Hitron H4R15MX User manual

1 2 3 4
TALK QUAD SEQ MODE
AUDIO
VOLUME
MUTE
USER INSTRUCTIONS
COLOR DVR MONITOR
Please read this manual thoroughly before use and keep it handy for future reference.
15 inch 4-CHANNEL COLOR
MULTIPLEXER DVR MONITOR

ISSUE 1 - MAY, 2005
THE INFORMATION IN THIS PUBLICATION IS BELIEVEDTO BE ACCURATE IN ALL
RESPECTS, HOWEVER, WECANNOT ASSUME RESPONSIBILITY FOR ANY
CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION
CONTAINED HEREIN IS SUBJECTTO CHANGE WITHOUT NOTICE. REVISIONS OR NEW
EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH CHANGES.
LIMITATION OF LIABILITY
2

CAUTION:
CAUTIONCAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by the qualified
personnel before operating it any further.
Unplug the unit from the wall oulet if it is not going to
be used for several days or more. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials(curtains, draperies)
that may block the ventilation holes.
Height and vertical linearity controls located at the
rear panel are for special adjustments by qualified
personnel only.
Do not install the unit in an extremely hot or humid
place or in a place subject to excessive dust,
mechanical vibration.
The unit is not designed to be waterproof.
Exposure to rain or water may damage the unit.
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use strong
solvents such as thinner or benzine as they might
damage the finish of the unit.
Retain the original carton and packing materials for
safe transport of this unit in the future.
Safety ----------------------------------------- Installation -----------------------------------
Cleaning --------------------------------------
PRECAUTIONS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE
VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT.
WARNING AND CAUTIONS
3

FCC COMPLIANCE STATEMENT
INFORMATION TO THE USER: THIS EQUIPMENT HAS BEEN
TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A "CLASS
A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE
PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE
EQUIPMENT IS OPERATED IN ACOMMERCIAL ENVIRONMENT.
THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO
FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS
LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE
THE USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE
ATHIS OWN EXPENSE.
CAUTION : CHANGES OR MODIFICATIONS NOT EXPRESSLY
APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD
VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN
ICES-003.
WARNING
THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE
USER MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.
CE COMPLIANCE STATEMENT
4

1.
2.
3.
4.
5.
6.
6A.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
READ INSTRUCTIONS -- All the safety and operating
instructions should be read before the appliance is operated.
RETAIN INSTRUCTIONS -- The safety and operating
instructions should be retained for future reference.
CLEANING -- Unplug video monitor or equipment from the
wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
ATTACHMENTS -- Do not use attachments not
recommended by the video monitor or equipment
manufacturer as they may result in the risk of fire, electric
shock or injury to persons.
WATER AND MOISTURE -- Do not use video monitor or
equipment near water -- for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet basement, or
near a swimming pool, or the like.
ACCESSORIES -- Do not place video monitor or equipment
on an unstable cart, stand or table. The video monitor or
equipment may fall, causing serious injury to a child or adult,
and serious damage to the equipment. Wall or shelf
mounting should follow the manufacturer's instructions, and
should use a mounting kit approved by the manufacturer.
Video monitor or equipment and cart
combinations should be moved with
care. Quick stops, excessive force,
and uneven surfaces may cause the
equipment and cart combination to overturn.
VENTILATION -- Slots and openings in the cabinet and the
back or bottom are provided for ventilation, and to ensure
reliable operation of the video monitor or equipment and to
protect it from overheating. These openings must not be
blocked or covered. The openings should never be blocked
by placing the video monitor or equipment on a bed, sofa,
rug, or other similar surface. Video monitor or equipment
should never be placed near or over a radiator or heat
register. Video monitor or equipment receiver should not be
placed in a built-in installation such as a bookcase unless
proper ventilation is provided.
POWER SOURCES -- Video monitor or equipment should
be operated only from the type of power source indicated on
the marking label. If you are not sure of the type of power
supplied to your home, consult your video monitor or
equipment dealer or local power company. For video monitor
or equipment designed to operate from battery power refer to
the operating instructions.
GROUNDING OR POLARIZATION -- This video monitor
may be equipped with a polarized alternating - current line
plug (a plug having one blade wider than the other). This plug
will fit into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into the outlet,
try reversing the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the polarized plug.
Alternate Warnings - This video monitor is equipped with a
three-wire grounding-type plug, a plug having a third
(grounding) pin. This plug will only fit into a grounding-type
power outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety
purpose of the grounding-type plug.
POWER CORDS -- Protect the power cord from being
walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
HEED WARNINGS -- Follow all instructions marked on the
video monitor or equipment.
LIGHTNING -- For added protection for video monitor or
equipment during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the video product due to
lightning and power-line surges.
OVERLOADING --Do not overload wall outlets and
extension cords as this can result in a risk of fire or electric
shock.
OBJECT AND LIQUID ENTRY -- Never push objects of any
kind into video monitor or equipment through openings as
they may touch dangerous voltage points or short-out parts
that could result in a fire or electric shock. Never spill liquid of
any kind on the product.
SERVICING -- Do not attempt to service video monitor or
equipment yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE -- Unplug video monitor or
equipment from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
A. When the power-supply cord or the plug has been
damaged.
B. If liquid has spilled, or objects have fallen into the video
product.
C. If the video product has been exposed to rain or water.
D. If the video product does not operate normally by
following the operating instructions, adjust only those
controls that are covered by the operating instructions as an
improper adjustment of other controls may result in damage
and will often require extensive work by a qualified technician
to restore the video product to its normal operation.
E. If the video product has been dropped, or the cabinet
damaged.
F. When the video product exhibits a distinct change in
performance -- this indicates a need for service.
REPLACEMENT PARTS -- When replacement parts are
required, be sure the service technician has used
replacement parts specified by the manufacturer or that have
the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or other
hazards.
SAFETY CHECK -- Upon completion of any service or
repairs to this video product, ask the service technician to
perform safety checks to determine that the video product is
in proper operating condition.
FIELD INSTALLATION --This installation should be made by
a qualified service person and should conform to all local
codes.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that product heat.
IMPORTANT SAFEGUARDS
5

TABLE OF CONTENTS
CHAPTER 1. INTRODUCTION 7
1-1. FEATURES 7
CHAPTER 2. INSTALLATION 8
2-1. Monitor Installation with Cameras 8
2-2. Installation with a analog VCR or Security Time-lapse VCR 11
2-3. Installation with secondary monitors 13
2-4. Installation with Alarm Devices 15
2-5. Installation with a Two-way Intercom 17
CHAPTER 3. OPERATION 18
3-1. Front keys and Their Functions 18
3-2. Display Mode 21
3-3. Enter key in the quad display mode 22
3-4. Camera key in the freeze mode 23
3-5. Audio channel selection in the QUAD display 23
3-6. Volume control 23
3-7. Alarm Operation 24
CHAPTER 4. MENU 25
4-1. Navigating the menu 26
4-2. Monitor Picture control menu 26
4-3. System Shutdown 26
4-4. Entering the main menu 27
4-5. TIME/DATE 28
4-6. DISPLAY 29
4-7. CAMERA 29
4-8. Alarms 31
4-9. RECORDING SETUP 35
4-10. Disk Setup 39
4-11. Communications 40
4-12. Unit Setup 43
4-13. Entering the SEARCH menu 45
APPENDIX A. REAR SIDE OF MONITOR 48
APPENDIX B. TROUBLESHOOTING PROCEDURES 50
APPENDIX C. MAINTENANCE 51
EQUIPMENT SPECIFICATIONS 52
6

CHAPTER 1.
INTRODUCTION
1-1. FEATURES
The monitor is an observation system with four-channel color multiplexer DVR processor.
The monitor has a motion detection system. Motion detection sensitivity can be adjusted
and the user can set day and night motion detection schedules. The monitor operates as
a duplex recorder of high quality video and one channel audio and supports the network.
The monitor has the following features :
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
15'' Flat Color CRT Monitor.
Compatible with standard color cameras and other standard video sources.
Simple operator menus and easy to use front panel controls.
Automatical switching between NTSC and PAL according to the video format of
camera 1.
Digital Recording and playback using the internal hard disk.
Records up to 60 NTSC (50 PAL) Images per Second.
Full triplex operation allows simultaneous recording, playback, and live viewing.
Full Screen and camera sequencing with programmable sequence dwell times.
On-screen display includes date, time, sequence, freeze, alarm, motion detection,
video loss, audio channel, and 8-character camera titles.
Each camera has two programmable motion-detection areas for day and night setting.
Nonvolatile program memory saves all user settings and protects them against power
outages.
Alarm input polarity is user selectable.
Video Freeze and Electronic X2 Zoom with digital pan and tilt on the full-screen mode.
Four BNC input connectors and four BNC "Loop-Through" Video output connectors.
Recorder modular port - allows you to copy the monitor display, to monitor the
videotape or DVR backup, or to output to the secondary monitor.
Scheduled recording -possible to perform recording automatically at a scheduled
time on a designated day of a week.
Event Recording -At an event occurrence such as when an alarm signal is supplied,
recording mode (quality and recording rate) can be changed to high quality to record
pictures.
Simultaneous live view and playback view -In the playback mode, you watch the
live camera and playback camera in the 3 X 3 display screen simultaneously.
Panorama Playback-In the playback mode, you watch the panorama playback of
each camera.
7

CHAPTER 2.
INSTALLATION
2-1. Monitor Installation with Cameras
The observation monitor must be installed by qualified service and installation personnel.
The installation must be in accordance with all local and federal electrical and building
codes.
Perform the following steps to install the observation monitor. See Figure 1.
A. Unpack the observation monitor.
B. Place the observation monitor in a convenient location.
Do not plug the power cord into a power outlet until step J.
Caution:
The MAIN POWER on the rear of the monitor must be turned off
before camera cables are plugged into the camera ports, which are
also on the rear of the monitor. Plugging a camera cable into the
monitor with the power on could damage the monitor and/or camera.
C. Select an appropriate location for the cameras.
D. Install cameras to be connected to the monitor.
E. Route the assembled cable from the monitor to the camera.
Caution:
Be careful when routing the cable from the camera to the monitor.
Try not to put unnecessary strain on the cable or connectors.
The cable can be damaged if pulled by the connectors.
Do not place the cable next to fluorescent lights; interference may
result.
Do not use staples to support the cable, as you may damage the cable.
If the provided camera cable is not long enough, do not substitute a
telephone cable. Using a telephone cable could damage the camera
and/or the monitor.
F. For modular type, plug the cable into the connector port labeled "MONITOR" on the
rear of the camera.
G. For BNC type, plug the cable into the connector port labeled "VIDEO OUT" on the
rear of the camera.
H. Plug the other end of the cable into the corresponding camera connector port on the
rear of the monitor. The ports are labeled "CA1" for camera one, "CA2" for camera
two, etc.
8

I. Repeat steps D through G for additional observation cameras.
Caution:
Do not plug an observation camera and a standard security camera into the same
camera port on the rear of the observation monitor; i.e, an observation camera into
the RJ-11-E for CA1 and a BNC cabled standard security camera on the BNC input
for CA1.
NOTE:
Connecting a cable to the output BNC connector disconnects the termination for
that camera input signal, therefore an unused cable should be removed from the
BNC connector.
J. Plug the power cord for the monitor into a power outlet.
K. Turn on the MAIN POWER switch on the rear of the monitor and the POWER switch
on the front of the monitor.
L. The monitor displays a picture.
9

<FIGURE 1> Monitor with Cameras
AC IN
ON
OUTIN
1
2
3
4
CA1
OFF
CA2
CA3
CA4
RECORDER
ALARM
OUT
NO
COM
NC
RS485
NETWORK
Modular Camera Rear View
MONITOR INTERPHONE
BNC Camera Rear View
VIDEO OUT
Modular Cable
connector to Monitor
Modular Cable
connector to Camera
BNC Cable
connector to Monitor
BNC Cable
connector to Camera
Monitor Rear View
10

2-2. Installation with a analog VCR or Security Time-lapse VCR
The observation monitor has an internal hard disk for recording and playback.
But sometimes you may want to copy the playback of the internal hard disk using an
analog VCR tape.
At this time, perform the following steps after installing the monitor. See Figure 2.
A. Obtain the following equipment:
a. Analog VCR.
b. VCR interconnection cable.
c. Videotape.
B. Place the VCR in a convenient location.
(usually within reach of the observation monitor)
C. Plug the Modular connector of the VCR interconnection cable into the "RECORDER"
port on the rear of the monitor.
D. Connect the "Audio In" connector to the "Audio In" port on the VCR.
E. Connect the "Audio Out" connector to the "Audio Out" port on the VCR.
F. Connect the "Video In" connector to the "Video In" port on the VCR.
Use a RCA to BNC adapter if necessary.
G. Connect the "Video Out" connector to the "Video Out" port on the VCR.
Use a RCA to BNC adapter if necessary.
H. Press the VCR button on the front of the monitor.
I. Program the VCR using the manufacturer's instructions.
J. Press the mode button on the front of the monitor to return to a normal operation
mode.
K. Start recording using the manufacturer's instructions.
11

IN
FROM ANT
OUT TO TV
OUT
IN
VIDEO AUDIO
OU T
OUT
IN
VIDEO AUDIO
OU T
IN
IN
AC IN
ON
OUTIN
1
2
3
4
CA1
OFF
CA2
CA3
CA4
RECORDER
ALARM
OUT
NO
COM
NC
RS485
NETWORK
Monitor Rear View
Typical Time-Lapse Recorder Rear View
RCA to BNC
Adaptor VCR Interconnection cable
AUDIO OUT
AUDIO IN
VIDEO IN
VIDEO OUT
Typical Event Recorder Rear View
OR
NO
COM
NC
VHF
UHF
CH3
CH4
VCR Interconnection cable
<FIGURE 2> Observation Monitor with a recorder (Modular Type)
12

2-3. Installation with secondary monitors
The observation monitor has four video looping-out BNC jacks and one VCR modular
jack.
Perform the following steps after installing the monitor. See Figure 3.
A. Obtain the following equipment:
a. Monitors.
b. VCR interconnection cable.
c. BNC cables.
B. Place the secondary monitor and looping-out monitors in a convenient location.
C. Plug the Modular connector of the VCR interconnection cable into the "RECORDER"
port on the rear of the monitor.
D. Connect the "Audio In" connector to the "Audio In" port on the secondary monitor.
E. Connect the "Video In" connector to the "Video In" port on the
Use a RCA to BNC adapter and BNC cable if necessary.
F. Connect the "Video Out" connector to the "Video Out" port on the
Use a RCA to BNC adapter and BNC cable if necessary.
G. Connect the "Video Out" connector to the "Video Input" port on the looping-out
monitor for camera1.
H. Repeat step G for camera 2, 3, 4.
secondary monitor.
secondary monitor.
13

VIDEO OUT
OUTIN
VIDEO
OUTIN
AUDIO
AC IN
ON
OUTIN
1
2
3
4
CA1
OFF
CA2
CA3
CA4
RECORDER
ALARM
OUT
NO
COM
NC
RS485
NETWORK
Monitor Rear View
VCR Interconnection cable
RCA to BNC
Adaptor
OUT
IN
OUT
IN
AUDIO OUT
VIDEO IN
AUDIO IN
<FIGURE 3> Observation Monitor for secondary monitors
14

2-4. Installation with Alarm Devices
The monitor can annunciate alarms and activate a recorder or other external alarm device
when an alarm is received at the observation monitor.
Perform the following steps after the installation of the monitor. See Figure 4
A. Obtain one of the alarm device units
B. Locate a suitable location for the alarm device.
C. Mount the alarm device using the manufacturer's instructions.
D. Route the alarm device cable from the alarm device to the observation camera.
E. Connect the ends of the cable to the alarm device following the manufacturer's
instructions.
F. Turn OFF the MAIN POWER switch on the observation monitor.
G. Plug the RJ-11-E connector of the alarm device cable into the interphone port, on the
rear of the camera or plug a dual alarm interface adapter into the interphone port and
plug the alarm device cable(s) into the dual alarm interface adapter.
Caution:
Be careful when routing the cable from the camera to the alarm device. Try not to
put unnecessary strain on the cable or connectors.
The cable can be damaged if pulled by the connectors. Do not place the cable next
to fluorescent lights; interference may result.
Do not use staples to support the cable, as you may damage the cable.
If the provided camera cable is not long enough, do not substitute a telephone
cable. Using a telephone cable could damage the camera and/or alarm device.
Alarm cable may be added to the alarm device cable if it is not long enough.
All connections should be properly connected and insulated to prevent
electrical shock and fire hazards.
H. Turn on the MAIN POWER switch for the observation monitor and the POWER switch
on the front of the monitor.
Place the monitor in the desired operating mode.
15

MONITOR INTERPHONE
Camera Rear View
To Monitor
Wire color
Black : Alarm input
Shield : Ground
External Alarm Device Cable
OR
OR
External Alarm Device Cable
Passive Infrared Detector W/Power Supply
<FIGURE 4> Alarm Device Installation (Modular Type)
16

2-5. Installation with a Two-way Intercom
The monitor has the ability to have a two-way intercom between the monitor and the
camera location.
Perform the following steps after installing the monitor. See Figure 5.
A. Obtain an intercom station.
B. Select a suitable location for the intercom station. The typical mounting height should
be between 30'' and 42'' above the floor for easy access.
C. Route the intercom cable from the observation camera to the intercom station.
D. Plug one end of the cable into the jack on the rear of the intercom station.
E. Turn OFF the MAIN POWER switch on the observation monitor.
F. Plug the RJ-11-E connector of the intercom cable into the interphone port, on the rear
of the camera.
Caution:
Be careful when routing the cable from the camera to the intercom station.
Try not to put any unnecessary strain on the cable or connectors.
The cable can be damaged if pulled by the connectors.
Do not place the cable next to fluorescent lights; interference may result. Do not
use staples to support the cable, as you may damage the cable. If the provided
camera cable is not long enough, do not substitute a telephone cable. Using a
telephone cable could damage the camera and/or alarm device.
G. Turn on the MAIN POWER switch for the observation monitor, and the POWER
switch on the front of the monitor.
H. Place the monitor in the desired operating mode.
To Monitor
CAMERA
BACK OF CAMERA
MONITOR INTERPHONE
CAMERA WITH BUILT-IN INTERCOM
VIDEO DOOR
PHONE CAMERA
To Monitor
INTERCOM
<FIGURE 5> Two-way Intercom Installation
17

CHAPTER 3.
OPERATION
3-1. Front keys and Their Functions
CA1 CA2 CA3 CA4
TALK QUAD SEQ MODE
AUDIO
VOLUME
MUTE
1 2 3 4 5 6
<FIGURE 6> Front Panel
PART FUNCTION DESCRIPTION
1SPEAKER Sound from the camera locations, the RECORDER audio, or the
playback audio can be monitored from the internal speaker.
2TALK Press and hold the TAL K to send audio from the monitor's
built-in microphone to an optional intercom. The LED above the
talk Key is illuminated during the operation.
2QUAD The QUAD key is used to change the screen to the QUAD
display in the live mode. The LED above the QUAD key is
illuminated during the operation.
In the playback mode, pressing QUAD key will display the
quad screen and pressing QUAD key again will display
the 3x3 screen with four live cameras and four playback
cameras.
2SEQ Press SEQ key is used to change the screen to the sequence
display in the full-screen display mode. The LED above the SEQ
key is illuminated during the operation.
2MODE Press MODE to switch the monitor into the RECORDER mode in
the live display mode. In this RECORDER mode, the monitor
displays the video signal through the RECORDER input port.
The LED above the mode key is illuminated during the
RECORDER mode. Press MODE again to switch the monitor
into the live display mode from RECORDER display mode.
Press MODE to return to the live display mode from the playback
mode.
18

PART FUNCTION DESCRIPTION
21~4 These CAMERA NUMBER keys are used to display a camera in
the full-screen displayed mode. In the playback mode, pressing
camera key again will display the panorama display mode.
The LED above the camera key is illuminated during the
operation.
3ARROW The Up, Down, Left and Right keys are used whenever you
need to move the screen in the zoom mode and in the menu
mode.
3ENTER The ENTER key is used to select a submenu or menu items, or
save selections made in menus.
3MUTE
(LEFT)
Press MUTE key to set the audio level to the minimum level.
AUDIO
(RIGHT)
Press AUDIO key to change the camera audio signal in the
QUAD display mode.
3
Volume
UP/DOWN
Press Volume DOWN key to decrease the volume level.
Press Volume UP key to increase the volume level.
3
4ZOOM Press ZOOM key to enter or exit the Zoom Mode in the
full-screen mode only.
The LED above the zoom key is illuminated during the operation.
4RECORD Press RECORD key to record cameras.
Press RECORD key to stop recording again if enabled in the
menu. The LED above the record key is illuminated during the
record mode.
4PAUSE Press PAUSE key to freeze the screen in the live mode.
Press PAUSE again to unfreeze the screen in the live mode and
the freeze mode.
Press PAUSE key to pause playback picture in the playback
mode. Press PAUSE key again to resume playback in the
pause mode. The LED above the pause key is illuminated
during the pause mode.
4MENU The MENU key will place the unit in the programmable setup
mode in the live mode. Press MENU key to enter the search
menu in the playback mode.
The LED above the menu key is illuminated during the menu
mode.
19

PART FUNCTION DESCRIPTION
4REWIND Press REWIND key to start rewind playback(x1) of recordings
and press REWIND key again to speed up rewind up to X16 in
the playback mode.
Press REWIND key to speed down rewind for a slow reverse
playback up to X 1/60(50) in the pause mode. The LED above
the rewind key is illuminated during the rewind mode.
4REVERSE
PLAY
Press REVERSE PLAY key to start reverse playback.
Press REVERSE PLAY key to step back one frame in the pause
mode.
The LED above the reverse playback key is illuminated during
the reverse playback mode.
4PLAY Press PLAY key to start playback.
Press PLAY key to step forward one frame in the pause mode.
The LED above the playback key is illuminated during the
playback mode.
4FAST
FORWARD
Press FAST FORWARD key to start playback (x1) of recordings
and press FAST FORWARD key again to speed up the playback
forward up to X16 in the playback mode.
Press FAST FORWARD key to speed down forward for a slow
playback up to X 1/60(50) in the pause mode.
The LED above the fast forward playback key is illuminated
during the fast forward playback mode.
5POWER Press POWER key to turn the monitor ON. Press POWER key
again to turn the monitor OFF. The power LED illuminates while
the power switch is in the ON position. The main power switch is
located on the back of the monitor.
6MIC Through this microphone, you can make yourself heard at the
camera site.
Hold down TAL K key while you talk.
