Hi-view HLC-36BM User manual

User Manual
Megapixel
IP CAMERA

2
WARNINGS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
COPYRIGHT
THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY REGISTERED
TO THEIR RESPECTIVE COMPANIES.

CONTENT
V1.0_120821
PrefaceI. 4
Product Specications II. 4
Product Installation III. 7
Monitor Setting A. 7
Hardware Installation B. 8
IP Assignment C. 10
Install ActiveX control D. 12
Live Video IV. 15
IP Camera Conguration V. 17
System A. 18
NetworkB. 22
A/V Setting C. 38
Event List D. 44
Network Conguration VI. 52
I/O Conguration VII. 54
Factory Default VIII. 56
Package Contents IX. 57
Micro SD Card Compatibility X. 58

4
PrefaceI.
This IP Camera is a 720P real time IP camera with the web server
built in. User can view real-time video via IE browser. IP Camera supports
simultaneously H.264, Motion JPEG & MPEG4 video compression and dual
streaming which provides smooth and high video quality. The video can be
stored in the Micro SD card and played back remotely. With user friendly
interface, it is an easy-to-use IP camera which is designed for security
application.
Product SpecicationsII.
Main Features:
HD 720P Real Time•
Digital Noise Reduction•
Digital Wide Dynamic Range•
Shutter Speed adjustable•
Sense Up adjustable•
IR-Cut lter (Option)•
Power over Ethernet available•
H.264/ M-JPEG / MPEG4 compression•
Micro SD card backup•
Support iPhone/iPad/Android•
Triple Streaming•
SDK for Software Integration•
Free Bundle 36 ch recording software•
HLC-36BM Specications
Hardware
CPU ARM 9 ,32 bit RISC
RAM 128MB
Flash 16MB
Image sensor 1/4” Megapixel CMOS sensor
Lens Changeable Yes, CS Mount
Sensitivity 1.0 [email protected]
Support DC IRIS Yes
Shutter Time 1 / 5 ~ 1 / 10,000 sec
ICR Mechanism IR cut Filter

5
I/O 1 D.I / 1 D.O
RS-485 Yes
Audio G.711(64K) and G.726(32K,24K) audio compression
Input : Mic Built-in
Output: 3.5mm phone jack, Support 2-way.
Power over Ethernet Yes
Power 12V DC Power consumption Max：2.4W
PoE Power consumption Max：2.88W
Operating Temperature -10°C ~ 45°C
Dimensions 125 x 53 x 60 (mm)
Weight 400g
Network
Ethernet 10/ 100 Base-T
Network Protocol IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access list,
IEEE 802.1X, RTSP, TCP/ IP, UDP, SMTP, FTP, PPPoE,
DHCP, DDNS, NTP, UPnP, 3GPP, SAMBA, Bonjour
System
Video Resolution 1280x800@30fps, 1280x720@30fps, 1280x720@30fps,
640x480@30fps, 320x240@30fps, 176x144@30fps
Video Adjust Brightness, Contrast, Hue, Saturation, Sharpness, Shutter
Speed adjustable, AGC, Sense-Up, D-WDR, Flip, Mirror,
Noise reduction
Triple Streaming Yes
Image snapshot Yes
Full screen monitoring Yes
Privacy Mask Yes, 3 different areas
Compression format H.264/ M-JPEG/ MPEG4
Video bitrates adjust CBR, VBR
Motion Detection Yes, 3 different areas
Triggered action Mail, FTP, Save to SD card, DO, SAMBA
Pre/ Post alarm Yes, congurable
Security Password protection, IP address ltering, HTTPS
encrypted data transmission, 802.1X port-based
authentication for network protection, QoS/DSCP
Firmware upgrade HTTP mode, can be upgraded remotely
Simultaneous connection Up to 10
Micro SD card management
Recording trigger Motion Detection, IP check, Network break down (wire
only), Schedule, DI

6
Video format AVI, JPEG
Video playback Yes
Delete les Yes
Client System requirement
OS Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or above,
Chrome, Safari, Firefox
Mobile Support iOS 4.3 or above, Android 1.6 or above.
Hardware Suggested Intel Dual Core 2.53G,RAM: 1024MB, Graphic card:
128MB
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.

7
Product InstallationIII.
Monitor SettingA.
Right-Click on the desktop. Select “ Properties”1.
Change color quality to highest (32bit).2.

8
Hardware InstallationB.
Box Camera Construction1.
The standard type is CS-
mount lens. If you use C-mount
lens, please apply the CS-C
conversion ring.
Connector Instruction2.
The back panel of camera is as below. Plug in the power adaptor, and connect
the IP camera to PC or network. Set up the network congurations according
to the network environment. About I/O setting, please refer to chapter VII in
User Manual: "I/O Conguration" for detail.
PoE (Power Over Ethernet)(Optional) 3. 802.3at, 30.0W PoE Switch is recommended
Power over Ethernet (PoE) is a technology that integrates power into a
standard LAN infrastructure. It enables power to be provided to the network
device, such as an IP phone or a network camera, using the same cable as
that used for network connection. It eliminates the need for power outlets at
the camera locations and enables easier application of uninterruptible power
supplies (UPS) to ensure 24 hours a day, 7 days a week operation.

9

10
IP AssignmentC.
You can use the software“IP Installer” to assign the IP address of IP Camera. 1.
The software is in the attached CD.
There are two language versions of IP installer. Choose one as your need:2.
IPInstallerCht.exe: Chinese version
IPInstallerEng.exe: English version
There are 3 kinds of IP conguration.3.
Fixed IP (Public IP or Virtual IP)a.
DHCP (Dynamic IP)b.
Dial-up (PPPoE)c.
Execute IP Installer4.
For Windows XP SP2 user, the following message box may pop up. Please 5.
click “Unblock”.
IP Installer conguration:6.

11
IP Installer will search for all IP Cameras connected on Lan. Click “Search 7.
Device” to refresh the result list.
Click one of the IP Camera listed on the left side. The network conguration 8.
of this IP camera shows on the right side. You may change the “name” of the
IP Camera as your preference (eg: Ofce, warehouse). Change the parameter
and click “Submit” . It will apply the change and reboot the Device.
Please make sure that the IP address of your PC and IP Camera are on the 9.
same subnet.
The same Subnet:
IP CAM IP address: 192.168.1.200
PC IP address: 192.168.1.100
Different Subnets:
IP CAM IP address: 192.168.2.200
PC IP address: 192.168.1.100
To Change PC IP address:
Control Panel→Network Connections→ Local Area Connection Properties→
Internet Protocol (TCP/IP) → Properties
A quick way to access remote monitoring is to double-click the selected IP 10.
Camera listed on “Device list” of IP Installer. An IE browser will be opened.

12
If you link to the IP Camera successgully, there pops a box asking you to log 11.
in. Please key in the default user name"admin" and password"admin" when
you link to the IP Camera for the rst time. You can revise the user name and
password later. Please refer to Chapter V: "A.2. User Management".
Install ActiveX controlD.
For the rst time to view the camera video via IE, it will ask you to install the
ActiveX component.
If the installation failed, please check the security setting for the IE browser.1.
IE→Tools → Internet Options → Security Tab → Custom Level → Security a.
Settings → Download unsigned ActiveX controls→ Select “Enable” or
Prompt.
IE → Tools → Internet Options → Security Tab → Custom Level →Initialize b.
and script ActiveX controls not marked as safe → Select “Enable” or
Prompt.

13
1 2
3 4
5
When popup the following dialogue box, click “Yes”.

14
You can choose another way. Go to: IE→Tools → Internet Options… → 2.
Security Tab → Trusted sites → Add the IP address and click "OK".
In the site list you can key one single IP address or a LAN address. For
example, if you add "192.168.21.*", all the IP address under .21 LAN will be
regarded as trusted sites.

15
Live VideoIV.
Start an IE browser, type the IP address of the IP camera in the address eld.
It will show the following dialogue box. Key-in the user name and password. The
default user name and password are “admin” and “admin”.
When the IP Camera is connected successfully, it shows the following
program interface.
Double-click the video to switch to full screen view. Press “Esc” or double-
click the video again back to normal mode.
1. : Get into the administration page
2. : Video Snapshot

16
Show system time, video resolution, and video refreshing rate3.
Adjust image, 1/2x, 1x, 2x4.
Select video streaming source 5. (If in”Video Setting” the streaming 2 setting is
closed, this option will not appear here.)
IP Camera supports 2-way audio. Click the “Chatting” check box, then you 6.
can use microphone connected to the PC to talk to the Camera side.
Show how many people connect to this IP camera.7.
Tick the Relay out "ON" box to trigger the relay output for testing. Tick "Off" to 8.
stop triggering.
Right-Click the mouse on the video, it will show a
pop-up menu.
Snapshot: Save a JPEG picture1.
Record Start: Record the video in the local PC. It will ask you where to save 2.
the video. To stop recording, right-click the mouse again. Select “Record
Stop”. The video format is AVI. Use Microsoft Media Player to play the
recorded le.
Mute: Turn off the audio. Click again to turn on it. 3.
The "mute" botton does not affect the playback recording video. As long as
the "IP Camera to PC" option in the audio setting is enabled, all the audio will
be recorded into the playback video even you click "mute" in the live page.
Full Screen: Full-screen mode.4.
ZOOM: Enable zoom-in and zoom-out functions. Select “Enable digital zoom” 5.
option rst within the pop-up dialogue box and then drag and drop the bar to
adjust the zoom factors.
Frame Buffm Sec: Build a buffm to accumulate several video frame and 6.
play at a regular intervals. This function can make video smooth-going when
the Network speed is slow and lag. If you select “100”, the interval between
every frame is xed to 100 mSec. The slower the Network is, the bigger value
should be selected. The default value is null.

17
IP Camera CongurationV.
Click to get into the administration page as below.
Click to back to the live video page.

18
SystemA.
System Information1.
Server Information: Set up the camera name, select language, and set up a.
the camera time.
Server Name: This is the Camera name. This name will show on the IP (i)
Installer.
Select language: There are 11 languages to choose from. When you (ii)
change the language, it will show the following dialogue box for
conrmation.
OSD Setting: Select a position where date & time stamp / text showing on b.
screen.
Moreover, click Text Edit can entry to adjust the OSD contents which is
Alpha of text. Finally, click Upgrade button to reserve the setting.

19
Server time setting: Select options to set up time - “NTP”, “Synchronize c.
with PC’s time”, “Manual”, “The date and time remain the same”.
Note: To synchronize with the NTP Server, please set the IP camera up on
the WAN instead of LAN.

20
2. User Management
IP CAMERA supports three different users, administrator, general user, and
anonymous user.
Anonymous User Login:a.
Yes: anonymous login is allowed
No: Username & password are required to access this IP camera
Add user:b.
Type the user name and password, then click “Add/Set”.The guest user
can only browse the live video page and is not allowed to enter the
conguration page.
Click “edit” or “delete” in the user list to modify them. The system will ask c.
you to key in the password in the pop-up window before you edit the user
information.
