1.0 Preface
Dear customer. Thank you for selecting the HW 86010 DECT transceiver
module. You have made a good choice, since HW 86010 is a powerful and
very versatile product that easily adds DECT communication to your
application.
This document will help you in getting the optimum integration result. This
covers mechanical, electrical and RF aspects.
Höft & Wessel aims for best customer satisfaction. In case of any problems
with this manual or with our products please do not hesitate to contact us.
Your feedback will enable our specialists to solve your problems and
continually improve our products and documentation.
1.1 About this document
This integration manual contains the full technical specification of the HW
86010 as well as all necessary information for a successful integration.
HW 86010 is a future-proof product which offers a number of flexible
interfaces and features. It is delivered together with Höft & Wessel DECT
firmware.
This Integration manual is focussed on the description of hardware features.
Not all of these possibilities are supported by the standard firmware but
some will require a customised firmware. Please always read this
Integration manual together with the Firmware manual in order to verify that
your desired operation is possible.

Integration Manual HW 86010
!< 4 1 © Höft & Wessel AG
page 6/46 AM 30.07.04 1.22 IM86010-1-22_.doc Subject to amendment, errors excepted
1.2 Contact Höft & Wessel AG
For immediate assistance please address yourself to the Höft & Wessel
service line:
Telephone: [phone]
Telefax: [phone]
Email: in[email protected]
If you have general questions concerning Höft & Wessel communication
products you may directly contact the communications department:
Telephone: [phone]
Telefax: [phone]
Email: [e-mail]
Latest revisions of all publicly available documentation and firmware
downloads are available from our web-site www.hoeft-wessel.de
Höft & Wessel AG
Rotenburger Strasse 20
D-30659 Hannover
GERMANY

HW 86010 Integration Manual
© Höft & Wessel AG 14<!
Subject to amendment, errors excepted IM86010-1-22_.doc 1.22 30.07.04 AM page 7/46
2.0 Product overview
The DECT transceiver module HW 86010 is a highly versatile and powerful
engine for popular and advanced DECT applications. It provides both RF
and baseband signal processing as well as a complete DECT protocol
stack.
2.1 General description
Built around a 55 MHz high-speed µC core the architecture of the HW
86010 features a full set of useful interfaces for best support of voice and
data services in various environments.
These include RS-232 for circuit data transmission, PCM interface to
connect to standard ISDN or PBX systems, I²C for auxiliary functions and
analogue input/output for voice. Additional general purpose I/Os plus an
accessible bus interface make the HW 86010 ideally suited for automation
and control applications with specific I/O requirements.
The RF section of the HW 86010 comprises a single-blind-slot radio, fully
compliant with EN 300 175-2. It offers improved functionality. Three
antenna connections allow flexible configurations. E.g. use of two antennas
for standard antenna diversity, together with an additional directional
antenna. Switching between antennas is performed under software control.
The DECT protocol stack has been implemented as firmware running on
the µC of the HW 86010. Please consult your Firmware manual for a
detailed description of the Firmware features.
The ultra-compact and low-voltage design make the HW 86010 optimally
suited for battery powered devices.

Integration Manual HW 86010
!< 4 1 © Höft & Wessel AG
page 8/46 AM 30.07.04 1.22 IM86010-1-22_.doc Subject to amendment, errors excepted
2.2 Architecture
Figure 1: Architecture of DECT transceiver module HW 86010
RS-232 Asynchronous serial interface, full duplex, selectable data rate up
to 115,2 kBd
PCM Isochronous serial interface, IOM-2 compatible, full duplex,
maximum clock rate 4,096 MHz, data rate 256 kBd
I²C Isochronous serial interface used for control of on-board
peripherals, half duplex
GPIO General purpose digital I/O pins
DECT core Dedicated µC that runs the DECT firmware
Radio RF section that generates and receives radio signals
Bus Direct interface to the internal bus of the core µC
FLASH Non-volatile memory used to store the firmware and parameters
Voice Interfaces for microphone, speaker and ringer
ADC/PWM Analogue input and PWM output (used to generate analogue
output signals)
Reset Monitors power supply and resets the module if voltage is too low
or external reset input is activated
Power Control Generates operating voltage for the DECT core and the radio

HW 86010 Integration Manual
© Höft & Wessel AG 14<!
Subject to amendment, errors excepted IM86010-1-22_.doc 1.22 30.07.04 AM page 9/46
2.3 Environmental Conditions
2.3.1 Storage Temperature Range
°C
Nominal -25 to +75
2.3.2 Operating Temperature Range
°C
Nominal +15 to +35
Extreme -10 to +55
2.3.3 Humidity
% rel.
Nominal 0 to 90, non-condensing

Integration Manual HW 86010
!< 4 1 © Höft & Wessel AG
page 10/46 AM 30.07.04 1.22 IM86010-1-22_.doc Subject to amendment, errors excepted
3.0 Hardware description
3.1 Mechanical characteristics
3.1.1 Dimensions
mm
Length 53.0, tolerances see section 3.1.3
Width 37.0, tolerances see section 3.1.3
Height 7.2, tolerances see section 3.1.3
3.1.2 Weight
g
Weight 18 +/- 2

HW 86010 Integration Manual
© Höft & Wessel AG 14<!
Subject to amendment, errors excepted IM86010-1-22_.doc 1.22 30.07.04 AM page 11/46
3.1.3 Mechanical drawing
Figure 2: Mechanical drawing

Integration Manual HW 86010
!< 4 1 © Höft & Wessel AG
page 12/46 AM 30.07.04 1.22 IM86010-1-22_.doc Subject to amendment, errors excepted
3.1.4 Antenna Assembly
3.1.4.1 Specification of internal wire antenna
37,00 mm
5,00 mm
1,00 mm
45,00 mm
Silver-plated copper wire ∅0.75 mm
90°
Shrink-on sleeve
Figure 3: Internal wire antenna
3.1.4.2 Mounting of antennas
80°-
90°
Figure 4: Recommended mountings of internal wire antennas
Caution: Be careful not to shortcut or ground the antennas, since this
may damage the HW 86010.
The antennas are DC coupled with the module.

HW 86010 Integration Manual
© Höft & Wessel AG 14<!
Subject to amendment, errors excepted IM86010-1-22_.doc 1.22 30.07.04 AM page 13/46
Figure 5: Recommended mounting of external antenna
An external antenna (50Ωimpedance) may be connected as indicated.
Figure 6: Soldering the external antenna

Integration Manual HW 86010
!< 4 1 © Höft & Wessel AG
page 14/46 AM 30.07.04 1.22 IM86010-1-22_.doc Subject to amendment, errors excepted
3.2 Electrical characteristics
3.2.1 Supply voltage V3P3
min. max.
Absolute maximum rating -0.5V +3.63V
Operating +3.0V +3.6V
Ripple +/-30mV
Voltage V3P3 is used as power supply for the baseband section of HW
86010. It is the reference voltage for all digital I/Os.
The current consumption on V3P3 depends on the power management.
Power management only applies to the PT, not to the FT. The PT may enter
a sleep mode whilst the FT is always active.
During firmware download the current consumption is higher, because
additional power is needed for writing the Flash memory
Mode average I3P3 peak I3P3
Sleep mode (PT only) 9mA 50mA
Active mode 40mA 50mA
Firmware download 40mA 90mA
All values are approximate figures measured under typical operating
conditions (20°C).

HW 86010 Integration Manual
© Höft & Wessel AG 14<!
Subject to amendment, errors excepted IM86010-1-22_.doc 1.22 30.07.04 AM page 15/46
3.2.2 Supply voltage VBATP
min. max.
Absolute maximum rating -0.5V +5.5V
Operating +3.3V +4.7V
Ripple +/-100 mV
Voltage VBATP is used as power supply for the radio section of HW 86010.
Mode average IBATP peak IBATP
Sleep mode (PT only) 3mA 300mA
Scan mode (PT only) 60mA 300mA
Idle mode (FT only) 50mA 400mA
1 traffic bearer 50mA 400mA
4 traffic bearers 110mA 400mA
All values are approximate figures measured under typical operating
conditions.
IBATP
100mA/div
t2ms/div
Figure 7: Typical IBATP bursts (multi-bearer connection active)
The current consumption on VBATP depends on the power management
and on the number of active traffic bearers. Power management only
applies to the PT, not to the FT. The PT may enter a sleep mode whilst the
FT is always active. If no communication is active, the FT operates in idle
mode. In this mode it sends out a dummy bearer.

Integration Manual HW 86010
!< 4 1 © Höft & Wessel AG
page 16/46 AM 30.07.04 1.22 IM86010-1-22_.doc Subject to amendment, errors excepted
Even in sleep mode a PT stays synchronised to the FT. In case
synchronisation is lost, the PT scans all DECT channels until it finds a
suitable FT. In scan mode the PT requires more power.
Caution: When a PT does not receive a valid FT it enters scan mode. This
may reduce stand-by time of battery-powered devices. Try to avoid this
situation.
3.2.3 Logical signals
Signal min. max.
Logical high output V3P3 - 0.3V V3P3
Logical low output 0.0V +0.5V
Logical high input 0.7 x V3P3 V3P3 + 0.3V
Logical low input -0.5V 0.3 x V3P3
Iout output logical high 2mA source
Iout output logical low 2mA drain

HW 86010 Integration Manual
© Höft & Wessel AG 14<!
Subject to amendment, errors excepted IM86010-1-22_.doc 1.22 30.07.04 AM page 17/46
3.3 Radio specification
Parameter Values
Frequency range 1880.064MHz to 1898.208MHz
Number of channels 10
Channel spacing 1.728MHz
Frequency offset ±50kHz at extreme conditions
Modulation Gaussian Frequency Shift Keying
(GFSK: BxT=0.5 ; m= 288kHz)
Multiplexing Time Division Multiple Access (TDMA)
Bearers per channel 12 full-slot duplex bearers
Number of bearers
used at the same time
6
Total system data rate 7.5 Mbit/s at the air interface
Maximum data rate for
a single radio
384 kbit/s at the air interface
Data rate per bearer
per direction
32 kbit/s at the air interface
Transmitter power 250mW during active transmit slot
Range inhouse: up to 50m
outdoor: up to 300m
Reference timer
accuracy
better than 5 ppm at nominal conditions
better than 10 ppm at extreme conditions
Packet jitter <0.1µs
Packet delay
variations
<2.0µs at extreme conditions
Receiver sensitivity -87 dBm typical at 10-3 BER
Antennas 2 internal, 1 external antenna
Load impedance 50Ωexternal antenna

Integration Manual HW 86010
!< 4 1 © Höft & Wessel AG
page 18/46 AM 30.07.04 1.22 IM86010-1-22_.doc Subject to amendment, errors excepted
3.4 Interface description
3.4.1 Connector specification
The external interface of the HW 86010 is implemented as 50-pin
connector. The connector on the module is compatible to Samtec part
number CLP-125-02-G-D-BE.
The recommended way to connect the HW 86010 is bottom-entry, i.e.
through the printed circuit board. A suited connector is Samtec FTSH-125-
01
The following figures illustrate two preferred mounting scenarios
2,0 mm
Connector
Connector
Figure 8: No components fitted on target PCB below HW 86010.
Minimum distance between PCBs 2,0 mm
When Samtec FTSH-125-01 is used as mating connector, minimum
distance between the PCBs is 2.92mm, as given by the profile of the
Samtec connector.
4,0 mm
Connector
Connector
Figure 9: Components fitted on target PCB below HW 86010.
Distance between PCBs depend on component heights
(here: 4,0 mm)

HW 86010 Integration Manual
© Höft & Wessel AG 14<!
Subject to amendment, errors excepted IM86010-1-22_.doc 1.22 30.07.04 AM page 19/46
3.4.2 Connector pinout
Other names Name Pin Pin Name Other names
VXOP 02 01 VXON
VXIP 04 03 VXIN
MICP 06 05 MICN
GPIO13 RINGP 08 07 RSTNO
GPIO14 PWM 10 09 ADC
SCL 12 11 SDA
GPIO2 14 13 GPIO1
PCMCLK GPIO4 16 15 GPIO3 PCMFSYNC
PCMDO GPIO6 18 17 GPIO5 PCMDI
CS1N GPIO8 20 19 GPIO7 INT0
GND 22 21 RSTBI
GPIO10 DTRI 24 23 RTSI GPIO9
TXDI 26 25 RXDO
VBATP 28 27 V3P3
BOOT1 DSRO 30 29 CTSO BOOT0
GPIO12 RIIO 32 31 DCDIO GPIO11
WRLN 34 33 RDN
DATA(1) 36 35 DATA(0)
DATA(3) 38 37 DATA(2)
DATA(5) 40 39 DATA(4)
DATA(7) 42 41 DATA(6)
ADR(1) 44 43 ADR(0)
ADR(3) 46 45 ADR(2)
ADR(5) 48 47 ADR(4)
GPIO16 BNK1 50 49 BNK0 GPIO15
The shown connector pinout directly corresponds to the physical connector
pinout, if the HW 86010 is oriented as shown in Figure 2, i.e. pin 1 is
located in the top right corner of the connector.

Integration Manual HW 86010
!< 4 1 © Höft & Wessel AG
page 20/46 AM 30.07.04 1.22 IM86010-1-22_.doc Subject to amendment, errors excepted
3.4.3 RS-232 interface
3.4.3.1 Signal description
The RS-232 interface uses the following interface signals
Signal I/O Description
TXDI I Serial data from host to HW 86010
RXDO O Serial data from HW 86010 to host
RTSI I Hardware handshake from host
CTSO O Hardware handshake from HW 86010
DTRI I Host ready signal
DSRO O HW 86010 ready signal
DCDIO I/O Carrier detect modem lead signal
RIIO I/O Ring indicator modem lead signal
Caution: All interface signals are 3.3V CMOS level. You must provide
an external V.24 line driver, if you want to connect the RS-232 port to a
standard V.24 device (PC, modem etc.). Connecting the module to a
V.24 line without external line drivers may damage the module.
3.4.3.2 Interface parameters
The HW 86010 is equipped with a fully featured UART.
Parameter Value
Parity None
Even
Odd
Mark
Space
Character size 5 bit
6 bit
7 bit
8 bit
Stop bits 1
1½ (for 5 bits character size only)
2
Baud rate 600 Bd
to 115200 Bd
