Hitachi RAD-25RPA User manual

NO. 0531E
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
ROOM AIR CONDITIONER
INDOOR UNIT + OUTDOOR UNIT
DECEMBER 2012 Refrigeration & Air-Conditioning Division
SERVICE MANUAL
PM
REFER TO THE FOUNDATION MANUAL
TECHNICAL INFORMATION
FOR SERVICE PERSONNEL ONLY
DC INVERTER (WALL TYPE)
TYPE
MODEL
POWER SOURCE
TOTAL INPUT
TOTAL AMPERES
CAPACITY
TOTAL INPUT
TOTAL AMPERES
CAPACITY
DIMENSIONS
(mm)
NET WEIGHT
SPECIFICATIONS
CONTENTS
SPECIFICATIONS------------------------------------------------------ 5
HOW TO USE ---------------------------------------------------------- 7
CONSTRUCTION AND DIMENSIONAL DIAGRAM---------52
MAIN PARTS COMPONENT --------------------------------------55
WIRING DIAGRAM ---------------------------------------------------57
CIRCUIT DIAGRAM --------------------------------------------------59
BLOCK DIAGRAM ----------------------------------------------------67
BASIC MODE ----------------------------------------------------------69
REFRIGERATING CYCLE DIAGRAM---------------------------87
DESCRIPTION OF MAIN CIRCUIT OPERATION-----------89
SERVICE CALL Q & A-------------------------------------------- 121
PARTS LIST AND DIAGRAM------------------------------------ 150
RAD-18RPA
RAD-25RPA / RAC-25NPA
RAD-35RPA / RAC-35NPA
RAD-50RPA / RAC-50NPA
COOLING
HEATING
850
650
298
45
750
235
400
16
750
570
280
38
750
235
400
16
750
570
280
38
750
235
400
16
750
235
400
16
RAD-18RPA
RAD-25RPA
RAD-35RPA
RAD-50RPA
1 PHASE, 50Hz, 220-240V
560 (155-850)
2.56~2.35
1.80 (0.9 ~ 2.5)
6,150 (3,070-8,540)
690 (155-1,050)
3.20-2.92
2.50 (0.9 ~ 3.2)
8,540 (3,070-10,930)
1 PHASE, 50Hz, 220-240V
695 (155-1,050)
3.19~2.93
2.50 (0.9 ~ 3.0)
8,540 (3,070-10,240)
970 (155-1,400)
4.45-4.08
3.50 (0.9 ~ 5.5)
11,950 (3,070-17,070)
1 PHASE, 50Hz, 220-240V
1,240 (155-1,280)
5.69~5.22
3.50 (0.9 ~ 4.0)
11,950 (3,070-13,660)
1,700 (115-1,920)
7.81-7.15
4.80 (0.9 ~ 6.6)
16,390 (3,070-22,530)
1 PHASE, 50Hz, 220-240V
2,000 (155-2,060)
9.10~8.37
5.0 (0.9 ~ 5.6)
17,070 (3,070-19,120)
2,300 (155-2,530)
9.87-9.05
6.0 (0.9 ~ 7.5)
20,490 (3,070-25,610)
OUTDOOR UNITOUTDOOR UNITOUTDOOR UNIT INDOOR UNITINDOOR UNITINDOOR UNIT INDOOR UNIT
RAD-18RPA
RAC-50NPARAD-50RPARAC-35NPARAD-35RPARAC-25NPARAD-25RPA
(W)
(A)
(kW)
(B.T.U./h)
(W)
(A)
(kW)
(B.T.U./h)
W
H
D
(kg)
RAC-25NPA
RAC-35NPA
RAC-50NPA
WIRELESS REMOTE
CONTROLLER
(SPX-RCKA)
WIRED REMOTE
CONTROLLER
(SPX-RCDA)
OPTIONAL

– 1 –
SAFETY DURING REPAIR WORK
1. In order to disassemble and repair
the unit in question, be sure to
disconnect the power cord plug
from the power outlet before starting
the work.
2. If it is necessary to replace any parts, they should be replaced with respective genuine parts for the unit,
and the replacement must be effected in correct manner according to the instructions in the Service Manual
of the unit.
If the contacts of electrical
parts are defective, replace the
electrical parts without trying to
repair them.
3. After completion of repairs, the initial state
should be restored.
4. Lead wires should be connected and laid as
in the initial state.
5. Modification of the unit by user himself should
absolutely be prohibited.
6. Tools and measuring instruments for use in repairs or inspection should be accurately calibrated in advance.
7. In installing the unit having been repaired, be careful to prevent the occurence of any accident such as
electrical shock, leak of current, or bodily injury due to the drop of any part.
8. To check the insulation of the unit, measure the insulation resistance between the power cord plug and
grounding terminal of the unit. The insulation resistance should be 1M or more as measured by a 500V
DC megger.
9. The initial location of installation such as window, floor or the other should be checked for being and safe
enough to support the repaired unit again.
If it is found not so strong and safe, the unit should be installed at the initial location reinforced or at a new
location.
10. Any inflammable thing should never
be placed about the location of
installation.
11. Check the grounding to see whether
it is proper or not, and if it is found
improper, connect the grounding
terminal to the earth.

– 2 –
WORKING STANDARDS FOR PREVENTING BREAKAGE OF SEMICONDUCTORS
1. Scope
The standards provide for items to be generally observed in carrying and handling semiconductors in relative
manufacturers during maintenance and handling thereof. (They apply the same to handling of abnormal
goods such as rejected goods being returned).
2. Object parts
(1) Micro computer
(2) Integrated circuits (IC)
(3) Field-effect transistors (FET)
(4) P.C. boards or the like on which the parts mentioned in (1) and (2) of this paragraph are equipped.
3. Items to be observed in handling
(1) Use a conductive container for carrying and storing of parts. (Even rejected goods should be handled
in the same way).
Fig. 1. Conductive Container
(2) When any part is handled uncovered (in counting, packing and the like), the handling person must always
use himself as a body earth. (Make yourself a body earth by passing 1M earth resistance through a
ring or bracelet).
(3) Be careful not to touch the parts with your clothing when you hold a part even if a body earth is being
taken.
(4) Be sure to place a part on a metal plate with grounding.
(5) Be careful not to fail to turn off power when you repair the printed circuit board. At the same time, try
to repair the printed circuit board on a grounded metal plate.
1M
Fig. 2. Body Earth
Body earth
(Elimik conductive band)
Clip for connection with a
grounding wire
IC
A conductive polyvinyl bag IC
Conductive sponge

– 3 –
(6) Use a three wire type soldering iron including a grounding wire.
Bare copper wire (for body earth)
Working table
Resistor of 1 M (1/2W)
Earth wire
Fig. 3. Grounding of the working table
Screw stop at the screwed
part using a rag plate
Soldering iron
Grounding wire
Fig. 4. Grounding a soldering iron
Use a high insulation mode (100V, 10M or higher) when ordinary iron is to be used.
(7) In checking circuits for maintenance, inspection or some others, be careful not to have the test probes of
the measuring instrument shortcircuit a load circuit or the like.
Metal plate (of aluminium, stainless steel, etc.)
Staple

– 4 –
1. In quiet operation or stopping the running, slight flowing noise of refrigerant in the refrigerating cycle is
heard occasionally, but this noise is not abnormal for the operation.
2. When it thunders near by, it is recommend to stop the operation and to disconnect the power cord plug
from the power outlet for safety.
3. The room air conditioner does not start automatically after recovery of the electric power failure for
preventing fuse blowing. Re-press START/STOP button after 3 minutes from when unit stopped.
4. If the room air conditioner is stopped by adjusting thermostat, or missoperation, and re-start in a moment,
there is occasion that the cooling and heating operation does not start for 3 minutes, it is not abnormal
and this is the result of the operation of IC delay circuit. This IC delay circuit ensures that there is no
danger of blowing fuse or damaging parts even if operation is restarted accidentally.
5. This room air conditioner should not be used at the cooling operation when the outside temperature is
below 10°C (50°F).
6. This room air conditioner (the reverse cycle) should not be used when the outside temperature is below
–15°C (5°F).
If the reverse cycle is used under this condition, the outside heat exchanger is frosted and efficiency
falls.
7. When the outside heat exchanger is frosted, the frost is melted by operating the hot gas system, it is not
trouble that at this time fan stops and the vapour may rise from the outside heat exchanger.
!
CAUTION

– 5 –

– 6 –

– 7 –
!
SAFETY PRECAUTION
● Please read the “Safety Precaution” carefully before operating the unit to ensure correct usage of the unit.
● Pay special attention to signs of “ Warning” and “ Caution”. The “Warning” section contains matters which,
if not observed strictly, may cause death or serious injury. The “Caution” section contains matters which may result
in serious consequences if not observed properly. Please observe all instructions strictly to ensure safety.
● The sign indicate the following meanings.
● Please keep this manual after reading.
WARNING
PRECAUTIONS DURING INSTALLATION
●Do not reconstruct the unit.
Water leakage, fault, short circuit or fire may occur if you reconstruct the
unit by yourself.
●Please ask your sales agent or qualified technician for the installation of
your unit. Water leakage, short circuit or fire may occur if you install the
unit by yourself.
●Please use earth line.
Do not place the earth line near water or gas pipes, lightning-conductor, or
the earth line of telephone. Improper installation of earth line may cause
electric shock.
●A circuit breaker should be installed depending on the mounting site of the
unit. Without a circuit breaker, the danger of electric shock exists.
●Do not install near location where there is flammable gas. The outdoor unit
may catch fire if flammable gas leaks around it.
●Please ensure smooth flow of water when installing the drain hose.
CAUTION
!
!
PRECAUTIONS DURING SHIFTING OR MAINTENANCE
PRECAUTIONS DURING OPERATION
●Avoid an extended period of direct air flow for your health.
W
A
R
N
I
N
G
!
●Should abnormal situation arises (like burning smell), please stop operating the unit
and turn off the circuit breaker. Contact your agent. Fault, short circuit or fire may
occur if you continue to operate the unit under abnormal situation.
●Please contact your agent for maintenance. Improper self maintenance may cause
electric shock and fire.
●Please contact your agent if you need to remove and reinstall the unit. Electric
shock or fire may occur if you remove and reinstall the unit yourself improperly.
●If the supply cord is damaged, it must be replaced by the special cord obtainable
at authorized service/parts centers.
●Do not insert a finger, a rod or other objects into the air outlet or inlet. As
the fan is rotating at a high speed, it will cause injury. Before cleaning, be
sure to stop the operation and turn the breaker OFF.
●During thunder storm, disconnect and turn off the circuit breaker.
●Do not use any conductor as fuse wire, this could cause fatal accident.
!
Make sure to connect earth line.
Indicates the instructions that must be followed.
The sign in the figure indicates prohibition.
W
A
R
N
I
N
G
!
0531E (RAD-18RPA) 7-10 7 2/20/14 4:53 PM

– 8 –
PRECAUTIONS DURING OPERATION
●Do not attempt to operate the unit with wet hands, this could cause fatal
accident.
●When operating the unit with burning equipments, regularly ventilate the
room to avoid oxygen insufficiency.
●Do not direct the cool air coming out from the air-conditioner panel to face
household heating apparatus as this may affect the working of apparatus
such as the electric kettle, oven etc.
●Do not place plants directly under the air flow as it is bad for the plants.
●Please ensure that outdoor mounting frame is always stable, firm and
without defect. If not, the outdoor unit may collapse and cause danger.
●Do not splash or direct water to the body of the unit when cleaning it as
this may cause short circuit.
●When operating the unit with the door and windows opened, (the room humidity is always above
80%) and with the air deflector facing down or moving automatically for a long period of time,
water will condense on the air deflector and drips down occasionally. This will wet your furniture.
Therefore, do not operate under such condition for a long time.
●If the amount of heat in the room is above the cooling or heating capability of the unit (for
example: more people entering the room, using heating equipments and etc.), the preset room
temperature cannot be achieved.
● This appliance is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
●Young children should be supervised to ensure that they do not play with the appliance.
●Do not climb on the outdoor unit or put objects on it.
●Please switch off the unit and turn off the circuit breaker during cleaning,
the high-speed fan inside the unit may cause danger.
●Turn off the circuit breaker if the unit is not to be operated for a long period.
C
A
U
T
I
O
N
!
●The product shall be operated under the manufacturer specification and
not for any other intended use.
●Do not put water container (like vase) on the indoor unit to avoid water
dripping into the unit. Dripping water will damage the insulator inside the
unit and causes short-circuit.
●Do not use any aerosol or hair sprays near the indoor unit. This chemical
can adhere on heat exchanger fin and blocked the evaporation water
flow to drain pan. The water will drop on tangential fan and cause water
splashing out from indoor unit.
0531E (RAD-18RPA) 7-10 8 2/20/14 4:53 PM

– 9 –
MULTI-AIR CONDITIONER
With this multi-air conditioner, several indoor units can be connected to one outdoor unit to be driven. You
can operate the required number of indoor units.
Combination of Operations:
●You cannot operate the indoor units in
the following combinations. ●The indoor unit which is switched on first continues
to operate, but other indoor units which is switched
on later does not operate while the lamp lights.
●To re-start an indoor unit which was operated later,
stop the indoor unit which was operated first or
later and reset the type of operation, then perform
operation again.
One unit
Heating
Other unit
Cooling
Dehumidifying
Circulating (fan)
Adjusting the Number of Indoor
Units:
Decrease the number of
indoor units to be operated
especially when it is very
hot or cold or when you
want to reach the present
temperature quickly.
Stopped Indoor Units:
When an indoor unit is operated in the
cooling, heating or dehumidifying mode in
the room, the sound of refrigerant flow may
be heard from a stopped indoor unit or a
stopped indoor unit may become warm.
This is because the indoor unit returns
refrigerant to the outdoor unit to be ready
for operation.
When operation mode is selected:
●When heating operation is automatically selected for the first indoor unit, the next indoor unit will then
start to heat. Also, if cooling or dehumidifying is automatically selected for the first indoor unit, the next
indoor unit will also start to cool or dehumidify.
During automatic operation:
0531E (RAD-18RPA) 7-10 9 2/20/14 4:53 PM

– 10 –
INDOOR UNIT
NAMES AND FUNCTIONS OF EACH PART
WIDTH (mm)
750
MODEL
RAD-18RPA/RAD-25RPA/RAD-35RPA/RAD-50RPA
HEIGHT (mm)
235
DEPTH (mm)
400
MODEL NAME AND DIMENSIONS
0531E (RAD-18RPA) 7-10 10 2/20/14 4:53 PM

– 11 –
CIRCUIT BREAKER
When you do not use the room air conditioner, set the circuit breaker to “OFF”.
HOW TO USE THE AIR CONDITIONER EFFECTIVELY
1. An average room temperature setting is probably the best for you as well as
being economical.
Excessive cooling or heating is not recommended for health reasons. High electricity
bills may also result.
Close the curtains or blinds to prevent heat from flowing into or escaping the
room as well as to make more effective use of electricity.
2. At intervals, the doors and windows should be opened to let fresh air in.
Make sure the room is ventilated when operating the air
conditioner at the same time as other heating appliances.
3. Using the timer is recommended before going to sleep or going out.
4. The following must never be used for cleaning the indoor and outdoor units.
Benzine, thinner and scrub can damage plastic surfaces or coating.
Hot water above 40°C can shrink the filter and deform plastic parts.
5. Do not block the air intake and air outlet.
Do not block the air outlets and intakes of the indoor and outdoor units with
curtains or other obstacles which could degrade air conditioner performance and
cause unit failure.
CAUTION
!
Note
●The recommended temperature range for safety testing should be as below:
Cooling Heating
Minimum Maximum Minimum Maximum
Indoor Dry bulb °C 21 32 20 27
Wet bulb °C 15 23 12 19
Outdoor Dry bulb °C 21 43 2 21
Wet bulb °C 15 26 1 15
0531E (RAD-18RPA) 11-16 11 2/20/14 4:53 PM

– 12 –
Suitable Room Temperature Install curtain or blinds
Ventilation Effective Usage Of Timer
Do Not Forget To Clean The Air Filter Please Adjust Suitable Temperature
For Baby And Children
Warning
Freezing temperature
is bad for health and a
waste of electric power.
!
It is possible
to reduce heat
entering the
room through
windows.
At night, please use the “OFF or ON timer
operation mode”, together with your wake up
time in the morning. This will enable you to
enjoy a comfortable room temperature. Please
use the timer effectively.
Dusty air filter will reduce the air volume and
the cooling efficiency. To prevent from wasting
electric energy, please clean the filter every
2 weeks.
Please pay attention to the room temperature
and air flow direction when operating the unit
for baby, children and old folks who have
difficulty in movement.
Caution
Do not close the room for a long period of
time. Occasionally open the door and windows
to allow the
entrance of
fresh air.
!
THE IDEAL WAYS OF OPERATION
0531E (RAD-18RPA) 11-16 12 2/20/14 4:53 PM

– 13 –
FOR USER’S INFORMATION
The Air Conditioner And The Heat Source In The Room
Not Operating For A Long Time
When Lightning Occurs
Caution
If the amount of heat in the room is above the cooling
capability of the air conditioner (for example: more
people entering the room, using heating equipments
and etc.), the preset room temperature cannot be
achieved.
!
When the indoor unit is not to be used for a long
period of time, please switch off the power from the
mains. If the power from mains remains “ON”, the
indoor unit still consumes about 10W in the operation
control circuit even if it is in “OFF” mode.
Warning
To protect the whole unit during lightning, please
stop operating the unit and remove the plug from
the socket.
!
Interference From Electrical Products
Caution
To avoid noise interference, please place the indoor
unit and its remote controller at least 1m away from
electrical products.
!
0531E (RAD-18RPA) 11-16 13 2/20/14 4:53 PM

– 14 –
MAINTENANCE
●Before cleaning, stop unit operation with the remote controller and turn off the circuit breaker.
!
WARNING
1Pull the filter toward the center until it detached from the hold-
ers. Then take it out from holders
(refer to diagram).
●Do not expose the unit to water as it may cause an electric shock.
●For cleaning inside the air conditioner, consult your sales agent.
●Avoid using detergent when cleaning the heat exchanger of the indoor unit. Unit failure may result.
●When cleaning the heat exchanger with a vacuum cleaner, make sure to wear gloves so as not to injure
your hands on the heat exchanger fins.
!
CAUTION
1. AIR FILTER
Clean the air filter, as it removes dust inside the room. Be sure to clean the
filter once every two weeks so as not to consume electricity unnecessarily.
2Remove dust from the filter using a vacuum cleaner. If there
is too much dust, use neutral detergent. After using neutral
detergent, wash with clean water and dry in the shade.
3Install the filters.
Gently insert back the filter into the holders.
!CAUTION
●Do not wash with hot water at more than 40°C. The filter may shrink.
●When washing it, shake off moisture completely and dry it in the shade; do not expose it directly to
the sun. The filter may shrink.
●Do not operate the air conditioner with the filter removed. Dust may enter the air conditioner and
cause trouble.
0531E (RAD-18RPA) 11-16 14 2/20/14 4:53 PM

– 15 –
1
2
3
REGULAR INSPECTION
PLEASE CHECK THE FOLLOWING POINTS BY QUALIFIED SERVICE PERSONAL EITHER
EVERY HALF YEARLY OR YEARLY. CONTACT YOUR SALES AGENT OR SERVICE SHOP.
Is the earth line disconnected or broken?
Is the mounting frame seriously affected by rust and is the
outdoor unit tilted or unstable?
Is the plug of power line firmly plugged into the socket?
(Please ensure no loose contact between them).
AFTER SALE SERVICE AND WARRANTY
WHEN ASKING FOR SERVICE, CHECK THE FOLLOWING POINTS.
When it does not operate
●Is the fuse all right?
●Is the voltage extremely high or low?
●Is the circuit breaker “ON”?
●Was the air filter cleaned?
●Does sunlight fall directly on the outdoor unit?
●Is the air flow of the outdoor unit obstructed?
●Are the doors or windows opened, or is there any source
of heat in the room?
●Is the set temperature suitable?
CONDITION CHECK THE FOLLOWING POINTS
Notes
●In quiet or stop operation, the following phenomena may occassionally occur,
but they are not abnormal for the operation.
(1) Slight flowing noise of refrigerant in the refrigerating cycle.
(2) Slight rubbing noise from the fan casing which is cooled and then gradually
warmed as operation stops.
●The odor will possibly be emitted from the room air conditioner because the
various odor, emitted by smoke, foodstuffs, cosmetics and so on, sticks to it. So
the air filter and the evaporator regularly must be cleaned to reduce the odor.
●Please contact your sales agent immediately if the air conditioner still fails to operate normally after the above
inspections. Inform your agent of the model of your unit, production number, date of installation. Please also
inform him regarding the fault.
●Power supply shall be connected at the rated voltage, otherwise the unit will be broken or could not reach
the specified capacity.
When it does not cool well
When it does not hot well
0531E (RAD-18RPA) 11-16 15 2/20/14 4:53 PM

– 16 –
MEMO
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
Please note:
On switching on the equipment, particularly when the room light is dimmed, a slight brightness fluctuation
may occur. This is of no consequence.
The conditions of the local Power Supply Companies are to be observed.
0531E (RAD-18RPA) 11-16 16 2/20/14 4:53 PM

– 17 –
PRECAUTIONS FOR USE
●In case of power failure happen, Wired Remote Controller may not show current operating mode when power
comes back. However unit will continue to operate at previous setting mode.
●Some features of Wireless Remote Controller are not available when use Wired Remote Controller as mentioned
below:
●Powerful
●Information
●One touch clean
●Leave home
●Powerful
●Information
●One touch clean
●Leave home
●Powerful
●Information
●One touch clean
●Leave home
●Powerful
●Information
●One touch clean
●Leave home
●Powerful
●Information
●One touch clean
●Leave home
Standard Wireless Remote Controller Features not available on Wired Remote Controller
RAR-5E1
RAR-5E2
RAR-5E3
RAR-5E4
RAR-5E5
●Silent
●Weekly timer
●Auto swing (vertical)
●Auto swing (horizontal)
●Silent
●Weekly timer
●Auto swing (vertical)
●Silent
●Weekly timer
●Auto swing (vertical)
●Air purify
●Silent
●Weekly timer
●Auto swing (vertical)
●Extended
●Silent
●Weekly timer

– 18 –
NAMES AND FUNCTIONS OF REMOTE CONTROLLER
■This controls the operation function and timer setting of the room air conditioner.
Precautions for Use
●Do not put the remote controller in the following places.
●Under direct sunlight.
●In the vicinity of a heater.
●Handle the remote controller carefully. Do not drop it on the floor, and protect it from water.
●Once the outdoor unit stops, it will not restart for about 3 minutes (unless you turn the power switch
off and on or unplug the power cord and plug it in again).
This is to protect the device and does not indicate a failure.
●If you press the MODE SELECTOR button during operation, the device may stop for about 3 minutes
for protection.
OPERATION LAMP
START/STOP Button
Press this button to start operation.
Press it again to stop operation.
Transmission Sign
The transmission sign blinks
when a signal has been
send.
RESET SWITCH
ROOM TEMPERATURE
Setting Button
Room temperature setting.
Value will change quicker
when keep pressing.
CANCEL Button
Cancel timer reservation.
FAN SPEED Button
This determines the fan
speed. Every time you press
this button, the intensity of
circulation will change from
(AUTO) to (HIGH)
to (MED) to (LOW)
to (SILENT)(This button
allows selecting the optimal
or preferred fan speed for
each operation mode).
MODE SELECTOR Button
Use this button to select the
operating mode. Every time you
press it, the mode will change
from (AUTO) to (HEAT)
to (DEHUMIDIFY) and to
(COOL) cyclically.
SLEEP Button
Use this button to set the sleep
timer. ( Page 25)
SET Button
Timer setting reservation.
OFF TIMER Button
Select the turn OFF timer.
ON TIMER Button
Select the turn ON timer.

– 19 –
AUTOMATIC OPERATION
The device will automatically determine the mode of operation, HEAT or COOL depending on the current
room temperature. The selected mode of operation will change when the room temperature varies.
■As the settings are stored in the memory in the remote controller,
you only have to press the (START/STOP) button next time.
Press the MODE selector button so that the display indicates
the (AUTO) mode of operation.
● When AUTO has been selected, the device will automatically
determine the mode of operation, HEAT or COOL depending
on the current room temperature. However the mode of
operation will not change when indoor unit is connected
to multi type outdoor unit.
●If the mode automatically selected by the unit is not
satisfactory, manually change the mode setting (HEAT,
DEHUMIDIFY or COOL).
1
START
STOP
VARIOUS FUNCTIONS
■Auto Restart Control
●If there is a power failure, operation will be automatically restarted when the power is resumed with
previous operation mode.
(As the operation is not stopped by remote controller.)
●If you intend not to continue the operation when the power is resumed, switch off the power supply.
When you switch on the circuit breaker, the operation will be automatically restarted with previous operation
mode.
Note:1. If you do not require Auto Restart Control, please consult your sales agent.
2. Auto Restart Control is not available when Timer or Sleep Timer mode is set.
Press the (FAN SPEED) button to select AUTO, HIGH, MED,
LOW or SILENT.
Press the (START/STOP) button.
Operation starts.
Press the button again to stop operation.
2
Set the desired FAN SPEED with the (FAN SPEED) button (the
display indicates the setting).
(AUTO) (HIGH) (MED)
(SILENT) (LOW)
