Hisense HTFF525AW Mounting instructions

USER'S OPERATION MANUAL
R E F R I G E R A T O R
MODEL HTFF525AW
HTFF525AS
MODEL HTFF525AW
HTFF525AS

1
IMPORTANT: before you install your refrigerator PLEASE CHECK FOR ANY DAMAGE
OR MARKS. If you find that the refrigerator is damaged or marked you must report this
within 7 days if you wish to claim for the damaged marks under the manufactures
warranty.
This does not affect your statutory rights.

2
1. PARTS IDENTIFICATION
1. ice tray
2. ice box
3. air outlet
4. freezer shelf
5. freezer temperature control
knob
6. temperature regulator in
refrigerator chamber
7. light cover
8. refrigerator shelf
9. adjustable refrigerator shelf
10. side plate
11. crisper cover
12. crisper
13. hole for the base grille
14. wheel
15. freezer bin
16. refrigerator bin cover
17. door switch
18. small refrigerator bin
19. lower refrigerator bin
Note: Due to unceasing modification of our products your refrigerator may be slightly different
from this Instruction Manual, but its functions and using methods remain the same.

3
Refrigerator Chamber
This compartment should be used to stove food for normal household use. Here are some guidelines to
maximize refrigeration storage.
①Area: it is suitable for storing small bottles, etc.
②Area: it is suitable for storing butter and cheese, etc.
③Area: it is suitable for storing bottled liquid and canned food, etc.
④Area: it is suitable for storing cake, cooked-food and milk products, etc.
⑤Area: it is suitable for storing sweetmeats and canned food, etc.
⑥Area: it is suitable for storing fruits, vegetable and salad, etc.
Shelf of refrigerator chamber
There are two adjustable shelves in refrigerator chamber, and they can be taken out to be cleaned.
Crisper
It is suitable for storage of fruits and vegetable.
Crisper cover
Is used for controlling the temperature of the crisper and assists the
vegetable losing moisture. The controlling knob on the cover can be used to
regulate the humidity in the drawer.

4
Door bin
It is suitable for storage of eggs, canned liquid, bottles and packed food, etc. Do not place too many heavy
items in the bin.
Temperature regulator in refrigerator
zRefrigerator not cool enough? Set the temperature controller
to suit.
zSet the controller according to the ambient temperature
in different seasons
For normal operation, set the temperature controller at the
position between “Cold” and “Colder”.
Notice: Do not place the food on the air outlet, and block
airflow.
Changing the Light Bulb
Before removing the light bulb, disconnect the electricity leading into the refrigerator at the main power
supply. Failure to do so could result in electrical shock or personal injury.
zUse the cross screw driver to take the screws out.
zRemove the light cover by pushing down the two bottom ends of
the plastic cover and draw up the cover.
zUnscrew the bulb.
zReplace with a 10 watt-refrigerator bulb that is of the same
shape and size.
zReplace the light bulb cover
zThe method of changing the light bulb on the left side and the
right side is the same.
Freezer chamber
It is for freezing and storing frozen food including ice cream.
How to use the freezer compartment
How to Make Ice
Ice cubes
1Take the tray out.
2Add water
Colder
Cold
Raise the rod a little

5
ADD WATER
water level
Fill to the level and
push it on the ice tray
Push the left Side of the
rod and move it
3When ice is formed, twist the rod according to the direction of the arrow.
Turning it to drop ice
cube into the ice box.
NOTICE:
(1) It takes about two hours to make ice.
(2) Ice bucker should not be used to make ice ,otherwise it may
crack.
CAUTION
zAvoid direct contact with ice tray as it may stick to your hands.
Temperature regulator in freezer chamber
zIn case of too much frozen food or ice making in chamber.
Please set the temperature control knob at “MAX” position.
zIn case of using the refrigerator in usual condition. Please set
the temperature regulator at “MED” position.
zIn case of a little frozen food in chamber.
Please set the temperature controller at “MIN” position.
Ice box is
inadvisable
to make ice

6
2. REVERSIBLE DOOR INSTRUCTION
The fridge has been built with the door hinges on the right. If you wish to change the opening direction,
follow the instruction below:
Note: Unplug the fridge from its electrical outlet.
Empty everything in the fridge, including shelves, food, etc.
All parts removed must be saved to reinstall the door.
1. First, remove the 3 left hinge
cover. Then remove the right
upper hinge cover, and the
three bolts, then remove the
upper hinge that hold the door
in place. Lift the upper door
and place it on a padded
surface to prevent it from
scratching.
2. Remove the two flange screw,
then remove the middle hinge
that hold the lower door in
place. Lift the lower door and
place it on a padded surface to
prevent it from scratching.
3. Remove the hinge hole cover
from the right holes as
illustrated and transfer them to
the uncover hole at the left
side.

7
4. Remove the screws that hold
the lower hinge, and transfer
them to the opposite side, and
tighten the screws.
5. Make the support reverse the
direction 180 degree, transfer
the support to the left property
position.
6. Transfer the lower door to the
property position. Secure the
door’s level, make the lower
hinge pin into the lower hole
of the door, then tighten the
bolts.
7. Make the middle hinge reverse
the direction 180 degree, then
transfer it to the left property
position. Make the middle
hinge pin in the upper hole of
the lower door, then tighten the
bolts.
8. Transfer the upper door to the
property position. Secure the
door’s level; make the middle
hinge pin into the lower hole
of the upper door.

8
9. Make the lower hinge reverse
the direction 180 degree, then
transfer it to the left property
position. Make the lower hinge
pin into the upper hole of the
door, then tighten the bolts,
tighten the screws to secure the
door.
10. Place the 3 right hinge cover at
the left position. Take another
right upper hinge from the
plastic bag that is used to cover
user manual, then set it to the
right property position.

9
3. HOW TO ASSEMBLE THE BASE GRILLE
The base grille is first placed in the refrigerator chamber. Before changing the reversible door, please take
the base grille out and then assemble the base grille by fixing two screws with a screwdriver according
to the direction of the arrowhead in the figure 1.
Figure 1
