Herrmidifier 2000 User manual

Features & Benefits
Quiet,Solid
Reliability
erricane CS Series is designed to precisely
metersteamfromeitheracentralboilerorahumid-
ifier with zero maintenance and 96.4% energy
efficiency. Every component of the Herricane CS
Series distribution system is made entirely of
worry-free stainless steel.
At our leading-edge test facility, research has
proven that under specific conditions, a Guaran-
teed Evaporative Distance (GED), heat gain and
static gain can be offered on the entire CS Series.
Eachsystemisalsotestedwithpressurizedsteamto
assurequality.
Herrmidifier has built in the kind of reliability that
eliminates a two-fold servicing nightmare: the
limited accessibility of an induct humidification
installation that not only makes servicing difficult,
but often hides the fact that service is required
untilit's toolate.
H
Herricane™CS Series SteamDistributionSystem
• Zero maintenance
• Quality construction /quality
control — all units
• Tested prior to shipment
• Flexible enough to employ steam
from any source
• Central boiler,humidifier or
unfired boiler
• Capacities to 2000 lbs/hr (907 kg/hr)
• Horizontal or vertical airflow
• Stainless steel precision nozzles
• Guaranteed Evaporative Distances
(GED)
• Quiet Operation - 1/5 the noise of
other brands
• Superb energy efficiency
• Three-year warranty on distribution
systems (one-year on accessories)
Our proven, metered nozzle design extends
into the steam manifold. It allows the driest
steam to discharge evenly across the entire
length of the manifold.

Unit Specifications
Herricane™CS Series SteamDistributionSystem
Series 1000 2000 3000 4000
Capacities 100 lbs/hr 600 lbs/hr 2000 lbs/hr 1600 lbs/hr
(45 kg/hr) (273 kg/hr) (910 kg/hr) (726 kg/hr)
Manifold Lengths 10ft 10ft 10 ft 10ft
(Max.) (3.1m) (3.1m) (3.1 m) (3.1m)
Construction StainlessSteel StainlessSteel Stainless Steel StainlessSteel
Grid Height N/A N/A 8 ft 8 ft
(Max.) (2.4m) (2.4 m)
Proven Nozzle Design
Herrmidifierwasoneofthefirsttouseanozzle
that extends into the steam manifold. This
innovative precision-metered nozzle design
allows the driest steam to discharge evenly
across the entire length of the manifold — a
feature critical to the success of any humidifi-
cation installation.Tests have proven that without
precision-meterednozzlesandaccuratelydesigned
manifolds, distribution will be uneven, with as
much as 50% differential in humidity from side to
side in the air handler/duct.
1000 SINGLETUBE
HUMIDIFIER 2000 SINGLETUBE HUMIDIFIER
3115 HORIZONTAL
DISTRIBUTIONPIPE,
MULTI-TUBE HUMIDIFIER
4116VERTICAL
DISTRIBUTIONPIPE,
MULTI-TUBE HUMIDIFIER
Form No. 02-0405
©2001 Trion Inc. 01/02Herrmidifier is a registered trademark of Herrmidifier Company, Inc. Herricane is a trademark of Trion, Inc.
