Hitachi L42SP04E User manual

L42SP04E
GB
F
D
Instructions for use
Notice d'utilisation
Bedienungsanleitung
Digital LCD Colour Television
Télévision Couleur LCD Digital
Digitales LCD-Farb-TV-Gerät

English - 1 -
Contents
Features ................................................................. 3
Accessories ............................................................ 3
Introduction............................................................. 4
Preparation............................................................. 4
Safety Precautions ................................................. 4
Power Source ..................................................... 4
Power Cord......................................................... 4
Moisture and Water ............................................ 4
Cleaning.............................................................. 4
Ventilation ........................................................... 4
Heat and Flames ................................................ 4
Lightning ............................................................. 4
Replacement Parts ............................................. 4
Servicing............................................................. 5
Waste Disposal................................................... 5
Information for Users in European Union
Countries ............................................................ 5
Disconnecting the Device ................................... 5
Headphone Volume ............................................ 5
Installation........................................................... 5
LCD Screen ........................................................ 5
Warning .............................................................. 5
Overview of the Remote Control ............................ 6
LCD TV and Operating Buttons.............................. 7
Viewing the Connections- Back Connectors .......... 8
Viewing the Connections - Side Connectors ........ 10
Power Connection .................................................11
Aerial Connection ..................................................11
Using the Cable Holder .........................................11
Using Digital Multimedia Connectors.................... 12
USB Memory Connection ................................. 12
Side HDMI Connection......................................... 12
Connecting the LCD TV to a PC........................... 13
Connecting to a DVD Player................................. 14
Using Side AV Connectors ................................... 15
Using Other Connectors....................................... 16
Connecting Other Equipment via Scart ................ 17
Inserting Batteries in the Remote Control
Handset ................................................................ 18
Operating Range for the Remote Control............. 18
Switching the TV On/Off ....................................... 18
To Switch the TV On......................................... 18
The TV will then switch on................................ 18
To Switch the TV Off ......................................... 18
Input Selection...................................................... 19
Basic Operations .................................................. 19
Operation with the Buttons on the TV............... 19
Volume Setting.............................................. 19
Programme Selection ................................... 19
Viewing Main Menu....................................... 19
AV Mode ....................................................... 19
Operation with the Remote Control .................. 19
Volume Setting.............................................. 19
Programme Selection (Previous or Next
Programme).................................................. 19
Programme Selection (Direct Access) .......... 19
Initial Settings ....................................................... 20
General Operation................................................ 21
Information Banner ........................................... 21
Electronic Programme Guide (EPG) .................... 21
Displaying the Subtitles .................................... 22
Digital Teletext (** for UK only) ......................... 22
Analogue Teletext ............................................. 22
Widescreen....................................................... 22
IDTV Menu System .............................................. 23
Channel List...................................................... 23
Navigating the Entire Channel List ............... 23
Moving the channels in the channel list ........ 23
Deleting the Channels in the Channel List.... 23
Renaming Channels ..................................... 24
Adding Locks to Channels ............................ 24
Setting Favourites......................................... 24
How to Add a Channel to a
Favourites List ........................................25
Removing a Channel from a
Favourite List..........................................25
On Screen Help ........................................... 25
Program Guide ............................................. 25
Timers............................................................... 25
Conditional Access ........................................... 26
TV Setup........................................................... 26
Setup ................................................................ 26
Configuration ................................................ 26
AC3 Audio (*for EU countries only) ........27
Hard of Hearing (*for EU countries only) 27
Favourite Mode.......................................27
Channel List ...........................................27
Scan Encrypted .....................................27
Receiver Upgrade ..................................27
Over Air Download (OAD) ......................27
Parental Control .....................................27
Time Settings..........................................28
Audio Description ...................................28
Standby Search (*) .................................28
Language...................................................... 29
Preferred.................................................29
Current....................................................29
Language Settings............................................ 29
Installation..................................................... 29
Automatic Channel Scan........................30
Manual Channel Scan ............................30
First Time Installation..............................30
Media Browser.................................................. 31
Playing MP3 Files............................................. 32
Viewing JPG Files............................................. 32
Slideshow Options............................................ 32
Video Playback ................................................. 32
Navigating the Analogue TV Menu System.......... 33
Analogue TV Menu System.................................. 33
Picture Menu..................................................... 33

English - 2 -
Mode............................................................. 33
Brightness/Contrast/Colour/Sharpness ........ 33
Colour Temp.................................................. 33
Noise Reduction ........................................... 33
Film Mode ..................................................... 33
Game Mode .................................................. 33
Picture Zoom ................................................ 34
Reset ............................................................ 34
Store ............................................................. 34
Sound Menu ..................................................... 34
Volume.......................................................... 34
Equalizer....................................................... 34
Balance......................................................... 34
Headphone ................................................... 34
Volume....................................................34
Store.......................................................34
Sound Mode ................................................. 35
AVL ............................................................... 35
Audio Out...................................................... 35
Effect............................................................. 35
Store ............................................................. 35
Dolby VS....................................................... 35
Dolby VS Mode............................................. 35
Feature Menu ................................................... 35
Movie Sense ................................................. 35
Pip-Pap ......................................................... 36
Pip-Pap...................................................36
Pip Size ..................................................36
PIP Position ............................................36
Source ....................................................36
Program..................................................36
Swap.......................................................36
Sleep Timer................................................... 36
Child Lock ..................................................... 36
Language...................................................... 36
Default Zoom ................................................ 36
Blue Background .......................................... 36
Menu Timeout ............................................... 37
Teletext Language ........................................ 37
Antenna Power (optional) ............................. 37
Ext Out.......................................................... 37
Install Menu ...................................................... 37
Program ........................................................ 37
Band ............................................................. 37
Channel ........................................................ 37
Colour System .............................................. 37
Sound System .............................................. 37
Fine Tune...................................................... 37
Search .......................................................... 37
Store ............................................................. 37
Install Menu in AV Modes.............................. 37
Colour System........................................38
Store ............................................................. 38
Program Table............................................... 38
Name......................................................38
Move.......................................................38
Delete .....................................................38
APS (Auto Programming System)..........38
Source Menu .................................................... 38
PC Mode Menu System........................................ 39
PC Position Menu............................................. 39
Autoposition .................................................. 39
H (Horizontal) Position.................................. 39
V (Vertical) Position ...................................... 39
Phase............................................................ 39
Dot Clock ...................................................... 39
PC Picture Menu........................................... 39
Sound Menu ................................................. 40
Feature Menu ............................................... 40
Source Menu ................................................ 40
Displaying TV Information .................................... 40
Mute Function....................................................... 40
PIP (Picture-in-Picture) and PAP (Picture-and-
Picture) Modes ..................................................... 40
Picture Mode Selection......................................... 40
Freezing Picture ................................................... 40
Zoom Modes......................................................... 40
Auto .................................................................. 40
16:9................................................................... 41
4:3..................................................................... 41
Panoramic......................................................... 41
14:9................................................................... 41
Cinema ............................................................. 41
Subtitle.............................................................. 41
Zoom................................................................. 41
Teletext ................................................................. 41
Tips....................................................................... 42
Screen Care...................................................... 42
Image Persistence............................................ 42
No Power.......................................................... 42
Poor Picture...................................................... 42
No Picture......................................................... 42
Sound ............................................................... 42
Remote Control................................................. 42
Input Sources.................................................... 42
Appendix A: PC Input Typical Display Modes....... 43
Appendix B: AV and HDMI Signal Compatibility
(Input Signal Types).............................................. 44
Appendix C: Pin Specifications............................. 45
SCART connector pin specifications ................ 45
HDMI connector pin specifications ................... 45
Signal Input....................................................... 45
PC RGB Terminal (D-sub 15-pin connector). 45
S-input connector pin specifications ................. 45
Appendix E: PIP/PAP Mode Combinations .......... 46
Appendix D: Supported File Formats for
USB Mode ............................................................ 47
Specifications ....................................................... 48
UK Guarantee....................................................... 49

English - 3 -
Features
• Remote controlled colour LCD TV.
• Fully integrated digital TV (DVB-T).
• Two HDMI connectors for digital video and
audio. This connection is also designed to
accept high definition signals.
• 200 programmes from VHF, UHF.
• OSD menu system.
• Two scart sockets for external devices (such
as video, video games, audio set, etc.).
• Stereo sound system. (German+Nicam)
• Teletext, fastext, TOP text.
• Headphone connection.
• Automatic programming system.
• Forward or backward manual tuning.
• Sleep timer.
• Child lock.
• Automatic sound mute when no
transmission.
• NTSC playback.
• PIP / PAP / PAT functions.
• AVL (Automatic Volume Limiting).
• When no valid signal is detected, after 5
minutes the TV switches itself automatically
to standby mode.
• PLL (Frequency Search).
• PC input.
• Plug&Play for Windows 98, ME, 2000, XP,
Vista.
• Audio line out.
• Game Mode.
• 100 Hz frequency scan.
• Movie Sense.
• Dolby VS
Accessories
TV DTV
M
INFO
123
456
789
0-/--
EXIT
SWAP
P<P I-II
SOURCE
AV
/
/
GUIDE
WIDE
PP
OK
SELECT
ABC DEF GHI
JKL MNO PQR
STU VWX YZ
P+
P -
+
RC 1050
Remote Controller
Batteries
2 X AAA
Instruction Book
Quick Guide
Cable Holer

English - 4 -
Introduction
Thank you for choosing this product. This
manual will guide you in the proper
operation of your TV. Before operating
the TV, please read this manual
thoroughly.
Please do keep this manual in a safe
place for future references.
Preparation
For ventilation, leave a free space of at least
10 cm all around the set. To prevent any faults
and unsafe situations, please do not place any
objects on top of the set.
Use this device in moderate climates.
Safety Precautions
Please read the following recommended
safety precautions carefully for your
safety.
Power Source
The TV set should be operated only from a 220-
240 V AC, 50 Hz outlet.
Power Cord
Do not place the set, a piece of furniture, etc.
on the power cord (mains lead) or pinch the
cord. Handle the power cord by the plug. Do
not unplug the appliance by pulling from the
power cord and never touch the power cord with
wet hands as this could cause a short circuit or
electric shock. Never make a knot in the cord or
tie it with other cords. The power cords should
be placed in such a way that they are not likely
to be stepped on. A damaged power cord can
cause fire or give you an electric shock. When it
is damaged and needs to be replaced, it should
be done by qualified personnel.
Moisture and Water
Do not use this device in
a humid and damp place
(avoid the bathroom, the
sink in the kitchen, and near
the washing machine). Do
not expose this device to
rain or water, as this may be
dangerous and do not place
objects filled with liquids,
such as vases, on top. Avoid
dripping or splashing.
If any solid object or liquid falls into the cabinet,
unplug the TV and have it checked by qualified
personnel before operating it any further.
Cleaning
Before cleaning, unplug the TV
set from the wall outlet. Do not
use liquid or aerosol cleaners.
Use soft and dry cloth.
Ventilation
The slots and openings on the TV set are
intended for ventilation and to ensure reliable
operation. To prevent overheating, these
openings must not be blocked or covered in
anyway.
Heat and Flames
The set should not be placed
near to open flames and
sources of intense heat such
as an electric heater. Ensure
that no open flame sources,
such as lighted candles,
are placed on top of the TV.
Batteries should not be exposed to excessive
heat such as sunshine, fire or the like.
Lightning
In case of storm and lightning
or when going on holiday,
disconnect the power cord
from the wall outlet.
Replacement Parts
When replacement parts are required, make
sure that the service technician has used

English - 5 -
replacement parts, which are specified by the
manufacturer or have the same specifications as
the original one. Unauthorized substitutions may
result in fire, electrical shock or other hazards.
Servicing
Please refer all servicing to
qualified personnel. Do not
remove the cover yourself as
this may result in an electric
shock.
Waste Disposal
Instructions for waste disposal:
• Packaging and packaging aids are recyclable
and should principally be recycled. Packaging
materials, such as foil bag, must be kept away
from children.
• Batteries, including those which are heavy
metal-free, should not be disposed of with
household waste. Please dispose of used
battery in an enviromentally friendly manner.
Find out about the legal regulations which
apply in your area.
• Cold cathode fluorescent lamp in LCD
PANEL contains a small amount of mercury;
please follow the local laws or regulations for
disposal.
Information for Users in European
Union Countries
The mark is in compliance
with the Waste Electrical
and Electronic Equipment
Directive 2002/96/EC
(WEEE).
The mark indicates the
requirement NOT to dispose
the equipment including any
spent or discarded batteries
as unsorted municipal waste, but use the return
and collection systems available. If the batteries
or accumulators included with this equipment,
display the chemical symbol Hg, Cd, or Pb,
then it means that the battery has a heavy
metal content of more than 0.0005% Mercury,
or more than 0.002% Cadmium or more than,
0.004% Lead.
Disconnecting the Device
The mains plug is used to disconnect TV set
from the mains and therefore it must remain
readily operable.
Headphone Volume
Excessive sound pressure from
earphones and headphones
can cause hearing loss.
Installation
To prevent injury, this device
must be securely attached to the wall in
accordance with the installation instructions
when mounted to the wall (if the option is
available).
LCD Screen
The LCD panel is a very high technology product
with about a million thin film transistors, giving
you fine picture details. Occasionally, a few
non-active pixels may appear on the screen
as a fixed blue, green or red point. Please note
that this does not affect the performance of
your product.
Warning
Do not leave your TV in standby or operating
mode when you leave your house.
LICENSE NOTICE
Manufactured under license from Dolby
Laboratories.
TRADEMARK ACKNOWLEDGMENT
“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.

English - 6 -
Overview of the Remote Control
TV DTV
M
INFO
123
456
789
0-/--
EXIT
SWAP
P<P I-II
SOURCE
AV
/
/
GUIDE
WIDE
PP
OK
SELECT
ABC DEF GHI
JKL MNO PQR
STU VWX YZ
P+
P -
+
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
RC 1050
Standby1.
Cursor up2.
Cursor right3.
Info4.
Numeric buttons5.
Exit (in DTV mode)6.
Programme up7.
Volume up8.
TV / Digital TV9.
AV / Source10.
Yellow (Feature menu) / Current language11.
(*)
Blue (Install menu) / Favourite selection (*)12.
Hold (in TXT mode) / PIP position13.
Update (in TXT mode) / PAP mode14.
Index page / Guide (in DTV mode)15.
Reveal (in TXT mode) / Switch from TV to16.
PC
Expand (in TXT mode) / Image Size17.
Mix (in TXT mode) / PIP mode18.
Teletext19.
Time / Subtitle on-off20. (**) (in DTV mode)
Red (Sound menu) /21. Channel list (in DTV
mode)
Green (Picture menu) /22. Subtitle (*) (in DTV
mode)
Swap / Previous programme23.
Mono/Stereo - Dual I-II24.
Programme down / Page up (in DTV25.
mode)
Volume down26.
Personal preferences27.
Okay (store) / Select (in DTV mode)28.
Cursor down29.
Cursor Left30.
Menu31.
Mute32.
(*) Only available for EU country options.
(**) Only available for UK country option.

English - 7 -
LCD TV and Operating Buttons
FRONT VIEW
REAR VIEW
SIDE VIEW
Standby button1.
TV/AV button2.
Programme Up/3.
Down buttons
Volume Up/Down4.
buttons
Note: Press “ ”/
“ ”buttons at the
same time to view main
menu.

English - 8 -
Viewing the Connections- Back Connectors
12 13 14
1. S/PDIF Digital Out outputs digital audio signals of the currently watched source.
Use a digital optic cable to transfer audio signals to a device that has S/PDIF input.
2. Subwoofer Out is for connecting an external, active subwoofer to the set to give a much
deeper bass effect.
Use an appropriate RCA cable to connect the set to a subwoofer unit.
Audio Line Out3. outputs audio signals to an external device such as an optional sound
system.
To connect an external amplifier and speakers to your TV; connect the TV’s audio LINE
OUT sockets to the line input sockets on an external amplifier with a stereo phono to phono
cable.
4. SCART 2 inputs or outputs for external devices.
5. SCART 1 inputs or outputs for external devices.
Connect the SCART cable between SCART sockets on TV and SCART socket on your
external device (such as a decoder, a VCR or a DVD player).
Note: If an external device is connected via the SCART sockets, the TV will automatically
switch to AV mode. If both sockets are employed at the same time, SCART 1 will override
SCART 2 unless manually selected.
Note: You should connect the decoder to EXT-1, if you are planning to watch a scrambled
channel. The decoder might not function properly if you do not connect the decoder to the
Scart 1 (Ext-1) socket.

English - 9 -
6. Component Video Inputs (YPbPr) are used for connecting component video.
You can connect the component video and audio sockets with a device that has component
output. Connect the component video cables between the COMPONENT VIDEO INPUTS
on on the TV and the component video outputs of your device. While connecting, be sure
that the letters on your TV, “Y”, “Pb”, “Pr” correspond with your device’s connectors.
7. PC/YPbPr Audio Inputs are used for connecting audio signals of a PC or a device that
connects to the TV via YPbPr.
Connect the PC audio cable between the AUDIO INPUTS on the TV and audio output of
your PC to enable PC audio.
Connect the audio cable between AUDIO IN on the TV and audio outputs of your device to
enable component audio.
8. S/PDIF Coaxial Out outputs digital audio signals of the currently watched source.
Use an SPDIF coaxial cable to trasfer audio signals to a device that has S/PDIF input.
ANT Input9. connects to an aerial.
Note that if you use a decoder or a media recorder, you should connect the aerial cable
through the device to the television with an appropriate aerial cable, as shown in the
illustration on the following pages.
10. PC Input is for connecting a personal computer to the TV set.
Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.
11. RS232 Service pin
12. HDMI 3: HDMI Input
HDMI 2:13. HDMI Input
14. HDMI 1: HDMI Input
HDMI Inputs are for connecting a device that has an HDMI socket.
Your LCD Television is capable of displaying High Definition pictures from devices such as
a High Definition Satellite Receiver or DVD Player. These devices must be connected via
the HDMI sockets or Component Socket. These sockets can accept either 720p or 1080i
signals. No sound connection is needed for an HDMI to HDMI connection.
When you use the wall mount kit (not provided with the LCD TV), we would definitely recommend
to plug all your cables into the back of the LCD before mounting to the wall.

English - 10 -
Viewing the Connections - Side Connectors
CI Slot is used for inserting a CI card. A CI card allows you to1.
view channels that you subscribe to. For more information,
see “Conditional Access” section.
Side USB input.2.
Note: Codec update cannot be performed.
Side HDMI Input is for connecting a device that has an HDMI3.
socket. Note that PIP/PAP function will not be available while
in HDMI-4 source.
4. Headphone jack is used for connecting an external
headphone to the system. Connect to the HEADPHONE jack
to listen to the TV from headphones.
Video Input is used for connecting video signals5. from external
devices.Connect the video cable between the VIDEO IN
socket on the TV and the VIDEO OUT jack on your device.
Audio Inputs are used for connecting audio signals6. from
external devices. Connect the audio cable between AUDIO
IN on the TV and the AUDIO OUTPUT jacks on your device.
Note: If you connect a device to the TV via the VIDEO INPUT,
you should also connect your device with an audio cable to
AUDIO IN on the TV to enable audio.
S-Video Input is used for connecting an S-Video signal (e.g.7.
from a camcorder or VCR). For using S-VIDEO input; connect
the video cable between the S-VIDEO input on the TV and
the S-Video output on your device. Connect the audio cable
between the AUDIO INPUTS (indicated with letter C in the
illustration) on the TV and the audio jacks on your device.
Standby switch is used for turning the TV on or off.8.
C

English - 11 -
Power Connection
IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.
• After unpacking, allow the TV set to reach the ambient room temperature before you connect
the set to the mains.
• Plug the power cable to the mains socket outlet.
Aerial Connection
• Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.
Using the Cable Holder
You can use the supplied cable holder as the following:
• Place the cable holder into the cable holder hole located on the rear side of the TV as illustrated
above.
• Place cables into the cable holder after all necessary connections are made.
REAR VIEW

English - 12 -
Using Digital Multimedia Connectors
• You can connect USB devices to your TV by using the USB input of the TV. This feature allows
you to display/play JPG and MP3 files stored in a USB stick.
• It is possible that certain types of USB devices (e.g. MP3 Players) may not be compatible with
this TV.
• You may back up your files before making any connections to the TV set in order to avoid any
possible data loss. Note that manufacturer will not be responsible for any file damage or data
loss.
• Do not pull out USB module while playing a file.
CAUTION: Quickly plugging and unplugging USB devices, is a very hazardous operation.
Especially, do not repeatedly quickly plug and unplug the drive. This may cause physical
damage to the USB player and especially the USB device itself.
SIDE VIEW USB MEMORY
USB Memory Connection
• Plug your USB device to the USB input of the TV.
Note: USB hard disk drives are not supported.
• It is recommended that you connect your USB device directly to the USB input of the TV. Some
compatibility problems may occur if you use a separate cable connection.
Side HDMI Connection
You can use side HDMI input to connect a device that has an HDMI connector to your TV. Use
an appropriate HDMI cable to make such a connection. Note that you should switch to HDMI-
4 source to view the content from the connected device. Power off both the TV and the device
before making any connections.
• Side HDMI Input supports connections between HDMI devices such as DVD players. You can
use side HDMI input of the TV to connect to an external HDMI device. Use an HDMI cable to
connect.
HDMI DEVICE SIDE VIEW
HDMI
DEVICE
SIDE
VIEW

English - 13 -
Connecting the LCD TV to a PC
For displaying your computer’s screen image on your LCD TV, you can connect your computer
to the TV set.
• Power off both computer and display before making any connections.
• Use 15-pin D-sub display cable to connect a PC to the LCD TV.
• When the connection is made, switch to PC source. See “Input selection” section.
• Set the resolution that suits your viewing requirements. Resolution information can be found in
the appendix section.
REAR VIEW
PC audio cable
(not supplied)
to AUDIO INPUTS
on the TV
PC RGB cable
(not supplied)
to PC input
Audio
Inputs
PC Input

English - 14 -
Connecting to a DVD Player
If you want to connect a DVD player to your LCD TV, you can use connectors on the TV set. DVD
players may have different connectors. Please refer to your DVD player’s instruction book for
additional information. Power off both the TV and the device before making any connections.
Note: Cables shown in the illustration are not supplied.
• If your DVD player has an HDMI socket, you can connect via HDMI. When you connect to DVD
player as illustrated below, switch to HDMI source. See, “Input Selection” section.
•Most DVD players are connected through SCART sockets. Use a scart cable to connect as
shown below.
•You may also connected through COMPONENT sockets. Use a component video cable to connect
video input. For enabling audio, use a component audio cable as illustrated below. When done,
switch to YPbPr source. See, “Input selection” section.
Note: These three methods of connection perform the same function but in different levels of quality. It is not
necessary to connect by all three methods.
HDMI
inputs
Scart sockets
Component
video
inputs
Component
audio
inputs
DVD Player
REAR VIEW

English - 15 -
Using Side AV Connectors
You can connect a range of optional equipment to your LCD TV. Possible connections are shown
below. Note that cables shown in the illustration are not supplied.
• For connecting a camcorder, connect to the S-VIDEO or VIDEO IN socket and the AUDIO
SOCKETS. Do not connect the camcoder to S-VIDEO and VIDEO IN socket at the same time
since it can cause noise in the picture. For selecting the related source, see the section “Input
selection” in the following parts.
• To listen the TV sound from headphones, connect to the HEADPHONE jack of theTV.
Camcorder
Headphone
SIDE VIEW

English - 16 -
Using Other Connectors
You can connect a range of optional equipment to your LCD TV. Possible connections are shown
below. Note that cables shown in the illustration are not supplied.
• For connecting a to a device that has SPDIF support, use an appropriate SPDIF cable to enable
sound connection.
• To connect external speakers; connect the audio output sockets on the TV to an external amplifier
that is connected to a speaker system.
• After connecting the cable between your TV and external amplifier, turn your TV and amplifier
on.
• You can refer to your amplifier and speaker set instruction manual for further information.
External Speakers
A device that
supports
SPDIF signal.
REAR VIEW

English - 17 -
Connecting Other Equipment via Scart
Most devices support SCART connection. You can connect a; DVD recorder, a VCR or a decoder
to your LCD TV by using the SCART sockets. Note that cables shown in the illustration are not
supplied.
Power off both the TV and the devices before making any connections.
For more information, refer to your device’s own instruction book.
REAR VIEW
Scart sockets
Decoder
DVD Recorder Video Recorder

English - 18 -
Inserting Batteries in the
Remote Control Handset
• Remove the battery cover located on the back
of the handset by gently pulling backwards
from the indicated part.
• Insert two AAA/R3 or equivalent type batteries
inside. Place the batteries in the right directions
and replace the battery cover.
Note:If you are not going to use the remote control
for a long period, please remove the batteries in
order to avoid any battery leakage. Otherwise, the
remote control can get damaged because of battery
leakage.
Operating Range for the
Remote Control
• Point the top of the remote control toward the
LCD TV’s remote sensor LED while pressing
a button.
30 30
TV DTV
M
INFO
123
456
789
0-/--
EXIT
SWAP
P<P I-II
SOURCE
AV
/
/
GUIDE
WIDE
PP
OK
SELECT
ABC DEF GHI
JKL MNO PQR
STU VWX YZ
P+
P -
+
Remote range is approximately 7m/23ft.
Switching the TV On/Off
To Switch the TV On
· Connect the power cord to the 220-240V AC
50 Hz.
· Switch the “ ” button to position “|” so the TV
will switch to standby mode. Then the standby
LED lights up.
· To switch on the TV from standby mode
either:
· Press the “ ” button, P+ / P- or a numeric
button on the remote control.
· Press the -P/CH or P/CH+ button on the TV.
The TV will then switch on.
Note: If you switch on your TV via PROGRAMME
UP/DOWN buttons on the remote control or on the
TV set, the programme that you were watching last
will be reselected.
By either method the TV will switch on.
To Switch the TV Off
• Switch the “ ”button to position 2 as
illustrated, ( ) so the TV will switch OFF.
•To power down the TV completely, unplug
the power cord from the mains socket.
Note: When the TV is switched to standby mode,
standby LED can blink to indicate that features such
as Standby Search, Over Air Download or Timer is
active.

English - 19 -
Input Selection
Once you have connected external equipment
to your TV, you can switch to different input
sources.
• Press “ ”repeatedly on the remote control
to select the required source.
or,
• Select “Source” option from the main menu
by using “ ” or “ ” button. Use then “ ” or
“” button to highlight an input and press “
” button to select.
Note: You can mark desired source options by
pressing the OK button. Therefore, when “ ” button
is pressed, only the marked source options will be
available (except for the TV source).
Basic Operations
You can operate your TV using both the
remote control and onset buttons.
Operation with the Buttons on the TV
Volume Setting
• Press “ ” button to decrease volume or
button to increase volume, so a volume
level scale (slider) will be displayed on the
screen.
Programme Selection
• Press “P/CH +” button to select the next
programme or “P/CH -” button to select the
previous programme.
Viewing Main Menu
• Press “ ”/“ ”buttons at the same
time to view main menu. In the Main menu
select sub-menu using “P/CH -” or “P/CH +”
buttons and enter the sub-menu using “
” or “ ” buttons. To learn the usage of the
menus, refer to the menu system sections.
AV Mode
• Press the “TV/AV” button in the control panel
on the TV to switch between AV modes.
Operation with the Remote Control
• The remote control of your TV is designed
to control all the functions on your TV. The
functions will be described in accordance with
the menu system of your TV.
• Functions of the menu system are described
in the following sections.
Volume Setting
• Press “ ” button to increase the volume.
Press “ button to decrease the volume.
A volume level scale (slider) will be displayed
on the screen.
Programme Selection (Previous or Next
Programme)
• Press “P -” button to select the previous
programme.
• Press “P +” button to select the next
programme.
Programme Selection (Direct Access)
• Press numeric buttons on the remote control
to select programmes between 0 and 9. The
TV will switch to the selected programme.
To select programmes between 10 - 299
(for IDTV) or 10-199 (for analogue), press
the numeric buttons consecutively (e.g. for
programme 27, first press 2 and then 7).
When the pressing time is due for the second
numeric button, only the first digit programme
will be displayed. The limit of the delay time
is 3 seconds.
• Press directly the programme number to
reselect single digit programmes.
