QUICK START INSTRUCTIONS
Q.S.I. HLF 1700 Eng V4-2019 HLF Italian Design
QUICK START INSTRUCTIONS
HLF 1700
ENGLISH
Part Code: 9BQE17G04

QUICK START INSTRUCTIONS
HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
RETAIN FOR FUTURE USE !
The copyright of these Instructions Manual, which are entrusted to the recipient
personally, remains with the HLF company.
The content may not be disclosed or made available to any third party without the
express consent of the HLF company.
These Operating Instructions must be read and applied by anyone performing work with
or on the equipment described.
In particular, it is imperative that all such persons familiarise themselves with the safety
instructions.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1 Installation
1.1 Transport
During the transport of the HLF 1700 coffee maker it is important to avoid the following
operations:
•Turning the box upside down or lay it down on its side
•Dropping the box
•Exposing it to rain, excessive cold or heat, or damp places
1.1.1 Receiving the unit
NOTE
Before to open the box of the HLF 1700 coffee maker, check out the packaging to be
sure there is no damage.
If damage is noticed, place a claim with the freight forwarder immediately.
Check for:
•Dents or damage of the box
•Wet areas
•Signs of tampering
1.1.2 Un-packing
The HLF 1700 coffee maker is packed in a strong carton specifically designed for this
unit. This should protect the unit during the transportation.
To further protect it, take out the unit from the box only when you have reached the
location where the machine will be installed, and only after all the electrical and water
connections are in place.
To take out the unit, you have to cut the plastic strip, and take out the upper carton
cover with the white styrofoam sheets. Then you can take out the pallet.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
NOTE
Only for installations in the United States of America
To meet the cleaning requirements in the United States, it is mandatory to install
the raising-machine kit.
Remove the four feet from the raising-machine kit accessory box, previously
ordered.
Unscrew all the feet (A) supporting the coffee machine;
screw the foot (B) (accessory) to foot (A);
fix the support under the machine and repeat for the other 3 supports.
(See image below)
CAUTION
The packing material must not be left accessible to others, as it is a potential source of
danger. For the disposal contact qualified companies.
Now the unit is free and ready to be installed on a base, table or cabinet strong enough
to hold 50 Kg.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.1.3 Checking the internal of the unit
Open the front door and check if any damage is visible. If you see damage, call for
technical service.
WARNING
Don’t try to operate the HLF 1700 coffee maker in case of presence of internal
damages. Even if the damages are minimal, it’s strongly recommended to leave the unit
disconnected from the power supply and call the technical service.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.2 Procedure
1.2.1 Minimum Requirements
The machine must only be installed using the supplied connection cables and hoses.
Any existing cables or hoses must not be reused. The manufacturer is not liable for any
damages arising from improper installation.
The use of incorrect connections voids the warranty!
Water Requirements: flow rate of at least 3 L/min.
For example:
Fill a container of 3 Liter capacious and make sure the time it takes to be filled in is 60
seconds or less (or 1 Liter in 20 seconds or less).
The maximum pressure of the water line has to be between 1 to 6 bar.
Electric Requirements: Be sure to choose a wall plug with enough power to supply the
unit and that it’s grounded in observance with current safety norms.
Refer to paragraph 1.3.3 of this Instruction Manual to select the correct wall plug.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.2.2 Filling the inside water tank (non Self Cleaning machine)
To fill the inside water tank of the unit, open the front door and take off the top lid of the
HLF 1700 coffee maker.
On the left side of the machine, it’s visible a clear tube that goes into a white water tank.
Pull up the clear tube together with the round cap from the tank. Then pull out the water
tank and fill it with fresh water.
After filling the tank, replace it into its original place and be sure to re-insert the clear
tube into the tank and close it with the round cap.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.2.3 Water connection (if external water kit is installed)
On the back of the HLF 1700 is located the inlet water valve that permits the connection
of the machine to the direct water line.
CAUTION
The water connection must only be connected to drinking water.
The maximum pressure of the water line has to be between 1 to 6 bar in order to
prevent damages to the inlet water valve. A lower pressure will not be sufficient to open
the inlet water valve, meanwhile a higher pressure will brake the valve causing in this
way a water flood.
Refer to the national laws of your country for the connection to the water line.
To connect the water line to the HLF 1700, is necessary to use a tube with a female
screw of ¾ of inch at each end of it, as showed on the following picture.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.2.4 How to connect the Drainage Kit
Remove the four feet from the raising-machine kit accessory box, previously ordered.
See following instructions and image below the instruction list:
1. Unscrew all the feet (A) supporting the coffee machine;
2. screw the foot (B) (accessory) to foot (A); fix the support under the machine and
repeat for the other 3 supports.
3. Install the drip tray with the 2 screws provided with the kit, then connect the pipe
to the drip tray.
Then make a hole in the plastic drip tray (see following image).
In this way the liquid collected, will be discharged externally through the tube that was
previously connected (previous step).

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
WARNING
Refer to planning diagram for respective distances.
1.2.5 Electric connection
Insert the power cord on the back of the machine near to the main power switch.
WARNING
INSERT THE POWER CORD INSIDE A CORRECT WALL PLUG, WITHOUT USING
ANY OTHER ELECTRIC ADAPTER.
THE USE OF EXTENSION CORDS, ADAPTERS AND/OR MULTIPLE PLUGS IS
STRONGLY FORBIDDEN !

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.3 Start up and operation mode
1.3.1 Loading products
CAUTION
Refer to chapter 5.5 Re-Fill Ingredients for software instructions concerning the
ingredients re-fill.
1.3.1.1 Coffee beans
Fill up the coffee beans hopper with fresh coffee beans.
Remember to open the beans stopper located at the bottom of the coffee beans hopper.
(see image A below).

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
NOTE
At first installation, strong pull the stopper so that the pin is completely pulled out (see
image B below)
NOTE
It’s recommended to use a mix of coffee beans for automatic coffee makers, in order to
avoid a rapid consumption of the grinder’s blades and also to get the best performance
for the HLF 1700
For information refer to a coffee beans dealer.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.3.1.2 Powder (in case the Soluble is installed)
Open the front door, remove the top lid and take out the container and fill it with soluble
powder.
NOTE
It’s recommended to do always this operation taking the powder container out of the
machine, in order to keep the interior of the machine clean from dust.
Place back the container in its original position.
1.3.1.3 Milk (In case of fresh milk machine)
WARNING
Refer to paragraph 2.2.1.3 for the proper use of the milk with HLF 1700 machine.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
Open the door of the machine and take out the clear pipe from the inside. Pass the pipe
through the milk tube holder on the side of the machine and then put it inside the milk
container.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.3.1.4 Detergent (in case of a Self Cleaning machine)
In order to refill detergent tank follow the instructions below.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
When the detergent tank sensor is disabled and the detergent tank needs to be refilled,
you will see this alarm in the main screen:
To show the detergent tank refill request, either press on the Reset button or
open the door, refill the detergent tank and close the door.
Choose the correct quantity of detergent refilled (assuming the capacity of a
bottle of detergent is 1000ml), insert the password (default is 123456, you can
edit or disable it in Main Menu > Security), and the alarm will disappear.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
1.3.2 Turning ON the unit
Turn on the unit by the main switch situated on the back of the HLF 1700 coffee maker.
The coffee group will position and the front LED will start blinking fast. The machine is
ready to be connected to an Android device via Bluetooth. See Paragraph 1.3.3.
If touch screen is installed, the touch screen will be turned on. Please refer to Paragraph
1.3.4 of this guide.
1.3.3 Connecting the unit via Bluetooth –MyHLF App
The machine is controlled by an Android device.
You can download the app “My HLF” from Google Play Store.
After the installation of the App, enable the GPS and open the app.
At the first start up My HLF will search automatically for HLF’s machines.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
When discovery process is finished, select from the shown list the device with the Serial
number of the machine, placed on a label on the back of the machine.

HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020
At the first time of connection, a "Pair Code" will be requested. Type in 1234 and push
OK. Once the connection is established the message will appear on the screen.
