Hitachi SF-P130TCV User manual

Instruction Manual
Washing Machine
Fully Automatic
Model
SF-P130TCV
Thank you for purchasing a Hitachi fully automatic washing
machine.
■Please read this Instruction Manual carefully for proper
operation of the machine.
■Please keep this Instruction Manual for future reference.
$XWR
6HOI&OHDQ 1RUPDO 3UHZDVK %ODQNHW
+HDY\
(DV\5HIUHVK
&
6WDLQ&DUH &
$OOHUJ\&DUH
6RDN (QHUJ\6DYH:DWHU6DYH
6SHHG\'HOLFDWH
:DWHU3RZHU
6KRZHU3OXV
+ROGVHF
3RZHU2Q2
'HOD\7LPHU :DWHU/HYHO :DVK 5LQVH 6SLQ
0HPRU\7XE&OHDQ 7XE'U\
3URJUDP
6WDUW3DXVH
7LPH/HIW
0LQ 0LQ 0LQ
(;
7LPHV
:DWHU/HYHO
/
K
For household use only
EN
Contents
Preparation for use
Environmentally Friendly Waste Disposal.... 2
Hints and Tips for Eco-friendly Washing...... 2
Safety Instructions.......................................... 3
Installation........................................................ 5
nParts and Accessories ................................ 5
nControl Panel and Display........................... 6
nPreparation Before Use............................... 8
Operation
How to Use the Washing Machine................. 9
Program Overview........................................... 16
List of Programs.............................................. 17
nHow to Customize the Program.................. 20
In Case of Power Outage................................ 23
Maintenance
Care and Maintenance .................................... 24
Troubleshooting.............................................. 25
Error Codes...................................................... 26
How to Install the Washing Machine ............. 27
Customer Service............................................ 31
Specifications.................................................. 31

2
Environmentally Friendly Waste Disposal
Disposing of the packaging
The shipping package has protected your new washing machine on its way to your home. All materials are
ecologically harmless and recyclable. Please contribute to a better environment by disposing of packaging
materials in an environmentally conscious manner.
Ask your dealer about current means of disposal.
Risk of choking!
Do not let children play with packaging and associated parts.
There is a risk of suffocating with plastic bags and collapsible boxes.
Disposing of your old appliance
Old appliances are not worthless rubbish. Environment-conscious recycling can reclaim them to valuable
new materials.
Risk of death!
Unplug the power plug from appliances you are no longer using. Cut offthe power cord and dispose of it
with the plug.
If you wish to discard this product, contact your local authorities or dealer and ask for the correct method of
disposal.
Hints and Tips for Eco-friendly Washing
nKeep the load limit of each program.
nThis washing machine features power-saving operations with a built-in inverter controller which enables
the machine to optimize operations according to the conditions of your clothes.
nAdd detergent according to the degree of soiling, laundry size, and water hardness. Follow the detergent
manufacturer's instructions regarding the amount of detergent to use.
nYou may enjoy further enhanced water-saving technology such as “Spin Shower Rinse” with this
Washing Machine: water consumption is less than the former models.

3
Safety Instructions
This washing machine is designed for home use only.
Before operating the washing machine, please read these safety instructions carefully.
WARNING
Issues which could cause death or serious injury.
General safety
nDo not dismantle, repair or modify the washing machine.
This could cause malfunction, fire, electric shock or injury.
Contact your local service center for repairs.
nDo not put fire sources or anything inflammable in or near the washing machine (gas, diesel, petroleum,
thinner, alcohol, or clothes stained with these substances).
This could cause an explosion or fire.
nDo not pour water on the washing machine during operation.
This could cause an electric shock.
nDo not climb on the washing machine. Do not place heavy object, drop any object or apply impact on the
lid glass.
This could cause lid glass breakage. If any scratch or breakage is found on lid glass, stop using the
washing machine and contact your local service center to request inspection and repair.
nDo not forcibly open the lid during operation:
Lid Lock Switch is designed to prevent from opening the lid during operation. This is because touching
the washing tub while it is spinning may result in serious injury. If you can open the lid during operation,
please stop using the Washing Machine immediately and refrain from touching the inside.
Contact your local service center for repair.
nThis appliance is not intended for use by persons with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge (including children) unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Installation
nDo not install the washing machine in an extremely humid place, such as a bathroom or a place exposed
to rain.
Risk of fire, electric shock, current leakage, corrosion or product damage.
nDo not install the washing machine on a board with castors or on an unstable surface.
This may cause injury or malfunction due to abnormal vibration.
nThe washing machine must be grounded if you use a two-pin plug adapter on the three-pin plug.
Failing to do so could cause an electric shock, electronic substrate and electronic parts damage.
nUse a new water supply hose to connect the washing machine to the water tap.
nThe opening must not be obstructed by carpeting if the washing machine is installed on a carpeted floor.
Power source and cord
nDo not insert or remove the power plug with wet hands.
This could cause an electric shock.
nUse the rated voltage. Do not connect other devices to the same outlet.
Using the washing machine and other electric appliances on the same outlet may cause the plug to
overheat and result in fire.
nClean offany dust on the power plug.
A dirty or dusty plug may cause a fire.
nDo not use an electric socket or outlet that is damaged or loose.
This could cause an electric shock, short circuit, or fire.
nDo not damage, cut, modify, bend, or fold the power cord.
This could damage the power cord and cause a fire or electric shock.
nDo not use an extension cord on the power cord.
This could cause an overheating or fire.
nIf the power cord is damaged, it must be replaced by a service agent or repair shop authorized by the
manufacturer to avoid risks.

4
Safety Instructions
Child safety
nKeep packaging out of reach of children and infants.
Danger of suffocation.
nDo not let children climb onto the washing machine or to get into the tub. Do not leave boxes or chairs
near the washing machine that children could use to climb onto it.
This may cause injury.
nChildren should be supervised to ensure that they do not play with the appliance.
CAUTION
Issues which could cause injury or damage property.
General safety
nIf there is a water outage or if you are removing the water supply hose to reattach it, close the tap and
press the Start/Pause button, then wait 40 seconds and slowly open the tap.
Air pressure from a large amount of air in the water pipes could damage the washing machine.
nPeriodically check that the union nut on the water supply hose is tight.
A loose nut may cause a water leak.
nRemove the power plug from the outlet and close the water tap if you will not use the washing machine
for a long time.
Use
nAll packaging materials must be removed before using the washing machine.
This could cause malfunction or abnormal vibration.
nCheck inside the tub before operating the washing machine.
Check that no pets or small animals are in the tub.
nDo not wash items through which water does not flow easily such as raincoats, wet suit, ski suits,
sleeping bags, cushions, pillows, shoes, shower curtain.
The washing machine may not work properly, or it could cause injury or damage the washing machine.
nDo not fold and stack large items such as blankets together when washing them.
nDo not use a laundry net that is larger than 40cm on a side.
The clothes may become offbalance and cause abnormal vibration during the spin cycle.
nDo not load laundry over the lower part of the liquid load balancer (dotted line).
Doing so could cause laundry to fly out of the tub during the spin cycle and damage the clothes or the
washing machine, or cause a water leak.
nAlways put detergent into the detergent dispenser when washing laundry.
nDo not use water hotter than 50ºC.
nDo not open the lid without using the Lid Open Button.
This may cause the damage of lid and lid open button.
nDo not wash items together with coins, pins, or stones.
This may damage clothes or the washing machine, or cause a water leak.
Check inside pockets before washing.
nDo not press the buttons with sharp pointed objects.
nDo not put heavy objects, liquid-filled containers or equipment which produces heat on the washing
machine.
This may damage the washing machine or its top.
Care and maintenance
nIf detergent, fabric softener or bleach spills on the surface of the machine, clean it up with a damp cloth
immediately.
The plastic or steel parts of the washing machine may be damaged.
nDo not place equipment that produces heat near the washing machine.
This may cause deformation of the washing machine.
SF-P130TCV
Liquid Load
Balancer
Max

5
Dispenser
Tub
Parts and Accessories
Accessories
Water Supply Hose
(2 sets)
U Shape
Holder Drain Hose Assembly and Hose Clamp Foot Caps
(2 pieces)
Rat Guard
(2 pieces)
(1 set)
(1 piece) (1 set)
Optional accessories
Laundry Net
Refer to page 12
Part number PTSF-140JJS 001
Drain Hose
Lid
Dispenser
(For detergent/
bleach/softener)
Lid Lock Adjustable Foot
Power
Cord
Pulsator
Lint Filter
(cassette
type)
Liquid Load
Balancer
Powder Detergent/
Powder Bleach
Dispenser
Softener
Dispenser
Liquid Detergent/Liquid Bleach
Dispenser

6
$XWR
6HOI&OHDQ
)X]]\ 3UHZDVK %ODQNHW
+HDY\
6RDN (QHUJ\6DYH:DWHU6DYH
6SHHG\'HOLFDWH
:DWHU3RZHU
6KRZHU3OXV
+ROGVHF
3RZHU2Q2II
'HOD\7LPHU :DWHU/HYHO :DVK 5LQVH 6SLQ
7XE&OHDQ 0HPRU\ 3URJUDP
6WDUW3DXVH
7LPH/HIW
0LQ 0LQ 0LQ
(;
7LPHV
:DWHU/HYHO
/
K
:DWHU7HPS
1 2
8
5
43
910111213
67
Power button Press this button to switch power on and off(when power on, please hold
1sec and display is on). The washing machine automatically
switches offwhen operations are finished. The washing machine also turns
offautomatically if it is not operated or no button is pressed for 10 minutes
after the power has been turned on.
Start/Pause button Press this button to start or pause the operation. When the washing machine
is paused for over twenty-four hour without any operations, it turns off
automatically.
Shower Plus button To add the water shower during the operation, press this button. Extra
amount of water supplied depends on load amount or program. If you want to
cancel this option, press this button again.
This function is available during the washing and normal rinsing processes.
This button does not function if the water level has already reached at the
highest level of each program.
Water Power button The strength of the water flow changes each time this button is pressed.
Water flow strength is shown on the Water Level/Timer indicator.
(0: normal, 1: strong, 2: stronger, -1: weak, -2: weaker)
This function is available during the washing and normal rinsing processes.
Program button Press this button to select the program. The program changes each time the
button is pressed.
Water Temp button Press this button to select the water temperature. The water temperature
changes each time this button is pressed. (Warm →Hot →Cold)
Control Panel and Display
During Operation (lid closed)
NOTES
nDirectly touch the buttons on the Control Panel with your bare finger.
nIf you find water drops, detergent or other foreign substances on the Glass Lid, please clean them up
with a dry cloth.

7
Memory button
0HPRU\
To record your customized washing course, press this button for more than 3
seconds after selecting each detail such as water level, wash time, rinse time
and spin time. From the next laundry, you can recall this memorized course
just by pressing this button after turning the Washing Machine on.
Auto Self Clean
button “Auto Self Clean” function automatically cleans both inner and outer tubs to
keep the washing machine clean. This setting is switched offat the time of
shipment from the factory. Once switched on, the “Auto Self Clean” function
operates every time you wash your laundry.
Spin button Press this button to change the spin time. The spin time can be set between
1 and 9 minutes.
Rinse button Press this button to change the rinse time.
Wash button Press this button to change the washing time. The washing time can be set
between 3 to 24 minutes.
Water Level button You can set the amount of Water each time you press the Water Level
button.
Delay Timer button The delay time can be set between 3 and 12 hours. Lights in the Delay Timer
mode. When this mode is on, Delay Timer button is lighted.
Displays all cycle Information, remaining time and error codes.
'HOD\7LPHU :DWHU/HYHO :DVK 5LQVH 6SLQ
7LPH/HIW
0LQ 0LQ 0LQ
(;
7LPHV
:DWHU/HYHO
/
K
A B C D E
Lid lock : The Lid is locked when this symbol is lighted.
Adjust the “Water Level” of program (shown as ‘Water Level’)
Remaining time of the program (shown as ‘Time Left’)
Time of the Wash.
Time of the Rinse.
Time of the Spin.
Control Panel and Display
During Operation (lid closed)

8
Sorting of the laundry
nSort laundry according to the type of fabric and care label symbols (cottons, blended fabrics, synthetics,
wool, hand washable items, etc.).
nDo not wash extremely small loads, such as only a pair of jeans.
This may cause abnormal vibration during the spin cycle.
nSeparate colored and white items.
Risk of injury!
Do not wash the following items through which water does not flow easily, because doing so creates
abnormal vibration during the spin cycle and could cause injury or malfunction.
– Waterproof items, such as a wet suit, ski suit, shower curtain, etc.
– Items with non-slip rubber backing such as door mats.
– Cushions, pillows, shoes, etc.
Detergents and additives
nUse an appropriate amount of detergent according to the detergent indicator of the washing machine.
The type and amount of detergent vary depend on the type of fabric, volume, load size, degree of soiling,
and hardness of the water used.
Use less detergent if:
– The load is small.
– The laundry is not very dirty.
nToo much detergent can result in excess foam, which reduces rinse efficiency or may cause a water
leak.
nDepending on the detergent brand, detergent may not dissolve completely in the detergent tray if the
water pressure is low or the water is too cold.
Page 24: Care and Maintenance
nWhen using softeners or bleaches, follow the instructions on the package.
* If water pressure is unstable during operation, it may cause the water remaining in Detergent and
Softener box.
Preparation Before Use
Preparation of the laundry
nRemove foreign objects, if any (coins, safety pins, etc.).
nPut delicate clothes (knits, lingerie, etc.) in a net.
nRemove large lumps of lint, mud, sand, hair, and pet hair from laundry, if any.
nTie strings and close fasteners, if applicable.
Check the label Put delicate clothes
in a net Remove foreign objects Knot the long strips, zip or button Separate colored and white items

9
How to Use the Washing Machine
1Sort the laundry
nSort the laundry according to the type of fabric, care label symbol, and degree of soiling.
Page 8: Preparation of the laundry
nDo not exceed the maximum load.
nLaundry shall not exceed this line.
Otherwise, laundry may jump out from the washing tub while spinning
and it may cause damage.
2Press the Power button to turn on the power
nIf no program is selected within 10 minutes, the washing machine
automatically switches itself off.
Press the Power button again to turn on the power.
ff
3Select and adjust the program
nSelect a program with the Program button.
Page 17: List of Programs
nYou can change the combination or settings of wash, rinse, and spin operations by the Wash,
Rinse, and Spin buttons.
nYou can switch on the “Auto Self Clean” function by the Auto Self Clean button.
Page 11: How to use the “Auto Self Clean” function
Once switched on, the “Auto Self Clean” function operates every time you do your laundry.
To deactivate, press the same button again while the power is on.
nYou can select the water temperature with the Water Temp button.
Page 14: How to use the Water Temp function
Set the operations
$XWR
6HOI&OHDQ
)X]]\ 3UHZDVK %ODQNHW
+HDY\
6RDN (QHUJ\6DYH:DWHU6DYH
6SHHG\'HOLFDWH
:DWHU3RZHU
6KRZHU3OXV
+ROGVHF
3RZHU2Q2II
'HOD\7LPHU :DWHU/HYHO :DVK 5LQVH 6SLQ
7XE&OHDQ
0HPRU\
3URJUDP
6WDUW3DXVH
7LPH/HIW
0LQ 0LQ 0LQ
(;
7LPHV
:DWHU/HYHO
/
K
:DWHU7HPS
Select a function.
Change the combination or settings
of Wash, Rinse, and Spin. Select a program.
4Press the Start/Pause button
nBefore operation starts, the laundry is weighed. Then, the
necessary amount of detergent and water shall be displayed.
SF-P130TCV
Max

10
How to Use the Washing Machine
5Put detergent into the detergent dispenser and close the lid
nOpen the detergent dispenser, add the amount of detergent shown on the package, and then
close the detergent dispenser.
nThe amount of detergent is based on a single 35-gram scoop of powder detergent. Since the
required amount of detergent varies depending on the type of detergent, follow the instructions
on the package of detergent.
nFor liquid detergent, follow the instructions on the package and add it to the liquid detergent/
liquid bleach dispenser.
nAdd softener to the softener dispenser according to the instructions on the package of softener.
Then, softener shall be added to the tub automatically before the final rinse.
nFor liquid bleach, follow the instructions on the package and add it to the liquid detergent/liquid
bleach dispenser.
nThe speed that the lid closes may vary, depending on the temperature; however, this is not an
abnormality.
Pausing a program: Press the Start/Pause button. The washing machine will switch
itself offif it is not restarted within 24 hours.
Adding clothes partway
through a program: Press the Start/Pause button to pause operation and add your clothes. The lid is locked while the tub is spinning, so wait
until the tub stops completely and the lid lock is automatically
released. After adding the clothes, close the lid and press the
Start/Pause button to restart the operation.
* Note: It is not recommended to add a large amount of clothes
as the washing machine first measures the load size to
determine optimum operation.
Adding water partway
through a program: Press the Shower Plus button to add water. To stop adding, press the same button again. If the water level is already at the
maximum level, water cannot be added any more.
* Note: This function cannot operate in the Tub Clean, Blanket
and Water Save Programs.
Changing strength of water
flow: Press the Water Power button.
You can repeatedly press the button to adjust the strength
through five levels.
* Note: This function operates in the Fuzzy, Prewash+, Delicate,
Speedy, Soak and Water Save courses for washing and
normal rinsing programs.
Depending on the program, maximum/minimum water power
you can change with this button is different. Also, when a load
amount is large, changes of water strength might not always
visibly distinctive.
Terminating a program: Press the Start/Pause button, then press the Power button to
turn offthe power.

11
How to Use the Washing Machine
6Take out the laundry (End of the program)
nThe alarm sounds when a program ends.
The alarm can be deactivated or the sound can be changed in 5 types if the button of Water
Level is pressed for at least 3 seconds.
Melody 1
*initial
setting Melody 2 Melody 3 Mono 1 Mono 2 No alarm
nThe washing machine automatically switches offwhen the operations are finished. Open the lid
and take out the laundry to dry.
How to use the “Auto Self Clean” function
Press the Power button to turn on
the power.
Select a program.
Press the Auto Self Clean button.
Press the Start/Pause button.
nWhen the “Auto Self Clean” function is running, about 14 more minutes and 10 more
liters of water are needed.
nThis setting is switched offat the time of shipment from the factory. Once activated, the “Auto Self Clean”
function operates every time you do your laundry.
nPrior to the final spin cycle, the outside of the tub, the back side of the pulsator, and the inside of the
outer tub are washed to eliminate dirt and mold.
nTo deactivate the “Auto Self Clean” function, press the Auto Self Clean button again while the power is on.
●The “Auto Self Clean” function runs just before spin cycle begins in each program.
●The “Auto Self Clean” function runs even when the washing machine has started operation from rinsing.
●The “Auto Self Clean” function cannot be set or cancelled during operation.
●The “Auto Self Clean” function is automatically cancelled when:
– The spin time is manually set to 1 minute.
– Spin-only operation is set.
– No spinning is set.
●Depending on the type and degree of dirt, some dirt may not be washed with the “Auto Self Clean”
function.
●If the washing machine is seldom used, some dirt may not be washed with the “Auto Self Clean” function.
●To clean the tub more completely, we recommend using the Tub Clean program along with the “Auto Self
Clean” function.
nThe “Auto Self Clean” function is deactivated when one of the following programs is selected.
– Blanket
– Tub Clean
nWhen the “Auto Self Clean” function is running, some water may flow out from the softener dispenser.
This is the normal operation of the washing machine and does not indicate a malfunction.
$XWR
6HOI&OHDQ
)X]]\ 3UHZDVK %ODQNHW
+HDY\
6RDN (QHUJ\6DYH:DWHU6DYH
6SHHG\'HOLFDWH
:DWHU3RZHU
6KRZHU3OXV
+ROGVHF
3RZHU2Q2
'HOD\7LPHU :DWHU/HYHO :DVK 5LQVH 6SLQ
7XE&OHDQ 0HPRU\ 3URJUDP
6WDUW3DXVH
7LPH/HIW
0LQ 0LQ 0LQ
(;
7LPHV
:DWHU/HYHO
/
K
:DWHU7HPS
1
2
34

12
How to Use the Washing Machine
How to use the Blanket program
Prepare the laundry.
nFold large items, such as quilts or blankets, as follows.
They should not be taller than 30cm after they are folded.
About 30cm 30cm
If it exceeds 30cm, use a laundry net, which is sold separately.
(Laundry net: Product number PTSF-140JJS 001)
Press the Power button to turn on
the power.
Select the Blanket program.
Press the Start/Pause button.
Add detergent and close the lid.
Water temperature setting cannot be changed when this program is selected.
Items you can wash with the Blanket program are as follows:
●Washable quilts
Blanket can be washed without laundry net when its size is:
150cm x 200cm or smaller, and less than 1.5 kg
Blanket should be washed in the laundry net when its size is:
Bigger than 150cm x 200cm up to 174cm x 225cm, heavier than 1.5kg up to 2.0kg
(Laundry net: Product number PTSF-140JJS 001)
●Washable blankets
Up to 3kg of synthetic blankets that are labeled as hand washable.
– For electric blankets, follow the instructions for the electric blanket.
●Other washable items
Mattress pads labeled as hand washable.
nDo not fold and stack large items together (such as sheets) when washing them.
The clothes may become offbalance and cause abnormal vibration during the spin cycle.
$XWR
6HOI&OHDQ
)X]]\ 3UHZDVK %ODQNHW
+HDY\
6RDN (QHUJ\6DYH:DWHU6DYH
6SHHG\'HOLFDWH
:DWHU3RZHU
6KRZHU3OXV
+ROGVHF
3RZHU2Q2
'HOD\7LPHU :DWHU/HYHO :DVK 5LQVH 6SLQ
7XE&OHDQ 0HPRU\ 3URJUDP
6WDUW3DXVH
7LPH/HIW
0LQ 0LQ 0LQ
(;
7LPHV
:DWHU/HYHO
/
K
:DWHU7HPS
23
4

13
How to Use the Washing Machine
How to use the Tub Clean program
nUse this program separately from other washing programs. (Do not put laundry into the tub.)
1 Press the Power button to turn on the power.
2 Select the Tub Clean program.
nThe Tub Clean program can be set to 3 or 11 hours. At first, “11 hours” is set. Press the Program button
again to set “3 hours”.
3 Close the lid, and press the Start/Pause button. The washing machine starts pouring water into the
tub. (Close the lid when C3 is displayed)
4 Press the Start/Pause button and open the lid, add tub cleaner to the tub by following the instruction
given on its package. (Liquid peroxide-based bleach is also effective as a tub cleaner. Since the
required amount of bleach varies depending on the type, follow the instructions given on its package.)
nWater is added to the maximum level to wash away invisible dirt from both outer and inner tubs.
Then, normal rinse operation will be performed twice to flush out any remaining dirt and tub cleaner.
How to use the Delay Timer
1 Press the Power button to turn on the power.
2 Select a program.
3 Press the Delay Timer button and select the time to finish washing.
Each press of the button starting from 3 hours to 12 hours later.
4 Press the Start/Pause button.
5 Add detergent and close the lid. The power turns offafter a short time.
6 Operations finish at the set time.
nThe Delay Timer is unavailable for the Blanket and Tub Clean programs.
nTo change the setting, press the Power button and do the settings again.
nIf there is a power outage while the timer is set, the timer setting is cancelled. If this happens, press the
Power button again and reset the timer.
nTo prevent your laundry from wrinkling, take them out from the Washing Machine to dry once the
operation is completed.

14
How to Use the Washing Machine
How to use the Prewash+ program
nYou can wash your heavily soiled laundry first, then add the regular laundry to wash offall together at a
time. With a guidance of Beep sound which is generated in about 20 minutes after starting the operation,
put additional laundry and detergent.
* Recommended amount of heavily soiled laundry is less than 2kg.
Additional amount of regular laundry should be less than 8kg.
+
Heavily
Soiled Items
If 15 minutes elapse from Beep sounds,
operation restarts automatically
Beep
Sounds
/
/
/
Spin-
Drying
RinsingWashing
additionally
Water
Inlet
Adding
laundry
and
Detergent
Normal
Soiled Items
Sensing
Dissolving
Prewash/Drain/Spin
about20minutes
Lessthan
8kg.
Lid Open Lid Close
Less than
2kg.
Operation:
Press the Power button to turn on the
power.
Select the Prewash+ program.
Press the Start/Pause button.
Put the detergent and close the lid.
When the Beep sounds, open the lid to add the Laundry and Detergent, then close the lid.
Others:
nPlease put additional laundry and detergent within 15 minutes after the Beep sounds.
If 15 minutes elapse from Beep sounds, operation restarts automatically.
nIn this case, rinsing starts without adding washing cycle.
How to set the Water Temperature
Operation:
Press the Power button to turn on the
power.
Select your desired program.
Set the water temperature by pressing
the Water Temp button.
Press the Start/Pause button to start
your selected program.
Others:
We recommend to use warm/hot/cold water for the
following cases:
nWarm water: Default water temperature setting is warm.
When your laundry is heavily soiled, warm water
washing is recommended, Warm water can also be
used for colorfast fabrics, dark fabrics, white and colored
synthetics, permanent press clothes or woolen items.
nHot Water: To wash soiled white or colorfast cottons,
linens, permanent press synthetics, we recommend to
use hot water.
nCold Water: This is suitable for lightly soiled or normally
soiled items.
nThe glass lid and the display screen may become
foggy with this program, but this is not failure. The fog
disappears in approximately 24 hours and it does not
affect the operation.
$XWR
6HOI&OHDQ
:DWHU3RZHU
6KRZHU3OXV
+ROGVHF
3RZHU2Q2II
'HOD\7LPHU :DWHU/HYHO :DVK 5LQVH 6SLQ
:DWHU7HPS7XE&OHDQ 0HPRU\
6WDUW3DXVH
7LPH/HIW
0LQ 0LQ 0LQ
(;
7LPHV
:DWHU/HYHO
/
K
)X]]\ 3UHZDVK %ODQNHW
+HDY\
6RDN (QHUJ\6DYH:DWHU6DYH
6SHHG\'HOLFDWH
3URJUDP
12
3
$XWR
6HOI&OHDQ
:DWHU3RZHU
6KRZHU3OXV
+ROGVHF
3RZHU2Q2II
'HOD\7LPHU :DWHU/HYHO :DVK 5LQVH 6SLQ
:DWHU7HPS7XE&OHDQ 0HPRU\
6WDUW3DXVH
7LPH/HIW
0LQ 0LQ 0LQ
(;
7LPHV
:DWHU/HYHO
/
K
)X]]\ 3UHZDVK %ODQNHW
+HDY\
6RDN (QHUJ\6DYH:DWHU6DYH
6SHHG\'HOLFDWH
3URJUDP
1
34
2
nHow to select water temperature
The water temperature can be changed
manually with every program (For some
programs, the most suitable temperature is
already fixed).
:DWHU7HPS
0LQ
:DWHU7HPS
0LQ
:DWHU7HPS
0LQ
Press
1 time
Warm
(Default)
Press
2 times
Hot
Press
3 times
Cold

15
How to Use the Washing Machine
Below settings are used for testing of Australian Standards.
Water & Energy efficiency labels are therefore based on the test result with the below settings.
WARM WASH setting
1. Close the lid of Washing Machine.
2. Press the “Power” button to switch on.
3. Press the “Water Save” button.
4. Press the “Water Temp” button until the “Warm” signal is illuminated.
(Please refer to the below image for “Warm” signal).
5. Press the “Water Level” button to set the water level to 86.
6. Press the “Wash” button to set the wash time to 99 mins.
7. Rinse operation is set by default
(Please DO NOT press “Rinse” button).
8. Press the “Spin” button to set the spin time to 9 mins.
9. Press the “Water Power” button to select the waterpower until “1” is displayed.
10. Press the “Start” button.
COLD WASH setting
1. Close the lid of Washing Machine.
2. Press the “Power” button to switch on.
3. Press the “Water Save” button.
4. Press the “Water Temp” button until the “Cold” signal is illuminated.
(Please refer to the below image for “Cold” signal).
5. Press the “Water Level” button to set the water level to 86.
6. Press the “Wash” button to set the wash time to 99 mins.
7. Rinse operation is set by default.
(Please DO NOT press “Rinse” button).
8. Press the “Spin” button to set the spin time to 9 mins.
9. Press the “Water Power” button to select the waterpower until “1” is displayed.
10. Press the “Start” button.
Note 1: This washing machine has wash cycles that are designed to use less water.
Low-sudsing detergent is recommended to use.
Note 2: Water pressure during testing is 350 kPa.
Note 3: The start of washing operation is defined to begin at the “end of the hot water fill” for correct
determination of maximum bath temperature measurement.
How to select “Warm” / “Cold”
Water temperature can be changed manually as
the right image shows.
:DWHU7HPS
0LQ
:DWHU7HPS
0LQ
:DWHU7HPS
0LQ
Press
1 time
Warm
(Default)
Press
2 times
Hot
Press
3 times
Cold

16
Program Type of Laundry / Notes Model / Max Load
P130TCV
Fuzzy For daily washing of cotton and linen items such as
shirts, underwear, towels, bed linen and table linen. 13 kg
Prewash+ You can wash your heavily soiled laundry first, then add
the regular laundry to wash offall together at a time. 10 kg
Delicate This is a gentle wash program for delicate items such
as lingerie and thin lace curtains. 6.5 kg
Speedy This program lets you wash small loads of lightly soiled
clothes and small items such as underwear. 6.5 kg
Soak For washable large items and heavily soiled durable
clothes. 10.4 kg
Blanket For washable large items such as duvets, blankets,
bedspreads, etc. 3 kg
Energy Save This program provides an Eco operation by saving energy while assuring the same washing performance
as the Fuzzy program. 13 kg
Water Save This program provides an Eco operation by saving water while assuring the same washing performance as
the Fuzzy program. 13 kg
Heavy Select this program to wash heavily soiled durable
clothes (jeans, sportswear, etc.) 13 kg
How to Use the Washing Machine
nHow to check the water temperature setting .
Press the
:DWHU7HPS
button during the operation.
Then, the water temperature setting shall be displayed for 3 seconds.
Once the program starts, the water temperature cannot be changed any more.
Program Overview

17
List of Programs
: Default settings : Changeable settings (via corresponding button)
Program Fuzzy Prewash+ Delicate
Pre Add
Maximum
load P130TCV 13 kg 2 kg 8 kg 6.5 kg
Amount
of water P130TCV 33 to 99 L
(adjusted automatically) 33 to 68 L 90 L 61 L
33 to 99 L - 47 to 86 L
Wash 15 min 45 min 6 min
3, 9, 12, 15, 18, 24 min,
or none --
Rinse
Spin Shower Rinse 2 times +
Normal Rinse 1 time (In case
of laundry exceeds 80%, the
process will be Spin Shower
Rinse 1 time and Normal Rinse
1 time.)
Normal Rinse 2 times Normal Rinse 1 time
Each time you press the Rinse
button, the setting changes in
sequence from Normal Rinse
2 times, Normal Rinse 3 times,
Normal Rinse 1 time, or none
Each time you press the Rinse button, the
setting changes in sequence from Normal
Rinse 1 time, Normal Rinse 2 times, Normal
Rinse 3 times, or none
Spin Time 6 min 3 min
1, 3, 6, 9 min, or none 1, 3, 6, 9 min, or none
Required
time
(guide) P130TCV 46 to 79 min 63 to 99 min 35 min
Program Speedy Soak Blanket
0.5 hrs 1 hrs 3 hrs 5 hrs
Maximum
load P130TCV 7 kg 10.4 kg 3 kg
Amount
of water P130TCV 54 L 33 to 99 L (adjusted automatically) 103 L
33 to 86 L 33 to 99 L 86 to 103 L
Wash 3 min 30 min 60 min 180 min 300 min 25 min
3, 9, 12, 15, 18, 24 min,
or none ---- -
Rinse
Normal Rinse 1 time Normal Rinse 2 times Normal Rinse
2 times
Each time you press
the Rinse button, the
setting changes in
sequence from Normal
Rinse 1 time, Normal
Rinse 2 times, Normal
Rinse 3 times, or none
Each time you press the Rinse button,
the setting changes in sequence from
Normal Rinse 2 times, Normal Rinse
3 times, Normal Rinse 1 time, or none -
Spin Time 3 min 6 min 9 min
1, 3, 6, 9 min, or none 1, 3, 6, 9 min, or none
Required
time
(guide) P130TCV 31 min 70 to
83 min 100 to 113 min 220 to 233 min 340 to 353 min 77 min

18
Program Energy Save Water Save Heavy
Maximum
load P130TCV 13 kg 13 kg 13 kg
Amount
of water P130TCV
33 to 99 L
(adjusted automatically) 33 to 94 L (adjusted automatically) 33 to 99 L (adjusted automatically)
33 to 99 L 33 to 94 L 33 to 99 L
Wash
48 min 15 min 18 min
-3, 9, 12, 15, 18, 24,
99 min, or none 12, 15, 18, 21, 24 min, or none
Rinse
Spin Shower Rinse
2 times + Normal Rinse
1 time (In case of laundry
exceeds 80%, the process
will be Spin Shower Rinse
1 time and Normal Rinse
1 time.)
Normal Rinse 2 times
Spin Shower Rinse
2 times + Normal Rinse
1 time (In case of
laundry exceeds 80%,
the process will be Spin
Shower Rinse 1 time and
Normal Rinse 1 time.)
-Each time you press the Rinse button, the setting changes in sequence from Normal Rinse 2 times,
Normal Rinse 3 times, Normal Rinse 1 time, or none
Spin Time
5 min 6 min 6 min
- 1, 3, 6, 9 min, or none
Required
time
(guide) P130TCV 83 to 100 min 42 to 153 min 52 to 78 min
List of Programs
: Default settings : Changeable settings (via corresponding button)

19
List of Programs
nThe wash time and the spin time may change during the program depending on the weight and type of
laundry being washed.
nThe displayed times are guidelines. More time may be required depending on the water pressure and the
type of laundry.
nPrograms cannot be changed once they are started. To change them, turn the power offand then on
again to re-select a program.
nWhen the “Auto Self Clean” function is running, about 14 more minutes and 10 more liters of water are
needed.
nSpin Shower Rinse* is used in the Fuzzy and Energy Save programs to enhance water-saving
performance without compromising the efficiency of rinsing.
* Spin Shower Rinse: A powerful shower and centrifugal force to rinse the detergent more effectively.
nThe clear part of the lid and control panel may become foggy or may form dew on the edge of lid if you
use hot water to wash your laundry; however, this is not an abnormality. Wipe it offafter washing your
laundry.
nIt has the potential not to be enough for max load according to the kind of clothes.
nEven if you set the delay timer, it may start soon according to the required time of the program.
nWater flow is adjusted automatically according to the amount of load and water level. When loads are
heavy and water level is high, water flow is adjusted at slower rate to maintain the performance of
washer.
nAmount of detergent is indicated according to following table as a guide.
Load (guide) Water Level Amount of detergent
8~13 kg 88~99 L 72 g (SF-P130TCV)
4~7 kg 68~82 L 46~55 g
0~3 kg 33~61 L 22~41 g
* The amount of detergent is based on a type of “20-gram per 30-liter”.
Since the required amount of detergent varies depending on the type of detergent, follow the instructions
on the package of detergent.

20
How to Customize the Program
If you want... To customize
the wash program
To reuse the wash
water and separate
your laundry
To not spin the laundry
because you are
worried about wrinkles
Operations Wash Rinse Spin Wash only Wash Rinse
Setting method
1.
ff
Turn on the power.
2. Fuzzy Select the Fuzzy program.
3. Set the amount of water.
If you do not set the amount of water, it is set automatically based on the
weight of the laundry.
4.
Set the operations
123
Set the wash time
with the Wash button.
Set the number and
type of rinses with the
Rinse button.
Set the spin time with
the Spin button.
1
Set the wash time
with the Wash button.
12
Set the wash time
with the Wash button.
Set the number and
type of rinses with the
Rinse button.
5. Press the Start/Pause button to start.
Remarks Operates according to the wash, rinse, and spin
settings.
Stops while the wash
water is still in the tub. Stops while the rinse water is still in the tub.
