Hitachi 65QLEDSM20 User manual

User Manual
65QLEDSM20

2
Welcome
Congratulations on your purchase!
This manual tells you all you need to know about using your new Hitachi product.
Please take special note of any important safety and usage information presented with the symbol.
All products brought to you by Hitachi are manufactured to the highest standards of performance and safety and, as part
of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for many years to come.

3
Contents
Welcome 2
Contents 3
Unpack and Prepare 4
What's in the box 4
Important Tips 5
Attaching the stand 6
Wall-mounting the TV 7
Connect to power 8
Connect your antenna 8
Controls and Connections 9
Get to know your TV 9
Control joystick on the TV 9
Ports on the TV 10
Remote Control 12
Setup 12
Using the Remote Control 13
Remote Pairing 13
Remote Overview 14
On-Screen Set Up 16
How to access other devices
connected to the TV 17
How to turn on/o subtitles in
live TV mode 17
How to play personal videos,
photos and music 17
Smart TV 18
Download or Delete Apps 19
Stream using Chromecast-
enabled Apps 20
Using Voice Interaction 21
Connect To Google Home 21
TV Setting Menus 22
Picture 24
Sound 26
Channel 27
Network & Internet 28
Accounts and Sign-in 30
Google Assistant 30
Apps 31
Retail Mode 31
About 32
Date & Time 33
Inputs 34
Power 35
Screen Saver 36
Location 36
Accessibility 37
Reset 37
Remotes & accessories 38
High Dynamic Range (HDR) 39
TV Guide 40
Recording 41
Recording Live TV 42
Scheduled Recording 42
Playback 42
Pause Live TV (Time-shift) 43
Troubleshooting 44
Specifications 47
Compliance and
Responsible Disposal 48

4 | UNPACK AND PREPARE
See the top box flap for
how to handle the TV
without damaging it!
Unpack and Prepare
What's in the box
Before installing your new TV, check you have everything
needed.
In the box you will find:
A. 65" Ultra HD Android TV
B. Remote Control
C. AAA Batteries
D. Mini AV Adaptor
E. TV Stands
F. Screws for the TV Stand
G. Warning Sheet
H. TV Toppling Safety Message
I. Quick Start Guide
J. Warranty Certificate
K. General Safety Warnings
L. User Manual
You will need:
• Phillips-head screwdriver (for stand installation)
• Someone to help you lift and install your TV
• Google account
• Internet connection (to access Smart TV apps and
functionality)
• Antenna cable (to watch live TV)
D
F
G
HIJKL
E

UNPACK AND PREPARE | 5
Important Tips
• Place the TV on a level surface.
• Place the TV away from any source that may generate heat or vibrations.
• Make sure there is enough space around vents for airflow.
• The remote control works up to 5 metres away from the TV.
• Unplug the TV before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Use only the power supply provided.
• It is highly recommended to use safety straps for securing the TV in place.
• Keep liquid, children and pets away from the TV at all times.

6 | UNPACK AND PREPARE
Unless you are wall-mounting the TV, you will need to
attach its stand/legs.
1. Lay the TV face-down on a soft, flat surface (like the
sofa, or a towel on a table) larger than the TV itself.
2. Match the stands to the installation points on the
underside of the TV.
3. Attach the stands to the TV at the installation points
using the screws provided. (Grab a screwdriver for
this bit).
Attaching the stand
• This TV is heavy! We recommend asking someone
to help you lift it.
• Unplug the TV from the power outlet before
installing or removing the stand.
• DO NOT place the TV standing upright without
its stand attached; it could damage the remote
sensor at the bottom of the TV.
• Only touch the frame, not the screen.
• It is highly recommended to use safety straps for
securing the TV.
CAUTION!
Do not apply
excessive force as
you might damage
the screw holes.
1
2
3

UNPACK AND PREPARE | 7
400mm
Back of the TV
200mm
Wall-mounting the TV
The TV comes with holes on the back panel for use with
wall-mounting brackets (bracket not included).
Use four standard M6*12mm screws (or longer, depending
on the mounting bracket) to wall-mount this TV (screws are
not included).
• Unplug the TV from the power outlet before
wall-mounting.
• Contact a professional for assistance with
wall-mounting the TV.
Required
• VESA Mounting
Bracket
• 4 x M6*12mm
screws (or longer
as required)
The screws in the package are for securing the TV stand
only. If you are wall-mounting the TV, consult a qualified
installer for advice on bracket support and wall support.

8 | UNPACK AND PREPARE
Free-to-air TV in HD (High Definition)
High Definition (HD) channels
provide the best viewing quality and
are available with a digital antenna
connection.
TV channels in Ultra HD resolution are not
currently available in Australia. Therefore
when you watch HD broadcast signals on
an Ultra HD TV, the picture can appear 'soft'
and lacks the detail you see when watching
the same content on an HD TV.
Connect to power
Make sure the TV is switched off at the power outlet
until you have finished connecting your cables.
Connect your antenna
Antenna cable not included.
ABC HD
SBS ONE HD
7HD
9HD
10 HD
PRIME7 HD
WIN HD
Example
HD Channels
Don't forget to plug in the TV
to the power outlet. Leave
the power switched off until
installation is finished.

CONTROLS AND CONNECTIONS | 9
1. : Select the next channel or move up.
2. + : Increase the volume level or move right.
3. - : Decrease the volume level or move left.
4. : • When TV is on standby, press to turn on.
5. : Select the previous channel or move down. See next page for more info on the connections.
Controls and Connections
Control joystick on the TV
Get to know your TV
1
2
3
4
5
On/Standby light and
Remote sensor
Bottom View
• When TV is on, press to enter the menu.
Use the joystick to navigate around the interface
and press to enter the highlighted item.
• When TV is on, press and hold to put TV on
standby.

10 | CONTROLS AND CONNECTIONS
1USB
STORAGE
• Plug in a USB stick to PVR record and pause live TV.
• Play media files stored on your USB storage device (supported file codecs and
extensions may vary).
• Update the TV software via USB.
2
HDMI IN
Use a high-speed
HDMI cable for
best picture and
sound quality.
SOUND
COMPUTER
All-digital connection between the TV and any HDMI device. Supports Ultra HD
resolution. Requires a high-speed HDMI cable (not included).
3
Headphone
Jack
SOUND
Connect to your headphones, amplifier, soundbar or audio device, using an AUX
cable (not included).
Ports on the TV
12 3
USB 2.0
(5V 500mA)
HDMI IN
1
