Hidden Hitch 87001 User manual

Maximum torque for tab nuts is 38 Ft. Lb.
MAX TRAILER WEIGHT MAX TONGUE WEIGHT
Metric
®
87001
JEEP CJ5, CJ7 & SCRAMBLER
Warning: This hitch is designed to safely carry the loads specified. Under no circumstances do we recommend exceeding the towing
vehicle manufacturer’s recommended vehicle towing capacties.
Bolt Size
3/8
7/16
1/2
5/8
3/4
30 Ft. Lb.
54 Ft. Lb.
72 Ft. Lb.
150 Ft. Lb.
245 Ft. Lb.
8 mm
10 mm
12 mm
14 mm
18 Ft. Lb.
36 Ft. Lb.
64 Ft. Lb.
103 Ft. Lb.
Grade 5 Torque Grade 8.8Torque
3500 lbs. 300 lbs.

INSTRUCTIONS
1. Remove bumper or bumperettes from vehicle.
2. Insert hex bolt (1) & (2) through the frame and loosely install l-bracket (B).
3. Loosely attach the hitch assembly (A) to the bumperette mounting holes at the back of the vehicle using the 7/16” hardware (5,6,7,8). (If
bumperettes are going to be reinstalled use 1/2” spacers (E) and 7/16” hardware provided.)
4. Attach l-bracket (B) to the hitch assembly using carriage bolt (4) and flange nut (3).
5. Tighten all bolts; refer to the torque table on the instruction sheet.
PARTS IDENTIFICATION / IDENTIFICATION DES PIECES (HARDWARE KIT NO. KA-8001-722)
A) Hitch Assembly A) Attelage 1) Hex bolt 1/2” X 4” (2) 1) Boulon hexagonal
B) L-Bracket B)Support en “L” 2) Flatwasher 1/2” (2) 2) Rondelle plate
C) Flat Bracket C)Support plat 3) Flange nut 1/2” (8) 3) Ecrou à rebord
D) Spacer 1/4” D)Espaceur 4) Carriage bolt 1/2” (8) 4) Boulon de carrosserie
E) Spacer 1/2” E)Espaceur 5) Hex bolt 7/16” (8) 5) Boulon hexagonal
6) Flatwasher 7/16” (16) 6) Rondelle plate
7) Lockwasher 7/16” (8) 7) Rondelle de blocage
8) Hex nut 7/16” (8) 8) Ecrou hexagonal
For vehicles with enclosed frame.
TOOLS REQUIRED: 1/2" capacity drill; 1/2" diameter drill bit; 3/4" socket; ratchet or impact gun to suit; 100 FT/LB torque wrench.
OUTILS REQUIS: Perceuse de 1/2 po capacitée; foret de 1/2 po diamètre; douille de 3/4 po; manche à rochet ou clé à chocs si nécessaire; clé
dynamométrique à 100 lb-pi.
INSTRUCTIONS
1. Remove bumper or bumperettes from vehicle.
2. Loosely attach the hitch assembly (A) to the bumperette mounting holes at the back of the vehicle using the 7/16” hardware (5,6,7,8). (If
bumperettes are going to be reinstalled use 1/2” spacers and 7/16” hardware provided.)
3. Attach flat bracket (C) to the hitch assembly using carriage bolts (4) and flange nuts (3).
4. Use the holes in the flat bracket (C) as a guide to drill two holes in the bottom of the frame.
5. Use carriage bolts (4) and flange nuts (3) to attach flat brackets to the frame.
6. Tighten all bolts; refer to the torque table on the instruction sheet.
PARTS IDENTIFICATION / IDENTIFICATION DES PIECES (HARDWARE KIT NO. KA-8001-722)
A) Hitch Assembly A)Attelage 1) Hex bolt 1/2” X 4” (2) 1) Boulon hexagonal
B) L-Bracket B)Support en “L” 2) Flatwasher 1/2” (2) 2) Rondelle plate
C) Flat Bracket C)Support plat 3) Flange nut 1/2” (8) 3) Ecrou à rebord
D) Spacer 1/4” D)Espaceur 4) Carriage bolt 1/2” (8) 4) Boulon de carrosserie
E) Spacer 1/2” E)Espaceur 5) Hex bolt 7/16” (8) 5) Boulon hexagonal
6) Flatwasher 7/16” (16) 6) Rondelle plate
7) Lockwasher 7/16” (8) 7) Rondelle de blocage
8) Hex nut 7/16” (8) 8) Ecrou hexagonal
TOOLS REQUIRED:1/2" capacity drill; 1/2" diameter drill bit; 3/4" socket; ratchet or impact gun to suit; 100 FT/LB torque wrench.
OUTILS REQUIS: Perceuse de 1/2 po capacitée; foret de 1/2 po diamètre; douille de 3/4 po; manche à rochet ou clé à chocs si nécessaire; clé
dynamométrique à 100 lb-pi.
For vehicles with open frame.
HITCH MOUNTS
HIDDEN HITCH TOW HOOKS
