Ch. 1
General Information
1.1 Product Description
1.2 Product Specifications
1.3 Inspection standard for TFT-LCD Panel
1.4 Product Dimensions
1.5 Odering Information
HMI-043T-B User’s Manual IUMHMI043T-B Ver.1.1A Dec, 2015 2
1.1 Product Description
ICOP Technology Inc. is proudly going to release a brand new HMI, which offers fanless
design, low power consumption, and IP65 front panel. The HMI-043T is powered by DMP
Vortex86Exm SoC, the new generation SoC of Vortex86 family, which is included
128MB/256MB memory and eMMC Flash memory. The resistive touch panel with LED
backlight TFT LCD increases operation convenience and visibility in outdoor environments.
The ultra-compact and thin exterior design is perfect for the present demanding embedded
and productive applications.
The new HMI-043T inherited PDX/PMX-series’ smooth appearance and ultra-texture
aluminum exterior design to make your industrial applications look more stylish. The versatile I/O
ports, 10/100Mps Ethernet, RS/232/485 , GPIO and Can bus etc. can fulfill fundamental
functions. Our consistent advantages feature stable performance, extended working temperature
support, low power consumption and fanless design. The open frame model can be
accommodated connectivity requirements to industrial machine platforms and industrial
automation equipment’s needs.
HMI-043T is not only supporting DOS, Linux, and Windows Embedded CE, but also
compatible with Arduino platform, which is an open-source electronics prototyping platform
based on flexible, easy to use hardware and software to meet ready-to-market demand and
provide competitive advantages for customers.
HMI-043T-B User’s Manual IUMHMI043T-B Ver.1.1A Dec, 2015 3
1.2 Product Specifications
HARDWARE SPECIFICATIONS
CPU DMP Vortex86Exm 400MHz
BIOS Coreboot BIOS
Cache L1:16KB I-Cache, 16KB D-Cache
L2: 4-way, 128KB L2 Cache
Memory 128MB / 256MB DDRIII onboard
Nand-Flash 512MB/1GB/2GB eMMC onboard (Optional)
Network
Integrated 10/100Mbps Ethernet
Support IEEE 802.3AT, PoE/PD (Optional)
Serial Interface
RS-232 x 1
RS-485 x 1
Can bus x 1 (Optional)
USB USB ports (Ver2.0) x 1
MECHANICAL & ENVIRONMENT
Power Requirement +7 ~ 24VDC
Power Consumption +12V@1A
Operating Temperature
0~+50°C (+32~+122°F) /
-20~+60°C (-4~+140°F)
Storage Temperature -30~+70°C (-22~ +158°F)
Operating Humidity 0% ~ 90% Relative Humidity, Non-Condensing
Dimensions 116.4 x 94.4 x 34.3mm (4.58 x 3.71 x 1.35 inches)
Weight 300g
HMI-043T-B User’s Manual IUMHMI043T-B Ver.1.1A Dec, 2015 4
LCD SPECIFICATIONS
Display Type 4.3” WQVGA TFT LCD
Backlight Unit LED
Display Resolution 480(W) x 272(H)
Luminance (cd/m2) 350 cd/m2
Contrast Ratio 450 : 1
Display Color 16.7M
Pixel Configuration R.G.B Vertical Stripe
Viewing Direction 6 o’clock
Viewing Angle Vertical 120o, Horizontal 140o
TOUCHSCREEN
Type Analog Resistive
Resolution Continuous
Surface Properties 3H / Anti-Glare
Transmittance 80%
Controller PS/2 interface
Software Driver DOS/Linux / WinCE
Durability 1 million
H
M
1
E
M
I-043T-B
U
