HENX A40DG65B01 Operation instructions

ORIGINAL INSTRUCTION
40-VOLT LITHIUM-ION
CORDLESS POWER HEAD
MODEL NUMBER A40DG65B01
WARNING:Toreduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future
reference.

2
A
B
C D
1
2
3
4
56
7
8
9
10
11 12
1
2
3
4
5
6
1
2
3
13 14

3
EF
GH
I

4
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings, instructions, illustrations and specifications
provided with this power tool. Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which may
ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do
not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of electric
shock.

5
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that have
the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless action can cause severe
injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if
detachable, from the power tool before making any adjustments, changing

6
accessories, or storing power tools. Such preventive safety measures reduce the
risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not allow for safe handling and control of
the tool in unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer.A charger that is
suitable for one type of battery pack may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that can
make a connection from one terminal to another.Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help.Liquid ejected from the battery may cause irritation
or burns.
e) Do not use a battery pack or tool that is damaged or modified.Damaged or
modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or

7
risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature.Exposure
to fire or temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool
outside the temperature range specified in the instructions. Charging improperly
or at temperatures outside the specified range may damage the battery and increase
the risk of fire.
6) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs. Service of battery packs should only be
performed by the manufacturer or authorized service providers.
Additional safety instructions for extended-reach hedge
trimmers
a) To reduce the risk of electrocution, never use the extended-reach hedge
trimmer near any electrical power lines. Contact with or use near power lines may
cause serious injury or electric shock resulting in death.
b) Always use two hands when operating the extended-reach hedge trimmer.
Hold the extended-reach hedge trimmer with both hands to avoid loss of control.
c) Always use head protection when operating the extended-reach hedge
trimmer overhead. Falling debris can result in serious personal injury.
Specific safety instructions for extended-reach hedge
trimmer
a) If any parts are damaged or missing, do not operate this product until the parts
are replaced. Use of this product with damaged or missing parts could result in
serious personal injury.
b) Do not attempt to modify this product or create accessories not recommended
for use with this product. Any such alteration or modification is misuse and

8
could result in a hazardous condition leading to possibly serious personal injury.
c) Never attach or adjust any attachment while the power head is running or with
the battery installed. Failure to stop the motor and remove the battery pack may
cause serious personal injury.
d) Clear the foreign objects e.g. wire fences, hidden wiring, nails, weeds or
rubbish within the hedges and bushes before operating the extended-reach
hedge trimmer.
e) Always use two hands when operating the extended-reach hedge trimmer. Hold
the extended-reach hedge trimmer with both hands to avoid loss of control.
f) Do not use on a ladder, roof top, tree, or other unstable support. Stable footing
on a solid surface enables better control of the hedge trimmer in unexpected
situations.
g) The user should make sure that the locking devices of any moving elements
(e.g. the extended shaft and pivoting element), if any,are in the locked position
before operating the extended-reach hedge trimmer.
Specific safety instructions for extended-reach hedge
trimmer
Cleaning and Maintenance
a) When servicing, use only identical replacement parts. Use of any other parts
may create a hazard or cause product damage. To ensure safety and
reliability, all repairs should be performed by a qualified service technician.
b) To prevent serious personal injury, remove the battery pack from the power
head before inspecting, cleaning, performing maintenance or changing add-on
attachments. A battery operated tool with the battery pack inserted is always
on and can start accidentally.
c) Avoid using solvents when cleaning plastic parts. Most plastics are susceptible
to damage from various types of commercial solvents and may be damaged
by their use. Use a clean cloth to remove dirt, dust, oil, grease, etc.
d) When cleaning the hedge trimmer attachment, DO NOT immerse it in water or
other liquids.

9
Additional safety instructions for pole saw
Assembly
a) If any parts are damaged or missing, do not operate this product until the parts are
replaced. Use of this product with damaged or missing parts could result in serious
personal injury.
b) Do not attempt to modify this product or create accessories not recommended for use with
this pole saw. Any such alteration or modification is misuse and could result in a hazardous
condition leading to possibly serious personal injury.
Operation
a) Keep all parts of the body away from the saw chain. Do not remove cut material or
hold material to be cut when blades are moving. Make sure the switch is off when
clearing jammed material. Saw chain continues to move after the switch is turned off.
A moment of inattention while operating the pole saw may result in serious personal
injury.
b) Carry the pole saw by the handle with the saw chain stopped. When
transporting or storing the pole saw, always fit the saw chain device cover.
Proper handling of the pole saw will reduce possible personal injury from the
saw chain.
c) Hold the pole saw by insulated gripping surfaces only, because the saw chain
may contact hidden wiring. A saw chain contacting a “live” wire may make
exposed metal parts of the pole saw “live” and could give the operator an
electric shock.
d) Do not use the pole saw in bad weather conditions, especially when there is a
risk of lightning. This decreases the risk of being struck by lightning.
e) To reduce the risk of electrocution, never use near any electrical power lines.
Contact with or use near power lines may cause serious injury or electric shock
resulting in death.
f) Always use two hands when operating the pole saw. Hold the pole saw with
both hands to avoid loss of control.
g) Always use head protection when operating the pole saw overhead. Falling
debris can result in serious personal injury.
h) Never attach or adjust any attachment while the power head is running or with
the battery installed. Failure to stop the motor and remove the battery may
cause serious personal injury.
i) Once assembled correctly, the pole saw attachment, extension pole and the
power head should not separate when pulled. Always test the connection by
pulling on them. Repeat the steps above if the pieces can be separated.
j) Never cut near power lines, electric cords, or other electric sources. If the bar
and chain jams on any electrical cord or line, DO NOT TOUCH THE BAR, CHAIN

10
OR THE ALUMINUM POLE! THEY CAN BECOME ELECTRICALLY LIVE AND
MAY BEVERY DANGEROUS. Continue to hold the pole saw by the insulated
rear handle or lay it down and away from you in a safe manner. Disconnect the
electrical service to the damaged line or cord before attempting to free the bar
and chain from the line or cord. Contact with the bar, chain, other conductive
parts of the pole saw, or live electric cords or lines will result in death by
electrocution or serious injury.
k) Do not allow familiarity with this product to make you careless. Remember that
a careless fraction of a second is sufficient to inflict serious injury.
l) Always wear safety goggles or safety glasses with side shield marked to
comply with ANSI Z87.1. Failure to do so could result in objects being thrown
into your eyes and other possible serious injuries.
m) Do not use any attachments or accessories not recommended by the
manufacturer of this product. The use of attachments or accessories not
recommended can result in serious personal injury.
Maintenance
a) When servicing, use only identical replacement parts. Use of any other parts
may create a hazard or cause product damage. To ensure safety and reliability,
all repairs should be performed by a qualified service technician.
b) Battery tools do not have to be plugged into an electrical outlet; therefore, they
are always in operating condition. To prevent serious personal injury, take extra
precautions and care when performing maintenance, service or for changing
the cutting attachment or other attachments.
c) To prevent serious personal injury, remove the battery pack from the power
head before servicing, cleaning, changing add-on attachments or when the
product is not in use.
d) Before performing any maintenance, make sure that the battery pack is
removed. Failure to heed this warning could result in serious personal injury.
e) Always wear gloves when handling the bar and chain; these components are
sharp and may contain burrs.
f) Never touch or adjust the chain while the motor is running. The saw chain is
very sharp; always wear protective gloves when performing maintenance to the
chain.
g) Store Idle Appliances Indoors - When not in use, appliances should be stored
indoors in a dry and high or locked-up place with the battery pack removed- out
of reach of children.
h) Maintain Appliance with Care - Keep cutting edge sharp and clean for best
performance and to reduce the risk of injury. Follow instructions for lubricating
and changing accessories. Keep handles dry, clean, and free from oil and
grease.

11
i) Check Damaged Parts - Before further use of the product, a guard or other part
that is damaged should be carefully checked to determine that it will operate
properly and perform its intended function. Check for alignment of moving
parts, binding of moving parts, breakage of parts, mounting, and any other
condition that may affect its operation. A guard or other part that is damaged
should be properly repaired or replaced by an authorized service center unless
indicated elsewhere in this manual.
j) Do not charge the battery pack in rain, or in wet locations.
Additional safety instructions for lawn trimmer
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Safe operating practices
Training
a) Read the instructions carefully. Be familiar with the controls and the correct use of the
machine.
b) Never allow children or people unfamiliar with these instructions to use the machine.
Local regulations can restrict the age of the operator.
c) Keep in mind that the operator or user is responsible for accidents or hazards occurring
to other people or their property.
Preparation
a) Before use, always visually inspect the machine for damaged, missing or misplaced
guards or shields.
b) Never operate the machine while people, especially children, or pets are nearby.
Operation
a) Wear eye protection and stout shoes at all times while operating the machine.
b) Avoid using the machine in bad weather conditions especially when there is a risk of
lightning.
c) Use the machine only in daylight or good artificial light.
d) Never operate the machine with damaged guards or shields or without guards or shields
in place.

12
e) Switch on the motor only when the hands and feet are away from the cutting means.
f) Always disconnect the machine from the power supply
1) whenever the machine is left unattended;
2) before clearing a blockage;
3) before checking, cleaning or working on the machine;
4) after striking a foreign object;
5) whenever the machine starts vibrating abnormally.
g) Take care against injury to feet and hands from the cutting means.
h) Always ensure that the ventilation openings are kept clear of debris.
Maintenance and storage
a) Disconnect the machine from the power supply before carrying out maintenance or
cleaning work.
b) Use only the manufacturer’s recommended replacement parts and accessories.
c) Inspect and maintain the machine regularly. Have the machine repaired only by an
authorized repairer.
d) When not in use, store the machine out of the reach of children.
Additional safety instructions for brush cutter
Training
a) Read the instructions carefully. Be familiar with the controls and the proper
use of the machine.
b) Never allow people unfamiliar with these instructions or children to use the
machine. Local regulations can restrict the age of the operator.
c) Keep in mind that the operator or user is responsible for accidents or
hazards occurring to other people or their property.
Preparation
a) Never operate this product while people, especially children or pets are nearby.
b) Wear eye protection and stout shoes at all times while operating this product.
c) The distance between the machine and bystanders shall be at least 15m.
d) The 3-teeth blades of brush cutters shall be well packed during transport to prevent
personal injury or damage.

13
Operation
a) Do not operate the brush cutter when the operator is tired,ill or under the
influence of alcohol or drugs.
b) Keep bystanders, children and pets at least 15m away from the machine
while it is in operation.
c) Never operate the brush cutter with damaged guards or shields or without
guards or shields in place.
d) Wear eye protection, hearing protection and stout shoes at all times while
operating the machine.
e) Take care against injury to feet and hands from the cutting means.
Noise and Vibration Declaration
The declared vibration total value and the declared noise emission values have
been measured in accordance with a standard test method and may be used
for comparing one tool with another. The declared vibration total value may
also be used in a preliminary assessment of exposure.
Warning!
The vibration and noise emission during actual use of the power tool can differ
from the declared total value depending on the ways in which the tool is used,
in particular, what kind of work piece is machined.
It is necessary to identify safety measured to protect the operator that are
based on an estimation of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as the times when the tool is
switched off and when it is running idle in addition to the trigger time)
Try to minimize the impact of vibration and noise. Exemplary measures to
reduce vibration exposure include wearing gloves while using the tool, limiting
working time, and using accessories in good condition.
Special Safety Instructions for Battery packet and Charger
If under extreme conditions any electrolyte should escape from the battery, it's essential to
avoid contact with skin. If electrolyte does come into contact with your skin, rinse it off with
water. In the event of electrolyte contact with your eyes, it's essential to consult a doctor.
a) This appliance is not intended for use by persons (including children) with reduced

14
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
b) Children should be supervised to ensure that they do not play with the appliance.
c) Before the use of the charger, read the instruction manual for it carefully.
d) During the charge process, the current used should correspond to the current of the
battery charger.
e) Never let moisture, rain or splashed water reaches the charging location.
f) The ambient temperature must not exceed 40oC. Never expose the device to direct
insulation.
g) If the electrical cable is damaged, the wire may only be replaced by the supplier or by
his repair workshop. Have repairs carried out only by an authorized specialist only.
h) Always keep the surface of the charger free from dust and dirt.
i) Do not throw batteries into water or fire, risk of explosion!
j) Never discharge the battery completely and recharge occasionally if not used for a
prolonged period.
This 40V power head A40DG 65B01 may be used with only the following HENX
attachments or subsequently introduced by HENX for use with this power head:
ATTACHMENT TYPE MODEL NUMBER
Brush cutter
Line trimmer
Pole saw
Pole hedge trimmer
AS-DCG350
AS-GZJ10
AS-GZX20
BATTERY
CHARGER
A40B25B01
A40B50B01
A40B75B01
A40KC250B01
A40MC75B01

15
Residual risks
Even when the tool is used as prescribed it is not possible to eliminate all
residual risk factors. The following hazards may arise in connection with the
tool’s construction and design:
1. Damage to lungs if an effective dust mask is not worn.
2. Damage to hearing if effective hearing protection is not worn.
3. Health defects resulting from vibration emission if the power tool is being used over
longer period of time or not adequately managed and properly maintained.
WARNING! This machine produces an electromagnetic field during operation. This
field may under some circumstances interfere with active or passive medical implants.
To reduce the risk of serious or fatal injury, we recommend persons with medical
implants to consult their physician and the medical implant manufacturer before
operating this machine.

16
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The safety
symbols and the explanations with them deserve your careful attention and understanding.
The symbol warnings do not, by themselves, eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident prevention measures. Read,
understand, and follow all safety symbols on the machine before trying to assemble and
operate it.
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s
Manual
To reduce the risk of injury, user must read and
under- stand the operator’s manual before using this
product.
Wear Eye
Protection
Always wear safety goggles or safety glasses with
side shields and a full face shield when operating this
product.
Wear Ear
Protection
Always wear sound barriers (ear plugs or ear
mufflers) to protect your hearing.
Wear Head
Protection
Wear an approved safety Standard hat to protect
your head.
Wear Protective
Gloves
Protect your hands with gloves when handling blade
or blade guard. Heavy-duty, nonslip gloves improve
your grip and protect your hands.
Wear Safety
Footwear
Wear non-slip safety footwear when using this
equipment.

17
Danger- Keep
hands Away from
Blades
Contact with blade will result in serious personal
injury.
Keep sufficient
distance away
from electrical
power lines
To prevent electrocution, do not operate within 33 ft.
(10m) of overhead electrical lines. Contact with or
use near power lines may cause serious injury or
electric shock resulting in death.
Falling objects Be aware of falling objects during the operation of
pole saw and extended-reach hedge trimmer.
Noise label A noise label marked with the declared noise
emission value shall be shown on the machine.
Do not expose to
rain
Do not expose the machine to rain.
DANGER —
Keep
Bystanders Away
Do not operate the machine when children or others
are nearby.
Blade thrust Be aware of blade thrust during operation
Keep bystanders
away
Ensure that other people and pets remain at least 15m
away from the liner trimmer when it is in use.
Max. speed for
output spindle
Max. speed for output spindle of grass trimmer and
brush cutter shall be marked on the machine.

18
Power Head A40DG65B01
SPECIFICATIONS
Voltage 40 V
Weight (Without battery
pack)
3.12 kg
PACKING LIST
40V A40DG65B01 power head 1
Brush Cutter attachment 1
Liner trimmer attachment 1
Extended Reach Hedge
Trimmer attachment
1
Pole saw attachment 1
Front-assist handle 1
Single shoulder strap 1
Operator’s manual 1
Hex wrench 1
DESCRIPTION
Refer to Fig. A for different parts of power head as follows.
1. Locking knob
2. Pipe joint
3. Front-assist handle
4. Shoulder-strap Mount Hanger
5. Control panel
6. Lock-off button
7. Trigger
8. Air outlet
9. Air inlet
10. Electric Contacts

19
11. Ejection mechanism
12. Battery-release button
13. Single Shoulder Strap (special accessory)
14. Tongue
ASSEMBLY
WARNING: If any parts are damaged or missing, do not operate this product until the parts are
replaced. Use of this product with damaged or missing parts could result in serious personal injury.
WARNING: Always remove the battery pack from the product when you are assembling parts,
making adjustments, cleaning, or when the product is not in use.
Installing An Attachment to the Power Head
WARNING: Read and understand entire Operator’s Manual for each optional
attachment used on this power head and follow all warnings and instructions. Failure to
follow all instructions could result in electric shock, fire and/or serious personal injury.
WARNING: This 40V power head A40DG65B01 is designed to be used only with
the HENX attachment models that are specified in this Operator’s Manual or subsequently
introduced by HENX for use with this power head. Use of other, unauthorized
attachments could cause serious personal injuries or property damage.
WARNING: Never install, remove, or adjust any attachment while the power head is
running or with the battery installed. Failure to stop the motor and remove the battery can
cause serious personal injury. NEVER OPERATE THE POWER HEAD WITHOUT AN
ATTACHMENT.
The attachment connects to the power head by means of a coupler device.
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Remove the end cap from the attachment shaft. Align the bulge on the attachment
shaft with the slot on the coupler and push the attachment shaft into the coupler until you
hear a clear “click” sound, which indicates that the attachment shaft is mounted into place.
Fig. B parts description see below:
1 Power head shaft 4 Bulge
2 Wing knob 5 Attachment shaft
3 Slot 6 Coupler

20
4. Pull the attachment shaft to verify whether it is securely locked into the coupler. If not,
rotate the attachment shaft from side to side in the coupler until it snaps into place.
5. Tighten the wing knob securely.
Removing the Attachment From the Power Head
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Pull or twist the attachment shaft out of the coupler.
Mounting and Adjusting the Front-assist Handle
1. Stop the motor and remove the battery pack,if installed.
2. Loosen 4 screws on front-assist handle upper cover to separate the upper cover from adjustable
front- assist handle (Fig. C).
Fig. C parts description see below:
1 Hex screw 3 Front-assist handle lower
cover
2 Front-assist
handle upper
cover
3. Adjust the front-assist handle lower cover until it locates in a proper position within threshold ring
(Fig. D).
4. Lock the front-assist handle upper cover by tightening the hex screws (Fig. E).
WARNING: Never operate the tool without the front- assist handle firmly in place.
WARNING: Only fix the front-assist handle between the threshold ring and the coupler.
Mounting the Shoulder Strap
Depress the strap hook to open it and attach it onto shoulder-strap mount hanger on the power
head (Fig. F).
Note: quick-release mechanism: pull the tongue by your fingers, the shoulder strap will be
taken off from the operator’s body under the weight of the machine.
