HIK VISION UD03451B User manual

Smart Camera User Manual
1
User Manual
UD03451B
Smart Camera

Smart Camera User Manual
2
User Manual
COPYRIGHT ©2016 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures, graphs are the properties of
Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be
“Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced,
changed, translated, or distributed, partially or wholly, by any means, without the prior written
permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties,
guarantees or representations, express or implied, regarding to the Manual.
About this Manual
This Manual is applicable to Smart Camera.
The Manual includes instructions for using and managing the product. Pictures, charts, images and
all other information hereinafter are for description and explanation only. The information contained
in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please
find the latest version in the company website (http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the properties of Hikvision in
various jurisdictions. Other trademarks and logos mentioned below are the properties of their
respective owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS
IS”, WITH ALL FAULTS AND ERRORS, AND HIKVISION MAKES NO WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS
DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY
SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING,
AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE
USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY

Smart Camera User Manual
3
OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT
SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY
RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER
DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION,
OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT
LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE
THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE
LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE
LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the limits for a digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with
"CE" and comply therefore with the applicable harmonized European standards
listed under the EMC Directive 2014/30/EC, the RoHS Directive 2011/65/EU.

Smart Camera User Manual
4
2012/19/EU (WEEE directive): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points. For
more information see: www.recyclethis.info.
Safety Instruction
These instructions are intended to ensure that the user can use the product correctly to avoid danger
or property loss.
The precaution measure is divided into ‘Warnings’ and ‘Cautions’:
Warnings: Serious injury or death may be caused if any of these warnings are neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
Warnings Follow these safeguards to
prevent serious injury or death.
Cautions Follow these precautions to
prevent potential injury or material
damage.
Warnings:
Please adopt the power adapter which can meet the safety extra low voltage (SELV) standard.
And source with 12 VDC (depending on models) according to the IEC60950-1 and Limited
Power Source standard.
To reduce the risk of fire or electrical shock, do not expose this product to rain or moisture.
This installation should be made by a qualified service person and should conform to all the
local codes.
Please install blackouts equipment into the power supply circuit for convenient supply
interruption.
Please make sure that the ceiling can support more than 50 (N) Newton gravities if the camera is
fixed to the ceiling.
If the product does not work properly, please contact your dealer or the nearest service center.
Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)

Smart Camera User Manual
5
Cautions:
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit
of ethanol and wipe it gently. If the camera will not be used for an extended period of time, put
on the lens cap to protect the sensor from dirt.
Do not aim the camera lens at the strong light such as sun or incandescent lamp. The strong
light can cause fatal damage to the camera.
The sensor may be burned out by a laser beam, so when any laser equipment is being used,
make sure that the surface of the sensor not be exposed to the laser beam.
Do not place the camera in extremely hot, cold temperatures (the operating temperature should
be between 0°C to 50°C), dusty or damp environment, and do not expose it to high
electromagnetic radiation.
To avoid heat accumulation, ensure there is good ventilation to the device.
Keep the camera away from water and any liquids.
While shipping, pack the camera in its original, or equivalent, packing materials. Or packing the
same texture.

Smart Camera User Manual
6
Table of Contents
Chapter 1 Overview.........................................................................................................................8
1.1 Introduction.................................................................................................................................... 8
1.2 Main Features................................................................................................................................. 8
1.3 Specifications.................................................................................................................................. 9
1.3.1 MV-SI622-00GM/MV-SI622-01GM Specification ........................................................................................ 9
1.3.2 MV-SI622-00GM/MV-SI622-01GM Response Curve ................................................................................. 10
1.4 Camera Physical Interfaces......................................................................................................... 10
1.4.1 Camera Structure ...................................................................................................................................... 10
1.4.2 Camera Dimension.................................................................................................................................... 11
1.4.3 Interfaces Introduction ............................................................................................................................. 12
1.4.4 Power and I/O Interface Introduction....................................................................................................... 12
1.4.5 External Light Source Interfaces................................................................................................................ 13
1.4.6 Installation Accessories ............................................................................................................................. 14
Chapter 2 Camera Installation and Configuration.....................................................................15
2.1 Installing the Camera ......................................................................................................................... 15
2.2 Client Installation................................................................................................................................ 19
2.3 Camera Configuration........................................................................................................................ 21
2.3.1 Viewing Camera IP Address ...................................................................................................................... 21
2.3.2 Setting Local Network ............................................................................................................................... 21
2.3.3 Setting via Attribute Tree .......................................................................................................................... 23
Chapter 3 Functions.......................................................................................................................28
3.1 Device Control..................................................................................................................................... 28
3.2 Reading Setting ............................................................................................................................ 28
3.2.2 Object Moving Mode ................................................................................................................................ 28
3.2.3 Running Mode........................................................................................................................................... 29
3.2.4 Code Parameters....................................................................................................................................... 29
3.2.5 Multi Frames Combine.............................................................................................................................. 30
3.3 Image Setting................................................................................................................................ 31
3.3.1 Camera Data Format ...................................................................................................................................... 31
3.3.2 Acquisition Frame Rate .................................................................................................................................. 31

Smart Camera User Manual
7
3.3.3 ROI Settings .................................................................................................................................................... 31
3.3.4 Exposure Time................................................................................................................................................ 32
3.3.5 Gain Control ................................................................................................................................................... 33
3.3.6 Gamma Correction ......................................................................................................................................... 34
3.3.7 Brightness....................................................................................................................................................... 35
3.3.8 Image Reverse ................................................................................................................................................ 35
3.3.9 Test Pattern..................................................................................................................................................... 35
3.4 Light Source Control ................................................................................................................... 37
3.5 Trigger and IO Control................................................................................................................ 38
3.5.1 Trigger Mode .................................................................................................................................................. 38
3.5.2 Opto-isolated output...................................................................................................................................... 41
3.5.3 Opto-isolated Input/Output Circuit........................................................................................................... 42
3.6 Communication Control.............................................................................................................. 43
3.6.1 Data Transmission .......................................................................................................................................... 43
3.6.2 Communication Protocol................................................................................................................................ 44
3.7 Result Setting................................................................................................................................ 44
3.8 User Set Control........................................................................................................................... 45
3.8.1 Parameters Saving and Loading...................................................................................................................... 45
3.8.2 User LED Indicator .......................................................................................................................................... 46
3.9 Arithmetic Control....................................................................................................................... 47
3.9.1 common arithmetic parameter ...................................................................................................................... 47
Chapter 4 Troubleshooting............................................................................................................49
4.1 Indicator Introduce...................................................................................................................... 49
4.2 Indicator Status Definition .......................................................................................................... 49
4.3 Indicator Status Description........................................................................................................ 50
4.4 FAQ ............................................................................................................................................... 51

Smart Camera User Manual
8
Chapter 1 Overview
1.1 Introduction
The smart camera adopts aviation plug to RJ45 interface to perform real-time transmission of
uncompressed or compressed image through a gigabit Ethernet interface. Remote image capturing
and camera control, for example, the operating mode and the image parameters adjustment, are
supported by client software.
The device is mainly used for code recognition. The camera reads the multiple types of codes and
the system recognizes and analysis the information of the code via algorithm processing of the
client.
1.2 Main Features
Intel E3845, Quad Cores, 1.9GHz, 4GB Memory.
Two light source control modes: Front light source or 24 V DC external light source.
Use hardware external trigger or software trigger to synchronize several cameras or external
devices connecting with the camera.
Real-time transmission of compressed or uncompressed image.
Protection ingress: IP67.

Smart Camera User Manual
9
1.3 Specifications
1.3.1 MV-SI622-00GM/MV-SI622-01GM Specification
Table 1. 1 MV-SI622-00GM/MV-SI622-01GM Specification
Model
Parameters
MV-SI622-00GM
MV-SI622-01GM
5 MP 1" CMOS Smart Camera
Camera
Sensor Type
1" global shutter CMOS
Resolution
2592 ×2048
Pixel Size
4.8 μm × 4.8μm
Frame Rate
30fps
Dynamic Range
> 60dB
SNR
> 40dB
Gain margin
0 to 24dB
Exposure Time
rang
5μs to 5s
Shutter Mode
Global shutter, supporting Auto, Manual, One-Push, etc. exposture modes.
Data Interfac
Gigabit Ethernet, via 8-pin waterproof connector.
RS-232
1 input serial port and 1 output serial port, supported via 12-pin Interface
Digital I/O
12-pin I/O interface,
3 GPI Input,
3 GPI Output
Cache
4G
Data Format
Mono 8
General
Power Supply and
Consumption
10VDC to 30VDC, Power Consumption < 15W without light source.
20VDC to 30VDC, Power Consumption < 45 W with light source on.
Temprature
Working Temprature: 0°C to 50°C (32°F to 122°F),
Storage Temprature: -30°C to 70°C (-22°F to 158°F)
Dimension
126mm×66mm×50mm (4.96″×2.60″×2.38″)
Weight
Approx. 800g (1.76lb)
Lens Mount
C-Mount

Smart Camera User Manual
10
Light Source
No light source
No lens waterproof shield
With light source
With lens waterproof shield
Control Client
Smart MVS
Protection Level
IP67(with the lens shield)
Certifications
CE, FCC, and RoHS
1.3.2 MV-SI622-00GM/MV-SI622-01GM Response Curve
Figure 1. 2 MV-SI622-00GM/MV-SI622-01GM Response Curve
The response curve data is provided by the chip manufacture.
1.4 Camera Physical Interfaces
1.4.1 Camera Structure
The smart camera consists of camera, lens, lamp cup, and housing. The figure below shows the
structure of the smart camera.

Smart Camera User Manual
11
Figure 1. 3 Smart camera Structure
1.4.2 Camera Dimension
The figure below shows the dimension of the smart camera without light source and camera
housing.
The camera should be installed with M4 screws from the package (supplied). Screw holes are in the
each front panel and rear panel of the camera, each panel can be used to fix the camera to the
bracket. If using other screws, you are recommended to adopt metric M4 screws of which the length
should be less than the sum of the depth of screw holes and the installation plate thickness.
Figure 1. 4 Dimension of Smart Camera

Smart Camera User Manual
12
The camera adopts the C-Mount lens interface.
1.4.3 Interfaces Introduction
The figure below shows the interfaces of the smart camera with light source and camera housing,
including aviation plug to RJ45 network interface, 12-pin power and I/O interface, and 5-pin
external light source interface. The camera interfaces with screw thread for connection between
camera and cable avoid loosening due to vibration.
2
3
1
Figure 1. 5 Smart camera Interfaces
Table 1. 2 Description of the Smart camera Interfaces
No.
Description
1
Power and I/O Connector
2
External Light Source
3
Gigabit Network Interface
1.4.4 Power and I/O Interface Introduction
The description of the 12-pin power and I/O connector is shown in the table below.

Smart Camera User Manual
13
2
3
4
56
7
8
9
1
10
11 12
Figure 1. 6 Power and I/O Interface
Table 1. 3 Description
No.
Signal
Color
I/O Type
Description
1
DC-PWR
White
/
DC 12V +
2
GND
Brown
/
Power Grounding
3
OPTO_OUT0
Green
Output
I/O Output 0
4
OPTO_OUT1
Yellow
Output
I/O Output 1
5
OPTO_OUT2
Grey
Output
I/O Output 2
6
OUT_COM
Pink
Output
Signal Output Grounding
7
OPTO_IN0
Blue
Input
I/O Input 0
8
OPTO_IN1
Red
Input
I/O Input 1
9
OPTO_IN2
Black
Input
I/O Input 2
10
IN_COM
Purple
Input
Signal Input Grounding
11
RS232_R
Grey/Pink
/
RS-232 Serial Port Input
12
RS232_T
Red/Blue
/
RS-232 Serial Port Output
1.4.5 External Light Source Interfaces
The description of the external light source interfaces are shown in the table below.
1
4
2
3
5
Figure 1. 7 Outer Light Source Interfaces

Smart Camera User Manual
14
Table 1. 4 Description
No.
Signal
Color
I/O Type
Description
1
LED+
Brown
Output
LED +
2
LED-
White
Output
LED -
3
GND
Blue
Output
Power Grounding
4
OPTO_PWM
Black
Output
light-coupled Isolation Trigger Signal
5
OPTO_GND
Grey
Output
light-coupled Isolation Grounding
1.4.6 Installation Accessories
Prepare the installation accessories listed below before you install the smart camera.
Table 1. 5 Accessory List
No.
Accessory Name
Number
Description
1
Camera
1
The smart camera.
2
Power I/O Cable
1
The 12-pin cable (included) or extension cable (not
included).
3
Ethernet Network Cable
1
3 meters KMbps network cable with aviation plug
to RJ45 network interface
4
External Light Source Cable
1
5-pin external light source cable
5
Power adapter (Optional)
1
12 V/24 V power adapter (above 2A/1A)
6
Lens (Optional)
1
C-Mount Lens
7
Mounting Bracket (Optional)
1
The mounting bracket is for mounting the camera.
8
Waterproof Lens Case
1
Lens case meets the IP67 protection ingress.

Chapter 2 Camera Installation and
Configuration
2.1 Installing the Camera
Steps:
1. Unpack the camera package, rotate the water-proof lens case anticlockwise,
and take out the lamp cup.
2. Install the lens to the camera body by rotating the lens clockwise.
3. Install the IR lamp cup (first), and water-proof lens case back.
Press the Bayonet as shown
by the Arrow to Separate
the Lamp Cup
Disassemble the Lamp Cup
Figure 2. 1 Lens Installation
4. Install the camera to the desired position by using M4 screws. There are three
installation types shown as the figures below, and choose the proper
installation type according to your needs.

Smart Camera User Manual
16
安装方式一示意图
Figure 2. 2 Type I Installation
安装方式二示意图
Figure 2. 3 Type II Installation

Smart Camera User Manual
17
安装方式三示意图
Figure 2. 4 Type III Installation
5. Use 8-pin avigation plug to RJ 45 network interface to connect the camera to a
switch or a network card..
Figure 2. 5 Connect Network Cable
6. Use the supplied cable with a 12-pin power and I/O interface to connect the
camera to a 24 V DC power adapter.
Figure 2. 6 Connect Power Cable

Smart Camera User Manual
18
7. If external light source is required, connect the camera to an external light
source.
Figure 2. 7 Connect the External Light Source
Use 10 V DC to 30 V DC without using light source, and otherwise use 20 V DC to
30 V .

Smart Camera User Manual
19
2.2 Client Installation
Windows XP /7/8 32/64bit is a requirement.
Visit www. hikvision. com to get more information.
The client software is integrating all hardware drivers.
Steps:
1. Get the client from the www. hikvision. com.
Support -> Download -> Client Software
2. Double click to run the client, and click Next to choose the language
according to your needs.
Figure 2. 8 Choose the Language
3. Click Next to install the program to the default installation directory C:\Program
Files (x86)\Smart MVS, which is not recommended. You are allowed to specify the
installation directory as you want by clicking Change to choose the directory from
your computer, or directly entering the directory in the text field.

Smart Camera User Manual
20
Figure 2. 9 Install the Program
4. Click Install to start the installation, and click Finish to complete the installation.
Figure 2. 10 Finish the Installation
