Hercules VENUS 40 User manual

VENUS 40/50
ALUMINIUM OUTDOOR UMBRELLA
ASSEMBLY INSTRUCTIONS
IMPORTANT, RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY
THIS ITEM IS INTENDED FOR OUTDOOR DOMESTIC USE ONLY,
NOT FOR COMMERCIAL USE
CAUTION:
Important Information
The umbrella should be lowered and secured in windy
conditions or when not being used.
Do not leave open flame or heat sources unattended
underneath the umbrella.
Do not allow children to remain unattended near the ropes
that raise the umbrella.
Secure the ropes that raise the umbrella to underneath
of the umbrella (see fig.4 page 3) in order to prevent fire
hazard and/or to strangulation hazard.
Care Instruction:
Wash umbrella canopy with a mild solution of soap and
water. Rinse thoroughly and drip-dry in an open position.
Do not use bleach or solvents on fabric or aluminum frame.
Keep closed when not being used. Not recommended for
use in patio tables. If used in a patio table, always use with
an umbrella base and lower in windy conditions.
Umbrella ribs may compress during shipping. Please
e opening your umbrella to
avoid causing permanent damage.
read these instructions befor
Please be advise that Hercules™ Instant Shelter provides a limited
manufacturing warranty that the Venus Aluminium Outdoor Umbrella
will be free from defects in original materials and workmanship.
Frame
Frames are warranted to be free from defects in materials and
workmanship for a period of six years for residential use(three years
for commercial use). Damage to frames due to improper assembly,
misuse, accidental damage, or exposure to water and sub-freezing
temperatures is not covered.
Fabric
The solution-dyed acrylic canvas is warranted for a period of
eight years for residential use(five years for commercial use)against
fading and rot. Fading or discoloration resulting from exposure to
the chemicals or spills is not covered.
Note: All operation should be according to the instruction manual.
* This warranty DOES NOT COVER the following items:
Failure caused by unreasonable or abusive use; failure caused
by neglect of reasonable and necessary care; acts of nature
(including but not limited to wind, hurricanes, tornadoes, and
storms) are not covered by this warranty.
The product is not covered by this warranty.
HERCULES VENUS ALUMINIUM OUTDOOR UMBRELLA
LETTER OF WARRANTY
1
For customer service in the New Zealand,
Free phone:[phone]
Hercules Wellington
P: 04 5699715
E: [email protected]
Hercules Auckland
P: 09 5731458
E: [email protected]
Hercules Christchurch
P: 03 3746381
E: [email protected]
Store & Office hours:
9:00AM - 5:00PM NZST, Monday – Friday
10:00AM - 3:00PM NZST, Saturday(Sunday & public holiday closed)
or visit www.herculesgazebo.co.nz/outdoor-umbrellas. www.herculesgazebo.co.nz/outdoor-umbrellas

TO ASSEMBLE THE UMBRELLA
Before opening your umbrella, first securely
fasten your umbrella into an umbrella base(not
included). Next, gently pull apart and separate
the ribs into their natural open position.
For the Venus 40 umbrellas, two poles
will be supplied for assembly(see Fig 2).
( Fig. 2)
TO OPEN THE UMBRELLA
Pull down the ropes until the umbrella is
fully open, then insert the pin into the hole.
Now the umbrella is ready to use. Tidy up
and secure the ropes.
Pin In Ropes
TO CLOSE THE UMBRELLA
Hold the rope firmly and remove the pin,
then release the rope slowly until the
umbrella is fully closed. Use tie straps to
secure umbrella canopy.
Pin Out
2 3 4
( Fig. 3)
( Fig. 4)
( Fig. 5)
( Fig. 6)
Click!
Pole
