Hitachi DB3DL User manual

Model Cordless Driver Drill
Modèle Perceuse-visseuse sans fil
Modelo Taladro atornillador a batería
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation INCORRECTE OU DANGEREUSE de cet outil motorisé peut entraîner la
mort ou de sérieuses blessures corporelles !
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce
produit. Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil
motorisé.Gardercemoded’emploiàladisponibilitédesautresutilisateursetpropriétaires
avant qu’ils utilisent l’outil motorisé. Ce mode d’emploi doit être conservé dans un
endroit sûr.
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily
injury!
This manual contains important information about product safety. Please read and
understand this manual BEFORE operating the power tool. Please keep this manual
availableforotherusersandownersbeforetheyusethepowertool.Thismanualshould
be stored in safe place.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización INAPROPIADA O PELIGROSA de esta herramienta eléctrica puede
resultar en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprendaestemanualANTESdeutilizarlaherramientaeléctrica.Guardeestemanual
para que puedan leerlo otras personas antes de utilizar la herramienta eléctrica. Este
manual debe ser guardado en un lugar seguro.
DB 3DL

Page
ASSEMBLY AND OPERATION ............................... 12
APPLICATIONS ................................................... 12
REMOVAL AND INSTALLATION METHOD
OF BATTERY ................................................ 12
CHARGING METHOD ......................................... 12
BEFORE USE ....................................................... 15
OPERATION......................................................... 15
THE SCOPE AND SUGGESTIONS
FOR USES .................................................... 18
MAINTENANCE AND INSPECTION ....................... 18
ACCESSORIES ......................................................... 20
STANDARD ACCESSORIES ............................... 20
OPTIONAL ACCESSORIES ................................. 20
PARTS LIST.............................................................. 60
TABLE DES MATIERES
Français Page
INFORMATIONS IMPORTANTES DE SÉCURITÉ ..... 21
SIGNIFICATION DES MOTS D’AVERTISSEMENT ..... 21
SECURITE ................................................................ 22
REGLES GENERALE DE SECURITE – POUR TOUS
LES OUTILS FONCTIONNANT SUR BATTERIE
.... 22
REGLES DE SECURITE SPECIFIQUES ET SYMBOLES .. 24
CONSIGNES DE SÉCURITÉ IMPORTANTES
POUR LE CHARGEUR DE BATTERIE .......... 26
CONSIGNES DE SÉCURITÉ IMPORTANTES
POUR L’UTILISATION DE LA BATTERIE
ET DU CHARGEUR DE BATTERIE .............. 27
DESCRIPTION FONCTIONNELLE ........................... 29
MODELE .............................................................. 29
NOM DES PARTIES ............................................ 29
SPECIFICATIONS ................................................ 30
Page
ASSEMBLAGE ET FONCTIONNEMENT ................ 31
UTILISATIONS .................................................... 31
MÉTHODE DE RETRAIT ET D’INSTALLATION
DE LA BATTERIE .......................................... 31
MÉTHODE DE RECHARGE ................................. 31
AVANT L’UTILISATION ...................................... 34
UTILISATION ....................................................... 34
PLAGE D’UTILISATION ET SUGGESTIONS ..... 37
ENTRETIEN ET INSPECTION .................................. 38
ACCESSOIRES ......................................................... 40
ACCESSOIRES STANDARD ............................... 40
ACCESSOIRES EN OPTION................................ 40
LISTE DES PIÈCES................................................... 60
Página
MONTAJE Y OPERACIÓN ...................................... 51
APLICACIONES ................................................... 51
MÉTODO DE EXTRACCIÓN E INSTALACIÓN
DE LA BATERÍA............................................ 51
MÉTODO DE CARGA .......................................... 51
ANTES DE LA UTILIZACIÓN .............................. 54
OPERACIÓN ........................................................ 54
ALCANCE Y SUGERENCIAS PARA LA
UTILIZACIÓN................................................ 57
MANTENIMIENTO E INSPECCIÓN ........................ 57
ACCESORIOS........................................................... 59
ACCESORIOS ESTÁNDAR ................................. 59
ACCESORIOS OPCIONALES .............................. 59
LISTA DE PIEZAS .................................................... 60
CONTENTS
ÍNDICE
Español Página
INFORMACIÓN IMPORTANTE SOBRE SEGURIDAD .... 41
SIGNIFICADO DE LAS PALABRAS DE SEÑALIZACIÓN .... 41
SEGURIDAD............................................................. 42
NORMAS GENERALES DE SEGURIDAD – PARA TODAS
LAS HERRAMIENTAS ALIMENTADAS CON BATERÍA ... 42
NORMAS Y SÍMBOLOS ESPECÍFICOS DE
SEGURIDAD ................................................. 44
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
PARA EL CARGADOR DE BATERÍAS ................. 46
INSTRUCCIONES IMPORTANTES DE SEGURIDAD PARA
LA BATERÍA Y EL CARGADOR DE BATERÍAS ........ 47
DESCRIPCIÓN FUNCIONAL.................................... 49
MODELO .............................................................. 49
NOMENCLATURA............................................... 49
ESPECIFICACIONES............................................ 50
English Page
IMPORTANT SAFETY INFORMATION ................ 3
MEANINGS OF SIGNAL WORDS ........................ 3
SAFETY ...................................................................... 4
GENERAL SAFETY RULES – FOR ALL
BATTERY OPERATED TOOLS....................... 4
SPECIFIC SAFETY RULES AND SYMBOLS......... 6
IMPORTANT SAFETY INSTRUCTIONS
FOR BATTERY CHARGER ............................. 7
IMPORTANT SAFETY INSTRUCTIONS
FOR USE OF THE BATTERY AND
BATTERY CHARGER...................................... 8
FUNCTIONAL DESCRIPTION.................................. 10
MODEL................................................................. 10
NAME OF PARTS ................................................ 10
SPECIFICATIONS ................................................ 11

English
3
IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in
the Instruction Manual before operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the
failure to observe basic safety rules or precautions. An accident can often be avoided by
recognizinga potentially hazardous situationbeforeitoccurs, and byobserving appropriate
safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Instruction Manual
and in the sections which contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by
WARNINGS on the power tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by
HITACHI.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in
death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in
minor or moderate injury, or may cause machine damage.
NOTE emphasizes essential information.

English
4
SAFETY
GENERAL SAFETY RULES – FOR ALL BATTERY OPERATED TOOLS
WARNING: Read and understand all instructions.
Failuretofollowallinstructions listed below, may result inelectric shock,
fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
1. Work Area
(1) Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
(2) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust. Power tools create sparks which may ignite the
dust of fumes.
(3) Keep bystanders, children and visitors away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical Safety
(1) A battery operated tool with integral batteries or a separate battery pack must be
recharged only with the specified charger for the battery.
Acharger thatmaybe suitableforone typeofbattery may createa risk offire when
used with another battery.
(2) Use battery operated tool only with specifically designed battery pack.
Use of any other batteries may create a risk of fire.
(3) Do not abuse the cord. Never use the cord to carry the tools or pull the plug from
an outlet. Keep cord away from heat, oil, sharp edges or moving parts. Replace
damaged cords immediately. Damaged cords increase the risk of electric shock.
3. Personal Safety
(1) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use tool while tired or under the influence of drugs, alcohol, or
medication. A moment of inattention while operating power tools may result in
serious personal injury.
(2) Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep
your hair, clothing and gloves away from moving parts. Loose clothes, jewelry, or
long hair can be caught in moving parts.
(3) Avoid accidental starting. Be sure switch is off position before inserting battery.
Carrying tools with your finger on the switch or inserting the battery pack into a
tool that have the switch on invites accidents.
(4) Remove adjusting keys or wrenches before turning the tool on. A wrench or a key
that is left attached to a rotating part of the tool may result in personal injury.
(5) Do not overreach. Keep proper footing and balance at all times. Properfooting and
balance enable better control of the tool in unexpected situations.
(6) Use safety equipment. Always wear eye protection. Dust mask, non-skid safety
shoes, hard hat, or hearing protection must be used for appropriate conditions.

English
5
4. Tool Use and Care
(1) Use clamps or other practical way to secure and support the workpiece to a stable
platform. Holding the work by hand or against your body is unstable and may lead
to loss of control.
(2) Do not force tool. Use the correct tool for your application. The correct tool will do
the job better and safer at the rate for which it is designed.
(3) Do not use tool if switch does not turn it on or off. Anytoolthatcannotbecontrolled
with the switch is dangerous and must be repaired.
(4) Disconnect battery pack from tool or place the switch in the locked or off position
before making any adjustments, changing accessories, or storing the tools. Such
preventive safety measures reduce the risk of starting the tool accidentally.
(5) Disconnect the battery or cord form the tool before making any adjustments,
changing accessories, or storing the tool. Such preventive safety measures reduce
the risk of starting the tool accidentally (when used with power supply).
(6) Store idle tools out of reach of children and other untrained persons. Tools are
dangerous in the hands of untrained users.
(7) When battery pack is not in use, keep it away from other metal objects like: paper
clips, coins, keys, nails, screws, or other small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may cause sparks, burns, or a fire.
(8) Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained
tools, with sharp cutting edges are less likely to bind and are easier to control.
(9) Check for misalignment or binding of moving parts, breakage of parts, and any
other condition that may affect the tools operation. If damaged, have the tool
serviced before using. Many accidents are caused by poorly maintained tools.
(10)Use only accessories that are recommended by the manufacturer for your model.
Accessories that may be suitable for one tool, may become hazardous when used
on another tool.
5. Service
(1) Tool service must be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
(2) When servicing a tool, use only identical replacement parts. Follow instructions in
the Maintenance section of this manual. Use of unauthorized parts or failure to
follow Maintenance Instruction may create a risk of electric shock or injury.
WARNING:
Some dust created by power sanding, sawing, grinding, drilling, and other construction
activitiescontainschemicalsknowntothe State of California tocause cancer, birth defects
or other reproductive harm. Some examples of these chemicals are:
●Lead from lead-based paints,
●Crystalline silica from bricks and cement and other masonry products, and
●Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.

English
6
SPECIFIC SAFETY RULES AND SYMBOLS
1. Hold tools by insulated gripping surfaces when performing an operation where the
cutting tool may contact hidden wiring. Contact with a “live” wire will make exposed
metal parts of the tool “live” and shock the operator.
2. ALWAYS wear ear protectors when using the tool for extended periods.
Prolonged exposure to high intensity noise can cause hearing loss.
3. NEVER place hands or other body parts near the drill bit or chuck during operation.
Hold the drill by its handle only.
4. Because the cordless driver drill operates by battery power, be aware of the fact that it
can begin to operate at any time.
5. When working at elevated locations, clear the area of all other people and be aware of
conditions below you.
6. NEVER touch moving parts.
NEVER place your hands, fingers or other body parts near the tool’s moving parts.
7. NEVER operate without all guards in place.
NEVER operate this tool without all guards or safety features in place and in proper
working order. If maintenance or servicing requires the removal of a guard or safety
feature, be sure to replace the guard or safety feature before resuming operation of the
tool.
8. Use right tool.
Don’t force small tool or attachment to do the job of a heavy-duty tool.
Don’t use tool for purpose not intended —for example— don’t use circular saw for
cutting tree limbs or logs.
9. NEVER use a power tool for applications other than those specified.
NEVER use a power tool for applications other than those specified in the Instruction
Manual.
10. Handle tool correctly.
Operate the tool according to the instructions provided herein. Do not drop or throw
the tool. NEVER allow the tool to be operated by children, individuals unfamiliar with
its operation or unauthorized personnel.
11. Keep all screws, bolts and covers tightly in place.
Keep all screws, bolts, and plates tightly mounted. Check their condition periodically.
12. Do not use power tools if the plastic housing or handle is cracked.
Cracks in the tool’s housing or handle can lead to electric shock. Such tools should not
be used until repaired.
13. Blades and accessories must be securely mounted to the tool.
Prevent potential injuries to yourself or others. Blades, cutting implements and
accessories which have been mounted to the tool should be secure and tight.

English
7
IMPORTANT SAFETY INSTRUCTIONS
FOR BATTERY CHARGER
1. This manual contains important safety and operating instructions for battery charger
Model UC3SFL.
2. Beforeusingbatterycharger,readall instructions and cautionary markings on(1) battery
charger, (2) battery, and (3) product using battery.
3. To reduce risk of injury, charge HITACHI rechargeable battery type EBM315. Other type
of batteries may burst causing personal injury and damage.
4. Do not expose battery charger to rain or snow.
5. Use of an attachment not recommended or sold by the battery charger manufacturer
may result in a risk of fire, electric shock, or injury to persons.
6. To reduce risk of damage to electric plug and cord, pull by plug when disconnecting
battery charger.
7. Make sure cord is located so that it will not be stepped on, tripped over, or otherwise
subjected to damage or stress.
14. NEVER use a tool which is defective or operating abnormally.
If the tool appears to be operating unusually, making strange noises, or otherwise
appears defective, stop using it immediately and arrange for repairs by a Hitachi
authorized service center.
15. Carefully handle power tools.
Should a power tool be dropped or struck against hard materials inadvertently, it may
be deformed, cracked, or damaged.
16. Do not wipe plastic parts with solvent.
Solvents such as gasoline, thinner, benzine, carbon tetrachloride and alcohol may
damage and crack plastic parts. Do not wipe them with such solvents.
Wipe plastic parts with a soft cloth lightly dampened with soapy water and dry
thoroughly.
17. ALWAYS wear eye protection that meets the requirement of the latest revision of ANSI
Standard Z87.1.
18. Definitions for symbols used on this tool
V............volts
—
---...........direct current
no..........no load speed
---/min ...revolutions per minute

English
8
Table 1
RECOMMENDED MINIMUM AWG SIZE FOR
EXTENSION CORDS FOR BATTERY CHARGERS
AC Input Rating Amperes* AWG Size of Cord
Equal to or but less Length of Cord, Feet (Meter)
greater than than 25 (7.5) 50 (15) 100 (30) 150 (45)
02 1818 18 16
23 1818 16 14
34 1818 16 14
8. An extension cord should not be used unless absolutely necessary. Use of improper
extension cord could result in a risk of fire and electric shock.
If extension cord must be used make sure:
a. That blades of extension cord are the same number, size, and shape as those of
plug on battery charger;
b. That extension cord is properly wired and in good electrical condition; and
c. That wire size is large enough for AC ampere rating of battery charger as specified
in Table 1.
*If the input rating of a battery charger is given in watts rather than in amperes, the
corresponding ampere rating is to be determined by dividing the wattage rating by the
voltage rating–for example:
1,250 watts
125 volts = 10 amperes
9. Do not operate battery charger with damaged cord or plug–replace them immediately.
10. Donotoperatebatterychargerif it has received a sharp blow, beendropped,orotherwise
damaged in any way; take it to a qualified serviceman.
11. Do not disassemble battery charger; take it to a qualified serviceman when service or
repair is required. Incorrect reassembly may result in a risk of electric shock or fire.
12. To reduce risk of electric shock, unplug charger from receptacle before attempting any
maintenance or cleaning. Removing the battery will not reduce this risk.
IMPORTANT SAFETY INSTRUCTIONS FOR USE OF THE
BATTERY AND BATTERY CHARGER
You must charge the battery before you can use the cordless driver drill. Before using the
model UC3SFL battery charger, be sure to read all instructions and cautionary statements
on it, the battery and in this manual.
REMEMBER: USE ONLY HITACHI BATTERY TYPE EBM315. OTHER TYPES OF BATTERIES
MAY BURST AND CAUSE INJURY!
Follow these instructions to avoid the risk of injury:

English
9
WARNING: Improper use of the battery or battery charger can lead to serious injury.
To avoid these injuries:
1. NEVER disassemble the battery.
2. NEVER incinerate the battery, even if it is damaged or is completely worn out. The
battery can explode in a fire.
3. NEVER short-circuit the battery.
4. NEVER insert any objects into the battery charger’s air vents. Electric shock or
damage to the battery charger may result.
5. NEVER charge outdoors. Keep the battery away from direct sunlight and use only
where there is low humidity and good ventilation.
6. NEVER charge when the temperature is below 50°F (10°C) or above 104°F (40°C).
7. NEVER connect two battery chargers together.
8. NEVER insert foreign objects into the hole for the battery or the battery charger.
9. NEVER use a booster transformer when charging.
10. NEVER use an engine generator or DC power to charge.
11. NEVER store the battery or battery charger in places where the temperature may
reach or exceed 104°F (40°C).
12. ALWAYS operate charger on standard household electrical power (120 volts). Using
the charger on any other voltage may overheat and damage the charger.
13. ALWAYS wait at least 15 minutes between charges to avoid overheating the charger.
14. ALWAYS disconnect the power cord from its receptacle when the charger is not in
use.
SAVE THESE INSTRUCTIONS
AND
MAKE THEM AVAILABLE TO
OTHER USERS
AND
OWNERS OF THIS TOOL!

English
10
FUNCTIONAL DESCRIPTION
NOTE:
The information contained in this Instruction Manual is designed to assist you in the
safe operation and maintenance of the power tool.
NEVER operate, or attempt any maintenance on the tool unless you have first read and
understood all safety instructions contained in this manual.
Some illustrations in this Instruction Manual may show details or attachments that
differ from those on your own power tool.
MODEL
DB3DL (MSK): with charger (UC3SFL) and case
NAME OF PARTS
1. Cordless Driver Drill (DB3DL)
䡬Battery (EBM315)
Fig. 1
Battery
Main switch
Clutch dial Shift knob Lock switch
Light
Nameplate
Light switch
Nameplate
Terminal hole
Battery release button

English
11
2. Battery Charger (UC3SFL)
SPECIFICATIONS
1. Cordless Driver Drill (DB3DL)
2. Battery Charger (UC3SFL)
Motor DC motor
No-load speed Low 200 / min
High 600 / min
Drilling
Metal (Thickness 5/64" (2 mm)
Capacity 1/32" (1.0 mm)) (Mild Steel or Aluminum)
Screw Wood screw #6 ×25/32" (3.5 mm ×20 mm)
Driver Small screw 3/16" (5 mm)
Bit shank size 1/4" (6.35 mm) Hex.
Model EBM315
Type Lithium - ion battery
Battery Voltage DC 3.6 V
Charging & discharging About 500 times
frequency
Weight 0.9 lbs. (0.4 kg)
Input power source Single phase: AC 120 V 60 Hz
Charging time Approx. 30 min.
(At a temperature of 68°F (20°C))
Charging voltage DC 3.6 V
Charging current DC 3.0 A
Weight 0.7 lbs. (0.3 kg)
NOTE: The charging time may vary according to temperature and power source voltage.
Fig. 2
Battery installation hole
Pilot lamp
Plug Nameplate
Cord

English
12
ASSEMBLY AND OPERATION
APPLICATIONS
䡬Use as a drill
Drilling of soft steel, plastic and aluminum materials
䡬Use as a screwdriver
Tightening and loosening of machine screws, wood screws and tapping screws
REMOVAL AND INSTALLATION METHOD OF BATTERY
䡬How to install the battery
Align the battery with the groove in tool handle and slip it into place.
Alwaysinsertitallthewayuntilitlocksinplacewithalittle click. If not, it may accidentally
fall out of the tool, causing injury to you or someone around you. (Fig. 3)
䡬How to remove the battery
Withdrawbatteryfromthe tool handle while pressingthe battery releasebuttons(2pcs.)
on the sides of the battery. (Fig. 3)
Fig. 3
CHARGING METHOD
NOTE: Before plugging into the receptacle, make sure the following points.
䡬The power source voltage is stated on the nameplate.
䡬The cord is not damaged.
WARNING: Do not charge at voltage higher than indicated on the nameplate.
If charged at voltage higher than indicated on the nameplate, the
charger will burn up.
Battery release button
Push
Handle
Battery
Insert
Pull out

English
13
1. Insert the plug of battery charger into the receptacle.
WARNING:
Do not use the electrical cord if damaged. Have it repaired
immediately.
2. Insertthebatterytothe batterycharger.
Insert the battery into the battery charger
as shown in Fig. 4.
3. Charging
䡬Whenthebatteryis connected to the battery
charger, charging will commence and the
pilot lamp will light on.
NOTE: If the pilot lamp does not light, pull
outtheplugfromthereceptacleand
check if the battery is properly
mounted.
䡬When the battery is fully charged, the pilot
lamp will go out.
NOTE: Thebattery charging time becomes
longer when a temperature is low
or the voltage of the power source
is too low.
Whenthepilot lamp doesnot gooff
even if more than four hour has
passed after start of the charging,
stop the charging and contact your
HITACHI AUTHORIZED SERVICE
CENTER.
䡬Regarding the temperature of the rechargeable battery.
The temperatures for rechargeable batteries are as shown in the table below, and
batteries that have become hot should be cooled for a while before being recharged.
Fig. 4
Rechargeable batteries
EBM315
Temperature at which the battery can be recharged
32°F — 122°F (0°C — 50°C)
Table 2
Battery
Pilot lump

English
14
䡬Regarding recharging time
Table 3 shows the recharging time required according to the type of battery.
NOTE: The recharging time may vary according to the ambient temperature and the
power supply voltage.
4. Disconnect battery charger from the receptacle.
CAUTION:
Do not pull the plug out of the receptacle by pulling on the cord.
Make sure to grasp the plug when removing from receptacle to avoid damaging cord.
5. Remove the battery from the battery charger.
Supportingthe battery chargerwithhand, pull outthebattery from thebatterycharger.
Regarding electric discharge in case of new batteries, etc.
As the internal chemical substance of new batteries and batteries that have not been
used for an extended period is not activated, the electric discharge might be low when
using them the first and second time. This is a temporary phenomenon, and normal
time required for recharging will be restored by recharging the batteries 2 – 3 times.
How to make the batteries perform longer.
䡬Recharge the batteries before they become completely exhausted.
When you feel that the power of the tool becomes weaker, stop using the tool and
recharge its battery. If you continue to use the tool and exhaust the electric current,
the battery may be damaged and its life will become shorter.
䡬Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after use. If such a battery is recharged
immediately after use, its internal chemical substance will deteriorate, and the battery
life will be shortened. Leave the battery and recharge it after it has cooled for a while.
CAUTION:
䢇When the battery charger has been continuously used, the battery charger will be
heated, thus constituting the cause of the failures. Once the charging has been
completed, give 15 minutes rest until the next charging.
䢇If the battery is recharged when it is warm due to battery use or exposure to sunlight,
the pilot lamp may not light.
The battery will not be recharged. In such a case, let the battery cool before charging.
䢇Ifthebatterychargerdoesnotworkwhilethe battery is mounted correctly, it is probable
that the battery or charger is malfunctioning. Take it to your authorized Service Center.
Table 3 Recharging time (approx. min.) at 68°F (20°C)
Battery Battery capacity (Ah)
voltage (V) 1.5 Ah
3.6 EBM315 30 min.

English
15
BEFORE USE
Check the work area to make sure that it is clear of debris and clutter.
Clear the area of unnecessary personnel. Ensure that lighting and ventilation is adequate.
OPERATION
How to make the batteries perform longer.
䡬Recharge the batteries before they become completely exhausted.
When you feel that the power of the tool becomes weaker, stop using the tool and
recharge its battery. If you continue to use the tool and exhaust the electric current,
the battery may be damaged and its life will become shorter.
1. Installing the bit
Always follow the following procedure to install
driver bit. (Fig. 5)
(1) Pull the guide sleeve forward.
(2) Insertthebit into thehexagonal holein thesocket.
(3) Release the guide sleeve and it returns to its
original position.
CAUTION
If the guide sleeve does not return to its original
position, then the bit is not installed properly.
2. Removing the bit
Please do the opposite point on the method of
installing bit.
3. Automatic spindle-lock mechanism
When the main switch is off, the bit is locked in place, and the tool can be used as a
manual screwdriver.
4. Confirm that the battery is mounted correctly
5. Change rotation speed
Fig. 6 Fig. 7
Fig. 5
Driver bit
Hexagonal hole
in the socket
Movement
Guide
sleeve
Shift knob
High speed
Shift knob
Low speed

English
16
Operatetheshiftknobtochangetherotationalspeed.Movetheshiftknobinthedirection
of the arrow. (See Fig. 6 and 7)
When the shift knob is set to “LOW”, the drill rotates at a low speed. When set to
“HIGH”, the drill rotates at a high speed.
CAUTION:
●When changing the rotational speed with the shift knob, confirm that the switch is off.
Changing the speed while the motor is rotating will damage the gears.
●When a large force is required for operation, set the shift knob to “LOW”. If “HIGH” is
set and the unit is used, it may cause the motor to burn out or malfunction prematurely.
6. Confirm the clutch dial position (see Fig. 8).
The tightening torque of this unit can be adjusted
according to the clutch dial position, at which the
clutch dial is set.
(1) When using this unit as a screwdriver, line up the
one of the numbers “1, 5, 9 ... 21” on the clutch
dial, or the black dot, with the triangle mark on the
outer body.
(2) When using this unit as a drill, line up the clutch
dial drill mark “ ” with the triangle mark on the
outer body.
CAUTION:
䢇The clutch dial cannot be set between the numbers
“1, 5, 9 ... 21” or the black dot.
䢇Do not use with the clutch dial set at the line
between the number “21” and the drill mark
“”. Doing so may cause damage (See Fig. 9).
7. Tightening torque adjustment.
(1) Tightening torque
Tightening torque should correspond in its intensity to the screw diameter. When too
strong power is used, the screw head may be broken or be injured.
Be sure to adjust the clutch dial position according to the screw diameter.
(2) Tightening torque indication (See Fig. 8)
The tightening torque differs depending on the type of screw and the material being
tightened.
The unit indicates the tightening torque with the numbers “1, 5, 9 ... 21” on the clutch
dial, and a black dot. The tightening torque at position “1” is the weakest and the
torque is strongest at the highest number.
(3) Adjusting the tightening torque (See Fig. 8)
Rotate the clutch dial and line up the numbers “1, 5, 9, ... 21” on the clutch dial, or the
black dot, with the triangle mark on the outer body. Adjust the clutch dial in the weak or
the strong torque direction according to the torque you need.
Clutch dial Triangle mark
Fig. 8
Weak
Fig. 9
Strong
Drill mark
Line
Triangle mark
LOW
Drill mark

English
17
CAUTION:
●Themotorrotationmaybelockedtoceasewhile the unit is used as drill. While operating
the driver drill, take care not to lock the motor.
●When setting the shift knob to “HIGH” (high speed) and the position of the clutch dial
is between “9” and “21”, it may happen that the clutch does not engaged and that the
motor is locked. In such a case, please set the shift knob to “LOW” (low speed).
●If the motor is locked, immediately turn the power off. If the motor is locked for a
while, the motor or battery may be burnt.
●Too long hammering may cause the screw broken due to excessive tightening.
8. Switch operation
(1) Lock switch
The tool is equipped with a lock switch. To activate
the main switch lock, move the lock switch to the
“䊲LOCK” position. Move the lock switch to the
opposite position to operate the tool. (Fig.10)
CAUTION:
Always set the lock switch to the “䊲LOCK”
positionwhen carrying or storing the tool eliminate
unintentional starting.
(2) Main switch
The main switch functions as a motor switch and
rotationaldirection selector switch.Whenthe main
switch is pushed to “R” indicated on the main
switch, the bit rotates clockwise. When the main
switch is pushed to “L” indicated on the main
switch, the bit rotates counterclockwise. When the
main switch is released, the tool stops. (Fig. 11)
9. Using the light
The light lights when the light switch is pushed.
When the light switch is pushed again, the light is
turned off. (Fig. 12)
CAUTION:
Do not look directly into the light. Such actions
could result in eye injury.
10. Using in the Straight or Pistol Configuration
Use the tool in the straight configuration when using
in confined spaces. Use it in the pistol configuration
whenusinginotherlocations. Selecttheconfiguration
thatbestmatchesthetoolapplication.Whenchanging
the configuration, the tool will make a clicking sound
whenitsnaps intoposition. Bend(orextend)the tool
until the clicking sound is heard.
Fig. 10
LOCK
Unlock
“䊲LOCK”
Lock switch
Lock
Fig. 12
Light switch
Fig. 11
R
L
Main switch
R
L

English
18
CAUTION:
When using the tool in the pistol configuration,
do not hold onto the bending portion of the tool
when returning to the straight configuration.
Your finger or other part of the hand may be
pinched by the bending portion resulting in
possible injury (Fig. 13).
THE SCOPE AND SUGGESTIONS FOR USES
Table 6
CAUTION:
●While operating the Cordless driver drill, take care not to lock the motor.
If the motor is locked, immediately turn the power off.
If the motor is locked for a while, the motor or battery will be burnt.
●Do not tighten too strongly as the screw heads will be damaged.
Work Cap position Suggestions
Drilling Steel Use for drilling purpose.
Aluminum
Screw Small 1 – 21 Use the bit and socket matching the screw
tightening screw diameter.
Wood 1 – Use after drilling a pilot hole.
screw
Bending portion
Fig. 13
MAINTENANCE AND INSPECTION
CAUTION: Pull out battery before doing any inspection or maintenance.
1. Checking the condition of the bit
The bits should be checked regularly. If worn or broken bits can slip or decrease the
efficiency of the motor and burn it out.
Replace worn bits with new ones.
CAUTION:If you use a driver bit of which point is worn or broken, it will be dangerous
since it slips. So replace it with a new one.
2. Check the Screws
Loose screws are dangerous. Regularly inspect them and make sure they are tight.
CAUTION:Using this power tool with loosened screws is extremely dangerous.
3. Check for Dust
Dust may be removed with a soft cloth or a cloth dampened with soapy water.
Do not use bleach, chlorine, gasoline or thinner, for they may damage the plastics.

English
19
4. Disposal of the exhausted battery
WARNING: Do not dispose of the exhausted battery. The battery must explode if it
is incinerated. The product that you have purchased contains a
rechargeable battery. The battery is recyclable. At the end of it’s useful
life, under various state and local laws, it may be illegal to dispose of
this battery into the municipal waste stream. Check with your local
solid waste officials for details in your area for recycling options or
proper disposal.
5. Storage
Storing in a place below 104°F (40°C) and out of the reach of children.
6. Service and repairs
Allquality power tools willeventuallyrequireservicing or replacementof partsbecause
of wear from normal use. To assure that only authorized replacement parts will be
used, all service and repairs must be performed by a HITACHI AUTHORIZED SERVICE
CENTER, ONLY.
7. Service parts list
CAUTION:Repair, modification and inspection of Hitachi Power Tools must be carried
out by a Hitachi Authorized Service Center.
This Parts List will be helpful if presented with the tool to the Hitachi
Authorized Service Center when requesting repair or other maintenance. In
the operation and maintenance of power tools, the safety regulations and
standards prescribed in each country must be observed.
MODIFICATIONS:
Hitachi Power Tools are constantly being improved and modified to incorporate the latest
technological advancements.
Accordingly, some parts may be changed without prior notice.

English
20
ACCESSORIES
WARNING: ALWAYS use Only authorized HITACHI replacement parts and
accessories. NEVER use replacement parts or accessories which are
not intended for use with this tool. Contact HITACHI if you are not sure
whether it is safe to use a particular replacement part or accessory
with your tool.
The use of any other attachment or accessory can be dangerous and
could cause injury or mechanical damage.
NOTE:
Accessories are subject to change without any obligation on the part of the HITACHI.
STANDARD ACCESSORIES
DB3DL
(MSK)
1Phillips bit (No. 2 ×50L) (Code No. 992671) ............. 1
2Battery (EBM315)........................................................ 2
3Battery Charger (UC3SFL).......................................... 1
4Plastic Case ................................................................. 1
Fig. 14
OPTIONAL ACCESSORIES.....sold separately
1. Battery (EBM315)
Fig. 15
NOTE:
Specifications are subject to change without any obligation on the part of the HITACHI.
1 2
34
