Dynojet Power Commander FC Service manual

2007-2014 Honda SH300i - 1IFC16901 www.powercommander.com
Installation Instructions
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
THE IGNITION MUST BE TURNED
OFF BEFORE INSTALLATION!
YOU CAN ALSO DOWNLOAD THE PCFC
CONTROL CENTER SOFTWARE AND
LATEST MAPS FROM OUR WEB SITE AT:
www.powercommander.com
2191 Mendenhall Drive North Las Vegas, NV 89081 [phone] www.powercommander.com
2007-2014 Honda SH300i
1 Power Commander FC
1 USB Cable
1 Installation Guide
2 Dynojet Decals
2 Velcro
1 Alcohol swab
1 Posi-tap
Parts List

IFC16901 www.powercommander.com 2007-2014 Honda SH300i - 2
SELECTING THE MAP POSITION
The Dynojet Power Commander Fuel Controller (PCFC) comes loaded with up to ten
maps. Using a #1 Phillips screwdriver, turn the map select dial to toggle between the
loaded maps. Refer to the map position table for the maps included in your PCFC.
USING THE RPM RANGE DIALS
The Low, Mid, and High RPM Dials refer to the RPM range, in thirds, of your vehicle.
Each dial allows +/- 10% fuel adjustment on top of what fuel changes are done in the
map. With the dial facing straight up, there is no additional fuel change.
For example, if your vehicle revs to 6000 RPM:
• The low RPM dial will adjust 0-3500 RPM
• The mid RPM dial will adjust 3501-7000 RPM
• The high RPM dial will adjust 7001-10500 RPM
USING PCFC CONTROL CENTER
Take your tuning to the next level with the PCFC Control Center software.
1 Using your web browser, navigate to www.powercommander.com.
2 Click Enter Race Ready.
3 Click Downloads.
4 Click Access Downloads for Power Commander FC.
5 Click the PCFC software Download button.
6 Open the zip folder.
7 Double-click the install file and follow the on-screen instructions to install the PCFC
Control Center software. The PCFC Control Center software and maps will be
stored in C:\Program Files\PCFC Control Center.
8 Return to the Downloads or Home page where you can enter the make, model, and
year of your bike to check for and download additional maps.
LOADING ADDITIONAL MAPS
1 Connect the USB cable from the computer to the PCFC. Verify the cable is fully
seated in the PCFC.
2 Run the Control Center software by double-clicking the program icon installed on
your desktop or on your start menu.
3 Click Open Map File and select a map file.
4 Click Send Map. You can send the map to any of the ten map positions.
ALTERING MAPS USING SOFTWARE
The values in the map represent a percentage of fuel change over stock. A value of 10 in
the map indicates at that throttle position and RPM range the vehicle will be 10% richer
than stock. If the value is -10, then it would be 10% leaner than stock. You have the
ability to fine tune your fuel curve by altering these values. The Control Center software
allows a value of +250 to -100 in each cell.
USB Port
HIGH RPM Dial
MID RPM Dial
LOW RPM Dial
MAP Select
STATUS Light
Position Note
Position 1
2008-2014 Honda SH300i
Stock exhaust
Stock filter

IFC16901 www.powercommander.com 2007-2014 Honda SH300i - 3
1 Lift up the seat.
2 Remove the eight bolts as shown in Figure A.
3 Remove the plastic trunk to access the engine.
4 Remove the battery access panel.
5 Using the supplied velcro, secure the PCFC next to the opening in the battery.
Make sure to clean both surfaces with the alcohol swab before attaching.
6 Attach the ground wire from the PCFC to the negative side of the battery as
shown in Figure B.
7 Unplug the stock wiring harness from the fuel injector as shown in Figure C.
Ground
FIG.A
FIG.B
FIG.C
Unplug

IFC16901 www.powercommander.com 2007-2014 Honda SH300i - 4
8 Attach the PCFC harness to the stock wiring harness and the fuel injector as
shown in Figure D.
9 Locate the Throttle Position Sensor (TPS)
connector.
The TPS connector is located on the throttle body
as shown in Figure E.
10 Using the supplied posi-tap, connect the grey wire
from the PCFC to the white/red wire.
11 Locate the stock O2 sensor connector.
The stock O2 sensor connector is located near the rear of the engine as
shown in Figure F. The connector is a clear 2-pin connector with a single
BLK/YEL wire.
12 Unplug this connector from the main wiring harness.
13 Plug the PCFC wiring harness in-line of the stock O2 sensor and the stock
wiring hanress.
14 Reinstall the battery access panel and the storage trunk.
FIG.D
FIG.E
FIG.F

IFC16901 www.powercommander.com 2007-2014 Honda SH300i - 5
The PCFC for this model controls the stock closed loop area. This area is
represented by the highlighted cells shown in Figure G. The PCFC is designed to
achieve a target AFR of 13.6:1. To use this PCFC you must retain your stock O2
sensor.
It is not recommended to alter the values in the highlighted area unless instructed to
do so by a PCFC technician.
The closed loop range can be adjusted from the PCFC software by going to
Device Tools >Closed Loop Adjustment. In this window you can use the slider
bars to enrichen/lean the closed loop range. We do not recommend an adjustment
beyond +/- 20.
FIG.G
