HOLDEN MY18 ZB Commodore Installation and operation manual

MY18 ZB Commodore
Service & Warranty Booklet

Vehicle identication certicate
Owner’s name
Owner’s address
Town State Postcode
Vehicle Identication Number (17 character ISOVIN)
Model name
Tyre size tted Wheel size tted
Registration number Engine number
Odometer reading
Date of purchase
Selling Dealer’s stamp and signature
Holden New Zealand Ltd., Company Number 1602 (hereinafter Holden)
Change of name, address or ownership
If you drive a pre-owned Holden, have moved house or changed any of your details, we’d
like to hear from you!
Holden uses your details to keep your vehicle’s factory provided Roadside Assistance and
Warranty details up to date.
It also helps us let you know if there is an existing rework action on your vehicle. To update
your details, please take a few minutes to ll in and mail the form at the back of this booklet
or visit Holden’s website at: www.holden.com.au/forms/change-of-owner-details
Printed in Australia
Part No. 92509026
November 2017
(MY18 ZB Commodore. Print 1)
© 2017 Holden New Zealand Ltd
Reproduction in whole or part is prohibited
without written approval from Holden New Zealand Ltd.,
Company Number 1602

Service
Voucher
1 Month
Complimentary
Inspection
At the end of the first month of enjoying your new
vehicle, your Holden Dealer is pleased to offer you
a Complimentary Vehicle Inspection.
This is an important part of your vehicle’s maintenance
schedule, where an expert Holden technician will ensure
that your vehicle’s systems are performing as intended.
Plus, it’s a great opportunity to ask any questions you
may have about your new Holden.
It’s all part of the Holden Complete Care program and
ensures the long term reliability and safety of your
vehicle.

Contents
Holden Warranty information ..........1
Servicing.......................................7
Maintenance schedule................10
Service charges..........................16
Service coupons.........................17
Additional service coupons.........45
Change of address or
ownership forms.........................51
Important information
Your vehicle has an Engine Oil Life
System (EOLS) which monitors vehicle
usage and driving patterns to maximise
the service life of the engine oil – refer
to Service information in the Owner’s
Manual for further details.
• Changeengineoilandlterwithin
1,000 km when Change Engine
Oil Soon is displayed in the Driver
Information Centre (DIC).
• The vehicle must have a maintenance
service(incl.oilandlter)atleastonce
every year even if Change Engine Oil
Soon message has not displayed in the
DIC.
Note:
• If Change Engine Oil Soon is
displayed within 5,000 km of the next
scheduled maintenance interval,
the scheduled service should be
performed.

1
Holden Warranty application
This Holden Warranty is given by Holden New Zealand Ltd., (Company Number
1602), (‘Holden’) of 2/118 Savill Drive, Mangere East, 2024, Auckland, New
Zealand. Holden Customer Care, New Zealand: 0800 465 336. The Holden
Warrantyappliestothevehicleidentiedontheinsidefrontcoverofthisservice
booklet. It is provided to the original and subsequent owners/operators driving
the vehicle within New Zealand during the Holden Warranty period.
ThebenetsconferredbythisHoldenWarrantyareinadditiontootherrights
and remedies available to you under consumer protection laws (including those
under the Consumer Guarantees Act 1993), which cannot be excluded or limited
(referred to as Statutory Rights). This Holden Warranty in no way limits or
restricts your rights or remedies under such Statutory Rights.
New Zealand vehicles
This Holden Warranty is only applicable to vehicles purchased and operated in
New Zealand.
However, this Holden Warranty will not apply for Holden vehicles exported and
operated outside of New Zealand or for Holden vehicles purchased outside of
New Zealand and imported into New Zealand.
Holden Warranty repairs covered
Subject to your non-excludable statutory rights and the exclusions shown
on the following pages, this Holden Warranty covers the correction, of any
manufacturing defect to materials or Holden workmanship and advised to a
Holden Dealer or Authorised Service Outlet, by repair or at Holden’s option by
replacement.
Holden Warranty period
ThecoverageunderthisHoldenWarrantycommencesfromthedateofrst
registration (or in the case of a demonstrator vehicle the date when the vehicle
wasrstplacedintoservicebytheDealer).Thiscoverageexpiresattheend
of the period of 3 years after the commencement date or after the vehicle has
travelled100,000kilometres,whicheveroccursrst.
No charge
Warranty work performed under this Holden Warranty (including parts and
labour) will be carried out at no cost to the vehicle owner. However, this work
shouldnotbeconfusedwithservicingspeciedintheMaintenanceschedulein
this service booklet for which a charge is payable.
Holden Warranty certicate

2
Holden Warranty exclusions
Damage
Your Holden Warranty does not extend to the following: Damage caused by an
accident,re,theftormovingobjectsstrikingthevehicle(includinginsidethe
vehicle); damage as a result of towing; damage caused by industrial fallout,
chemicalsorsealants;damagecausedbyatmosphericfalloutorood,hail,salt,
etc.
Maintenance items
Your Holden Warranty does not extend to services such as brake adjustment,
brakereplacement,replacementoflters,wiperrubbersetc.,whicharerequired
as part of normal vehicle maintenance. Refer to Maintenance Schedule further in
this booklet.
Bulbs
Bulbs are warranted for 12 months under this Holden Warranty.
Misuse
This Holden Warranty does not cover damage caused by:
(a) misuse or abuse of the vehicle such as by racing, rallying, overloading, etc
or neglect,
(b) operation of the vehicle after the defect is known,
(c) failure to carry out scheduled maintenance services. Refer to Maintenance
Schedule further in this booklet,
(d) use of incorrect types and grades of fuel, oil or lubricants,
(e) alterationormodicationsofthevehiclebyanyonenotauthorisedby
Holden,
(f) ttingofpartsoraccessoriesnotrecommendedbyHolden,
(g) any work carried out on the vehicle by anyone except an Authorised Holden
Dealer or Authorised Service Outlet.
Holden Warranty certicate

3
This section is designed to assist you to understand the Holden Warranty
provided with your new vehicle which is in addition to your Statutory Rights
which cannot be excluded, limited or restricted by this Holden Warranty.
The following are some of the most frequently asked questions for which detailed
answers are provided.
Q 1. How do I go about obtaining Holden Warranty service?
It is the responsibility of the Selling Dealer to provide Holden Warranty service,
therefore, you should take your vehicle to the Selling Dealer whenever Holden
Warranty service is needed. However, if this is not possible, you may go to any
other Authorised Holden Dealer. The details recorded inside the front cover of
this service booklet will be required by the Dealer.
Q 2. What should I do if my vehicle becomes unsafe or inoperative as a
result of a defect which is covered by the Holden Warranty?
You should contact the nearest Authorised Holden Dealer or Holden Roadside
Assistance as soon as possible, and arrange for that Dealer to carry out the
required Holden Warranty service.
Q 3. What should I do if, in an emergency, Holden Warranty service
is required and an Authorised Holden Dealer is not available to
provide such service at the time?
Subject to your Statutory Rights, if, in an emergency, a repair, replacement or
adjustment (covered by the Holden Warranty) is required to enable your vehicle
to be operated safely and it is not practical for you to go to an Authorised Holden
Dealer, the service (to the extent that it is necessary to enable your vehicle to be
operatedsafely)maybeperformedbyanyotherqualiedmechanicorrepairer.
A claim for the reasonable cost may be made under the Holden Warranty
through the Authorised Holden Dealer who would normally provide you with
Holden Warranty service. You must also take your vehicle to the Authorised
Holden Dealer for inspection of the service and/or completion of any required
Holden Warranty service, as soon as possible.
Note: During normal business hours, you should seek authorisation from your
nearest Authorised Holden Dealer or Holden Customer Care, prior to repairs
under your Holden Warranty being commenced.
Holden Warranty questions and answers

4
Q 4. Is damage or injury, loss of time, inconvenience, commercial or other
direct or indirect loss covered by the Holden Warranty?
No, these items are not covered under the Holden Warranty. Holden Warranty
only covers the repair, replacement or adjustment of those parts of your
vehicle which are found to be defective in materials or workmanship. No other
types of claim for compensation of any kind, even if the same resulted from a
consequence of a defect in materials or workmanship in your vehicle, will be
recognised under the Holden Warranty.
You may have rights under your non-excludable Statutory Rights to claim
compensation or other remedies outside of the Holden Warranty, but any claim
based on those rights should be separately pursued.
Q 5. Will I have to pay for maintenance costs during the Holden
Warranty Period?
Maintenance costs are not covered by the Holden Warranty. The Maintenance
schedules in this service booklet specify the minimum maintenance required for
your vehicle operating under normal conditions.
Subject to your Statutory Rights, the Maintenance items (except where they are
required as a result of defects in materials or workmanship) for which you will
have to pay include:
• Engine tune-up, including spark plugs replacement.
• Replacementofalllters,engineandotherbelts,hoses(includingLPG
hoses) wiper blades and clutch linings.
• Cleaningorushingoffuel,coolant,brake,engine,transmission,power
steering etc., after 3,000 km.
• Carbon and sludge removal.
• Maintenance servicing of emission control system devices.
• Adding to (or replacing) lubricants.
• Adding to (or replacing) air conditioning refrigerant, after 3,000 km.
• Any necessary adjustments to drive belts, transmission, clutch, park
brake etc.
• Wheel balancing – after 3,000 km.
• Wheel alignment.
• De-dusting or de-glazing of brake linings or pads – after 3,000 km.
• Brake pad/lining wear or damaged brake components due to brake/pad
lining wear.
• Clutch lining wear or damaged clutch components due to lining wear.
Holden Warranty questions and answers

5
• Brake disc pad or disc wear.
• Battery recharging.
• Paint,brightmetalnishandtrim,duetonormaldeterioration.
• Body panel adjustment – after 3,000 km.
• Door, or bonnet lock adjustments.
• Glassorchanneladjustments–after3,000km.
• Bodyrattle,squeaksandgeneraltighteningofbolts,fastenersandttings–
after 3,000 km.
• Chipped glass or breakage.
• Tornordamagedoormatsorcarpets.
• Normal wear and tear to trim components.
Q 6. Will I have to pay for any costs or expenses in connection with the
provision of Holden Warranty service?
All parts and labour used in carrying out Holden Warranty service at the
premises of the servicing Holden Dealer, are free of charge. Whenever Holden
Warranty service is to be carried out by the servicing Holden Dealer it is your
responsibility to deliver your vehicle to the servicing Holden Dealer’s premises.
If, as a result of a defect which is covered by the Holden Warranty, your vehicle
cannot be driven safely and you arrange for the nearest Authorised Holden
Dealer to carry out the required Holden Warranty service, Holden will accept
reasonable towing costs to move your vehicle to the nearest Holden Dealer’s
premises. Before employing a towing company, contact the nearest Holden
Dealer or Holden Roadside Assistance Service or Holden Customer Care to
obtain guidance.
Q 7. Would my vehicle’s engine benet from fuel additives, oil additives
or coolant additives not marketed by Holden?
Your Holden is engineered to perform at its optimum using Holden
recommendedlubricantsanduids.Theuseofsupplementaladditivesisnot
recommended as their use not only increases operating costs, but may indeed
be harmful to your vehicle.
Any negative impact or consequences due to the use of additives may affect the
validity of your Holden Warranty.
OnlytheuidsandlubricantsreferredtointheOwner’sManualshouldbe
used.
Holden Warranty questions and answers

6
Unauthorised statements in relation to Holden products
No Holden Dealer or other person is authorised or permitted to give or make
any statement, assertion or undertaking in relation to the quality, performance,
characteristics,descriptionsortnessforanypurposeofanyHoldenproductor
in connection with the supply of any Holden product, which is at variance with
any written statement, assertion or undertaking on any of these subjects given
or made by Holden in its published sales literature, and Holden does not accept
any responsibility for such unauthorised action.
Holden Warranty questions and answers

7
Servicing
Distance / Time based service intervals
The Complimentary inspection is due at 1 month of owning your new Holden.
Therstscheduledmaintenanceserviceisdueat1yearor15,000km
(whicheveroccursrst)fromtakingdeliveryofyourvehicleandthereafter,every
1yearor15,000km(whicheveroccursrst).
Additional services are required under certain driving conditions, such as when
towing. Refer to Maintenance Schedule further on in this booklet.
Complimentary inspection
The 1 month Complimentary inspection is performed free of charge by the
Selling Dealer.
A different Holden Dealer may perform this inspection if provided with
authorisation from the selling Dealer.
Determining the proper service interval
The operating conditions of your vehicle will determine the service interval. Use
the timeintervalortheodometerreading,whicheveroccursrst,todetermine
whentheserviceisdue.Itisimportanttorememberthatoilsanduidsinyour
vehicle will deteriorate over time, therefore if your vehicle has not travelled the
speciedserviceintervaldistance,thevehiclemust be serviced by time interval.
Under certain operating conditions, your Holden may require additional servicing
to ensure maximum safety, performance and longevity.
The additional service requirements typically include more frequent replacement
oflubricatingoilsforexample,engineandtransmissionuidsandthemore
frequent inspection of steering, suspension and brake system components. For
more information please refer to Maintenance Schedule further on in this booklet.
Your Holden Dealer will be able to determine the appropriate service
requirements for your vehicle according to your operating conditions.

8
Engine oil life system
If Change Engine Oil Soon appears in the Driver Information Centre (DIC),
theengineoilandltermustbereplacedwithin1,000kmandtheengineoil
lifesystemreset.Theengineoilandlterchangeshouldberecordedonan
additional service coupon.
Note: If Change Engine Oil Soon appears in the DIC within 5,000 km of the next
scheduled maintenance interval, the scheduled service should be performed,
theengineoilandlterchanged,andtheEOLSreset.Recordontheapplicable
coupon stub.
Service coupons
Service coupons are provided further on in this booklet. When each service is
performed, the appropriate coupon is removed. This reveals the next coupon to
remind you when the next service is due.
Aftereachservice,checktheservicehasbeenvalidatedbytheServiceProvider
and, where applicable, the Dealer’s stamp and signature is on the coupon stub.
This is important as it not only assists in the determination of Holden Warranty
claims, but enhances the value of the vehicle when selling.
Service coupons are provided for each service up to the 13 years / 195,000 km
service. For all subsequent services, refer to the maintenance schedule
‘After 13 years or 195,000 km’ on page 13. When performing these services,
record them on the additional service coupons provided on page 45.
Additional service requirements
If you are driving your vehicle outside of the normal driving conditions, you may
need to conduct additional servicing. Criteria for these additional services can
be found in the Maintenance Schedule. Additional service coupons can be found
further on in this booklet.
As a guide, if you operate your vehicle continually for a period of 1 month
or 1,000 km under any of the conditions listed, then additional services are
recommended. If you consider that further servicing may be required, consult
your Holden Dealer.
Servicing

9
Your Holden Dealer
When it comes to service, remember that your Holden Dealer has the trained
personnel and specialised equipment to correctly service your vehicle. Your
Dealer invites you to return for all your service needs both during and after the
HoldenWarrantyPeriod.
The safety, economy, emission control, performance and reliability of your
vehicle cannot be assured unless regular maintenance is performed, preferably
by factory-trained technicians at Holden Dealers.
Holden Warranty and service
Subject to your non-excludable Statutory Rights, all maintenance services listed in
this booklet, and replacement of service items, are the responsibility of the owner
and as such are NOT considered under the provisions of the Holden Warranty
toberectiedofdefectivematerialandworkmanship.Itemssuchaswheel
alignment, necessary adjustments to drive belts, transmission, clutch and parking
brake or any other items which may require servicing due to
fair wear and tear are carried out at the owner’s cost.
Damage caused by failure to have proper maintenance services carried out in
accordancewithHolden’sspecicationsmayvoidyourHoldenWarranty.As
a result, it is strongly recommended that such services be carried out by an
authorised Holden Dealer or Authorised Service Outlet and that you read the
Holden Warranty section previously in this booklet, so that you are aware of the
Holden Warranty exclusions.
Servicing

10
Maintenance schedule
Yearsorx1000km(whicheveroccursrst)
1234567891011 12 13
15 30 45 60 75 90 105 120 135 150 165 180 195
Under bonnet Engine oil *1 ●●●●●●●●●●●●● Engineoillter*1 ●●●●●●●●●●●●●
Reset engine oil life system *1 ○○○○○○○○○○○○○
Drive belt ○ ○ Timing belt (Diesel) *2 ● Spark plugs (4 cyl petrol) ● Spark plugs (V6 petrol) ● Cooling system ○○○○○○○○○○○○○
Engine coolant Replace every 5 years regardless of km
Brakeuid*3 Replace every 2 years regardless of km Powerbrakeunitandhoses ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Air cleaner element *4 ○○○●○○○●○○○●○
Battery and terminals ○○○○○○○○○○○○○
Under vehicle Brake lines, hoses and connections ○○○○○○○○○○○○○
Front and rear disc brakes ○○○○○○○○○○○○○
Fuel lines and hoses ○○○○○○○○○○○○○
Evaporative emissions system ○ ○
Dieselfuellter*5 ○ ● ○ ● ○ ● ○ ● ○ ● ○ ● ○ Powersteeringoperationandlinkages ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Automatictransmissionuid*6 ●
Years
km
●Replace
▲Tighten ○Inspect: Inspect and adjust, rotate, drain, lubricate, reset or clean as required. If repair or replacement is necessary, additional charges may apply.

11
Maintenance schedule
●Replace ▲Tighten ○Inspect: Inspect and adjust, rotate, drain, lubricate, reset or clean as required. If repair or replacement is necessary, additional charges may apply. *1 IfaChangeEngineOilSoonmessageisdisplayed,changetheengineoilandoillterwithinthenext1,000km. *2 Replacethetimingbeltat10yearsor150,000km(whicheveroccursrst). *3 Caravanortrailertowing,replacebrakeuidevery1year. *4 If the vehicle is operated in very dusty or sandy areas, clean and if necessary, replace the air cleaner element every 15,000 km. *5 Replacethedieselfuellterevery2yearsor30,000km(whicheveroccursrst).Ifthevehicleisoperatedinhighhumidityareasorsubstantially
varyingdaytimeandnighttimetemperatures,drainthefuellterevery6months.
*6 Ifthevehicleisoperatedunderanyofthefollowingconditions,changetheautomatictransmissionuidandlterevery90,000km. AExtended periods of idling or low speed operation. B Extended heavy load, high speed operation in outside temperatures above 35°C. C Driving for long period in cold temperatures or driving regularly for short distances only. D Caravan or trailer towing.
*7 YourHoldenDealerwillassessthewearonyourtyresandrotatedependingupontheirspecicationandcurrentserviceability.
Yearsorx1000km(whicheveroccursrst)
1234567891011 12 13
15 30 45 60 75 90 105 120 135 150 165 180 195
Under vehicle Final drive (AWD) ○○○○○○○○○○○○○
Front and rear suspension ○○○○○○○○○○○○○
CV joint dust boots and propshaft rubber couplings ○○○○○○○○○○○○○
Tyreconditionandinationpressure(incspare) ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Rotate wheels *7 ○○○○○○○○○○○○○
Check and tighten bolts and nuts on chassis and body ▲▲▲▲▲▲
Exhaust system and heat shields ○○○○○○○○○○○○○
Years
km

12
Maintenance schedule
Yearsorx1000km(whicheveroccursrst)
1234567891011 12 13
15 30 45 60 75 90 105 120 135 150 165 180 195
Interior / Exterior Parkbrakeoperation ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Horn, lights, washers and wipers ○○○○○○○○○○○○○
Seatbelt, webbing condition, buckle operation and retractor mechanism operation ○○○○○○○○○○○○○
Pollenlter(passengercompartmentairlter)*8 ○ ○ ○ ○ Expirydateontyresealantcanister(iftted) ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Door strikers, hinges, bonnet latch - lubricate ○○○○○○○○○○○○○
Key transmitter range ○○○○○○○○○○○○○
Road test Air conditioner performance ○○○○○○○○○○○○○
Cruise control operation ○○○○○○○○○○○○○
Parkpawloperation ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Check outstanding rework actions are complete ○○○○○○○○○○○○○
●Replace
▲Tighten ○Inspect: Inspect and adjust, rotate, drain, lubricate, reset or clean as required. If repair or replacement is necessary, additional charges may apply. *8Replacethepollenlter(passengercompartmentairlter)asrequired.Ifthevehicleisoperatedinverydustyorsandyareas,replacethepollen
lter(passengercompartmentairlter)every15,000km.
Years
km

13
Maintenance schedule
After 13 years or 195,000 km
Performevery1yearor15,000km
(whicheveroccursrst)
Performattimeordistance
(whicheveroccursrst)
Under bonnet Engine oil *1 ● Engineoillter*1 ●
Reset engine oil life system *1 ○ Drive belt *2 ○ Timing belt (Diesel) Replace every 10 years or 150,000 km Spark plugs (4 cyl petrol) Replace every 8 years or 120,000 km Spark plugs (V6 petrol) Replace every 13 years or 195,000 km Cooling system ○ Engine coolant Replace every 5 years regardless of km
Brakeuid*3 ○ Replace every 2 years regardless of km Powerbrakeunitandhoses ○
Air cleaner element *4 ○Replace every 4 years or 60,000 km
Battery and terminals ○
Under vehicle Brake lines, hoses and connections ○ Front and rear disc brakes ○ Fuel lines and hoses ○ Evaporative emissions system Inspect every 6 years or 90,000 km Dieselfuellter*5 ○ Replace every 2 years or 30,000 km Powersteeringoperationandlinkages ○ Automatictransmissionuid*6 Replace every 12 years or 180,000 km Final drive (AWD) ○
continued overleaf

14
Maintenance schedule
After 13 years or 195,000 km
Performevery1yearor15,000km
(whicheveroccursrst)
Performattimeordistance
(whicheveroccursrst)
Under vehicle Front and rear suspension ○ CV joint dust boots and propshaft rubber couplings ○ Tyreconditionandinationpressure(incspare) ○
Rotate wheels *7 ○ Check and tighten bolts and nuts on chassis and body Tighten every 2 years or 30,000 km Exhaust system and heat shields ○
Interior / Exterior Parkbrakeoperation ○
Horn, lights, washers and wipers ○ Seatbelt, webbing condition, buckle operation and retractor mechanism operation ○
Pollenlter(passengercompartmentairlter)*8 Inspect every 3 years or 45,000 km Expirydateontyresealantcanister(iftted) ○
Door strikers, hinges, bonnet latch - lubricate ○ Key transmitter range ○
Road test Air conditioner performance ○ Cruise control operation ○ Parkpawloperation ○
Check outstanding rework actions are complete ○
●Replace
○Inspect: Inspect and adjust, rotate, drain, lubricate, reset or clean as required. If repair or replacement is necessary, additional charges may apply.
