Hercules HCB014B Assembly instructions

20V Brushless Variable Speed Rotary Polisher/Sander
Model
HCB014B
Battery and Charger Sold Separately
WARNING: To prevent serious injury, User must read and
understand Owner’s Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1-888-866-5797
as soon as possible. Reference 59686.
Owner’s Manual &
Safety Instructions
22h

Page 2 For technical questions, please call 1-888-866-5797. Item 59686
IMPORTANT SAFETY INFORMATION
GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions
for future reference.
The term ″power tool″ in the warnings refers
to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
Work Area Safety
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
Electrical Safety
Do not expose power tools to rain or wet
conditions. Water entering a power tool
will increase the risk of electric shock.
Personal Safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while operating
power tools may result in serious personal injury.
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
3. Prevent unintentional starting. Ensure the
trigger is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energizing power
tools that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or
a key left attached to a rotating part of the
power tool may result in personal injury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry
or long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
9. Only use safety equipment that has been approved
by an appropriate standards agency. Unapproved
safety equipment may not provide adequate
protection. Eye protection must be ANSI-approved
and breathing protection must be NIOSH-approved
for the specific hazards in the work area.
10. Avoid unintentional starting. Prepare to
begin work before turning on the tool.
11. Do not lay the tool down until it has come to
a complete stop. Moving parts can grab the
surface and pull the tool out of your control.
12. When using a handheld power tool,
maintain a firm grip on the tool with both
hands to resist starting torque.
13. Do not leave the tool unattended when the
Battery Pack is connected. Turn off the tool,
and remove the Battery Pack before leaving.
14. This product is not a toy.
Keep it out of reach of children.
15. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.

Page 3For technical questions, please call 1-888-866-5797.Item 59686
Power Tool Use and Care
1. Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
2. Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch
is dangerous and must be repaired.
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any
adjustments, changing accessories, or storing
power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
5. Maintain power tools and accessories.
Check for misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power tool’s
operation. If damaged, have the power tool
repaired before use. Many accidents are
caused by poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling
and control of the tool in unexpected situations.
Battery Tool Use and Care
1. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to battery pack, picking up or carrying the
power tool. Carrying the power tool with your
finger on the switch or energizing power tool
that have the switch on invites accidents.
2. Disconnect the battery pack from the
power tool before making any adjustments,
changing accessories, or storing power
tool. Such preventive safety measures reduce
the risk of starting the power tool accidentally
Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of
fire when used with another battery pack.
3. Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
4. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
5. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
6. Do not use a battery pack or power tool that
is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
7. Do not expose a battery pack or power tool to
fire or excessive temperature. Exposure to fire or
temperature above 265°F may cause explosion.
8. Follow all charging instructions and do
not charge the battery pack or power tool
outside of the temperature range specified
in the instructions. Charging improperly or at
temperatures outside of the specified range may
damage the battery and increase the risk of fire.
9. Have servicing performed by a qualified
repair person using only identical
replacement parts. This will ensure that
the safety of the product is maintained.
10. Do not modify or attempt to repair the power
tool or the battery pack except as indicated
in the instructions for use and care.

Page 4 For technical questions, please call 1-888-866-5797. Item 59686
11. The battery Charger gets hot during use.
The Charger’s heat can build up to unsafe
levels and create a fire hazard if it does
not receive adequate ventilation, due to
an electrical fault, or if it is used in a hot environment.
Do not place the Charger on a flammable surface.
Do not obstruct any vents on the Charger.
Especially avoid placing the Charger on carpets
and rugs; they are not only flammable, but they
also obstruct vents under the Charger. Place the
Charger on a stable, solid, nonflammable surface
(such as a stable metal workbench or concrete floor)
at least 1 foot away from all flammable objects, such
as drapes or walls. Keep a fire extinguisher and a
smoke detector in the area. Frequently monitor the
Charger and Battery Pack while charging.
Service
1. Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
2. Never service damaged BATTERY packs. Service
of BATTERY packs should only be performed by
the manufacturer or authorized service providers.
3. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
Lithium Battery Safety Warnings
LITHIUM BATTERIES
STORE A LARGE AMOUNT
OF ENERGY AND WILL
VENT FIRE OR EXPLODE IF MISTREATED:
1. Keep Battery Pack dry.
2. DO NOT DO ANY OF THE FOLLOWING
TO THE BATTERY PACK:
• Open
• Drop
• Short-circuit
• Puncture
• Incinerate
• Expose to temperatures greater than 265°F.
3. Charge Battery Pack only according
to its Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.
Safety Warnings Common for
Sanding or Polishing Operations
1. This power tool is intended to function
as a sander or polisher. Read all
safety warnings, instructions, illustrations and
specifications provided with this power tool.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
2. Operations such as grinding, wire brushing,
or cutting-off are not recommended to be
performed with this power tool. Operations
for which the power tool was not designed may
create a hazard and cause personal injury.
3. Do not use accessories which are not
specifically designed and recommended
by the tool manufacturer. Just because the
accessory can be attached to your power tool,
it does not assure safe operation.
4. Do not use accessories which are not
specifically designed and recommended
by the tool manufacturer. Just because the
accessory can be attached to your power tool,
it does not assure safe operation.
5. The rated speed of the accessory must be at
least equal to the maximum speed marked on
the power tool. Accessories running faster than
their RATED SPEED can break and fly apart.
6. The arbor size of wheels, flanges, backing
pads or any other accessory must properly
fit the spindle of the power tool. Accessories
with arbor holes that do not match the mounting
hardware of the power tool will run out of balance,
vibrate excessively and may cause loss of control.
7. Do not use a damaged accessory.
Before each use inspect the accessory such
as abrasive wheels for chips and cracks,
backing pad for cracks, tear or excess wear,
wire brush for loose or cracked wires. If power
tool or accessory is dropped, inspect for
damage or install an undamaged accessory.
After inspecting and installing an accessory,
position yourself and bystanders away from
the plane of the rotating accessory and run
the power tool at maximum no-load speed
for one minute. Damaged accessories will
normally break apart during this test time.
8. Wear personal protective equipment. Depending
on application, use face shield, safety goggles
or safety glasses. As appropriate, wear dust
mask, hearing protectors, gloves and workshop
apron capable of stopping small abrasive or
workpiece fragments. The eye protection must
be capable of stopping flying debris generated
by various operations. The eye protection must

Page 5For technical questions, please call 1-888-866-5797.Item 59686
1. be capable of stopping flying debris generated by
various operations. The dust mask or respirator
must be capable of filtering out particles generated
by your operation. Prolonged exposure to high
intensity noise may cause hearing loss.
2. Keep bystanders a safe distance away
from work area. Anyone entering the
work area must wear personal protective
equipment. Fragments of workpiece or of a
broken accessory may fly away and cause
injury beyond immediate area of operation.
3. Never lay the power tool down until the
accessory has come to a complete stop.
The spinning accessory may grab the surface
and pull the power tool out of your control.
4. Do not run the power tool while carrying
it at your side. Accidental contact with the
spinning accessory could snag your clothing,
pulling the accessory into your body.
5. Regularly clean the power tool’s air vents.
The motor’s fan will draw the dust inside
the housing and excessive accumulation of
powdered metal may cause electrical hazards.
6. Do not operate the power tool near flammable
materials. Sparks could ignite these materials.
7. Do not use accessories that require liquid
coolants. Using water or other liquid coolants
may result in electrocution or shock.
8. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
9. Do not depress the spindle lock when
starting or during operation.
10. Use clamps (not included) or other practical
ways to secure and support the workpiece to
a stable platform. Holding the work by hand
or against your body is unstable and may
lead to loss of control and personal injury.
11. This product is not a toy.
Keep it out of reach of children.
12. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
In addition, people with pacemakers should:
• Avoid operating alone.
• Do not use with power switch locked on.
• Properly maintain and inspect
to avoid electrical shock.
• Properly ground power cord. Ground Fault Circuit
Interrupter (GFCI) should also be implemented
– it prevents sustained electrical shock.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or
snagged rotating wheel, backing pad, brush
or any other accessory. Pinching or snagging
causes rapid stalling of the rotating accessory
which in turn causes the uncontrolled power
tool to be forced in the direction opposite of the
accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or
pinched by the workpiece, the edge of the wheel
that is entering into the pinch point can dig into the
surface of the material causing the wheel to climb
out or kick out. The wheel may either jump toward
or away from the operator, depending on direction
of the wheel’s movement at the point of pinching.
Abrasive wheels may also break under these conditions.
Kickback is the result of power tool misuse and/or
incorrect operating procedures or conditions and can be
avoided by taking proper precautions as given below.
1. Maintain a firm grip on the power tool and
position your body and arm to allow you to
resist kickback forces. Always use auxiliary
handle, if provided, for maximum control over
kickback or torque reaction during start-up.
The operator can control torque reactions or
kickback forces, if proper precautions are taken.
2. Never place your hand near the rotating
accessory. Accessory may kickback over your hand.
3. Do not position your body in the area where
power tool will move if kickback occurs.
Kickback will propel the tool in direction opposite to
the wheel’s movement at the point of snagging.
4. Use special care when working corners, sharp
edges etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing
have a tendency to snag the rotating accessory
and cause loss of control or kickback.
5. Do not attach a saw chain woodcarving
blade or toothed saw blade. Such blades
create frequent kickback and loss of control.
Safety Warnings Specific
for Sanding Operations
Do not use excessively oversized sanding disc
paper. Follow manufacturer’s recommendations
when selecting sand paper. Larger sanding
paper extending beyond the sanding pad
presents a laceration hazard and may cause
snagging, tearing of the disc or kickback.

Page 6 For technical questions, please call 1-888-866-5797. Item 59686
Safety Warnings Specific for
Polishing Operations
Do not allow any loose portion of the polishing
pad or its attachment strings to spin freely.
Tuck away or trim any loose attachment strings.
Loose and spinning attachment strings can
entangle your fingers or snag on the workpiece.
Vibration Safety
This tool vibrates during use. Repeated or long-term
exposure to vibration may cause temporary or permanent
physical injury, particularly to the hands, arms and
shoulders. To reduce the risk of vibration-related injury:
1. Anyone using vibrating tools regularly or for an
extended period should first be examined by a
doctor and then have regular medical check-ups
to ensure medical problems are not being caused
or worsened from use. Pregnant women or
people who have impaired blood circulation to
the hand, past hand injuries, nervous system
disorders, diabetes, or Raynaud’s Disease should
not use this tool. If you feel any medical or
physical symptoms related to vibration (such as
tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.
3. Wear suitable gloves to reduce the
vibration effects on the user.
4. Use tools with the lowest vibration when there
is a choice between different processes.
5. Include vibration-free periods each day of work.
6. Grip tool as lightly as possible (while still keeping
safe control of it). Let the tool do the work.
7. To reduce vibration, maintain the tool as
explained in this manual. If any abnormal
vibration occurs, stop use immediately.
8. Center the Pad on the Backing
Pad to reduce vibration.
SAVE THESE
INSTRUCTIONS.
GROUNDING
TO PREVENT ELECTRIC SHOCK AND
DEATH FROM INCORRECT GROUNDING:
Check with a qualified electrician if you
are in doubt as to whether the outlet is
properly grounded. Do not modify the power cord
plug provided with the charger. Do not use the
charger if the power cord or plug is damaged.
If damaged, have it repaired by a service facility
before use. If the plug will not fit the outlet,
have a proper outlet installed by a
qualified electrician.
Extension Cords
1. Grounded tools require a three wire extension cord.
Double Insulated tools can use either
a two or three wire extension cord.
2. As the distance from the supply outlet increases,
you must use a heavier gauge extension cord.
Using extension cords with inadequately sized wire
causes a serious drop in voltage, resulting in loss of
power and possible tool damage. (See Table A.)
3. The smaller the gauge number of the wire, the
greater the capacity of the cord. For example,
a 14 gauge cord can carry a higher current
than a 16 gauge cord. (See Table A.)
4. When using more than one extension cord to make
up the total length, make sure each cord contains at
least the minimum wire size required. (See Table A.)
5. If you are using one extension cord for more
than one tool, add the nameplate amperes
and use the sum to determine the required
minimum cord size. (See Table A.)
6. If you are using an extension cord outdoors, make
sure it is marked with the suffix “W-A” (“W” in
Canada) to indicate it is acceptable for outdoor use.
7. Make sure the extension cord is properly wired
and in good electrical condition. Always replace
a damaged extension cord or have it repaired
by a qualified electrician before using it.
8. Protect the extension cords from sharp objects,
excessive heat, and damp or wet areas.

Page 7For technical questions, please call 1-888-866-5797.Item 59686
RECOMMENDED MINIMUM WIRE GAUGE
FOR EXTENSION CORDS* (120/240 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25′ 50′ 75′ 100′ 150′
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
TABLE A
* Based on limiting the line volt-
age drop to five volts at 150% of
the rated amperes.
Warning Symbols and Definitions
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to
avoid possible injury or death.
Indicates a hazardous
situation which, if not
avoided, will result in death or serious injury.
Indicates a hazardous
situation which, if not
avoided, could result in death or serious injury.
Indicates a hazardous
situation which, if not
avoided, could result in minor or moderate injury.
Addresses practices not
related to personal injury.
SYMBOLOGY
VVolts
Direct Current
AAmperes
n0xxxx/min. No Load Revolutions
per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking concerning Risk
of Respiratory Injury. Wear NIOSH-
approved breathing protection rated
for the hazards in your work area.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.

Page 8 For technical questions, please call 1-888-866-5797. Item 59686
SPECIFICATIONS
Battery Hercules 20V Li-ion 57373
(sold separately)
Charger Hercules 20V Li-ion 56559
(sold separately)
No Load Speed n0: 800-2400/min
Spindle Thread 5/8" -11
Max. Accessory
Diameter 7" (Ø180mm)
SETUP – BEFORE USE
Read the ENTIRE IMPORTANT
SAFETY INFORMATION section at the
beginning of this manual including
all text under subheadings therein
before set up or use of this product.
Charging
Charge battery pack after unpacking and before using
this tool. Follow instructions included with battery
charger (battery pack and charger sold separately).
Functional Description
2
1
3
4
5
6
7
1. D-Handle
2. Spindle Lock
3. Speed Dial
4. Trigger Lock
5. Trigger
6. Lock Off Button
7. Backing Pad
Lock Off Button and Trigger Lock
1. Push Lock Off Button in on the left
side to unlock the Trigger.
2. Push Lock Off Button in on right
side to lock the Trigger.
Lock Off Button
Trigger Lock
3. Push Trigger Lock in after pulling Trigger
to lock the tool in the ON position.
Assembly
TO PREVENT SERIOUS INJURY:
Do not operate this tool with one hand only or
without the Auxiliary Handle properly installed.
Auxiliary Handle
Option 1: Using with the D-Handle
The D-Handle (included) may be installed
for either right-hand or left-hand use.
Attach the D-Handle to the sides of the Front Cover,
using the Hex Key and two Hex Head Bolts.
Note: Slide the Hex Key through the
hole in the D-Handle to access the Bolt
on the long side of the Handle.
Insert Hex Key
through here
to access Bolt

Page 9For technical questions, please call 1-888-866-5797.Item 59686
Option 2: Using with Side Handle
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION section at the
beginning of this manual including
all text under subheadings therein
before set up or use of this product.
Tool Set Up
TO PREVENT SERIOUS INJURY FROM
ACCIDENTAL OPERATION:
Make sure that the Power Switch/Trigger is in the
off-position and remove its Battery Pack before
performing any procedure in this section.
Backing Pad
Push Spindle Lock, then thread Backing
Pad to Output Spindle securely.
Workpiece and Work Area Set Up
1. Designate a work area that is clean and well-lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. If working on panels not attached to a vehicle,
secure loose workpieces using a vise or clamps
(not included) to prevent movement while working.
3. There must not be hazardous objects, such
as utility lines or foreign objects, nearby that
will present a hazard while working.
4. You must use personal safety equipment
including, but not limited to, ANSI-
approved eye and hearing protection.
Polishing Instructions
TO PREVENT SERIOUS INJURY: Grip
the tool firmly in both hands.
1. Wash the work surface thoroughly, and
make sure it is free of dust, dirt, oil, grease, etc.
2. Place a clean Wool or Foam Pad (sold separately)
securely onto the Backing Pad. The Pad must
be centered on the Backing Pad to reduce
vibration and allow proper control of the tool.
3. Set speed dial to minimum setting.
NOTICE: Only use slower speeds for polishing.
Otherwise, damage may occur to the paint
being polished. Harbor Freight Tools is not
responsible for damage to the vehicle’s
finish due to improper use of this tool.
4. Apply a line 3-5 inches long of product (compound,
polish or product) on the work surface.
5. Make sure that the Trigger is in the off
position, then connect the battery pack.
CAUTION! Start and stop the tool only while it is
held firmly against the surface of the vehicle. Failure
to do so may result in the Foam Pad or Polishing
Bonnet being thrown from the Polishing Pad.
6. Position the pad to the right of the line of product.
Align the tool so that the line of product aligns to
what would be roughly 10 o’clock on the pad.
WARNING! TO PREVENT SERIOUS
INJURY: Allow the tool to come to a
complete stop before setting it down.
7. Hold the polisher with both hands, slightly lift (roughly
10 degrees) the leading edge of the pad and gently
pull the trigger and begin moving the pad from right
to left over the line of product on the surface. This
will pull the product into and under the pad, rather
than shooting it out and splattering it on the panel.
Keep pressure off of the tool when operating. The
Pad should LIGHTLY contact the polishing surface.
8. The entire process of picking up the line of product
should take only a second or two, then immediately
return the pad face to being flat on the work
surface and spread product over a work area no
larger than 2 feet by 2 feet to begin working.
NOTICE: To prevent damage to the Pad
and vehicle finish, only apply the Pad flat
against the surface when polishing.
Polishing Angle
Note: The most common error when polishing a vehicle
is applying too much product. If the Pad becomes
saturated with product, removing product will be
more difficult and will take longer. Applying too much
product may also reduce the life of the Pad. If the Pad
continually comes off the Backing Pad during use,
too much product may have been applied.

Page 10 For technical questions, please call 1-888-866-5797. Item 59686
1. Apply the product to all flat surfaces with broad,
sweeping strokes in a crisscross pattern to
ensure complete and even coverage.
2. Repeat previous steps to add more product.
Clean the pad often with compressed
air or a pad cleaning brush or spur.
3. When done, clean the pad, remove the battery
from the tool, then remove the pad and properly
store each indoors and out of children’s reach.
Sanding Instructions
1. Make sure that the surface to be sanded is wiped
clean of all dirt and debris, especially that of
previous courser sanding sessions, which will
scratch the surface of a finer grit sanding session.
2. Attach the desired grit Sanding Disk (sold
separately) onto the Backing Pad.
3. Rotate the Speed Dial to select
the desired speed setting.
4. Make sure that the Trigger is in the off position, then
connect the Hercules 20V
Li-ion battery into the battery compartment.
5. To start, grip the Polisher/Sander firmly with both
hands and press the Trigger. Release the Trigger
to stop. To use the Lock on button, while holding
in the Trigger, press the Lock On Button, then
release the Trigger. The Polisher/Sander will stay
on. Press and release the Trigger to stop.
6. Wait until the Polisher/Sander has reached
full speed, then gently contact the surface.
7. Keep heavy pressure off of the Polisher/Sander when
operating. Allow the sanding disk to do the work.
8. Move the Polisher/Sander in a uniform
pattern up and down or side to side as
you sand to ensure even sanding.
9. Periodically, stop the Polisher/Sander and
check for possible disc wear. Replace used
or worn sanding discs when necessary.
10. When finished, turn off and remove
battery from the Polisher/Sander.
11. Allow the tool to come to a complete
stop before setting it down.
12. To prevent accidents, turn off the tool and
disconnect its power supply after use. Clean, then
store the tool indoors out of children’s reach.
MAINTENANCE AND SERVICING
Procedures not specifically explained
in this manual must be performed
only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM
ACCIDENTAL OPERATION:
Make sure that the Trigger is in the off
position and remove its Battery Pack before
performing any procedure in this section.
TO PREVENT SERIOUS INJURY
FROM TOOL FAILURE:
Do not use damaged equipment.
If abnormal noise or vibration occurs, have
the problem corrected before further use.
Cleaning, Maintenance,
and Lubrication
1. BEFORE EACH USE, inspect the general
condition of the tool. Check for:
• leaking, swollen, or cracked battery pack,
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts, and
• any other condition that may
affect its safe operation.
2. AFTER USE, wipe external surfaces
of the tool with clean cloth.
3. Li-Ion BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
Do not short, incinerate or open battery.
4. Periodically, wear ANSI-approved safety goggles
and NIOSH-approved breathing protection
and blow dust and grit out of the motor
vents using dry compressed air.

Page 11For technical questions, please call 1-888-866-5797.Item 59686
NOTICE: Do not operate the tool without
both Dust Screens installed.
1. Remove Dust Screens by pressing in
tabs in each corner of the screen.
2. Once tabs have released, pull Dust
Screen to remove from tool housing.
3. Wear ANSI-approved safety goggles and
NIOSH-approved breathing protection
and blow dust and grit out of the dust
screens using dry compressed air.
4. Install Dust Screens by lining up tabs with the motor
housing slots and press in with even pressure.
5. Disconnect battery pack and store battery pack,
charger, and tool in dry, indoor area out of
reach of children and away from metal objects
(i.e., paperclips, coins) to prevent shorting.
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will not start. 1. Battery Pack not properly
connected.
2. Battery Pack not properly charged.
3. Battery Pack burnt-out.
4. Internal damage or wear. (Carbon
brushes or switch, for example.)
1. Remove Battery Pack, make sure there are no
obstructions, reinsert the Battery Pack according
to its shape (it should only fit one way), and
press firmly until the Battery Pack locks in place.
2. Make sure Charger is connected and
operating properly. Give enough time for
Battery Pack to recharge properly.
3. Dispose of old Battery Pack
properly or recycle. Replace Battery Pack.
4. Have technician service tool.
Tool operates slowly. 1. Excess pressure applied
to workpiece.
2. Battery Pack power low.
3. Battery Pack burnt-out.
1. Decrease pressure, allow tool to do the work.
2. Recharge Battery Pack.
3. Dispose of old Battery Pack
properly or recycle. Replace Battery Pack.
Performance
decreases over time.
Battery Pack wearing out. Battery Pack capacity will gradually
decrease through use. If symptoms
are severe, recycle old Battery Pack
(or dispose of properly) and replace it.
Excessive noise
or rattling.
Internal damage or
wear. (Carbon brushes or
bearings, for example.)
Have technician service tool.
Overheating. 1. Forcing tool to work too fast.
2. Blocked motor housing vents.
1. Allow tool to work at its own rate.
2. Wear ANSI-approved safety goggles and
NIOSH-approved dust mask/respirator while
blowing dust out of motor using compressed air.
Tool does not sand
or polish effectively.
1. Disc accessory may be
loose on Spindle.
2. Disc accessory may be
damaged, worn or wrong
type for the material.
3. Product sprays off polishing pad.
1. Be sure disc accessory arbor is correct
and Outer Flange/Arbor Nut is tight.
2. Check condition and type of disc accessory.
Use only proper type of disc
accessory in good condition.
3. Reduce RPM to minimum setting.
Follow all safety precautions whenever diagnosing or servicing
the tool. Disconnect power supply before service.

26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
For technical questions, please call 1-888-866-5797
Copyright©2022 by Harbor Freight Tools®. All rights reserved. No portion of this manual or
any artwork contained herein may be reproduced in any shape or form without the express
written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn
proportionally. Due to continuing improvements, actual product may differ slightly from the
product described herein. Tools required for assembly and service may not be included.
5-YEAR LIMITED WARRANTY
This Hercules tool is warranted to the original purchaser to be free from defects in materials and
workmanship for a period of five (5) years beginning on the date of purchase. This warranty does not
cover battery packs and battery chargers, which are covered under separate warranties. To obtain
warranty service, visit your local Harbor Freight retail store. Warranty registration is not required. The
product or part must be returned to us with proof of purchase (e.g. in-store receipt or packing slip/invoice)
and may require shipment by purchaser to a service center at purchaser’s expense. If our inspection
verifies a covered defect in materials or workmanship during the warranty period, we will, at our option,
repair or replace the defective product. We will return repaired products within a reasonable time at our
expense, but if we determine that there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then we will return the product to you if you pay return shipping costs.
This warranty does not cover any failure or damage that we determine is due directly or indirectly
to normal wear and tear, misuse, use not for the intended purpose or not in accordance with the
product manual, abuse, accident, rental, modification or alteration, unauthorized repair, improper
installation, neglect, lack of maintenance, or any other failure not arising from defective materials or
workmanship. Fraudulent returns or claims will be denied. The repair or replacement described in this
warranty shall be your sole and exclusive remedy. THIS WARRANTY IS EXCLUSIVE AND IN LIEU
OF ALL OTHER EXPRESS WARRANTIES, WRITTEN OR ORAL, AND ANY IMPLIED WARRANTIES
ARE DISCLAIMED TO THE EXTENT PERMITTED BY LAW AND OTHERWISE LIMITED TO THE
DURATION OF THE EXPRESS WARRANTY HEREIN. HARBOR FREIGHT SHALL NOT BE LIABLE
UNDER ANY CIRCUMSTANCES FOR ANY INCIDENTAL, INDIRECT, SPECIAL, CONSEQUENTIAL,
OR PUNITIVE DAMAGES OR COSTS ARISING FROM THIS WARRANTY OR THE USE OF THIS
PRODUCT. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THESE LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Reference UPC 193175478597 when ordering parts.
