Latte SoundMagic boom User manual

User Guide
SoundMagic™ boom
BC235D

1
Content
Caution
Accessories
Main Features and Specifications
Main Keys
LED Light Indicators
Power On/Off
Charging
Audio Input Operation
Bluetooth Receiver Function
Bluetooth Operation
Trouble Shooting
Contact Information

2
Thank you for choosing this beautiful, but powerful Bluetooth speaker, Latte
SoundMagic™ boom. The SoundMagic™ boom is a portable Bluetooth
speaker, which can be connected to your smart phone or any Bluetooth
enabled device via the latest Bluetooth Technology and play music
wirelessly.
Equipped with 2 powerful speakers, SoundMagic™ boom will deliver deep
and powerful, but balanced sound with Latte's digital signal processing
technology. It is small enough to carry around and powerful enough to
impress your friends at parties.
Thank you again for purchasing SoundMagic™ boom. We sincerely hope
you will enjoy SoundMagic™ boom anywhere you go.
Please read the manual carefully before use.
Caution
Do not use the product in extremely hot, cold, dusty or damp
environments.
The product contains a lithium battery and should be kept away from fire
or extremely high temperature environments to avoid explosion.
Do not disassemble, repair, or modify the product arbitrarily. These
actions will void the manufacturer's standard warranty.
Please charge the unit fully before you start using the product for the first
time.
If the product has not been in use for an extended time, please make sure
you charge the unit fully before you start using it again.
The product specifications and design may be changed without prior
notice.

3
1. Accessories
Bluetooth speaker ×1
User Guide ×1
Micro USB charge cable ×1
AUX line-in Cable (3.5mm Jack) ×1
2. Main features and Specifications
Music Play via Bluetooth V3.0+EDR
Handsfree Function (Built-in Microphone)
Φ3.5mm Audio Input Interface
RMS Output Power：2 X 2W
Speaker: 2 X 38mm/4Ω/3W
Frequency Response: 100Hz-20kHz
Supported Profiles: A2DP, AVRCP, GAVDP, AVDTP
Run Time : 8+ hours at 60% volume
Built-in 600mAh rechargeable Lithium battery
Power Source: Via Micro USB Cable. DC 5V Micro USB Power Adapter
(sold separate)
Charging Time : Approx. 3 hours
Dimensions: 6 X 2.12 X 2.2 (in)
Weight: Approx. 0.55lb

4
3. Main Keys
1: Microphone
2: Press shortly to select the previous song. Press and hold to
lower the volume.
3: In the Bluetooth search mode, press and hold for about 3 seconds
to enter the pairing mode. In the music play mode, press shortly to
pause and play music. When there is an incoming call, press shortly
to answer the call. During the call, press shortly to end the call
4: Press shortly to select the next song. Press and hold to
increase the volume.
1: LINE OUT: Connect to external speaker
2: AUX IN: Connect to external audio player (3.5mm)
3: LED light for charging indication
4: Micro USB jack for charging
5: Power Switch

5
4. LED Light Indicator
Front LED (Blue): Power on and Bluetooth not connected. The blue
light will flash.
Front LED (Blue): Power on and Bluetooth connected. The blue light
will be on.
Front LED (Red): The Aux line-in cable connected. The red light will be
on
Back LED (Red): The red light will be on when the speaker is being
charged. The red light will be off when the speaker is charged fully.
5. Power On/Off
Power On: Slide the power switch located on the back of the speaker to
"On" position.
Power Off: Slide the power switch located on the back of the speaker to
"Off" position.
6. Charging
Plug one end of the Micro USB charging cable to the computer and the other
end to the Micro USB DC 5V jack of the speaker (4) to charge the speaker.
When the speaker is being charged, the red light is on. The red light will turn
off when the speaker is fully charged.
NOTE:
When you charge the speaker while you are playing music, the sound might not be stable
because the current consumption during charging is high. If that happens, please charge the
speaker fully first and then start playing music again.
7. Audio Input Operation
When the speaker is on, please insert the AUX line-in (3.5mm) to the
speaker and into the Audio player. Once connected, the front LED indicator
light will change from blue to red.

6
8. Bluetooth Receiver Function
If you have an extra speaker without Bluetooth capability, but want to use it
wirelessly, SoundMagic boom will serve as a bluetooth Receiver. Simply
connect SoundMagic boom to your speaker via Line Out located on the back
of the speaker. Music will start playing from another speaker, not from your
SoundMagic boom.
9. Bluetooth Operation
Slide the power switch on the back of speaker to “ON” position. The blue
light will turn on and flash.
Go to "Setting" on your cell phone or Bluetooth enabled device and
activate the "Bluetooth" function. Scan for available Bluetooth devices
nearby.
When "SoundMagic boom" appears on the available Bluetooth device
list, select "SoundMagic boom" to establish connection (if asked for a
passcode, enter "0000"). When the connection is successfully
established, it produces a connection tone, and the blue light will be on
without flashing.
During the music play, the music play will stop when you receive a call.
You can do one of the following.
Answer the call: Press key shortly to answer the call
End the call: Press key shortly to end the call. The music
will resume automatically
Reject the call: Press key for about 3 seconds to reject the call
Note:
oWhen the number of the previously paired devices with the speaker exceeds the maximum
capacity (4 units), the speaker will automatically clear the first device paired in its memory.
OWhen the speaker is currently connected to a Bluetooth device and you want to pair a
different Bluetooth device, please disconnect the currently paired device before you
attempt to pair a new device.

7
10. Troubleshooting
Issue
Solutions
Bluetooth pairing
cannot be established
1. Low battery. Please charge the product fully before you start
using the speaker again
2. Please check if other phone or Bluetooth device is already
paired and connected to the speaker. The speaker can only be
connected to one Bluetooth device at a time. In this case, please
disconnected the currently connected device and pair the device
you are trying to connect again.
3. Move the speaker closer to your phone or Bluetooth device
4. Please check if your phone is connected to "SoundMagic
boom" in your phone's Bluetooth setting.
Power is on, but the
blue light is off.
Cannot pair.
The speaker has entered the sleeping mode due to prolonged
non-operation. Press and hold the pairing key on speaker to
wake it up.
The sound from the
speaker is too low or
has no sound.
1. When your phone is connected to the speaker, the Bluetooth
volume of your phone is not turned up enough or muted. Please
turn up the Bluetooth volume of your phone.
2. The output volume of your phone is too low. Please try to test it
with different Bluetooth device to check if the issue is with the
speaker or the Bluetooth device
The Bluetooth
connection range is
too short
Please check if there are any obstacles between your Bluetooth
device and the speaker.
Music plays normally,
but with interrupted
sound
1. Please check if there are any obstacles between your
Bluetooth device and the speaker.
2. Check if the distance between your Bluetooth device and the
speaker exceeds the connection range (33ft). Please shorten
the distance between your Bluetooth device and the speaker.
3. Low battery. Please charge the product fully before you start
using the speaker again
4. Please lower the volume a little bit.
Bluetooth cannot
connect to other
Bluetooth devices
If the speaker is currently paired with one Bluetooth device, you
cannot pair other Bluetooth devices. To pair another device,
disable the current connection and try to pair the new connection
with a different Bluetooth device..
Note: If the problem still cannot be solved, please contact technical support or our customer
service.

8
Contact Information
Technical Support:
Telephone: [phone] (M-F, 9 A.M - 5 P.M PST)
Email: [e-mail]
Online: support.lattezone.com
Facebook Support: www.facebook.com/lattestyle
RMA inquiry:
[e-mail] or visit support.lattezone.com
Genuine Accessories Purchase:
Please visit www.lattezone.com
Facebook: www.facebook.com/lattestyle
Twitter: www.twitter.com/lattestyle
Address:
Latte Communications Inc.
1622 Centre Pointe Dr
Milpitas CA 95035
