Hitachi R-S800PT0 User manual

Contents
Preparation for Use
Preparations before Use
Operation
Location of Food Storage
.......................
Parts Removal
....................................
Troubleshooting
2
.......................................
5
.......................................
6
..........................
6
...................
7
10-11
15
15
.............................
No Frost
Refrigerator
Refrigerant
For household use only
R600a
Model
...........................................
................
5
......................................
16
Warnings and Cautions for Safety
Freezer Compartment
Refrigerator Compartment
................
........................
18
Maintenance General Matter ...............
Maintenance and Troubleshooting
R-S800PT0
How to use Control panel
.......................
8
.................................
8
.................................
8
Serviece center
Installation
Before Use
Optimal Food Storage
Name and fuction of
The Control Panel
Temperature control
How to remove parts
General Problems
Dew or Frost is generated
.....................................
19
Instruction Manual
Thank you very much for purchasing the HITACHI refrigerator.
Before using this please read the instruction manual carefully for the correct usage.
Maintenance work must only be carried out at workshop
by well-trained maintenance worker
Other function
...........................................
9
12-13
14-15
16-17

Warning
Caution
This pictograph indicates "There is high possibility
of serious injury or death, if ignored".
This pictograph indicates "There is a high possibility
of injury or damage to property if ignored".
When you install ... T y.
Do not use a damaged or loose power plug or
Do not insert or remove the power plug with wet hands.
Do not splash water on or inside the refrigerator.
This may impair electricity insulation causing
Do not disassemble, repair, or modify your
refrigerator by yourselves.
Please consult with a retailer
if any repair is required.
If the supply cord is damaged,it must be replaced
by the manufacturer, its service agent or similarly
Do not put water containers or foreign
articles on the top of the refrigerator.
Opening and closing doors etc. may cause
the articles on the top of the refrigerator may
fall down, resulting in injury.
Be sure to unplug the power plug before maintaining
the refrigerator.
Be sure to hold the power plug to unplug.
Clean the dust on the power plug frequently with a dry cloth.
Unplug the power plug and wipe it with a dry cloth.
An insulation failure due to moisture, when dust
running down.
Connection of the power plug with the ord running up could
apply stress on the cord and cause electrical short or overheat,
Incomplete connection of the power plug could
Power Cord and Power Plug ...T
The symbols below are examples.
This symbol indicates "prohibited".
This symbol indicates "necessary".
WARNING
Rated
Voltage
During daily use ...T
2
harm or damage that may occur from ignoring directions.
This symbol denotes the precau
Do not use other electrical appliances
in the food storage compartment,
unless it is the type
recommended by
the manufacturer.
Do not use mechanical devices or other means
to accelerate the defrosting process,other than
those recommended by the manufacturer.
Do not install the refrigerator in a place where it
may come in contact with water.
Do not install the refrigerator in a place exposed to rain.
This may impair electricity insulation and
interference. Always ground this refrigerator and install earth
or moisture.
(Please consult with a retailer or Hitachi Service Center.)
Do not connect the wall outlet whose power capacity is less than the
refrigerator's. Also, do not use power sources
that are not a rated voltage.
If a power source is shared with other appliances
using double or multipoint adapters, the adapter
or portable power supplies at the rear of the appliance.
Warnings and Cautions for Safety follow the warnings and cautions below and those given throughout this manual.
To avoid harm to the user, other persons or damage to property,please read and

During daily use ...T
and is dangerous.
WARNING
.
3

During daily use ...To avoid illness and injury.
Food and containers inside the
freezer compartment should not
be touched with wet hands.
This may cause frost injury.
(Especially in case of metal items.)
Do not hold the top, bottom and
side of the doors when closing them.
caught by the door edge.
If someone else is using the
refrigerator, do not open or
operate the control panel.
Fingers may get caught in the
spaces between the doors and may cause injury.
Do not use door handles when carrying
the refrigerator.
up with a chain hoist or similar machines.
do move the refrigerator using
the wheels at its base.
lay a protective mat , etc. .
Use the carrying handle when carrying the refrigerator.
Hold the carrying handles only. If you hold door handles, your hands may slip and may cause injury.
More than 4 persons should carry the refrigerator for safety reasons.
Carry it with the doors facing upward.
Before carrying the refrigerator:
ottom
of the refrigerator.
Secure the doors well with adhesive tapes so they do not open.
If transporting in a vehicle, do not load the refrigerator on its side. This could damage the compressor.
Do not put your hands into the bottom
surface of the refrigerator cabinet.
When cleaning, putting your hands
near the bottom surface of the
refrigerator may result in injury by thin metal sheets.
Do not have your feet too
close when opening the door
of the refrigerator.
When opening the door, your
feet may be hit, resulting in injury.
to open and close the door.
CAUTION
When moving or carrying ...T r or to avoid injury.
4
Do not put bottles, etc. forcibly in
This may cause bottles dropping
Do not store food which smells or
food whose color is changed
abnormal.
Such an action may cause diseases.
Do not store glass bottles in the freezer
compartment.
freezing and cause injury.
over the front edge of each shelf.
Doors may not be closed properly or
Such as old cloth
Warnings and Cautions for Safety follow the warnings and cautions below and those given throughout this manual.
To avoid harm to the user, other persons or damage to property,please read and

5
Remove 2 screws (both sides)
Earthing cord
Earthing Terminal
Fix with earth screws
Without adjusting the legs, door height may not be level, or there
may be abnormal vibration or r conditions.
Follow the instructions below.
Turn the adjustable legs to lower the adjustable
r firmly.
Compare the height of left and right doors and
lower adjustable leg whose door
height is lower than the other until the both door
height become level.
Turn the adjustable leg for 1 turn makes approx.
1 mm door height change.
It will take sever r
and the door height becomes stable.
In case that the adjustable legs are dif rn:
emove 2 screws and then remove the adjuster cover.
Insert a screw driver to a groove of the adjustable
leg and turn.
4. Earthing wiring.
5.
Ground this refrigerator to prevent electric shock and noise interference.
Always ground this refrigerator when using it in places with high humidity
or moisture. (Please consult with retailers.)
Install on a r r.
r, place a wood board (1cm thick)
and place the refrigerator on the board.
r may be deformed or r color may be
changed due to a heat from the refrigerator.
In case of soft or fr rs on which the refrigerator might incline.
Do not install where the refrigerator is exposed on a direct sunlight or other heat sources.
Such circumstances may result in poor cooling performance or electricity costs increase.
Direct sunlight will cause discoloration of the plastic parts of the refrigerator.
Install in a atmosphere which is dry or has air ventilation.
This helps to avoid rusting and keeps electricity costs down.
* If you wish to install the refrigerator in a hot spring area
you may need to apply anti-rust treatment to the piping. Contact your dealer in advance.
A failure caused by that gas damage will not be covered under guarantee.
3. Allow enough space to release heat.
The refrigerator requires enough air ventilation space
around the cabinet to have ef rformance.
At least 5 cm space must be secured for the left/right,
top and back side of the refrigerator to the wall.
To ensure that the doors can open properly and fully,
make sure that the following space is avilable.
Please check the available space before installation
.
Following shows the installation dimensions for this refrigerator. Be sure to check if you with refrigerator can pass the house doors.
The refrigerator doors may have to be removed if the width or depth of the refrigerator are more than the width of the house doors.
To remove the refrigerator door, please consult with the retailer.
1. Check the width of the doors of the house.
1 cm.
.
5 cm.
5 cm.
179.5 cm
Adjuster Cover
Adjustable
Leg
The left door is lower.
Lower the left adjustable leg
The right door is lower
Lower the right adjustable leg
5 cm.
37 cm.
92 cm.
27 cm.
1
Adjusting the adjustable legs to keep the left/right
refrigerator door level.
Installation
2. Install the refrigerator in the following place.
Preparations before Use
WARNING
Do not connect the ground line to a gas pipe,
telephone line or lightning rod.

A refrigerator is not an appliance that increases the freshness of food but it is an appliance to brake the food being spoiled to
some extent. Please follow the User’s Guide carefully and take proper actions to keep food fresh.
1. Cleaning inside the refrigerato
r.
2. Connect the refrigerator to an exclusive wall power outlet.
The refrigerator can be connected to an outlet soon after it is installed.
3.
Allow enough duration for su
f
Keep enough space between food.
temperature and wastes electricity.
keep the temperature
inside even. Moreover,
it could result in food
near the vent freezing.
Using plastic wrap or sealed
containers prevents the
food from drying or
transition of smells.
Keep food hygienic.
unhygienic substances
can be found on food.
6
2
3
30 seconds after the power is connected, the compressor will start.
NOTICE
Before Use
Optimal Food Storage
Do not block the cold air vent.
Make food cool enough before putting it in the refrigerator.
Keep the food wrepped or sealed and store.
Do not place warm food on the chilled food.
Preparation before Use

7
Freezer Compartment
Refrigerator Compartment 2 5
NOTICE
Storage of packed small
food and drink such
as juice,milk,etc.
Refrigerator Door Pockets
Refrigerator Shelves
Storage of side dish,dessert,etc.
Vegetable Drawer
Storage of fruits and vegetable
Freezer Drawers
Storarage of packed small
frozen food
Not recommended for long
storage, because temperater
rise caused
by door open
may occur.
Freezer Door Pockets
Storage of frozen food and ice
cream,etc.
Freezer Shelves
Cheese
C , the setting of the refrigerator
compartment, freezer compartment while doors being closed and without food storage is shown in the table.
Location of Food storage
made by twist Ice maker
Twist Ice Maker

How to use Control panel
1
2
8
Temperature Control
Control Panel
Setting Refrigerator
Temperature button
Setting Freezer
Temperature button
“Quick Mode” Button
Control Panel
Name and Function of the Control Panel
This refrigerator control its temperature automatically Please adjust a temperature control dial as follows.
When not storing frozen
food or ice cream
For normal use. When making ice quickly or making
frozen food quickly or a surrounding
temperature is high and the freezer
compartment is not cold enough.
For food that doesn’t need
a lot of coldness.
For normal use. When cooling food more coldly
or quickly.

9
1
2
Cancel
You can set temperature by normal step ( 3 steps).
This function is subjected to change according model type.
Press button “Refrigerator”
for 5 seconds until 1 “PiPi!”
sound is heard.
Factory setting, the adjustment temperature by normal step ( 3 steps).
Setting
(Refrigerator compartment/ Freezer Compartment)
Press button “Refrigerator”
for 5 seconds until
1 “Peep!” sound is heard.
Each time you press the button, the corresponding indicator lamp changes in order shown below (9 steps).
Open the Refrigerator door before press buttom “Refrigerator” to setting.
( Lighting Blinking Turned off )
Quick Freezing/Quick Cooling/Energy Saving
Quick Cooling :
When you want to cool food or drinks quickly, use this function
When you want to freeze food or make ice quickly, use this function
Quick Freezing :
operation, lamp light is on.
Press button “First time”
for Start Quick Freezing
After 2 hours (approx.) Quick freezing
operation will be finished, lamp light is off.
1
3
for start two function operation,
Press button “Third time”
lamp both light is on.
Press button“Fourth time”
Energy Saving : Recommend to use this function in case of low storage volume, or a long vacation when the doors are not opened for long time.
2
operation, lamp light is on.
Press button“Second time”
for Start Quick Cooling
After 90 minutes (approx.) Quick cooling
operation will be finished, lamp light is off.
4
5
Press button“Fifth time”
for stop all function operation
lamp light is off.
operation, lamp light is on.
for Start Energy Saving
If “Energy Saving” operation is working in high humidity
environment, dew may appear
on refrigerator surface
.
Please stop “Energy Saving” operation in this case.
CAUTION
NOTICE
and closing the doors not to have a temperature rise of the refrigerator compartment.
uick coolin
defrost period, the operation will restart automatically.
g
freezer compartment will be done, Thus, try to avoid unnesessary opening
How to use temperature control
Other Functions
NOTICE
Indication
lamp
Setting Min MaxNormal

CAUTION
CAUTION
T
10
Adjustable-height Shelves
T
Quick Freezing
Freezer Drawers
Freezer Compartment
