Hitachi DZMV100A User manual

SERVICE MANUAL
DZ-MV100A
TK No. 7006E
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
DVD VIDEO CAMERA/RECORDER
2000December Digital Media Products Division,Tokai

Microsoft, MS, MS-DOS, Windows and Windows NT are registered trademarks of Microsoft Corporation.
Pentium and Celeron are registered trademarks of Intel Corporation.
Manufactured under license from Dolby Laboratories.
"Dolby" and double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works. (C) 1992-2000 Dolby Laboratories Inc. All rights reserved.
IBM is registered trademarks of International Business Machines Corporations.
Other company names and product names listed are trademarks or brand names belonging to each company.
CAUTION-1
CAUTION (COLOR LCD)
LCD display; the liquid crystal display (LCD) panel is mode by highly precise technology.
More than 99.99% of its picture elements (pixels) are effective, but some (less than 0.01%) may appear as colored
bright dots. This mode not indicate a fault as the LCD panel stretches the limits of current technology.
Many electrical and mechanical parts have special safety-related characteristics. These are often not evident from visual
inspection nor can the protection afforded by them necessarily be obtained by using replacement components rated for a
higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in this
Service Manual. Electrical components having such features are identified by marking with a on the schematics and the
parts list in this Service Manual. The use of a substitute replacement component which does not have the same safety
characteristics as the HITACHI recommended replacement one, shown in the parts list in this Service Manual, may create
shock, fire, or other hazards. Product safety is continuously under review and new instructions are issued from time to time.
For the latest information, always consult the current HITACHI Service Manual. A subscription to, or additional copies for,
HITACHI Service Manual may be obtained at a nominal charge from HITACHI SALES CORPORATION.
PRODUCT SAFETY NOTICE
!
CLASS 1
LASER PROCTECT
CAUTION
This product contains a laser diode of
higher class than 1. To ensure contin-
ued safety, do not remove any covers
or attempt to gain access to the in-
side of the product. Refer all servicing
to qualified personnel.
CAUTION BLE
VISI
AND
INVI SIBLE
LASER RADIATION
WHEN
OPEN.
DO NOT
STARE INTO BEAM.
Contents included:
ANA and DIG circuit board diagrams included are for reference during troubleshooting.
This manual does not include the schematic diagrams of ANA and DIG circuit boards, since these boards must be
replaced in units of board and their components are not assigned as service parts.
SHD, RAM2LD and PHD circuit board diagrams included are for reference during troubleshooting.
This manual does not include the schematic diagrams of SHD, RAM2LD and PHD circuit boards, since these
boards are included in the mechanism unit and they or their components are not assigned as service parts.

CAUTION-2
Notes When Using Service Manual
The following shows the contents to be noted when using service manual:
1. Value units used in parts list
This table shows locations of each part on circuit board
diagrams. The locations are indicated using the guide
scales on the external lines of diagrams.
1) One diagram indicated for each board
The values, dielectric strength (power capacitance) and
tolerances of the resistors (excluding variable resistors)
and capacitors are indicated in the schematic diagrams
using abbreviations.
[Resistors]
Certain symbols are indicated below for value units of
resistors, capacitors and coils in parts list. When you read
them note the following regular indications:
Indication in list Regular indication
KOHM ........................................... k
UF ................................................ µF
PF ................................................ pF
UH ................................................ µH
MH ............................................... mH
Parts
Resistor
Capacitor
Coil
2) Two diagrams indicated for each board
2. Values in schematic diagrams
Item
Value
Tolerance
Power
capacitance
Indication
No indication ...................................
K................................................... k
M.................................................. M
No indication ............................. ±5%
(All tolerances other than ±5% are
indicated in schematic diagrams)
No indication ............................ 1/8W
(1/16W for leadless resistors without
indication)
All capacitances other than the above
are indicated in schematic diagrams.
[Capacitors]
Item
Value
Dielectric
strength
Indication
No indication ................................. µF
P................................................... pF
No indication .............................. 50V
(All dielectric strengths other than 50V
are indicated in schematic diagrams)
Item
Value
Indication
µ.................................................... µH
m.................................................. mH
[Coils]
3. Identifications of sides A/B in
circuit board diagrams
1) Board having a pattern on one side and parts on both
sides.
Side A: Shows discrete parts, viewed from the pattern
side.
Side B: Shows leadless parts, viewed from the
pattern side.
2) Board having patterns on both sides and parts on
both sides.
Side A: Shows parts and patterns which can be seen
when the case is opened.
Side B: Shows parts and the pattern on the back of
side A.
4. Table for indexing locations of parts
Parts
Location
2 A
Symbol
No.
IC
IC1201
Type of part
Zone "A" on board diagram
Circuit No. Zone "2" on board diagram
Parts
Location
A - 2 A
Symbol
No.
IC
IC1201
Zone "2" on board
diagram
A: Shows side A
B: Shows side B
Zone "A" on board
diagram
Type of
part
Circuit No.

CHAPTER 1 GENERAL INFORMATION
1. Specifications ...................................................... E1-1
2. Information on DVD-RAM Discs ......................... E1-2
2.1 Comparison of DVD-RAM Discs .................. E1-2
2.2 DVD Video Recording Standard ................. E1-2
2.3 Comparison between
DVD-RAM and DVD-RW/R .......................... E1-3
2.4 Available DVD-RAM Discs ........................... E1-3
2.5 Initializing (formatting) DVD-RAM Discs ...... E1-4
2.6 Handling DVD-RAM Disc ............................. E1-4
2.7 Removing DVD-RAM Disc from Cartridge ... E1-4
3. Subsidiary Functions for Servicing ..................... E1-6
3.1 Forced disc formatting.................................. E1-6
3.2 Still (JPEG) file operation ............................. E1-6
3.3 Firmware version display ............................. E1-7
3.4 Error code display ........................................ E1-7
3.5 Playback file detailed information display .... E1-8
3.6 Deleting information control (RX) file ........... E1-8
4. Explanation of Trouble Messages ...................... E1-9
5. Troubleshooting Guide of DVD Video
Camera/recorder ................................................. E1-13
6. Updating Firmware.............................................. E1-16
6.1 Firmware programs ...................................... E1-16
6.2 How to update .............................................. E1-16
7. Service Manual Abbreviation List ....................... E1-17
8. Fro the Battery .................................................... E1-19
9. Extract from the Instruction Manual .................... E1-20
Cleaning ....................................................... E1-20
Names of Parts ............................................ E1-20
System Reset ............................................... E1-22
Setting Up the Battery .................................. E1-23
Setting Date and Time ................................. E1-24
Initializing DVD-RAM Disc............................ E1-25
Trouble Message ......................................... E1-26
CHAPTER 2 DISASSEMBLY
1. Parts Location ..................................................... E2-1
2. Before Starting Disassembly .............................. E2-3
3. Disassembly Procedure ...................................... E2-5
3.1 Top Cover, R-Block, L-Block ........................ E2-5
3.2 LCD-U Case, LCD Block, Front Block,
RUB Sheet ................................................... E2-6
3.3 Jack Cover, Flash Unit, JKR Circuit Board,
JKF Circuit Board, Microphone, IR Filter,
Lens Hood, Front Case ................................ E2-8
3.4 EVF Block, Rear Cover, Power Terminal ..... E2-9
3.5 ANA Circuit Board, Camera Block, DIG
Circuit Board, LSP Shield, Side Case-L....... E2-10
3.6 Disc Cover, Switch Unit................................ E2-10
3.7 Link Bracket R, Link Bracket L, Loader,
Mechanism Unit ........................................... E2-12
3.8 Lock Unit, Side Case-R ................................ E2-14
3.9 GYR Circuit Board, SEN Circuit Board,
Sensor, Lens ................................................ E2-14
CONTENTS-1
CONTENTS
3.10 Eye Control, EVF-F Case, Plate-F,
EVF-B Case, EVF LCD, EVF Backlight,
EBL Circuit Board......................................... E2-16
3.11 B/W LCD, LCD Power Unit, LCD Frame,
Backlight, Color LCD, LCD-B Case ............. E2-17
4. Disassembly When Trouble Has Occurred......... E2-18
4.1 Cleaning EVF Screen
(Removing Eye Control) ............................... E2-18
4.2 Removing DVD-RAM Disc ........................... E2-18
5. Information on Installation Position of
Shields, etc. ........................................................ E2-21
5.1 Side Case-L ................................................. E2-21
5.2 DIG Circuit Board ......................................... E2-21
5.3 ANA Circuit Board ........................................ E2-22
5.4 Power Terminal ............................................ E2-22
5.5 Front Block ................................................... E2-22
5.6 Mechanism Unit ........................................... E2-23
5.7 Miscellaneous .............................................. E2-24
CHAPTER 3 ELECTRIC CIRCUIT
ADJUSTMENT
1. Test Equipment/Jigs Necessary for
Adjustment ......................................................... E3-1
1.1 List of equipment and jigs ............................ E3-1
1.2 List of charts for adjustment ......................... E3-1
1.3 Test equipment, etc...................................... E3-1
2. Before Starting Adjustment ................................. E3-2
2.1 Connection for adjustment ........................... E3-2
2.2 Notes ............................................................ E3-2
2.3 Setting video camera/recorder ..................... E3-2
2.4 Setting test equipment ................................. E3-3
3. List of Adjustment Item ...................................... E3-4
4. Starting Adjustment Program (MAP: Manual
Adjustment Program) .......................................... E3-5
5. Adjustment Procedure ........................................ E3-6
5.1 Data Initialize................................................ E3-6
(1) Data Initialize................................................ E3-6
5.2 Adjustment ................................................... E3-6
(1) Sampling Pulse Adjustment ......................... E3-7
(2) Auto Iris Control Adjustment ........................ E3-7
(3) Shutter Adjustment....................................... E3-8
(4) White Balance Adjustment ........................... E3-10
(5) Chroma Gain Adjustment ............................. E3-10
5.3 Autofocus ..................................................... E3-12
(1) Zoom Trace Adjustment ............................... E3-12
(2) AF Noise Level Adjustment.......................... E3-12
5.4 Stabilizer ...................................................... E3-13
(1) Stabilizer Adjustment ................................... E3-13
5.5 Spot Noise .................................................... E3-13
(1) Spot Noise Adjustment................................. E3-13
6. Error Message .................................................... E3-15
6.1 Error Message of Adjustment....................... E3-15
6.2 Error Message of Autofocus ........................ E3-16
6.3 Error Message of Stabilize ........................... E3-16
6.4 Error Message of Spot Noise ....................... E3-16

CONTENTS-2
CHAPTER 4 EXPLODED VIEW
CABINET-1 ............................................................... 4-1
CABINET-2 ............................................................... 4-2
ELECTRONIC VIEWFINDER (EVF) ......................... 4-3
LCD ........................................................................... 4-3
CAMERA .................................................................. 4-4
ACCESSORIES ........................................................ 4-4
CHAPTER 5 REPLACEMENT
PARTS LIST
1. MECHANICAL PARTS LIST ............................... 5-1
2. ELECTRICAL PARTS LIST ................................ 5-2
CHAPTER 6 SCHEMATIC, CIRCUIT BOARD
AND BLOCK DIAGRAMS
SCHEMATIC DIAGRAMS
INTERNAL WIRING DIAGRAM ............................ 6-1
SENSOR [SEN] ..................................................... 6-3
GYRO [GYR] ......................................................... 6-4
EVF BACK LIGHT [EBL] ....................................... 6-5
JACK-F [JKF] ........................................................ 6-6
JACK-R [JKR] ........................................................ 6-7
CIRCUIT BOARD DIAGRAMS
SEN ....................................................................... 6-9
GYR ....................................................................... 6-9
EBL ........................................................................ 6-10
ANA [SIDE-A] (*1) ................................................. 6-11
ANA [SIDE-B] (*1) ................................................. 6-13
DIG [SIDE-A] (*1) .................................................. 6-15
DIG [SIDE-B] (*1) .................................................. 6-17
JKF ........................................................................ 6-19
JKR ........................................................................ 6-19
SHD (*2) ................................................................ 6-20
RAM2LD (*2) ......................................................... 6-20
PHD (*2) ................................................................ 6-21
BLOCK DIAGRAMS
AV PROCESS SECTION ...................................... 6-23
8cm DVD-RAM DRIVE SECTION ......................... 6-24
*1: The circuit board diagrams included are for reference
during troubleshooting.
This manual does not include the schematic diagrams
of ANA and DIG circuit boards, since these boards
must be replaced in units of board and their
components are not assigned as service parts.
*2: The circuit board diagrams included are for reference
during troubleshooting.
This manual does not include the schematic diagrams
of SHD, RAM2LD and PHD circuit boards, since these
boards are included in the mechanism unit and they or
their components are not assigned as service parts.

E1 - 1
CHAPTER 1 GENERAL INFORMATION
1. Specification
Power requirements 7.2 V DC
CCD (number of effective pixels) 1/4-inch interlaced, total number of pixels: approx.
1,000,000 (movie: approx. 720,000: still: approx.
1,000,000)
Lens F2.0 - 2.7, f = 3/16" - 1-15/16" (4.1 - 49.2 mm)
Filter diameter: 1-7/16" (37 mm)
Focal length (converted to 35 mm camera) Movie: approx. 1-3/4" - 20-13/16" (44 - 528 mm)
Still: approx. 1-1/2" - 17-15/16" (38 - 456 mm)
Focus Auto/Manual
Zoom Optical 12 ×, 48 × with digital zoom added
Required minimum illumination 8 lx
Viewfinder 0.44-inch color TFT (approx. 180,000 pixels)
LCD monitor 3.5-inch color TFT (approx. 200,000 pixels)
Electronic image stabilizer Electronic type
Shutter speed 1/60 - 1/4000 second (movie)
Flash (AUTO/ON/OFF) Still recording only
Self-timer recording Still recording only
External microphone jack 3.5 mm Ø stereo minijack: Recommended microphone
impedance 600 ohm - 1 k ohm
Recording mode Movie (with sound)
Still
Maximum recordable time Movie: approx. 60 minutes (FINE)*
(on both sides of disc) approx. 120 minutes (STND)*
Maximum number of recordable stills 1998*
(on both sides of disc)
Recording format Movie: Conforming to DVD video recording standard
(MPEG audio)
Still: Simultaneous recording, conforming to DVD video
recording standard and JPEG (1,280 × 960
pixels)
Audio playback format MPEG, Dolby AC3
Recording medium 8 cm DVD-RAM disc (conforming to DVD-RAM Book 2.1)
Jacks Video/Audio input/output × 1, S-video input/output × 1,
External microphone input × 1, Digital input/output
terminal (connected to PC USB jack) × 1
Battery system Lithium-ion
Power consumption approx. 6.5 W when recording with LCD monitor off
Dimensions approx. 3-1/16" × 4-1/4" × 6-9/16" (78 × 108 × 166 mm)
(W × H × D) (excluding hood and projections)
Operating temperature 32 - 104 °F (0 - 40 °C) (less than 80 %).
32 - 95 °F (0 - 35 °C) when connected to PC.
Storage temperature -4 - 140 °F (-20 - 60 °C)
Weight 1.83 lbs (approx. 830 g) (without battery or disc)
Total weight when recording 2.18 lbs (approx. 990 g) (when using BP16 battery)
Provided accessories AC adapter/charge, battery, DC power cable, AV input/
output cable, infrared remote control, 2 "AA" batteries for
remote control, lens cap string, shoulder strap, power
cable, 2 ferrite cores, DVD-RAM disc, PC connection
cable, PC connection software CD-ROM
* This number will decrease if stills and movies are recorded on the same disc.
AC Adapter/Charger DZ-ACP1
Power requirements 100 - 240 V AC, 50/60 Hz
Input capacity 40 VA (at 100 V)
DC output 8.0 V, 2.0 A
Charge output 8.4 V, 2.2 A
Weight approx. 0.61 lbs (approx. 280 g ) (AC adapter/charger)
External dimensions (W × H × D) approx. 2-9/16" × 1-15/16" × 4-1/8" (65 × 50 × 105 mm)
Ambient temperature 32 - 104 °F (0 - 40 °C)
Allowable relative humidity 20 - 85 %

E1 - 2
2. Information on DVD-RAM Discs
2.1 Comparison of DVD-RAM Discs
The 4.7GB DVD-RAM is standardized as Version 2.0 with respect to the 2.6GB DVD-RAM (Version 1.0), and the major
differences are as follows:
The 8-cm DVD-RAM media is standardized as Version 2.1: It can be used with disc removed from cartridge as well as in
cartridge in the same way as with 12-cm DVD-RAM Type 2.
Notes: 1) In addition to the above, the 4.7GB DVD-RAM has a new defect control system to handle real time recording of
AV data.
2) Among the rewritable DVD standards, only the 4.7GB DVD-RAM is standardized for the 8cm size.
2.2 DVD Video Recording Standard
The DVD video recording standard is a newly established common standard to record video on DVD in real time. The DVD
video standard has already been used for read-only DVD, but it was previously exclusively for playback, so the following
were difficult:
Recording in real time
Addition or deletion of video/audio
Editing
The DVD video standard was reviewed to establish a DVD video recording standard which defines the devices for achieving
the characteristics inherent in disc, starting with the following, in addition to the capabilities of real-time recording and editing
on rewritable DVD media:
Diameter of media
Capacity (per side)
Laser wavelength (NA)
Recording format
Track format
Track pitch
Date recording bit length
Sector size
Modulation scheme
Error correction format
Recording rate
8 cm
1.46 GB
650 nm (0.6)
Mark edge recording
Wobble land groove
0.615 µm
0.28 µm
2048 bytes
8/16 modulation
22.16 Mbps
12 cm
4.7 GB
2.6 GB DVD-RAM
(Version 1.0)
2.6 GB
0.74 µm
0.41 µm
11.08 Mbps
RSPC (Reed Solomon Product Coding)
DVD-ROM
(reference)
4.7/8.5 GB
650 nm (0.6)
(playback only)
(Playback only)
Pit
0.27 µm
(Playback only)
4.7 GB (1.46 GB) DVD-RAM
(Version 2.1 & 2.0)

E1 - 3
2.3 Comparison between DVD-RAM and DVD-RW/R
In addition to DVD-RAM in rewritable DVDs, DVD-RW and DVD-R are also available.
The following table shows the differences in major specifications (Note 1) between these discs:
(As of March 2000)
Video
Audio
Sub-picture
Multiplexing type
Coding format
Number of streams
Aspect ratio
Number of pixels (NTSC)
Still image data structure
Coding format
Number of streams
Number of channels per
stream
Coding format
Number of streams
Display control command
Data for control (Navigation pack)
DVD Video Recording
MPEG1/MPEG2
1 stream only
4 : 3 / 16 : 9
720 × 480, 704 × 480,
544 × 480, 480 × 480,
352 × 480, 352 × 240
I picture of one still
Up to 2
Mono/Stereo/Dual Mono/Multi
(up to 71 channels)
Run-length encoding
1 only
Sub-set of that at right
None
MPEG2 program stream
MPEG/Dolby AC3/Linear PCM
DVD Video (reference)
720 × 480, 704 × 480,
352 × 480, 352 × 240
Not defined
Up to 8
Mono/Stereo /Multi (up to 71
channels)
Up to 32
Full set
Provided (essential)
(As of April 2000,
investigated by Hitachi)
Capacity
(per side/both sides)
Laser wavelength (NA)
Write rate
Rewritable use
Cartridge
Video recording standard
8-cm standard
Major applications
DVD-RAM (4.7GB)
4.7 GB/9.4 GB
650 nm (0.6)
2X
at least 100,000 times
Provided (Note 2)
Conforming
Provided
For PC/AV
DVD-RW (4.7GB)
4.7 GB/-----
635 nm/650 nm (0.6)
1X
at least 1,000 times
None
Conforming
None
For AV
DVD-R (4.7GB)
4.7 GB/-----
635 nm (0.6)
1X
only once
None
Non-conforming
Provided
For authoring software
Note 1: The differences between media are shown: The drives of Hitachi and other companies and applied products also
have individual specifications.
Note 2: There are two types of DVD-RAM: Disc used only while it is in cartridge (Type 1) and disc can be removed from
cartridge (Type2).
2.4 Available DVD- RAM Discs
There are two types of DVD-RAM disc: for video camera and for PCs. Be sure to use 8 cm DVD-RAM discs (1.4 GB on one
side, 2.8 GB on both sides) noted for video camera use (for AV) with this DVD video camera/recorder.
Most discs for video camera use (for AV) can be removed from their cartridges for recording. Some discs for PC, however,
cannot be removed from their cartridges, and some can be removed but recording cannot be made on them. For details, read
the instruction sheet provided with discs or consult the disc maker.
Examples of discs that cannot be used on this DVD video camera/recorder:
8 cm DVD-RAM discs for PC, CD, DVD-ROM, DVD-Video, MO, MD, iD, floppy disks,etc.

E1 - 4
2.5 Initializing (formatting) DVD- RAM Discs
This DVD video camera/recorder can use only DVD-RAM discs for AV formatted in accordance with the UDF 2.01 file system:
No recording can be made on an unformatted disc.
2.6 Handling DVD- RAM Disc
When the DVD-RAM disc is used for an extended period of time, the temperature will increase because of the heat
inside the DVD video camera/recorder: Be careful when removing the disc.
The DVD-RAM disc is a very delicate recording medium. Leave the disc in the cartridge when using it in this DVD
video camera/recorder.
Do not remove the disc from the cartridge unless needed, and do not open the shutter of cartridge.
Be sure not to touch disc surfaces.
Take great care so as not to scratch or stain disc.
Be careful not to allow the cartridge with disc to fall.
Be careful not to allow condensation.
To store disc cartridge, insert it in plastic case provided.
Do not place the disc cartridge in following places:
Where exposed to direct sunlight for a long time.
Where the humidity is high, or in dusty place.
Where exposed to heat from heater, etc.
Where there may be condensation.
2.7 Removing DVD- RAM Disc from Cartridge
The DVD-RAM disc used with this DVD video camera/recorder can be removed from the cartridge and used with DVD-RAM
drives, DVD players and DVD recorders that are compatible with 8 cm DVD-RAM discs. Refer to the disc instruction sheet for
details on how to remove disc from cartridge.
Perform the following to remove the disc provided:
Removing the disc
1) Release the lock pins of cartridge.
The two lock pins are at the bottom left
corners of sides A and B.
Use a fine tipped pen to slide the lock
pin in the direction of arrow (1)
and then turn it in the direction of arrow
(2) to release it.
2) While pushing the release levers from both
sides inward, hold the center of disc tray
and pull it out to the front.
Replacing the disc in cartridge
1) Insert the disc into cartridge.
2) Fit in the disc tray until a click is heard.
(1)
(2)
Indication of side
S
I
D
E
A
1
2

E1 - 5
Tip:
The side that will be recorded when SIDE A of disc faces the hand strap is the
opposite side to the "SIDE A" indication.
Cautions:
Most generally available 8 cm DVD- RAM discs can be removed from cartridges
if they are for video cameras; However, before removing disc from cartridge,
read the instruction sheet provided with the disc or consult the disc maker.
Take care with the following when handling the removed disc:
Be sure not to touch disc surfaces.
Be careful not to drop the disc removed from cartridge.
Be sure not to bend the disc.
Do not leave the disc outside the cartridge.
Do not subject the disc to heat.
Do not write on disc with a ball- point pen or pencil.
Be sure not to wipe disc surfaces with thinner,water or anti- static agent.
Use dry, soft cloth to lightly wipe off dust or dirt that adheres to the disc. Never use solvents to clean the disc.
If the disc is removed from cartridge and the data stored by this DVD video camera/recorder is rewritten on devices other
than this DVD video camera/recorder,recording or playback may not be normal,or Disc Navigation may not operate
normally,when the disc replaced in cartridge is used on this DVD video camera/recorder again.
The cartridge protects the surfaces of disc on which high- density recording is possible.Once removed from cartridge, the
disc can be replaced in the cartridge and used with this DVD video camera/recorder, but be sure to observe the
following:
Before replacing the disc in cartridge, make sure that disc surfaces are not scratched,and that no dirt or fingerprint
adheres to them.
Do not record,edit or delete on the disc when scratches, dirt or fingerprints cannot be removed even if disc surface is
cleaned.
When replacing the disc in cartridge, insert it until a click is heard.
Writing similar to recording is be performed even with simple editing or deletion. Make sure that editing or deletion has
been securely performed with the disc removed from cartridge.
Write-protect tabs
The DVD-RAM disc cartridge has write-protect tabs to prevent overwriting
on recorded data. Make sure that the write-protect tab is set to the side
where recording is possible.
Cautions:
Dust, scratches or dirt on the disc surface may cause block noise
because of the principle of disc recording. This does not indicate a fault.
Be careful when handling the disc so that no dirt or fingerprints adheres
to the disc.
This DVD video camera/recorder has a function that allows recording,
avoiding portions of the disc with dust, scratches or dirt [The DVD video
camera/recorder sets to pause ( ) status and automatically restarts
recording ( REC )] .
This will interrupt recording for several seconds to several minutes, and
multiple thumbnails will be created in one recording as shown in the
figure. In this case, the recordable time will decrease.
A
side A
indication of
disc
Surface to
be recorded
Laser
SideBSideA
Recording not possible
Recording possible

E1 - 6
3. Subsidiary Functions for Servicing
Caution: This information deals with functions exclusively used for servicing (not disclosed to persons other than service
engineers): Do not disclose the information to customers.
Activate the functions with power on and LCD monitor open (LCD on-screen information display).
3.1 Forced disc formatting
Purpose:
To initialize without starting Disc Navigation
Pertinent case:
It is desired to initialize the disc, but the data on disc has been destroyed (without physical damage to disc) and Disc
Navigation will not start.
Operation procedure:
1) Insert the disc to be formatted.
2) Hold down the following 3 buttons simultaneously for at least 3 seconds:
SHIFT button
CANCEL button
LCD BRIGHT button
3) Follow the instructions on LCD screen thereafter.
3.2 Still (JPEG) file operation (Fig. 3-1)
Caution: Executing this operation Will delete all still files on disc: Copy necessary still
files to PC, etc.
Purpose:
To delete still (JPEG) files to be played back on PC from the disc without using PC.
[When recording stills, this DVD video camera/recorder stores both stills to be played
back on the video camera/recorder and stills to be played back on PC: Only the still
files to be played back on the video camera/recorder can be deleted using the normal
video camera/recorder operation (Disc Navigation).]
Pertinent case:
Complaint by customer that "the disc storage capacity will not increase even if still files
are detected".
Operation procedure:
1) Insert the disc whose still files are to be deleted, and press the DISC NAVIGATION
button to start Disc Navigation.
2) Simultaneously press the SHIFT and MENU buttons to display the hidden menu on
the screen (see Fig. 3-1).
3) Use the cursor button to choose "Delete all stills", and press the ENTER button.
4) Follow the instructions on LCD screen thereafter.
Notes: 1. If "Recorded info." is selected on the hidden menu screen, the types
and numbers of files recorded on disc will appear on the screen.
2. Press the CANCEL button to exit the hidden menu and recorded
info. display, and restore normal status.
Fig. 3-1 Example of Display
Delete all stills
Recorded info.

E1 - 7
3.3 Firmware version display (Fig. 3-2)
Purpose:
To display the versions of software programs recorded on the following micro-
processors in product (see Fig. 3-2):
System control (SH) microprocessor: $Revision
Camera control microprocessor: Cam Ver
Disc drive (PC1) main microprocessor: PC1 Main
Disc drive (PC1) core microprocessor: PC1 Core
Pertinent case:
When you are asked for checking by the factory, or you want to ask the factory about
the servicing method.
Operation procedure:
Press the following 3 buttons simultaneously:
SHIFT button
DISC NAVIGATION button
(forward search) button
Notes: 1. Operation (display) is possible without disc inserted.
2. Press the CANCEL button to exit the version display, and restore the
normal status.
3.4 Error code display (Figs. 3-3, 3-4, 3-5)
Purpose:
To investigate the error code when error message “DISC”appears on the LCD screen.
Pertinent case:
When you are asked for checking by the factory, or you want to ask the factory about
the servicing method to.
Operation procedure:
1) Make sure that camera image appears.
2) Press the DISPLAY button, and then, within 0.5 second, hold down the DISPLAY
button and (STOP) button for at least 3 seconds.
3) The screen shown in Fig. 3-3 will appear (this has nothing to do with this function):
Press the ENTER button to display the screen shown in Fig. 3-4. The numerals or
letters displayed in the C and D columns of RECVBUF row in Fig. 3-4 constitute
the error codes.
If the ENTER button is pressed from the screen in Fig. 3-4, the screen in Fig. 3-5
will appear (this has nothing to do with this function).
Notes: 1. Operation (display) is possible without disc inserted.
2. Simultaneously press the Display and STOP buttons to exit the
error code display, and restore normal status.
3. Each time the ENTER button is pressed from the screen in Fig. 3-3,
Fig. 3-4 will switch to Fig. 3-5 and then to Fig. 3-3. (Fig. 3-3 and 3-5
have nothing to do with this function).
Z9Y9 99 00/12/31 V9.99Z
CAM 99 88 AF 7Z 7Z 66
RECVBUF 0123456789ABCDEF
0000001000AB
0000001000AB
0000001000AB
Error Codes
0012
0012
0012
Z9Y9 99 00/12/31 V9.99Z
CAM 99 88 AF 7Z 7Z 66
SENDBUF 0123456789ABCDEF
9876543210CD
1234567890AB
5060708090
0012
0034
0102030405
123456
789012
DZ-MV100A
$Revision: 9.99
$Data: 2000/12/31 23:59:00 $
Cam Ver: 9. 09.z
PC Main: Z99Y. 88. 77. REV
PC Core: A11B. 22. 33. REV
Fig. 3-2 Example of Display
Z9Y9 99 00/12/31 V9.99Z
S 99 88 C 77 77 A 6Y 6Y
ABC012 345678D9EF01GH23
ABC012 345678D9EF01GH23
ABC012 345678D9EF01GH23
Fig. 3-3 Example of Display
Fig. 3-4 Example of Display
Fig. 3-5 Example of Display

E1 - 8
3.5 Playback file detailed information display
Purpose:
To display the program/play list number, scene number, bit rate, elapsed time and
elapsed position of the movie or still file being played back.
Pertinent case:
Used as a reference to find noise that occurs in the middle of a long recorded movie.
Operation procedure:
1) Insert the object disc and play it back.
2) Press the DISPLAY button to display the ordinary playback information (display the
operation mode for 3 seconds).
3) Quickly press the SHIFT button and then DISPLAY button.
Note: Press the CANCEL button to exit the playback file detailed information display,
and restore normal status.
3.6 Deleting information control (RX) file (Fig. 3-6)
Caution: This operation will delete information on all settings of skip, fade, title, etc. on
disc.
Purpose:
To erase the RX file, which controls and contains the information on thumbnails, etc.
Pertinent case:
1) Thumbnails cannot normally be displayed using Disc Navigation, or
2) "DISC ALMOST FULL" appears even if the disc has sufficient free space.
Note: The above defect may occur if power is shut off while data is being written to
the file.
Operation procedure:
1) Insert the disc whose RX file is to be deleted, and press the DISC NAVIGATION
button, making sure that the DVD video camera/recorder enters the disc navigation
mode.
2) Simultaneously press the following three buttons:
SHIFT
DISC NAVIGATION
(reverse skip search)
3) A hidden menu will appear: Use the cursor button to choose “Delete RX file”, and
then press the ENTER button. (see Fig. 3-6)
Note: The following shows function items other than Delete RX file that the hidden
menu contains:
Version: Same as in “3.3 Firmware version display”
ErrorCode: Same as in “3.4 Error code display”
Switch Diap Temp: Invalid
Staff: Staff roll display
Switch Scene No. Color: nvalid
Format 1: Same as in “3.1 Forced disc formatting”
Japanese/English: Switching the language to be displayed on
screen. When power is supplied again
after switching, some parts of on-screen
information will alternate between English
or Japanese.
Fig. 3-6 Example of Display
Version
ErrorCode
Switch Disp Temp
Staff
Switch Scene No. Color
Delete RX file
Format 1
Japanese
English

E1 - 9
Message
Control info. error
Disc error
No more scenes
Play List was deleted
Write protected
Check cartridge
Battery is low
Please charge battery
Cannot combine
Select multiple
scenes
Cannot combine
Deselect stills
Scenes over limit
Cannot divide
Scenes over limit
Cannot add scenes
Cause
Mismatch may occur
between the recorded
image and scene infor
mation.
Disc may be dirty.
Mismatch in recording
information may be caused
by editing done on some
device other than this DVD
video camera/recorder.
Disc may be dirty.
All scenes are unloaded
from the play list.
-----
-----
-----
-----
The number of entered
scenes has reached the
limit that can be entered.
The number of scenes
entered in play list has
reached the limit that can
be entered.
Troubleshooting
Update the control information.
Remove the disc and wipe off
fingerprints, dust, etc. before
reusing it, or use another disc.
Initialize the disc or use
another disc.
Remove the disc and wipe off
fingerprints, dust, etc. before
reusing it, or use another disc.
-----
Release write-protect of
cartridge.
Replace with a charged
battery.
Select a range of at least 2
scenes to be combined, and
then combine them.
Select only movies and
combine them.
Delete (unload) several
scenes.
Unload several scenes.
Technical explanation
This appears when editing,
etc. was performed near the
limit (999 scenes or 13MB) of
media on devices other than
this DVD video camera/
recorder, or on user operated
control files. (*1)
The message appears when
reading recorded files or
writing data to files is not
possible. If the message still
appears after the disc is
replaced with normal one,
there is a problem in the DVD
video camera/recorder.
This appears when user is
operating information (control)
files.
The message appears when
reading recorded files or
writing data to files is not
possible. If the message still
appears after the disc is
replaced with normal one,
there will be nay problem in
the DVD video camera/
recorder.
If all scenes have been
removed from play list on the
play list select or editing
screen, the play list will
automatically be deleted, and
then this message will appear.
This appears with write
protected disc when some
writing to disc, such as
addition, deletion of scenes,
etc., is to be executed.
If the battery remaining level is
the same as the indication of
battery mark blinking during
editing, this message will
appear and editing will not be
possible.
This is an issue on operation.
This appears when stills are to
be combined and the still
combining function is not
installed.
This appears if scene is to be
divided (increased) when the
number of scenes has reached
the upper limit of 999. (*1)
This appears when the
number of scenes has reached
999 and scenes are still to be
added to play list. (*1)
Faulty or
not
Error on
disc
Same as
above
Same as
above
Same as
above
None
None
None
None
None
None
None
4. Explanation of Trouble Messages
A message may appear while you are operating the DVD video camera/recorder. If a message appears, refer to the following
table and take appropriate corrective action.

E1 - 10
Message
Cannot remove scenes
Cannot delete scenes
Please update disc
Disc id full
Reformat for camera
Continue?
Error on disc
All data will be deleted
Continue?
Cause
This may occur when
scene that was edited for
division, etc. is to be
unload.
This may occur when
scene that was edited for
division, etc. is to be
deleted.
The thumbnail at the start
of program or play list may
not appear when disc
edited on device other
than this DVD video
camera/recorder is used,
or, when editing, such as
combining, is performed on
this DVD video camera/
recorder.
The number of entered
scenes has reached the
limit that can be entered,
so the control information
for generating thumbnails
cannot be added.
Has the disc been initial-
ized on a PC?
Has initializing the disc on
a PC been interrupted?
Troubleshooting
Combine the divided scenes,
and then unload them.
Combine the divided scenes,
and then delete them.
If thumbnail is information is
insufficient, Disc Navigation
will automatically create
thumbnails after it starts.
Combine several scenes or
delete (unload) them.
Choose "Yes" and initialize the
disc when using it on this DVD
video camera/recorder.
Technical explanation
This appears if CELL is to be
divided (increased) when the
number of CELLs has reached
the limit of 999. (If recording
continues without editing on
this DVD video camera/
recorder, 1 scene will make up
1 EP or 1 CELL. If scenes are
combined, the number of EPs
will decrease, but the number
of CELLs will not decrease. If
CELL is to be divided at the
upper limit number of CELLs,
several scenes must be
deleted in this status without
traversing multiple CELLs. (*2)
Same as above.
This appears if a disc in which
EP is not attached to the
beginning of program or play
list is inserted (this occurs
when EP was not attached to
the beginning of program or
play list when editing was
performed on devices other
than this DVD video camera/
recorder, or scenes traversing
multiple programs were
combined, and thumbnails
cannot be displayed on Disc
Navigation screen). This
message appears when Disc
Navigation is started first after
power is supplied: Operation
following message instructions
will attach EP to the beginning
of program or play list, thereby
enabling thumbnails to be
displayed.
This appears if the number of
scenes has reached 999 when
control information is being
updated. (*1)
This appears if the disc has a
file that has been recorded in
a format that cannot be
detected by UDF2.0. (This
problem will be solved if the
disc is formatted on this DVD
video camera/recorder.)
This appears if the disc has
logically been destroyed. (The
problem frequently occurs
because of problem in the
UDF file system.) Although the
disc for which this message
appeared cannot be used as
is, it may be usable after it is
initialized (Note, however, that
all recorded data will be
deleted).
Faulty or
not
None
None
None.
However,
the disc
has a
problem in
compat-
ibility.
None
Error on
disc
Error on
disc

E1 - 11
Message
Disc error
Failed format
Disc error
Keep disc inside and
restart
Disc full
Cannot execute
Drive heat too high
Please retry later
(1) Error Reading
Repair movie file?
(2) Error Reading
Repair movie file?
(3) Error occurred
Try to fix
Standby Continue?
Cause
The disc may be dirty.
Disc error could have
occurred during editing of
scenes.
-----
The temperature inside the
DVD video camera/
recorder is too high, and
reading or writing of the
data on disc may not be
performed normally.
It is possible that the
system cannot normally
complete writing of file
when power is turned off
for some reason during
recording or editing
(deleting, dividing or
combining scenes, or
creating play list). Selecting
"Yes" will automatically
repair the video file, but
even if "No" is selected,
the same message will
appear when the DVD
video camera/recorder is
turned on next time. (Do
not remove the disc while
the DVD video camera/
recorder is recognizing it:
lqnoring this will deactivate
the file repair function.)
Troubleshooting
Remove the disc and wipe off
fingerprints, dust, etc. before
reusing it, or use another disc.
Turn off the DVD video
camera/recorder with the disc
being used in it, connect AC
adapter/charger, and then
power the DVD video camera/
recorder again. Scenes will be
repaired.
Delete unnecessary scenes
before using this disc, or use
another disc.
Turn the DVD video camera/
recorder off and wait for a
while. The temperature will be
effectively decreased if the
DVD video camera/recorder is
placed in a well-ventilated
spot.
Follow the instructions on
screen, taking note of the
following cautions:
Data may not be repaired,
depending on the timing
when power was turned off.
Data may not be repaired
normally if data recorded on
another recorder is mixed in.
The repaired data may be
different from the original
recorded content because of
partial deletion of defective
portion.
Since the date/time for repair
is added to the repaired data
(only the corrected portion
for partial repair), the original
date/time information will be
lost.
Since all movies, and then all
stills, are repaired, the order
of recorded contents will be
lost.
(In case of message (3) only)
Technical explanation
This appears if formatting of
disc could not be normally
performed (writing could not
be done to specified address).
This appears if power is shut
off for some reason during
movie recording. This DVD
video camera/recorder has a
function that automatically
saves files if power is shut off
during movie recording: This
function will repair some files
when the DVD video camera/
recorder is restarted (it may
take 10-20 minutes to repair
files). The DVD video camera/
recorder must be stably
powered using AC adapter for
restart.
This may appear if some
operation, such as adding
thumbnails, etc., is attempted
when the recordable area on
disc has been nearly used up.
This appears if recording,
playback, etc. is performed in
an environment near the limit
of allowable operating tem-
perature (humidity) for an
extended time. This message
will not appear in ordinary
situations of use, and reliability
of recorded data will decrease
in a situation where this
message appears.
This DVD video camera/
recorder has a function that
automatically saves files if
power is shut off during movie
recording: This function will
repair some files when the
DVD video camera/recorder is
restarted (it may take 10-20
minutes to repair files), and the
message will appear at this
time. The DVD video camera/
recorder must be stably
powered using AC adapter for
restart.
Same as above
Same as above
Faulty or
not
Physical
defect on
disc
Error in
recorded
file layer
on disc
None
None
Basically,
none
Same as
above
Same as
above

E1 - 12
Message
Use AC adapter
Error occurred
Please charge/for-
mat disc
Cause
Scene cannot be repaired
when the DVD video
camera/recorder is
powered by a battery.
Abnormality with the disc
to be repaired.
Troubleshooting
If the AC adapter/charger is
unavailable in handy place,
remove the disc, use the
opposite side, or use another
disc. To repair the removed
disc, insert the disc into the
DVD video camera/recorder
afterwards, and connect the
AC adapter/charger.
Initialize the disc before using
it again, or use the other side
of the same disc or another
disc.
Technical explanation
This DVD video camera/
recorder has a function that
automatically saves files if
power is shut off during movie
recording: This function will
repair some files when the
DVD video camera/recorder is
restarted. Since it may take
10-20 minutes for file repair
work, the DVD video camera/
recorder must be stably
powered using AC adapter:
The message will appear at
this time. Note that if power is
again shut off while files are
being repaired, restoration of
those files being repaired will
no longer be possible.
This message appears if there
is a problem in the disc or in
this DVD video camera/
recorder. If the problem is not
resolved after multiple tries of
troubleshooting on the left, the
problem is in the DVD video
camera/recorder.
Faulty or
not
None
Basically,
none
*1: The number of recordable scenes on this DVD video camera/recorder is 999: Since the maximum number of EPs (record
ing points) defined by the RTR standard (DVD-RAM recording standard) is 999, and 1 EP is allocated to 1 scene, this
limitation exists.
*2: The number of recordable CELLs (minimum recording unit) on this DVD video camera/recorder is 999. This limitation
exists because the maximum number of CELLs defined by the RTR standard (DVD-RAM recording standard) is 999.

E1 - 13
5. Troubleshooting Guide of DVD Video Camera/recorder
Cautions: 1) This DVD video camera/recorder incorporates a laser emitter block and high-voltage section:
Take great care when performing work.
2) Disassemble and reassemble the DVD video camera/recorder according to "Chapter 2 Disassembly".
Do not dismantle the R block any farther than the status shown in Fig. 5-1.
3) Be careful not to short-circuit TL (test land), IC pins, etc. during work.
4) Use the frame of ANA or DIG circuit board for GND.
The whole circuit board must be replaced in the following cases because components of these circuit boards are not available
as service parts. Judge whether the circuit boards shown below are defective, referring to the troubleshooting guide on the
following pages:
ANA circuit board
DIG circuit board
PHD circuit board [to be replaced together with mechanism unit] on R-block (drive block).
Notes: 1) Use the specified "check points" only for reference: Estimate the "Troubleshooting due to check results" method
from the "symptom" and try replacing circuit boards, components, etc., as needed.
If it is absolutely necessary to confirm check points, etc., pull them out from circuit boards using lead wires, etc.
2) This troubleshooting guide describes only major defects: The listed causes of defects and troubleshooting may not
always apply.
3) Troubleshooting guide assumes that connectors are correctly connected and that cables are not damaged or
disconnected: Make sure that all connectors and cables are correctly connected, and that they are not damaged.
4) This troubleshooting guide assumes that disc is normal. If there is any abnormality in disc, a trouble message will
appear: Perform appropriate troubleshooting, referring to “Explanation of Trouble Messages” described previously.
5) For check point locations, refer to the circuit board diagram shown in Chapter 6.
Letters in brackets [ ] show the names and sides of circuit boards:
Examples: ANA-A: Side A of ANA circuit board
DIG-B: Side B of DIG circuit board
Fig. 5-1 Parts Locations
B
A
C
D
E
F
G
H
I
J
A: R-Block (Drive Block)
B: PHD Circuit Board
(Mechanism Unit)
C: DIG Circuit Board
D: ANA Circuit Board
E: SE Circuit Board
F: GYR Circuit Board
G: JKR Circuit Board
H: JKF Circui Board
I: Flash Circuit Biard (Flash Unit)
J: GND

E1 - 14
Symptom
No power
No information appears on
screen after pressing DIS-
PLAY button: POWER switch
does not work.
No operating sound
No sound from speaker
No audio from audio output
jack
Microphone sound cannot be
recorded
Sound from external micro-
phone cannot be recorded
No sound can be recorded
Speaker sound volume
cannot be adjusted
Operation switches on side
case L do not work
Zoom switch does not work
EJECT switch does not work
Detail of check
Continuity check
"Hi" when power turns on
Approx. 3V DC (SYS3V)
Approx. 3V DC (CAM3V)
Approx. 5V DC (CAM5V)
Approx. 1.8V DC (CAM1.8V)
Approx. 3V DC (DRV3V)
Approx. 5V DC (DRV5V)
Approx. 15V DC
Voltage varies when POWER
switch is turned on/off.
Connections of switch unit.
Red and blue wires are "Hi".
Connect jigs in the same way
as for adjustment, and start
adjustment program (only
startup is necessary, adjust-
ment is not necessary).
Goes "Hi" momentarily when
power is turned on (SH-RST
pulse).
Check connections.
Audio signal
Audio signal
Check connections
Audio signal
Connection of external
microphone
Sound is output from speaker.
Volume indicator on screen
operates.
Switch operation changes
voltage.
Switch operation changes
voltage.
Check point
L0501 [ANA-A]
F0502 [ANA-B]
(*1)
L0509 [ANA-A]
L0504 [ANA-A]
TL0520 [ANA-B]
(*1)
TL1523 [ANA-B]
(*1)
L0502 [ANA-A]
L0503 [ANA-A]
L0505 [ANA-A]
L0510 [ANA-A]
L0511 [ANA-A]
C0546 [ANA-A]
TL1501 [ANA-A]
-----
Red and blue wires
of the MV100
connection jig.
-----
IC4001-2 [DIG-A]
PG6301 [ANA-A]
(speaker connec-
tor)
TL6301 [ANA-A]
TL6302 [ANA-A]
TL1701 [ANA-A]
TL1702 [ANA-A]
PG6001 [JKR-A]
TL6091 [JKR-B]
TL6092 [JKR-B]
Microphone jack
(JK6051) [JKR-B]
-----
-----
PG1503-4 [ANA-A]
PG1503-5 [ANA-A]
TL1503 [ANA-A]
TL1501 [ANA-A]
Troubleshooting due to check results
NG: F0501 (fuse) faulty. Replace ANA
circuit board.
NG: F0502 (fuse) faulty. Replace ANA
circuit board.
NG: F0503 (fuse) faulty. Replace ANA
circuit board.
NG: F0504 (fuse) faulty. Replace ANA
circuit board.
NG: IC1501 faulty. Replace ANA circuit
board.
NG: IC1503 faulty. Replace ANA circuit
board.
NG: IC0501 or its peripheral circuits
faulty. Replace ANA circuit board.
NG: Check connections of switch unit.
OK: IC1501 or peripheral circuits faulty.
Replace ANA circuit board.
OK: Replace switch unit
NG: IC4001 faulty. Replace DIG circuit
board.
NG: IC4002 faulty. Replace DIG circuit
board.
NG: IC1501 faulty. Replace ANA circuit
board.
OK: IC4001 faulty. Replace DIG circuit
board.
NG: Connector connections faulty.
OK: Replace side case L (speaker).
NG: IC6301 or its peripheral circuits
faulty. Replace ANA circuit board.
NG: IC6103 or its peripheral circuits
faulty. Replace ANA circuit board.
OK: Check parts on JKR circuit board.
NG: Connector connections faulty.
OK: Replace microphone.
NG: Check IC6001, IC6091 and their
peripheral circuits.
OK: Replace ANA circuit board.
NG: External microphone connection
faulty. JK6051 contact faulty.
OK: Check Q6051 R/L and their
peripheral circuits.
NG: IC6301 faulty. Replace ANA circuit
board.
OK: IC5001 faulty. Replace DIG circuit
board.
NG: Replace switch unit.
OK: IC6301 faulty. Replace ANA circuit
board.
NG: Replace side case-L.
OK: CAM3V line or IC1501 faulty.
Replace ANA circuit board.
NG: Replace switch unit.
OK: IC1501 or its peripheral circuits
faulty. Replace ANA circuit board.
*1: Solder lead wire, etc. to check point for measurement.
*2: Perform measurement with GYR circuit board removed.

E1 - 15
Detail of check
3V DC when power supply is
not connected.
Pulse (CS-PNL signal)
Check damage to cable
between LCD power unit and
DIG circuit board
"Hi" when power turns on
(SYS-RST pulse).
Signal (G signal)
-----
Error message does not
disappear and POWER switch
does not work.
Error message does not
disappear after 3 seconds or
more.
-----
-----
No improvement after DIG
circuit board is replaced.
Error message appears
approx. 1 second after disc is
inserted.
Error message appears at
least 10 seconds after disc is
inserted
Disc cartridge is write-
protected
-----
Normally initialized disc was
inserted
Check CCD sensor drive
pulses
Check CCD output signal
27MHz clock signal (SYS-
CLK)
Image appears in LCD or
EVF.
0V when AV output cable is
connected
Troubleshooting due to check results
NG: Check backup lithium-ion batter and
JKR circuit board.
OK: IC1501, IC1504 or their peripheral
circuits faulty. Replace ANA circuit
board.
NG: IC1501 faulty. Replace ANA circuit
board.
OK: Check cable between LCD power
unit and DIG circuit board.
NG: Replace side case L.
OK: Replace LCD power unit.
NG: IC1501 faulty. Replace ANA circuit
board.
OK: IC4001 faulty. Replace DIG circuit
board.
NG: IC3801 faulty. Replace ANA circuit
board.
OK: Check flat cable between EVF and
ANA circuit board.
Movie encoder circuit faulty. Replace DIG
circuit board.
F0503 (fuse) faulty. Replace ANA circuit
board.
Yes: IC4001 (ATAPI system) or IC2001
(CODEC system) faulty. Replace
DIG circuit board.
No: Check connections between DIG
circuit board and mechanism unit.
IC4001 or clock circuit for IC4001 faulty.
Replace DIG circuit board.
IC4001 (ATAPI system) or IC2001
(CODEC system) faulty. Replace DIG
circuit board.
Replace mechanism unit.
Check connections between DIG circuit
board and mechanism unit. If no abnor-
mality is found, replace mechanism
block.
Replace mechanism unit.
Yes: Release write-protect.
No: Replace mechanism unit.
Initialize the disc.
Yes: Replace mechanism unit.
No: Initialize disc.
NG: Check connections between SEN
and DIG circuit boards. If there is no
abnormality, replace DIG circuit
board.
NG: Replace IC1001 (CCD sensor)
NG: IC1511 faulty. Replace ANA circuit
board.
OK: IC1401 faulty. Replace DIG circuit
board.
Yes: Check connections between ANA
and JKR circuit boards.
No: Replace ANA circuit board.
NG: Check AV input/output jack
(JK1981).
OK: IC1701 faulty. Replace ANA circuit
Symptom
Date is not backed up
No display in information LCD
(B/W)
Does not enter REC PAUSE
status
No image in EVF
Great block noise during
movie recording
Error message "DISC AC-
CESS" appears and disc is
not recognized.
Noise appears on Disc
Navigation screen
Error message "Error oc-
curred" appears
Error message "NO DISC"
appears even when normal
disc is inserted
Error message "CHECK
DISC" appears
Error message "DISC"
appears
Error message "Reformat for
camera. Continue?" appears
Camera image is abnormal
Camera image distorted (sync
faulty)
No video from video output
jack
Check point
TL1518 [ANA-A]
TL3704 [DIG-A]
-----
TL1509 [ANA-A]
R3841 [ANA-A]
-----
-----
-----
-----
-----
-----
-----
-----
-----
TL1003(*2) [SEN-B]
TL1004(*2) [SEN-B]
TL1005(*2) [SEN-B]
TL1006(*2) [SEN-B]
TL1016(*2) [SEN-B]
TL1017(*2) [SEN-B]
TL1001(*2) [SEN-B]
IC1512-1 [ANA-A]
-----
TL1712 [ANA-A]
