliance remove and discard it.
2. Installing the new filter:
Wet the new O-ring seals located at the middle of the filter and fit the filter into place.
Fill the water tank and plug the appliance into the power outlet.
Flush the filter as explained above.
NOTE: You may see small amounts of black particles at times; these are small pieces of Carbon from the
filter. These carbon particles are food grade and are not harmful. They will not impair the performance of
your filter or unit.
NOTE: Water flow rate is dependent on the volume of water in the filter bottle. For optimum flow rate, keep
filter bottle full of water. First filtration will take longer than subsequent.
NOTE: If the appliance has not been used for more than two weeks, flush the filter before use.
NOTE: If the filter and unit will not be used for a long period of time. Unplug the unit from the wall
socket. Remove the filter bottle from the unit and clean with warm soapy water. Flush the water
cooler-drain all water from the taps and via the drain plug and dry the unit.

Emptying the internal tank
Switch off the unit and unplug from the mains supply.
Turn the unit upside down to reveal a drain plug located in the centre of the base.
Remove the spring clip securing the silicone cap to the drain and remove the silicone cap.
Drain the unit.
Refit the silicone cap and spring clip.
CARE & MAINTENANCE
Please note:
Do not use harsh detergents or abrasive cleaners.
Do not place any part of this appliance in the dishwasher.
Wipe the base with a clean cloth or paper towel.
Wash the water tank in warm soapy water using a mild detergent.
Do not immerse the base in water or any other liquid.
If the unit is to be moved or if it is to be stored for a prolonged period without being used, it is
recommended to drain the internal tank of any remaining water.
It is recommended that the unit is disassembled and cleaned periodically (every 2-3 months).
To Clean:
1. Remove the filter and remove the Unfiltered Water Chamber.
2. Wash the Unfiltered Water Chamber with warm soapy water.
3. Use a damp non-abrasive cloth to wipe down the outside of the unit. Do not immerse body of unit in
water.
4. Dry unit and parts with a soft dry cloth.
Sanitation:
1. Combine two tablespoons of baking soda (bicarbonate soda) with 2 Litres of lukewarm water into
separate jug or container and set aside.
2. Remove the Unfiltered Water Chamber and Filter Cartridge.
3. Pour mixture into Filtered Water Chamber.
4. Hold down the tap to ensure mixture fills the cooling tank. Leave for a minimum of 4 hours (ideally leave
overnight).
5. Drain out mixture then flush 2-3 Litres of clean water through the unit until it has been flushed clean.
6. Remove the Drain Plug (underneath unit) to drain any excess water in the cooling tank. This is
important to ensure all of the bicarbonate mixture is removed from the cooler.
7. With the drain plug still removed, pour 2 Litres of water through to remove any excess bicarbonate
mixture from the system. Reinstate drain plug.
8. Flush clean water through the unit and rain out via taps. Tilt the unit back and forth to remove trapper
water from unit.
WARNING: Switch “OFF” power and unplug unit before cleaning. The filter cartridge should be replaced
every 150 Litres or 2 Months, whichever occurs first. This ensures filters perform as stated. If water has
been left sitting in unit for more that 3 days, discard water and flush out unit.

TROUBLE SHOOTING
Problem
Possible Causes
What To Do
Leaking from top/bottom of unit
Drain Plug underneath unit is not
closed fully.
Check Drain Plug located
underneath unit is closed and
sealed completely.
Not cooling
Unit not plugged into wall socket or
wall socket not switched on.
Check connection to wall socket.
Check power switch in front of unit
is on.
Unit uses a thermoelectric chip to
chill water; performance of unit is
dependent on room temperature.
Cooling light will remain on when
unit is attempting to cool water to
optimal temperature.
Bad taste from cooler
New, new silicone, new tap.
Follow the Sanitizing instructions,
under “Care & Maintenance”
Build up of bacteria.
Leaking from taps
Silicone in tap in not sealed
properly / or tap cracked.
Call customer service hotline
No or limited water flow
Water Level in Filtered Water
Chamber is too low.
Rate of flow from tap depends on
level of water in Filtered Water
Chamber. Fill Unfiltered Water
Chamber with water.
Filtered Water Chamber is empty.
Fill Unfiltered Water Chamber with
water.
Internal cold water tank frozen up
water.
Turn unit off for 24hrs, after 24hrs
–check water flow from tap. Switch
the unit power on. If unit continues
to freeze, call customer service
hotline.
Filter is too old, not allowing water
to filter through and enter Filtered
Water Chamber
Replace filter cartridge
Air bubble/ Air lock inside tubing or
unit.
Call customer service for
instructions
SPECIFICATIONS
Model
WFC5
Description
Water Filter Cooler
Voltage & Frequency
220-240Vac, 50/60Hz
Wattage
75 Watts
Filter Cartridge Replacement Model (Pack of 3)
WF3
Filter Cartridge Life
150 Litres (2 Months)*
Filter Cartridge Flow Rate
100-400ml/min
Weight
3.2kgs
Total Water Capacity
8.5L
Filtered Water Tank Capacity
4.5L

CUSTOMER SERVICE
Australian Customer Service
GAF Control (Sales) Pty Ltd
P.O Box 19
Altona North Victoria 3025
Phone: [phone]
Hours: 9am-5pm (EST) Mon-Fri
www.gafcontrol.com.au
*This product may vary slightly to the product illustrated due to ongoing product development.
