Hill Pro Audio M Series User manual

-

General information
M10 User Manual
Version 1.1 en, 09/2017
Hill Pro Audio.
Retain this manual for future reference
When this product is resold, the new owner should be provided with this manual.
Hill Pro Audio LTD
Unit 2, Fryor’s court, Murton, York, YO19 5UY
Tel : [phone] Email : [e-mail], www.hillproaudio.co.uk
CONTENTS

1. Safety guidelines..................................................................4
1.1. Use of loudspeakers...............................................................4
1.2.1.2. User responsibility.......................................................................4
2. HZM10...................................................................................................................5
2.1. Product description / Accessories....................5
2.2. Connections & Cabling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.3. Operation & Amplification.........................................6
2.4. Digital Signal Settings..........................................................6
2.5. Dispersion characteristics.............................................7
2.6. Technical specifications......................................................7
3. Manufacturer Responsibilities......... 5
3.1. EU conformity......................................................................................5
3.2. WEEE declaration......................................................................5
3.3. Returns & Repairs.........................................................................5
CONTENTS

Hill Pro Audio LTD. HZM10 Manual v1.1 en
2 HZM10
2.5. Dispersion characteristics
The Following graph shows a single cabinet,
horizontal dispersion isobar plot.
White : -6dB (with inset -2dB line)
Gray : -10dB
Black : less than -10dB
Fig 4 : Horizontal isobar plot
2.6. Technical Specifications
Frequency Response / 80Hz - 20kHz +/- 4dB
Maximum SPL / 136dB
Measured pink noise calculated to 1 metre
(average concert level -12dB).
Power Handling / 1,100 Watts
Specified as the maximum instantaneous
undistorted RMS power.
Configuration / Remote-powered 2 way compact line-array
loudspeaker enclosure.
Directivity / Horizontal : 140 °
Vertical : Configuration dependant
Enclosures per drive unit / Hi-Z 2000 : 2
Hi-Z 4000 : 4
Internals / Quad 5” driver [MF]
Neodymium energised compression driver. 44mm
rigid polymer diaphragm [HF]
Defined aperture diffraction HF waveguide
Connection / NL8 X1
Dimensions / Height : 160mm
Depth : 450mm
Width : 668mm
Cabinet weight / 18.2kg (40 LBS)
7

3.1. EU conformity
All Hill Pro Audio products mentioned in this manual conform to
EU regulations. This includes all versions and variants of each
product, unless the product has been modified past the technical
specifications declared within this manual.
We declare that all products mentioned within this manual are in
conformity of the respective EC directives including all applicable
amendments.
For more information on EU conformity, contact info@hillproaudio.
co.uk or visit our website.
3.2. WEEE declaration
All electronic equipment must be destroyed separately from
normal waste when its operational lifetime has ended.
Please ensure this product is disposed of according to respective
regulations or agreements. If you require more information on
correct disposal of any products within this manual then please
contact Hill Pro Audio directly.
3.3. Returns & Repairs
Hill Pro Audio offer a full repair and support system through their
distributors. If you are having issues with your product please
contact your distributor - or contact Hill Pro Audio directly for
general queries or concerns.
3 MANUFACTURER RESPONSIBILITIES
Hill Pro Audio LTD. HZM10 Manual v1.1 en
8
