Beta Three T15a THUNDER Series Pro User manual

UM-T15a-20121105 ver C
T15a
User Manual
TwoWay15" Full Range
Active Speaker
THUNDER Series Pro Loudspeaker System

1
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Read the instruction first before using this product.
Pay attention to all warnings.
Obey all operating instructions.
Do not expose this product to rain or moisture.
Do not block any ventilation openings. Install according to instructions .
Do not install this product near any heat source, such as , heater, burner, or any other equipment with heat radiation .
Only use spare parts by manufacturer.
Pay attention to the safety symbol on the of the cover.
manual
Please keep this manual for future reference
Clean this equipment with a dry cloth.
manufacturer's
a
supplied the
outside
SAFETY INSTRUCTIONS
PLEASE READTHIS MANUAL FIRST
Thank you for a buyin product. Read this manual first as it will help you operate the system properly. Please keep this manual
for future reference. g
WARNING:
Thisproduct mustbeinstalledbyprofessionals.Whenusing hangingbracketsorrigging otherthanthosesuppliedwith
theproduct,pleaseensuretheycomplywiththelocalsafetycodes.
Theexclamationpoint withinan equilateral triangleis intendedtoalertyoutothe presenceof important
operatingand servicinginstructions.
ATTENTION:Don't refit the system or spare partswithoutbeingauthorizedasthiswill .voidthewarranty
WARNING: Don't (suchas candles) theequipment.placenakedflames closeto

T15a
2
CONTENT
4
5
3
3
3
3
4
5
5
6
6
6
7
CONTENT
Features
Description
Applications
Frequency Response and Impedance Curve
AMPLIFIER MODULE
INSTALLATION
Mounting Accessories
Installation Reference
INTRODUCTION
Technical Sheet
2D Dimension
TECHNICAL SPECIFICATION
Amplifier Module
THUNDER Series Pro Loudspeaker System
Product information is subject to change without
prior notification. Please visit www.elderaudio.com
for latest updates.

T15a
3
T15a
THUNDER Series Pro Loudspeaker System
Features
INTRODUCTION
Applications
Multifunctional hall
Auditorium
Church
Conference room
Small performance
TwoWay15" Full Range Active Speaker
Description
Compact lightweight design with unique appearance.
Performance enhanced with built-in DSP.
Heavy duty powered coated steel grill.
35mm SMART pole mount for vertical and 5°
downward tilt.
Integrated feet for stage monitor applications.
M8 rigging points for convenient installation.
New generation Class D amplifier, durable and reliable.

4
T15a
LINE OUT A
MIC/LINE IN A VOLUME
MODE
PWR SIG CLIP
MUSIC FLAT
LOWCUT LINE MIC
0 dB
SYSTEM
RoHS ON
OFF
POWER
LINE OUT BLINE IN B MIX OUT
S/N:
WARNING - PLEASE FOLLOW
THE INSTRUCTIONS SUPPLIED
WITH THE LOUDSPEAKER.
DO NOT SUSPEND OVERHEAD.
15" ACTIVE LOUDSPEAKER
1100W
1 2 5
3 4 6
7
8
11
9
10
12
13
14
17
16
15
THUNDER Series Pro Loudspeaker System AMPLIFIER MODULE
8. Line input signal indicator.
9. Line/microphone input A.
10. Line/microphone output A.
11. Line input B.
12. Line output B.
13. Power ON/OFF switch.
14.Volume control.
1. Music mode
2. Flat mode
3. Low cut mode
4. Power indicator
5. Signal indicator
6. Clip indicator
7. Microphone input
signalindicator.
Elder Audio Manufacture Co.,Ltd.
Made In China
15. MIX output.
16. Protection fuse. Use only fuse of the
correct amp rating.
17. Power supply input. Make sure that
the voltage is set for your country's
correct voltage.
Attention :Before changing the MODE switch, please
power the speaker off to avoid possible damage.
Rear Panel Amplifier Module
FUSE:T10AL/250V
AC INPUT:100V-120V ~ 50/60Hz
RATED POWER CONSUMPTION:250W

5
T15a
THUNDER Series Pro Loudspeaker System
5. Speaker stand application
INSTALLATION
Installation Accessories(Optional) Installation Reference
1. Speaker stand
Warning:Make sure the mounting accessories safety
factor not less than 5:1 or meet the local standard during
installation .
1.Reference A
2.Reference B
3.Reference C
4.Reference D
2. U-Bracket

6
T15a
70
80
90
100
110
130
dB
20 50 100 200 500 1k 2k 5k 10k 20k -180.0
-108.0
-36.0
36.0
108.0
180.0
Deg
THUNDER Series Pro Loudspeaker System TECHNICAL SPECIFICATION
Specification
Frequency response(-3dB):
Max. SPL:
Transducer:
Input:
Connector:
Input impedance(line):
Input level:
Input overloading level:
Wire connection:
Heat radiation:
Power cable:
45Hz-17kHz
133dB
1 15"Woofer×
XLR for input, XLR for output
20Kohm balanced input, 10Kohm unbalanced input
0 dBV (0.775V rms, 1.0V peak)Line-100Hz
Maximum input level 8V peak
pin 1: ground; pin2: signal +; pin3: signal -
Forced air-cooled drives
90°×60°
Dispersion(H×V):
1 1.7"×Compression Driver
Safety voltage range:
Amplifier power output:
Cabinet:
Handle:
Painting:
Cabinet dimension(W D H):× ×
Packing dimension :(W×D×H)
Net weight:
Gross weight:
1100W
Flying/ Mounting accessories：
Frequency response curve
8×M8 hanging point, SMART pole mount system
Polypropylene injection moulding
Rated impedance: 8 Ohms
Music mode
Flat mode
Low cut mode
32.0kg(70.4 lb)
28.7kg(63.1 lb)
460×396×780mm(18.2×15.6×30.7in)
528×480×865mm(20.8×18.9×34.1in)
Channel one (Mic/Line) balanced input
IEC 3 pin power connector
Two side, one rear
Powered coated grill
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)

460mm
[18.2in]
7
780mm
[30.7in]
396mm
[15.6in]
T15a
THUNDER Series Pro Loudspeaker System
Top view
Front view
Side view Back view
Bottom view
2D Dimension
TECHNICAL SPECIFICATION

Notes:
