Hitron HT-EM4 User manual

LEDs
Tech Support
To access user manuals, Frequently Asked Questions etc, visit our
website at: www.hitron-americas.com/HTEM4
Warning
- Risk of electrical shock. Do not expose the device to water
or moisture.
- The device is a high-performance communications device
designed for home and office environments.
- Do not use the device outdoors. Keep the device in an environment
between 0°C - 45°C (32°F - 113°F). To avoid overheating, do NOT
place any object on top of the device.
- Do not restrict the flow of air around the device.
- The manufacturer assumes no liabilities for damage caused by any
improper use of the device.
Disclaimer
The manufacturer assumes no liabilities with respect to the contents of this document. The manufacturer
also reserves the right to revise this document or update the content thereof without any obligation
to notify any person of such revisions or amendments. Hitron and the Hitron logo are registered
trademarks of Hitron Technologies in the US or other countries. Product photo may differ from the
actual product. Specifications subject to change without notice.
3
Power Green when powered on.
Activity Blink when sending or
receiving data over the
MoCA network.
Link Blue for 1000 Mbps
Ethernet connection.
Green for 100 Mbps
Ethernet connection.
MoCA Blue high-speed mode.
Green low-speed mode.
Off if not connected to
another MoCA device.
HT-EM4
MoCA 2.5 Network Adapter
Quick Install Guide
Quick Install Guide - HT-EM4 - MoCA 2.5 Network Adapter

1
Step 1: Connect to your Modem/Router
Note: Not all routers have MoCA built into the router. If your router does
not support MoCA, or you are unsure if your router has MoCA, please
complete Step 1.
Get a MoCA 2.5 Network Adapter and Ethernet Cable.
Connect the Ethernet Cable from the Modem/Router to the
MoCA 2.5 Network Adapter.
Get the Coax Cable and connect the Coax Cable from the
Coax Outlet on the wall to the Top Coax Port on the MoCA 2.5
Network Adapter.
Note: If you have a TV or cable set top box near your modem/router,
connect a coax cable from the 2nd Coax port marked TV to the TV or
set top box.
Get the Power Adapter (External, 12V DC, 1A, made by AOEM,
Model #ADSO12T-W120100) and connect it from the MoCA 2.5
Network Adapter to a Power Outlet.
Wait until the Power Light on the front of the adapter is GREEN.
Coax Outlet
TV
Modem Router
Power outlet
A
C
B
D
E
A
B
C
D
E
2
Step 2: Connect to your Device
Get a MoCA 2.5 Network Adapter and Ethernet Cable.
Connect the Ethernet Cable from the Access Point or Device
(gaming console, streaming TV player, laptop etc.) to the
MoCA 2.5 Network Adapter.
Get the Coax Cable and connect the Coax Cable from the
Coax Outlet on the wall to the Top Coax Port on the
MoCA 2.5 Network Adapter.
Get the Power Adapter and connect it from the MoCA 2.5
Network Adapter to a Power Outlet.
Wait until the Power Light on the front of the adapter is GREEN
and the MoCA light turns GREEN or BLUE.
Note: The MoCA light will turn Green when the MoCA network
is in low speed.
Coax Outlet
TV
Gaming Console,
Streaming TV player etc...
Power outlet
A
C
B
D
E
E
A
B
C
D
E
Quick Install Guide - HT-EM4 - MoCA 2.5 Network Adapter Quick Install Guide - HT-EM4 - MoCA 2.5 Network Adapter
