Hobbico AquaCraft EP1 Installation and operating instructions

Warranty
•AquaCraft™will warrant this motor for 90 days after the purchase from defects in materials or
workmanship. AquaCraft will either repair or replace, at no charge, the incorrectly made part.
• Make sure you save the receipt or invoice you were given when you ought your motor! It is your
proof of purchase and we must see it efore we can honor the warranty.
• To return your EP1 for repairs covered under warranty you should send your motor to:
Hobby Services
3002 N Apollo Drive Suite 1
Champaign, IL 61822
Attn: Service Department
Phone: [phone]:00 am - 5:00 pm Central Time M-F
E-mail: hobbyser[email protected]
HCAZ3023 for HCAB7861Entire Contents © Copyright 2004
ASSEMBLY AND OPERATION MANUAL
™
EP1
™
Electric
Outboard Motor

Thank you for purchasing the AquaCraft EP1! We at AquaCraft
know how exciting a new ho y purchase can e and we know
you’re anxious to get started, ut please take time to read these
instructions carefully and completely efore attempting to
operate your motor. This manual contains the instructions you
need to safely operate and maintain your motor. As with any
ho y, there is the possi ility of injury. Arming yourself with
knowledge is the est way to avoid injury.
PLEASE NOTE: Your hobby dealer ca ot accept a retur o
the EP1 outboard u it after it has bee used.
All pictures, descriptions, and specifications found in this
instruction manual are su ject to change without notice.
AquaCraft maintains no responsi ility for inadvertent errors in
this manual.
A template has een provided for you on page 3 of this
manual. This will help to accurately place the mounting holes.
Mount the out oard unit in the center of the rear of the oat
and so that the surface ride plate is even with the ottom of
the transom as shown.
The steering control arms of the EP1 out oard unit have een
outfitted with 4.8mm alls, ut will accept clevis or Z- end
links as well. You can attach to either control arm or oth ut
it is est, of course, to do whichever makes your oat perform
to its fullest potential.
When you are through operating your oat for the day, e sure
to perform these asic maintenance procedures. This will
prolong the life of the EP1 Out oard motor and help to ensure
trou le-free running. Be sure to tur the power “OFF” to
your boat a d tra smitter before performi g a y
mai te a ce.
• Flip your oat over and shake any excess water from the
motor compartment.
• Locate and remove the “end cap” (see “Exploded Vie ”
on page 4) at the ase of the out oard y turning it
counterclockwise. This will allow you to release any
water trapped in the gear housing. The “ ullet” at the
front of the out oard unit is also removed y
counterclockwise rotation. This allows access to the front
shaft earing.
• Make sure the propeller and drive dog are free of moss.
After every 10-12 hours of leisurely run time or after a day of
competition, it is a good idea to disassem le and re-lu ricate
the gears, shafts, and earings of the out oard unit with fairly
heavy-duty grease (not oil). Be sure to wipe away any old
grease ut DO NOT use any de-greasing agents. Refer to the
“Exploded Vie ” on the ack cover for an assem ly diagram.
You can increase the performance of the AquaCraft EP1 y
adjusting the ride height or the thrust angle of the propeller.
Making slight adjustments can make major differences, so it is
a good idea to keep a record of any adjustments you make
and how they affect performance. In addition to these
adjustments, performance may also e affected y the weight
distri ution of your on oard radio gear, speed control, attery
pack(s), etc…
GO FASTER
The EP1 comes equipped with a 27-turn stock motor ut can
e upgraded y replacing it with almost any 550-can size
motor. Be sure to consult the instructions for your speed
control unit to determine motor upgrade limits.
1. After clipping or de-soldering the red (+) and lack (-)
motor wires, simply remove the two 3 x 8mm hex head
screws on the underside of the motor compartment and gently
lift out the stock motor. Be sure to remove the water-cooling
coil and jacket from the stock motor and place it on the
upgrade motor efore installation.
2. Solder the red (+) and lack (-) motor wires to the proper
wiring lugs and attach the upgrade motor to the out oard unit
with the two 3 x 8mm hex head screws.
PLEASE READ BEFORE ru i g the EP1 o your model:
•NEVER attempt to swim after a stalled or capsized oat!
Wait patiently for the wind currents to return the oat to
SAFETY PRECAUTIONS
GETTING MORE OUT OF YOUR EP1
REGULAR MAINTENANCE
BASIC MAINTENANCE
STEERING LINKAGE
EP1 INSTALLATION
SPECIFICATION & DESCRIPTION CHANGES
INTRODUCTION
2

shore or use a tennis all attached to the end of a fishing
rod to retrieve a stalled or capsized oat.
• It is dangerous to operate any R/C model at any time that
there is not sufficient light.
• R/C models produce vi rations which will cause screws,
nuts, olts, etc, on your model to ecome loose over
time. It is importa t to make sure that all hardware is
secure efore operating your model.
•The edges of the propeller are very sharp a d ca cut your
fi gers if you are not careful. At no time should you ever
attempt to stop the prop with your hand. In the event that
weeds ecome entangled in the propeller, turn the EP1’s
power “OFF” efore attempting to remove them.
• Total run time of the EP1 can vary depending upon what
attery pack and ESC com ination you are using. When
you notice a decrease in power or sluggish steering
response, it means the attery pack is nearly drained and
it’s time to head for shore. As soon as the oat reaches
shore, turn off the power to the oat’s receiver and
transmitter (in that order).
•CAUTION: Your motor a d battery may be hot! Allow
them to cool for a few minutes efore attempting to
remove the attery pack.
• Adult supervision is strongly recommended! Children
should e warned a out the dangers of playing in close
proximity to water.
• R/C oats are controlled y radio signals, which are
suscepti le to possi le interference from other R/C
transmitters, paging systems, or other electrical noise.
Before tur i g your radio tra smitter a d receiver o ,
make sure no one else in the area is operating a radio on
the same frequency (channel).
• Do not touch the propeller anytime the electronics are
turned “ON.” Pay close atte tio to items such as loose
clothing, shirt sleeves, ties, scarves, long hair or any
loose o jects that may come in contact with the spinning
propeller. If your fingers, hands, etc. come in contact
with the spinning propeller, you may e severely injured.
• The speed and mass of R/C oats can inflict property
damage and severe personal injury if a collision occurs.
Never ru a R/C boat i the prese ce of swimmers or
where the possi ility of collision with people, wildlife, or
property exists.
• Electric motors can generate considera le heat. Do ot
touch a y part of your motor until it has cooled.
Touching the motor immediately after running the oat
may result in a serious urn.
If the buyer is ot prepared to accept the liability associated
with the use of this product, the buyer is advised to retur
the EP1 immediately i ew a d u used co ditio to the
place of purchase.
To order replacement parts for the AquaCraft EP1, use the order
num ers in the Replaceme t Parts List that follows. Replacement
parts are availa le only as listed and can e purchased from
ho y shops or mail order/Internet order firms. Hardware items
(screws, nuts, olts) are also availa le from these outlets. If you
need assistance locating a dealer to purchase parts, visit
www.hobbico.com and click on “Where to uy.” If this kit is
missing parts, contact Ho ico Product Support.
Replaceme t Parts List
Order # Item Descriptio
HCAB7861 EP1 Out oard Motor Unit *This is the part num er
for the entire unit.
HCAB6457 Out oard Upper Cover #1
HCAB7857 Out oard Lower Unit #2
HCAB7750 Propeller Set #16,17,18,19 x2
HCAB7856 Ball Bearings #G x4
HCAB3479 Motor #3
HCAB7858 Motor Coupler & Gasket #6, A, #7
HCAB8100 Transom Mount #22, C x2, D x2
HCAB7801
Linkage Ball Studs & Linkages #23 x2, E x2, F x2
HCAZ3023 Instruction Manual
Hardware Listi g
A. 3 x 3mm Set Screw
B. 3 x 8mm Hex Head Screw
C. 3 x 16mm Hex Head Screw
D. 3mm Nylon Insert Locknut
E. 2mm Nut
F. 2 x 8mm Screw
G. 5 x 10mm Ball Bearing
OUTBOARD MOTOR TEMPLATE
ORDERING REPLACEMENT PARTS
3

EXPLODED VIEWS
