HIOTH TECHNOLOGY CT-SMEO2001-ID User manual

HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
Door/Window Detector
Introduction
Door/Window Detector is used to detect the door, window or drawer whether is illegally opened
or moved. As the first line of defense of smart home security, the door/window detector can be
divided into the door switch, door sensor and door alarm.
This wireless detector is with power-saving design; when the door is closed, it does not emit radio
signals and the power consumption is only a few microamperes. When the door is opened, imme-
diately fired about 1 second wireless alarm signal, and then stop on their own, even if the door has
been opened will not be transmitting signals.
Technical Information
Solar powered without external power supply;
Achieve linkage, scene and other functions under HiotH system;
Easy installation and long service life.
CT-SMEO2001-ID

HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
Specification
1. Wireless protocol: EnOcean 868.3MHz
2. Data rate/Modulation type: 125kbps/ASK
3. Power supply: Wireless passive, Solar energy or use CR1216 battery
(CR1216 battery, about 5 years in total, for dark area usage)
4. Initial operation time in darkness: About 6 days, at least 90 hours
(In the condition of 25 ℃ , full powered and no external battery charged)
5. Solar storage time: about 2.5 minutes from exhausted status
(Under 400lux / 25 ℃ incandescent or fluorescent lamp)
6. Operating temperature: 0～40℃
7. Operating range: 30m
8. Dimension: 80mm×26mm×18mm
Operation
NETWORK ENTRY
1) Please follow the below menu order on APP to find the network join interface:
Log in > Menu bar > Device Management > Add device
1）Choose "Enocean" and the corresponding gateway as well as enter the device ID on APP,
then click "";

HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
2) Open the rear lid, press the pairing button on the back in 8 seconds.
2）Refresh the device list after prompting "Add device successfully", the device will be dis-
played.
Installation Instruction
This EnOcean wireless detector can be directly powered by solar energy as well as installed a
CR1216 battery. If you want to secure it in one place, simply paste the double-sided adhesive in
the back and attach it to the door or window. On the other hand, you can also remove the door to
re-paste in the future if necessary.
INSTALLATION
Paste
GUIDE
Pay attention to the following situations before installation, so as to prevent the abnormalities.
Do not place it:
Pairing Button
In easily damaged locations
In a stable place
Nearby magnetic objects

HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
Safety Notice
Do not place the device to work in the metal container, in case the signal is blocked.
Keep the device away from acid-base and corrosive solids, liquids, gases, to avoid damage.
Avoid overexertion during operation, to protect device from mechanical damage.
Pay attention to the using range.
