HIKOKI DS14DSDL User manual

Handling instructions
DS 14DSDL ∙DS 18DSDL
DV 14DSDL ∙DV 18DSDL
DS18DSDL DV18DSDL
0000BookDS14DSDL.indb10000BookDS14DSDL.indb1 2017/12/0518:21:432017/12/0518:21:43

2
power source and/or battery pack, picking up or
carrying the tool.
Carrying power tools with your finger on the switch
or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts.
Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and safer
at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/
or the battery pack from the power tool before
making any adjustments, changing accessories,
or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power toolʼs operation.
If damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer.
A charger that is suitable for one type of battery pack
may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk of
injury and fire.
GENERAL POWER TOOL SAFETY
WARNINGS
WARNING
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the offposition before connecting to
0000BookDS14DSDL.indb20000BookDS14DSDL.indb2 2017/12/0518:21:432017/12/0518:21:43

3
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
6) Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts.
This will ensure that the safety of the power tool is
maintained.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.
CORDLESS DRIVER DRILL / IMPACT
DRIVER DRILL SAFETY WARNINGS
<DV14DSDL/DV18DSDL>
1. Wear ear protectors when impact drilling.
Exposure to noise can cause hearing loss.
<DS14DSDL/DS18DSDL/DV14DSDL/DV18DSDL>
1. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
2. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory or fastener may contact hidden wiring.
Cutting accessory and fasteners contacting a "live" wire
may make exposed metal parts of the power tool "live"
and could give the operator an electric shock.
ADDITIONAL SAFETY WARNINGS
1. Make sure that the area to be drilled is absolutely free
of any hidden obstructions including electrical wiring,
water, or gas pipes. Drilling into the aforementioned may
result in electric shock or short circuit, gas leak or other
hazards that can cause serious accidents or injuries.
2. Make sure to securely hold the tool during operation.
Failure to do so can result in accidents or injuries.
3. Secure the workpiece. A workpiece clamped with
clamping devices or in a vice is held more secure than
by hand.
4. Setting up and checking the work environment. Check
if the work environment is suitable by following the
precaution.
5. Do not allow foreign matter to enter the hole for
connecting the rechargeable battery.
6. Never disassemble the rechargeable battery and
charger.
7. Never short-circuit the rechargeable battery.
Shortcircuiting the battery will cause a great electric
current and overheat. It results in burn or damage to the
battery.
8. Do not dispose of the battery in fire. If the battery is burnt,
it may explode.
9. Bring the battery to the shop from which it was purchased
as soon as the post-charging battery life becomes too
short for practical use. Do not dispose of the exhausted
battery.
10. Do not insert object into the air ventilation slots of the
charger. Inserting metal objects or inflammables into the
charger air ventilation slots will result in electrical shock
hazard or damaged charger.
11. When mounting a bit into the keyless chuck, tighten the
sleeve adequately. If the sleeve is not tight, the bit may
slip or fall out, causing injury.
12. When changing the rotational speed with the shift knob,
confirm that the switch is off. Changing the speed while
the motor is rotating will damage the gears.
13. The clutch dial cannot be set between the numerals "1,
3, 5 … 22" or the dots, and do not use with the clutch dial
numeral between "22" and the line at the middle of the
drill mark. Doing so may cause damage.
14. Resting the unit after continuous work.
15. After use for continuous tightening wood screw works,
rest the unit for 15 minutes or so when replacing the
battery. The temperature of the motor, switch, etc., will
rise if the work is started again immediately after battery
replacement, eventually resulting in burnout.
16. The motor may stop in the event the tool is overloaded. In
this should occur, release the tool’s switch and eliminate
the cause of the overload.
17. The motor rotation may be locked to cease while the unit
is used as drill. While operating the driver drill, take care
not to lock the motor.
18. If motor is locked, immediately turn the power off. If the
motor is locked for a while, the motor or battery may be
burnt.
19. The use of the battery in a cold condition (below 0 degree
Centigrade) can sometimes result in the weakened
tightening torque and reduced amount of work. This,
however, is a temporary phenomenon, and returns to
normal when the battery warms up.
20. Install securely the hook. Unless the hook is securely
installed, it may cause an injury while using.
21. To prevent the battery power consumption caused
by forgetting to turn offthe LED light, the light goes off
automatically in about 15 minutes.
22. Do not look directly into the light. Such actions could
result in eye injury.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with the
protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may
stop. This is not the trouble but the result of protection
function.
1. When the battery power remaining runs out, the motor
stops.
In such a case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes of
overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand, please
be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
○During work make sure that swarf and dust do not fall on
the battery.
○Make sure that any swarf and dust falling on the power
tool during work do not collect on the battery.
0000BookDS14DSDL.indb30000BookDS14DSDL.indb3 2017/12/0518:21:442017/12/0518:21:44

4
○Do not store an unused battery in a location exposed to
swarf and dust.
○Before storing a battery, remove any swarf and dust that
may adhere to it and do not store it together with metal
parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject the
battery to severe physical shock.
3. Do not use an apparently damaged or deformed battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specified.
7. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately stop
further recharging.
8. Do not put or subject the battery to high temperatures or
high pressure such as into a microwave oven, dryer, or
high pressure container.
9. Keep away from fire immediately when leakage or foul
odor are detected.
10. Do not use in a location where strong static electricity
generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears abnormal
during use, recharging or storage, immediately remove it
from the equipment or battery charger, and stop use.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using the
battery for the first time, do not use and return it to your
supplier or vendor.
WARNING
If a conductive foreign matter enters in the terminal of lithium
ion battery, the battery may be shorted, causing fire. When
storing the lithium ion battery, obey surely the rules of
following contents.
○Do not place conductive debris, nail and wires such as
iron wire and copper wire in the storage case.
○To prevent shorting from occurring, load the battery in
the tool or insert securely the battery cover for storing
until the ventilator is not seen.
REGARDING LITHIUM-ION BATTERY
TRANSPORTATION
When transporting a lithium-ion battery, please observe the
following precautions.
WARNING
Notify the transporting company that a package contains a
lithium-ion battery, inform the company of its power output
and follow the instructions of the transportation company
when arranging transport.
○Lithium-ion batteries that exceed a power output of
100Wh are considered to be in the freight classification
of Dangerous Goods and will require special application
procedures.
○For transportation abroad, you must comply with
international law and the rules and regulations of the
destination country.
Wh
Power Output
2 to 3 digit number
USB DEVICE CONNECTION
PRECAUTIONS (ONLY WITH
UC18YSL3 CHARGER)
When an unexpected problem occurs, the data in a USB
device connected to this product may be corrupted or lost.
Always make sure to back up any data contained in the USB
device prior to use with this product.
Please be aware that our company accepts absolutely no
responsibility for any data stored in a USB device that is
corrupted or lost, nor for any damage that may occur to a
connected device.
WARNING
○Prior to use, check the connecting USB cable for any
defect or damage.
Using a defective or damaged USB cable can cause
smoke emission or ignition.
○When the product is not being used, cover the USB port
with the rubber cover.
Buildup of dust etc. in the USB port can cause smoke
emission or ignition.
NOTE
○There may be an occasional pause during USB
recharging.
○When a USB device is not being charged, remove the
USB device from the charger.
Failure to do so may not only reduce the battery life
of a USB device, but may also result in unexpected
accidents.
○It may not be possible to charge some USB devices,
depending on the type of device.
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
DS14DSDL / DS18DSDL:
Cordless Driver Drill
DV14DSDL / DV18DSDL:
Cordless Impact Driver Drill
Read all safety warnings and all instructions.
V Rated voltage
n0No-load speed
Bpm Impact rate
Ls Low speed
Hs High speed
Brick
0000BookDS14DSDL.indb40000BookDS14DSDL.indb4 2017/12/0518:21:442017/12/0518:21:44

5
Wood
Metal
Machine screw
Wood screw
Drill chuck capacity
kg Weight
Drilling
Impact drilling
Switching ON
Switching OFF
Disconnect the battery
Battery capacity
Light switch
Remaining battery indicator switch
Change rotation speed - High speed
Change rotation speed - Low speed
Clockwise rotation
Counterclockwise rotation
The battery remaining power is nearly empty.
Recharge the battery soonest possible
The battery remaining power is a half.
The battery remaining power is enough.
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed on page 9.
Standard accessories are subject to change without notice.
APPLICATIONS
<DS14DSDL / DS18DSDL>
○Driving and removing of machine screws, wood screws,
tapping screws, etc.
○Drilling of various metals
○Drilling of various woods
<DV14DSDL / DV18DSDL>
○Drilling of brick and concrete block, etc.
○Driving and removing of machine screws, wood screws,
tapping screws, etc.
○Drilling of various metals
○Drilling of various woods
SPECIFICATIONS
The specifications of this machine are listed in the Table on
page 9.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect to the power source. (Fig. 2)
When charging the battery from an AC power source
○Connect the charger’s power cord to the receptacle.
<UC18YFSL, UC18YML2>
When connecting the plug of the charger to a receptacle,
the pilot lamp will blink in red (At 1-second intervals).
<UC18YSL3>
When connecting the plug of the charger to a receptacle,
the charge indicator lamp will blink in red (At 1-second
intervals).
CAUTION
Do not use the electrical cord if damaged. Have it
repaired immediately.
When charging the battery from a DC 12V in-car power
source (UC18YML2)
○Secure the battery charger in place in the car.
Use the strap supplied with the battery charger to fasten
the battery charger in place and prevent it from moving
inadvertently. (See Fig. 18)
CAUTION
Do not place the battery charger or battery under the
driver’s seat. Secure the battery charger in place to
prevent it from moving inadvertently as this may lead to
an accident.
○Insert the cigarette lighter connecting plug into the
cigarette lighter socket.
If the plug is loose and falls out of the cigarette lighter
socket, repair the socket. As the socket may be faulty,
you are recommended to contact your local car dealer.
Continued use of the socket may result in an accident
due to overheating.
2. Insert the battery into the charger. (Fig. 2)
Firmly insert the battery into the charger.
3. Charging
<UC18YFSL, UC18YML2>
When inserting a battery in the charger, the pilot lamp
will light up continuously in red.
When the battery becomes fully recharged, the
pilot lamp will blink in red (At 1-second intervals).
(See Table 1-a)
●Pilot lamp indication
The indications of the pilot lamp will be as shown in
Table 1-a, according to the condition of the charger or
the rechargeable battery.
<UC18YSL3>
When inserting a battery in the charger, the charge
indicator lamp will blink in blue.
When the battery becomes fully recharged, the charge
indicator lamp will light up in green. (See Table 1-b)
●Charge indicator lamp indication
The indications of the charge indicator lamp will be as
shown in Table 1-b, according to the condition of the
charger or the rechargeable battery.
Fig. 18
0000BookDS14DSDL.indb50000BookDS14DSDL.indb5 2017/12/0518:21:442017/12/0518:21:44

6
Table 1-a
Indications of the pilot lamp
The pilot
lamp
lights or
blinks.
Before
charging Blinks (red)
Lights for 0.5 seconds. Does not light for 0.5
seconds. (offfor 0.5 seconds)
While charging Lights (red) Lights continuously
Charging
complete Blinks (red)
Lights for 0.5 seconds. Does not light for 0.5
seconds. (offfor 0.5 seconds)
Charging
impossible Flickers (red)
Lights for 0.1 seconds. Does not light for 0.1
seconds. (offfor 0.1 seconds) Malfunction in the
battery or the charger
Overheat
standby
Lights (green)
(UC18YML2)
Lights continuously Battery overheated.
Unable to charge.
(Charging will
commence when
battery cools)
Blinks (red)
(UC18YFSL)
Lights for 1 second. Does not light for 0.5
seconds. (offfor 0.5 seconds)
Charging
with in-car
power source
impossible
(UC18YML2)
Blinks (green)
Lights for 0.5 seconds. Does not light for 0.5
seconds. (offfor 0.5 seconds) Malfunction in the
battery or the charger
NOTE: When standby for cooling battery, UC18YML2 / UC18YFSL cools the overheated battery by cooling fan.
(However, the cooling fan does not function when charging the battery with a DC 12V in-car power source.)
Table 1-b
Indications of the charge indicator lamp
Charge
indicator
lamp
(red / blue /
green /
purple)
Before
charging
Blinks
(red)
Lights for 0.5 seconds. Does not light for
0.5 seconds. (offfor 0.5 seconds) Plugged into power source
While
charging
Blinks
(blue)
Lights for 0.5 seconds. Does not light for
1 second. (offfor 1 second) Battery capacity at less than 50%
Blinks
(blue)
Lights for 1 second. Does not light
for 0.5 seconds. (offfor 0.5 seconds) Battery capacity at less than 80%
Lights
(blue)
Lights continuously Battery capacity at more than 80%
Charging
complete
Lights
(green)
Lights continuously
(Continuous buzzer sound: about 6
seconds)
Overheat
standby
Blinks
(red)
Lights for 0.3 seconds. Does not light for
0.3 seconds. (offfor 0.3 seconds)
Battery overheated. Unable to
charge. (Charging will commence
when battery cools)
Charging
impossible
Flickers
(purple)
Lights for 0.1 seconds. Does not light for
0.1 seconds. (offfor 0.1 seconds)
(Intermittent buzzer sound: about 2
seconds)
Malfunction in the battery or the
charger
NOTE: When standby for cooling battery, UC18YSL3 cools the overheated battery by cooling fan.
0000BookDS14DSDL.indb60000BookDS14DSDL.indb6 2017/12/0518:21:452017/12/0518:21:45

7
●Regarding the temperatures and charging time of the battery.
The temperatures and charging time will become as shown in Table 2
Table 2
Charger
Battery UC18YFSL UC18YML2
(AC/DC)*1UC18YSL3
Charging voltage V 14.4V -18V
Weight kg 0.5 0.7 0.6
Temperatures at which the battery can be
recharged 0oC – 50oC -10oC – 50oC
Charging time for battery capacity, approx.
(At 20oC)
1.3Ah
1.5Ah
2.0Ah
2.5Ah
3.0Ah
4.0Ah
5.0Ah
6.0Ah
Min.
Min.
Min.
Min.
Min.
Min.
Min.
Min.
20
22
30
35
45
60
75
90
20/50
22/60
30/80
35/100
45/120
60/160
75/200
90/240
15
15
20
25
20
26
32
38
Number of battery cells 4 – 10
*1AC power supply / DC 12V (in-car) power supply
NOTE
The recharging time may vary according to the ambient
temperature and power source voltage.
<UC18YML2>
Especially, using a DC 12V in-car power source may
require longer recharging time at high temperatures.
CAUTION
When the battery charger has been continuously used,
the battery charger will be heated, thus constituting
the cause of the failures. Once the charging has been
completed, give 15 minutes rest until the next charging.
4. Disconnect the charger’s power cord from the
receptacle or cigarette lighter socket.
5. Hold the charger firmly and pull out the battery.
NOTE
Be sure to pull out the battery from the charger after use,
and then keep it.
CAUTION
○If the battery is charged while it is heated because it has
been left for a long time in a location subject to direct
sunlight or because the battery has just been used, the
pilot lamp of UC18YML2 charger lights up green, or the
pilot lamp of UC18YFSL charger lights for 1 second,
does not light for 0.5 seconds (offfor 0.5 seconds), or
the charge indicator lamp of UC18YSL3 charger lights
for 0.3 seconds, does not light for 0.3 seconds (offfor 0.3
seconds). In such a case, first let the battery cool, then
start charging.
○When the pilot lamp or charge indicator lamp flickers in
red (at 0.2-seconds intervals), check for and take out
any foreign objects in the charger’s battery connector. If
there are no foreign objects, it is probable that the battery
or charger is malfunctioning. Take it to your authorized
Service Center.
○Since the built-in micro computer takes about 3
seconds to confirm that the battery being charged with
charger is taken out, wait for a minimum of 3 seconds
before reinserting it to continue charging. If the battery
is reinserted within 3 seconds, the battery may not be
properly charged.
○Check the voltage of the in-car power source when
the pilot lamp flickers in green (every 0.2 seconds)
continuously. (UC18YML2)
If the voltage is 12V or lower, it indicates that the car
battery has weakened and cannot be charged.
○If the pilot lamp or charge indicator lamp does not blink
in red (every second) even though the charger cord
or cigarette lighter connecting plug is connected to
the power, it indicates that the protection circuit of the
charger may be activated.
Remove the cord or plug from the power and then
connect it again after 30 seconds or so. If this does not
cause the pilot lamp or charge indicator lamp to blink
in red (every second), please take the charger to the
HiKOKI Authorized Service Center.
MOUNTING AND OPERATION
Action Figure Page
Removing and inserting the battery 110
Charging 2 10
Installing / Removing the side handle 3 10
Tightening torque adjustment 4 10
Selecting the drill position 5 11
Selecting the impact position 6 11
Change rotation speed 7 11
Removing and mounting the hook 8 11
Remaining battery indicator 9 11
How to use the LED light 10 11
Mounting the bit 11 12
Reversing the rotational direction 12 12
Switch operation 13 12
Check and replacing the carbon brush 14 12
Charging a USB device from an
electrical outlet 15-a 13
Charging a USB device and battery
from an electrical outlet 15-b 13
How to recharge USB device 16 13
When charging of USB device is
completed 17 13
Selecting accessories ―14
0000BookDS14DSDL.indb70000BookDS14DSDL.indb7 2017/12/0518:21:452017/12/0518:21:45

8
MAINTENANCE AND INSPECTION
1. Inspecting the tool
Since use of as dull tool will degrade efficiency and
cause possible motor malfunction, sharpen or replace
the tool as soon as abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool. Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
4. Inspecting the carbon brushes (Fig. 14)
The motor employs carbon brushes which are
consumable parts. Since and excessively worn carbon
brush can result in motor trouble, replace the carbon
brush with new ones when it becomes worn to or near
the “wear limit” ⓐ. In addition, always keep carbon
brushes clean and ensure that they slide freely within the
brush holders.
NOTE
When replacing the carbon brush with a new one, be
sure to use the HiKOKI Carbon Brush Code No. 999054.
5. Replacing carbon brushes (Fig. 14)
Take out the carbon brush by first removing the brush
cap and then hooking the protrusion of the carbon brush
with a flat head screw driver, etc.
When installing the carbon brush, choose the direction
so that the nail ⓑof the carbon brush agrees with the
contact portion ⓒoutside the brush tube. Then push it in
with a finger. Lastly, install the brush cap.
CAUTION
Be absolutely sure to insert the nail of the carbon brush
into the contact portion outside the brush tube. (You can
insert whichever one of the two nails provided).
Caution must be exercised since any error in this
operation can result in the deformed nail of the carbon
brush and may cause motor trouble at an early stage.
6. Cleaning on the outside
When the driver drill is stained, wipe with a soft dry cloth
or a cloth moistened with soapy water. Do not use chloric
solvents, gasoline or paint thinner, for they melt plastics.
7. Storage
Store the driver drill in a place in which the temperature
is less than 40°C and out of reach of children.
NOTE
Storing lithium-ion batteries.
Make sure the lithium-ion batteries have been fully
charged before storing them.
Prolonged storage (3 months or more) of batteries with
a low charge may result in performance deterioration,
significantly reducing battery usage time or rendering
the batteries incapable of holding a charge.
However, significantly reduced battery usage time may
be recovered by repeatedly charging and using the
batteries two to five times.
If the battery usage time is extremely short despite
repeated charging and use, consider the batteries dead
and purchase new batteries.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
Important notice on the batteries for the HiKOKI
cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used with
batteries other than these designated by us, or when
the battery is disassembled and modified (such as
disassembly and replacement of cells or other internal
parts).
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
0000BookDS14DSDL.indb80000BookDS14DSDL.indb8 2017/12/0518:21:452017/12/0518:21:45

9
DS14DSDL DS18DSDL DV14DSDL DV18DSDL
V V 14.4 18 14.4 18
n0Ls /min 0 -350 0 -350 0 -350 0 -400
n0 Hs /min 0 -1600 0 -1600 0 -1700 0 -1800
Bpm Ls /min ――0 -5250 0 -6000
Bpm Hs /min ――0 -25500 0 -27000
mm ――14 16
mm 50 65 50 65
mm 13 13 13 13
mm6666
mm8888
mm 1.5 -13 1.5 -13 1.5 -13 1.5 -13
kg kg 2.0 2.1 2.1 2.2
DS14DSDL, DS18DSDL, DV14DSDL, DV18DSDL
(NN)
11
1―
2―
1―
1―
11
0000BookDS14DSDL.indb90000BookDS14DSDL.indb9 2017/12/0518:21:452017/12/0518:21:45

10
1
D E
1
2
2
<UC18YML2> <UC18YFSL> <UC18YSL3>
11 1
2
22
34
1
1
2
2
0000BookDS14DSDL.indb100000BookDS14DSDL.indb10 2017/12/0518:21:462017/12/0518:21:46

11
56
DS14DSDL
DS18DSDL
DV14DSDL
DV18DSDL
DV14DSDL
DV18DSDL
78
1
1
2
2
3
3
910
0000BookDS14DSDL.indb110000BookDS14DSDL.indb11 2017/12/0518:21:462017/12/0518:21:46

12
11 12
1
2
3
13
0
Ls
350 /min
400 /min
Hs
1600 /min
1700 /min
1800 /min
14
3mm
11.5mm
0000BookDS14DSDL.indb120000BookDS14DSDL.indb12 2017/12/0518:21:462017/12/0518:21:46

13
15
ab
16
1
2
17
2
1
0000BookDS14DSDL.indb130000BookDS14DSDL.indb13 2017/12/0518:21:462017/12/0518:21:46

14
14.4V (Li-ion)
18V (Li-ion)
UC18YML2 (14.4V - 18V)
UC18YFSL (14.4V - 18V) 331906
983006
337140
336475
336471
999054 329897
337131
UC18YSL3 (14.4V –18V)
0000BookDS14DSDL.indb140000BookDS14DSDL.indb14 2017/12/0518:21:462017/12/0518:21:46

15
0000BookDS14DSDL.indb150000BookDS14DSDL.indb15 2017/12/0518:21:472017/12/0518:21:47

806
Code No. C99700111 G
Printed in China
Shinagawa Intercity Tower A, 15-1, Konan 2-chome,
Minato-ku, Tokyo, Japan
0000BookDS14DSDL.indb160000BookDS14DSDL.indb16 2017/12/0518:21:472017/12/0518:21:47
