HOLDEN WN Series User guide

WN CAPRICE HOLDEN.COM.AU
WN CAPRICE
OWNER’S HANDBOOK

GM Holden Ltd, ABN 84 006 893 232 (hereinafter Holden)
Change of name, address or ownership
If you drive a pre-owned Holden, have moved house or changed any of your details, we’d like to
hear from you!
Holden uses your details to keep your vehicle’s factory provided RoadsideAssistance and Warranty
details up to date.
It also helps us let you know if there is an existing safety recall or rework on your vehicle. To update
your details, please take a few minutes to ll in and mail the form at the back of the Service/Warranty
booklet or visit Holden’s website at: www.holden.com.au/forms/change-of-owner-details
GM Holden Ltd (Holden) is collecting the new owner’s personal information in order to process
the request for transfer for the specied vehicle. We may disclose your personal information to our
related companies and third parties who provide us with (or help us provide) products and services,
including to overseas locations such as the USA, and other countries in Europe, Oceania and Asia.
Holden’s privacy policy (available at: www.holden.com.au/privacypolicy) states how you can seek
to access or correct any personal information Holden holds about you, how to complain about a
privacy breach by Holden and how Holden will deal with a privacy complaint.
You can contact Holden on 1800 033 349 or alternatively, you may prefer to email Holden at:
[email protected]
Note: Please refer to the inside front cover of the Service/Warranty booklet for the Vehicle
Identication Certicate.
Printed in Australia © 2015 GM Holden Ltd
Part No. 92277337 Reproduction in whole or part is
July 2015 prohibited without written approval from
(MY16 WN Caprice. Print 1) GM Holden Ltd, ABN 84 006 893 232

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
Contents Introduction . . . . . . . . . . . . . . . . . . . . . . 2
In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keys, Doors, and Windows . . . . . 16
Seats and Restraints . . . . . . . . . . . 36
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 57
Instruments and Controls . . . . . . . 62
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . 93
Infotainment System . . . . . . . . . . . . 99
Climate Controls . . . . . . . . . . . . . . 178
Driving and Operating . . . . . . . . . 185
Vehicle Care . . . . . . . . . . . . . . . . . . 225
Service and Maintenance . . . . . 278
Technical Data . . . . . . . . . . . . . . . . 280
Customer Information . . . . . . . . . 288
Index .................... 290

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
2 Introduction
Introduction

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
Introduction 3
Introduction
This Owner's Handbook provides
you with all the necessary
information to enable you to drive
your vehicle safely and efficiently.
Make sure your passengers are
aware of the possible risk of
accident and injury which may result
from improper use of the vehicle.
Using this Manual
.This manual describes all
options and features available
for this model. Certain
descriptions, including those
for display and menu
functions, may not apply to
your vehicle due to model
variant.
.The In brief section will give you
an initial overview.
.The table of contents at the
beginning of this manual and
within each chapter shows
where the information is located.
.The index will enable you to
search for specific information.
.Directional data, e.g. left or right,
or front or back, always relate to
the direction of travel.
.The Bluetooth
®
word mark and
logo are registered trademarks
and are owned by the Bluetooth
SIG, Inc.
.iPod
®
is a registered trademark
of Apple Inc.
.ESP
®
is a registered trademark
of Daimler AG.
Danger, Warning, and
Caution
{Danger
Text marked {Danger provides
information on risk of fatal injury.
Disregarding this information may
endanger life.
{Warning
Text marked {Warning
provides information on risk of
accident or injury. Disregarding
this information may lead to injury.
Caution
Text marked Caution provides
information on possible damage
to the vehicle. Disregarding this
information may lead to vehicle
damage.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
4 Introduction
2NOTES

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
In Brief 5
In Brief
Initial Drive Information
Remote Keyless Entry (RKE)
System . . . . . . . . . . . . . . . . . . . . . . . . 5
Door Locks . . . . . . . . . . . . . . . . . . . . . 5
Seat Adjustment . . . . . . . . . . . . . . . . 6
Head Restraint Adjustment . . . . . . 6
Seat Belts ....................... 7
Mirror Adjustment . . . . . . . . . . . . . . . 8
Steering Wheel Adjustment . . . . . 8
Instrument Panel Overview . . . . 10
Interior Lighting . . . . . . . . . . . . . . . . 11
Exterior Lighting . . . . . . . . . . . . . . . 12
Horn ........................... 13
Washer and Wiper Systems . . . 13
Climate Controls . . . . . . . . . . . . . . . 14
Transmission . . . . . . . . . . . . . . . . . . 14
Parking . . . . . . . . . . . . . . . . . . . . . . . . 14
Getting Started . . . . . . . . . . . . . . . . 14
Initial Drive
Information
Remote Keyless Entry
(RKE) System
Q: Lock and arm the alarm
K: Unlock and disarm the alarm
Y: Boot unlock
See Keys 016.
See Door Locks 023.
Door Locks
To lock, insert the key into the
driver's door lock and turn towards
the rear of the vehicle, then turn it
back to the vertical position and
remove.
This will lock all doors.
To unlock, turn the key towards the
front of the vehicle to unlock the
driver's door.
See Keys 016.
See Door Locks 023.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
6 In Brief
Seat Adjustment
The vehicle has the following levers
and switches for seat adjustment.
1. Lumbar
2. Recline
3. Forwards/backwards, up/down,
cushion tilt
See Seat Position 038.
Head Restraint
Adjustment
{Warning
The head restraint is a safety
feature.
The centre of the head restraint
should be at eye level, never at
neck level.
.Lift the head restraint up to
raise it.
.Push the locking button and
push the head restraint down to
lower it.
.Front head restraints cannot be
removed.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
In Brief 7
.To adjust horizontally, pull the
front head restraint forwards and
engage in one of three positions.
.To return to its rearmost position,
pull fully forwards and release.
The vehicle has adjustable rear
head restraints, these can be
removed.
See Head Restraints 036.
See Child Restraint Systems 052.
Seat Belts
Pull the metal tongue across your
body into the buckle, until it clicks
into place.
The belt should not be twisted.
It should lie flat and fit firmly across
your hips.
To remove, press the release button
on the buckle to allow the belt to
retract.
See Three-Point Seat Belt 044.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
8 In Brief
Mirror Adjustment
Automatic dimming rear view
mirror
The vehicle has an automatic
dimming rear view mirror.
The mirror will automatically switch
in and out of night view.
See Automatic Dimming Rear View
Mirror 030.
Exterior mirrors
Power mirrors
L: Left side mirror selected
R: Right side mirror selected
): No mirrors selected
To adjust an exterior rear view
mirror:
1. Press the switch (2) to Lor R.
2. Press the switch (1) to adjust
the mirror.
See Power Mirrors 029.
Steering Wheel
Adjustment
{Warning
Do not attempt to adjust the
steering wheel while driving.
1. Move the lever down to unlock.
2. Move the steering wheel up,
down, closer or away.
3. Move the lever up to lock.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
In Brief 9
4. Ensure the steering wheel is
locked in position before
driving.
See Steering Wheel Controls 065.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
10 In Brief
Instrument Panel Overview

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
In Brief 11
1. Vents. See Adjustable Air
Vents 0183.
2. Glovebox 057.
3. Vents. See Adjustable Air
Vents 0183.
4. Infotainment system controls.
See Overview 0101.
5. Infotainment screen. See
Overview 0101.
6. Sunlight sensor. See Air
Conditioning System 0178.
7. Engine Start/Stop button. See
Ignition Positions 0187
8. Windscreen Wiper/Washer
066.
9. Steering wheel controls. See
Cruise Control 0199.
10. Horn 066.
11. Instrument Cluster 071.
12. Steering wheel controls. See
Overview 0101.
13. Lever for:
Turn and Lane-Change Signals
095.
Headlamp High/Low-Beam
Changer 093.
Driver Information Centre (DIC)
079.
14. Exterior Lamp Controls 093.
15. Instrument panel illumination
switch. See Interior Lighting
011.
16. Head-up display controls. See
Head-Up Display (HUD) 081.
17. Steering Wheel Adjustment
065.
18. Heated seat switches. See
Heated Front Seats 041.
19. Hazard Warning Flashers 095.
20. Climate control switches. See
Air Conditioning System 0178.
21. Electric Parking Brake 0194.
22. Electronic stability control
switch. See Electronic Stability
Control (ESC) 0198. Park
Assist switches. See Parking
Assist 0203.
23. Front Storage 058.
24. 12 volt power socket. See
Power Outlets 068.
25. Shift lever. See Transmission
Display 0190.
Interior Lighting
+: On/off
4: Door activated
Dome Lamps 096.
Reading Lamps 097.
Glovebox Lamps 097.
Load Compartment Lamps 096.
Battery Power Protection 098.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
12 In Brief
Exterior Lighting
O: Off
AUTO: Automatic headlamps
;: Park lamps
2: Headlamps
#: Fog lamps
D: Instrument lighting dimmer
See Exterior Lamp Controls 093.
High/low beam
High beam: Push lever
Low beam: Push the lever forward
again
Headlamp flash: Pull lever
The high beam lamps can be
flashed even if the headlamps and/
or ignition are off.
See Exterior Lamp Controls 093.
See Headlamp High/Low-Beam
Changer 093.
Turn signals
Left: Lever up
Right: Lever down
See Exterior Lamp Controls 093.
See Turn and Lane-Change Signals
095.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
In Brief 13
Hazard warning flasher
Press |to turn the hazard warning
flasher on and off when the ignition
is in any position.
See Hazard Warning Flashers 095.
Horn
Press a.
Washer and Wiper
Systems
Mist: Wipers cycle while the lever is
held up
OFF: Off
INT: Intermittent wipe
LO: Slow
HI: Fast
L: Pull to wash the windscreen.
The wipers will also cycle for a
short time.
See Windscreen Wiper/Washer
066.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
14 In Brief
See Washer Fluid 0235.
Climate Controls
The climate control panel is located
in the centre of the instrument
panel.
Settings for the driver and
passenger can be adjusted
independently.
See Air Conditioning System 0178.
Transmission
Automatic transmission
P: Park
R: Reverse
N: Neutral
D: Drive
+/–: For Sport Shift mode, move the
shift lever to position Dthen push to
the left.
While in Sport Shift mode, move the
shift lever to the +or –position to
enable Active Select (A/S) mode.
See Automatic Transmission 0190.
Parking
1. Apply the park brake.
2. Select position P.
3. Shut all windows.
4. Turn the ignition off and
remove the key from the
vehicle.
5. Press Qon the key to lock all
doors and to arm the alarm
system.
Getting Started
Check before starting
.Check that windows, mirrors and
lamps are clean.
.Visually check tyre inflation.
Check the tyre pressures
each week.
.Ensure that all doors are closed
and secured.
.Position your seat for
comfortable driving.
.Adjust rear view mirrors.
.Fasten seat belts.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
In Brief 15
.Check that the warning
indicators illuminate when
turning the ignition on.
See Driving Environment 0185.
See Starting the Engine 0189.
Starting the engine with the
Engine Start/Stop button
{Warning
Do not switch the engine off while
the vehicle is moving as there will
not be any power assist for the
brakes.
.The electronic key must be
inside the vehicle.
.Press the brake pedal and move
the shift lever to P or N.
.Press the ENGINE START/
STOP button.
The LED will illuminate.
.To switch the engine off, press
the ENGINE START/STOP
button again.
See Starting the Engine 0189.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
16 Keys, Doors, and Windows
Keys, Doors, and
Windows
Keys and Locks
Keys ........................... 16
INFOCARD . . . . . . . . . . . . . . . . . . . . 19
Remote Keyless Entry (RKE)
System . . . . . . . . . . . . . . . . . . . . . . . 19
Remote Keyless Entry (RKE)
System Operation . . . . . . . . . . . . 19
Remote Vehicle Start . . . . . . . . . . 22
Door Locks . . . . . . . . . . . . . . . . . . . . 23
Door Open Reminder . . . . . . . . . . 25
Automatic Door Locks . . . . . . . . . 25
Safety Locks . . . . . . . . . . . . . . . . . . . 26
Doors
Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Vehicle Security
Vehicle Alarm System . . . . . . . . . 28
Immobiliser Operation . . . . . . . . . 28
Exterior Mirrors
Power Mirrors . . . . . . . . . . . . . . . . . . 29
Heated Mirrors . . . . . . . . . . . . . . . . . 30
Reverse Tilt Mirrors . . . . . . . . . . . . 30
Interior Mirrors
Automatic Dimming Rear View
Mirror......................... 30
Windows
Power Windows . . . . . . . . . . . . . . . 31
Roof
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 33
Keys and Locks
Keys
The key operates all locks and the
ignition.
.Press Qto lock the doors and to
arm the alarm system.
.Press Kto unlock the doors and
to disarm the alarm system. See
Door Locks 023.
.Press and hold Yto unlatch
the boot lid. See Boot 026.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
Keys, Doors, and Windows 17
.Press Qthen press and hold /
for remote vehicle start. See
Remote Vehicle Start 022.
Panic/vehicle locate button
.To locate the vehicle, press %
briefly.
The exterior lamps will flash and
the horn will chirp.
.In an emergency, press and hold
%for at least 2 seconds.
The horn will sound and the turn
signals will flash.
.To cancel, press %or turn the
ignition on.
Foldaway key blade
1. Press the button to extend the
key blade.
2. To retract the key blade, press
the button and fold the blade
into the key.
The key engages audibly.
Matching transmitter(s) to your
vehicle
Two keyless entry transmitters are
coded to the vehicle.
If the vehicle's key is lost, inform a
Holden Dealer immediately so the
vehicle can be reprogrammed and
will no longer recognise the
missing key.
Additional transmitters also require
re-coding to match the new
transmitter.
Personal identity keys
The vehicle has personal identity
keys. Two sets of settings can be
stored.
.All features can be customised.
See Vehicle Personalisation
089.
.Settings are stored when a
personal identity key is removed.
.Press Kto recall the settings.
The features remembered by each
of the two memories are:
.Vehicle configuration settings
.Climate control settings
.Radio settings
Features revert to the last setting
used for each key.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -
7/16/15
18 Keys, Doors, and Windows
Note
.Two different memories are
available, memory one and
memory two.
If a third key is made, the third
key becomes memory one and
the other two keys become
identical memory two keys.
.The personal settings will not be
applied until the Kbutton is
pressed on the key and is
identified.
.If the vehicle battery has been
disconnected, some settings
may be forgotten.
The adjustments will be
remembered the next time the
features are adjusted.
About the keys
.The remote control in the key
has a range of approximately
100 metres.
.The range depends on the
charge of the key battery, on
ambient conditions, the key's
location and the area
between them.
.If the key buttons do not work,
move closer to the vehicle.
.Take care to ensure no button is
pressed unintentionally,
especially when the vehicle is
out of sight.
.Metallic window tint reduces the
range of the key.
.If any door or the bonnet is open
when Qis pressed, the horn will
chirp twice.
.The key buttons may not work if
the vehicle is parked near strong
radio activity, such as under TV
towers (most likely in high
lookout car parks).
.Ensure other keys on the key
ring are not between the key and
the vehicle.
.Always store spare keys in a
safe, dry place.
.Do not disassemble the keys.
.At times, a decrease in range
may occur, which is normal.
.If the transmitter does not work:
‐You may need to stand closer
during rainy or snowy weather
‐Other vehicles or objects may
be blocking the signal
If you are still having trouble,
contact a Holden Dealer.
.If pressing the key buttons does
not work, the doors can be
locked and unlocked by turning
the key in the driver's door lock:
‐Turn the key towards the rear
of the vehicle to lock all doors
‐Turn the key towards the front
of the vehicle to unlock the
driver's door
Opening the door will cause
activation of the alarm after a
preset period of time. If this
occurs, insert the key into the
ignition and turn on.
