High End Systems Uno User manual

User Manual
Version 1.0.1

2
Table of Contents
Welcome.............................................................................................................................................................................................3
Contacting High End Systems...................................................................................................................................................4
Patents......................................................... ............................................................................................................................7
Warranty Information................................................ ................................................................................................................9
Important Safety Information........................................... .......................................................................................................10
Fixture Overview................... ................................................... ....................................................................................11
Features.................................................................................. ...............................................................................................12
Safety Considerations..................................................................................................................................................................13
General Guidelines........................... ......................................................................................................................................14
Installation Instructions................... ................................................... ........................................................................15
Technical Specifications......................................... ....................................................................................................16
Mounting Instructions........................................................... ...........................................................................................17
DMX Control Connections............................................................ .............................................................................................18
DMX Start Address....................................... ................................................................................................................................19
DMX termination...... ...............................................................................................................................................................19
Control Board..................................................................................................................................................................................20
Control Board Functions................... ......................................................................................................................................21
Preset, Programming and Playback.......... .................................................................................................26
DMX Protocol..............................................................................................................................................29
Error Codes.................................................................................................................................................33

3
Welcome
Notice
© Barco Lighting Systems, 2014, All Rights Reserved Information and specifications in this document are subject to change without
notice. Barco Lighting Systems assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
Trademarks used in this text: High End Systems, Wholehog, and Lithopatterns are registered trademarks: and intellaspot, Internal
Effects, the High End Systems globe logo, and the Hog logo are trademarks of Barco Lighting Systems, High End Systems, Inc.is a
registered trademark. Belden is a registered trademark of Belden, Inc. Other trademarks and trade names may be used in this
document to refer to either the entities claiming the marks and names or their products. High End Systems disclaims any proprietary
interest in trademarks and trade names owned by others.

4
Contacting High End Systems ®
Sales Department
High End Systems, Inc.
2105 Gracy Farms Lane
Austin, TX 78758 USA
voice:512.836.2242
fax:[phone]
Toll Free: 800.890.8989
Customer Service
High End Systems, Inc.
2105 Gracy Farms Lane
Austin, TX 78758 USA
voice:800.890.8989
fax: [phone]
toll free: 800.890.8989
email: [email protected]
World Wide Web
http://www.highend.com

5

6

7

8

9
Warranty Information
Limited Warranty
Unless otherwise stated, your product is covered by a one year parts and labor limited warranty. Dichroic filters and LithoPatterns®
high resolution glass gobos are not guaranteed against breakage or scratches to coating. It is the owner’s responsibility to furnish
receipts or invoices for verification of purchase, date, and dealer or distributor. If purchase date cannot be provided, date of
manufacture will be used to determine warranty period.
Returning an Item Under Warranty for Repair
It is necessary to obtain a Return Material Authorization (RMA) number from your dealer or point of purchase BEFORE any units are
returned for repair. The manufacturer will make the final determination as to whether or not the unit is covered by warranty.
A fixture must be returned in its original packaging. Any other parts returned to High End Systems must be packaged in a suitable
manner to ensure the protection of such product unit or parts, and such package shall be clearly and prominently marked to indicate
that the package contains returned Product units or parts and with an RMA number. Accompany all returned Product units or parts
with a written explanation of the alleged problem or malfunction. Ship returned Product units or parts to: 2105 Gracy Farms Lane,
Austin, TX 78758 USA.
Note: Freight Damage Claims are invalid for fixtures shipped in non-factory boxes and packing materials.
Freight
All shipping will be paid by the purchaser. Items under warranty shall have return shipping paid by the manufacturer only in the
Continental United States. Under no circumstances will freight collect shipments be accepted. Prepaid shipping does not include
rush expediting such as air freight. Air freight can be sent customer collect in the Continental United States.
REPAIR OR REPLACEMENT AS PROVIDED FOR UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER. HIGH END SYSTEMS, INC. MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO ANY
PRODUCT, AND HIGH END SPECIFICALLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. HIGH END SHALL NOT BE LIABLE FOR ANY INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGE, INCLUDING LOST PROFITS, SUSTAINED OR INCURRED IN CONNECTION WITH ANY PRODUCT OR CAUSED BY
PRODUCT DEFECTS OR THE PARTIAL OR TOTAL FAILURE OF ANY PRODUCT REGARDLESS OF THE FORM OF ACTION,
WHETHER IN CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, AND WHETHER OR NOT
SUCH DAMAGE WAS FORESEEN OR UNFORESEEN.
Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized repairs or parts. This warranty gives
you specific legal rights, and you may also have other rights which vary from state to state.

10
Important Safety Information
Instructions pertaining to continued protection against fire, electric shock, and injury to persons are found
throughout this manual. Please read all instructions prior to assembling, mounting, and operating this
equipment.
The following international caution and warning symbols appear in margins throughout this manual to
highlight messages.

11
Fixture Overview
1: Lens
2: Display
3: Left-button
4: Mode/Esc-button
5: Down-button
6: ENTER-button
7: Right-button
8: Up-button
9: Handle
10: Fuse
11: Power out
12: Power in
13: 5 pin - DMX out
14: 5 pin - DMX in

12
Features
•60W high power LEDs
•Extremely Long Life:50,000 Hr and low power consumption.
•DMX channel mode: 15 channels.
•Pan/tilt movement: 16 bit resolution
For smooth and precise resolution.
Pan: 540° Tilt: 265°movement.
High speed of pan/tilt movement, speed of pan/tilt movement is adjustable.
Scan position memory, auto reposition after unexpected movement.
•Strobe effect with 18 flashes per second and pulse effect .
•General dimming and blackout for all four colors.
•Excellent color mixing and rainbow effect.
•Display: Can be changed 180° reverse to fit for different installation position.
•Dimmer intensity from 0%~100%.
•Control board with full color LCD graphic display and touch-keyboard.
•Rechargeable Back up Battery for Display.
•Software-upload by optional accessory via DMX line.

13
Safety Considerations
This device has left the factory in perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely
necessary for the user to follow the safety instructions and warning notes written in this user manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not accept liability for
any resulting defects or problems.
•If the device has been exposed to temperature changes due to environmental changes, do not switch it on immediately. The
condensation could cause damage to the device. Leave the device switched off until it has reached room temperature.
•This device falls under protection-class I. Therefore it is essential that the device be earthed.
•If protection screen, lens or ultraviolet screen in the fixture is apparently damaged or is damaged to exceed their own effective degree,
such as cracked and gashed, it must be replaced.
•The electrical connection must carry out by a qualified person.
•Make sure that the available voltage is within stated range.
•Make sure the power cord is never crimped or damaged by a sharp edge. Replace cable immediately if damaged, this work must be done
by an authorized dealer.
•Always disconnect from power, when the device is not in use or before cleaning it. Only handle the power cord by the plug. Never pull
out the plug by tugging the power cord.
•Don't project the beam onto combustible substances, as this causes a safety hazard.
•Please be aware that damages caused by manual modifications will void warranty.
•During initial start-up some smoke or smell may arise. This is a normal process and does not necessarily mean that the device is
defective, it should decrease gradually
•If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or his service
agent or a similar qualified person in order to avoid a hazard. All screws for installing the devices or parts of the device have to be
tightly connected and must not be corroded.
•There must not be any deformations on the housing, color lenses, fixations and installation spots (ceiling, suspension, trussing).
•Mechanically moved parts must not show any traces of wearing and must not rotate with unbalances.
•The electric power supply cables must not show any damage, material fatigue or sediments.
•Further instructions depending on the installation spot and usage have to be administered by a skilled installer and any safety problems
have to be removed.

14
General Guidelines
•This device is a lighting effect for professional use on stages, theaters, or other professional installations, etc., the device
was designed for indoor use only.
•This fixture is only allowed to be operated with the max alternating current which stated in the technical specifications
printed on the fixture.
•Lighting effects are not designed for permanent operation. Consistent operation breaks may ensure that the device will
serve you for a long time without defects.
•Do not shake the device .Avoid brute force when installing or operating the device.
•While choosing the installation-spot, please make sure that the device is not exposed to extreme heat, moisture or dust.
Please don't project the beam onto combustible substances. The minimum distance between light-output from the projector
and the illuminated surface must be more than 0.5 meter.
•If you use the quick lock cam in hanging up the fixture, please make sure the quick lock fasteners turned in the quick lock
holes correctly.
•Operate the device only after having familiarized with its functions. Do not permit operation by persons not qualified for
operating the device. Most damages are the result of unprofessional operation.
•Please use the original packaging if the device is to be transported.
•For safety reasons, please be aware that all modifications on the device are forbidden.
•If this device will be operated in any way different to the one described in this manual, the product may suffer damages and
the guarantee becomes void. Furthermore, any other operation may lead to short-circuit, burns, electric shock, lamp
explosion, crash, etc.
•In order to make the lights in good condition and extend the life time, we suggest a regular cleaning to the lights.

15
Installation Instructions
•
The installation must always be secured with a secondary safety attachment, e.g. an appropriate safety cable.
•
The installation of the effect has to be built and constructed in a way that it can hold 10 times the weight for 1 hour
without any harming deformation.
•
The applicable temperature for the lighting is between -10°C to 45°C. Do not use the lighting under or above the
temperature.
•
Never stand directly below the device when mounting, removing or servicing the fixture.
•
The operator has to make sure the safety and technical installations are approved by an expert before taking using
this fixture in the field for the first time.
•
These installations must be inspected by a skilled person once a year.
•
Overhead mounting requires extensive experience, including amongst others calculating working load limits,
installation material being used, and periodic safety inspection of all installation material and the device. If you
lack these qualifications, do not attempt the installation yourself. Improper installation can result in serious bodily
injury.
Attachment Instructions
•Attach the Omega clamp on the bracket by tighten the M12 bolt on the bracket to the hole in the middle of the bracket.
•Insert the quick-lock fasteners of the bracket into the respective holes on the bottom of the fixture.
•Tighten the quick-lock fasteners fully clockwise.
•Install the second Omega clamp.
•Attach the safety-cable through the holes on the bottom of the base. Attach to the trussing system or other safe fixation
point.
•Be sure the safety is fully looped, the quick-link is attached and fully tighten
•Inspect for complete attachment before lifting over-head

16
Technical Specifications
•Power supply: AC 100-240V~，50/60Hz
•Power consumption: 110W
•Packing dimensions: 31.5x24.5x46cm
•Net weight: 5.5 KGS
•Gross weight: 10.5 KGS

17
Mounting
Be sure this fixture is kept at least 0.5m away from any flammable materials (decoration etc.). Always use and install the supplied
safety cable as a safety measure to prevent accidental damage and/or injury in the event the clamp fails.
Overhead mounting requires extensive experience, including amongst others calculating working load limits, a fine knowledge of the
installation material being used, and periodic safety inspection of all installation material and the fixture. If you lack these
qualifications, do not attempt the installation yourself. Improper installation can result in bodily injury.

18
DMX Control Connection
Connect the provided XLR cable to the female 5-pin XLR output of your controller and the other side to the male 5-pin XLR input of
the moving head. You can chain multiple moving heads together through serial linking. The cable needed should be two core,
screened cable with XLR input and output connectors. Please refer to the diagram below:

19
DMX Start Address
All fixtures should be given a DMX starting address when using a DMX signal, so that the correct fixture responds to the correct
control signals. This digital starting address is the channel number from which the fixture starts to “listen” to the digital control
information sent out from the DMX controller. The allocation of this starting address is achieved by setting the correct number on the
display located on the base of the device.
You can set the same starting address for all fixtures or a group of fixtures, or make different address for each fixture individually.
If you set the same address, all the units will start to “listen” to the same control signal from the same channel number. In other
words, changing the settings of one channel will affect all the fixtures simultaneously.
If you set a different address, each unit will start to “listen” to the channel number you have set, based on the quantity of control
channels of the unit. That means changing the settings of one channel will affect only the selected fixture.
In the case of this LED moving head, which is a 15 channel fixture, you should set the starting address of the first unit to 1, the
second unit to 16(15 + 1), the third unit to 31 (15+16 ), and so on.
DMX Connection with DMX terminator
For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque,
it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The
DMX terminator is simply an XLR plug with a 120 Ω resistor connected between pins 2 and 3,which is then plugged into the output
XLR socket of the last fixture in the chain. Please see illustrations below:

20
Control Board
