HOLLAND MARINE PARTS Jet Thruster JT-30 Guide

D-010-04
Installation manual
& user guide
Jet Thruster Single & Combi
www.jetthruster.com
Manufactured by
Holland Marine Parts B.V.
Jet Thrusters:
JT-30 / JT-50 / JT-70 / JT-90
All our products are manufactured according to CE regulations.
We keep the rights to change descriptions, graphs or statements,
which are required for technical development of our Jet Thruster systems.
Keep this manual
onboard!
D-010-06

2 Holland Marine Parts D-010-04
D-010-06

Holland Marine Parts 3
D-010-04
(( ))
Electrical
Installaon
12V
12V
D-010-06

4 Holland Marine Parts D-010-04
D-010-06
20Amps

Bow or Stern only

Bow & Stern Thruster



Green Light on
- Power is on (no power check fuse)

- Power on + Controller func�on ok

- Motor overheated, let cool down
- No common ground, check wiring diagram

- Valve is not open in �me, restart system
- Check micro switches for water damage
- Open valve to clean inside
CONTROLLER UNIT: DIPSWITCH SETTINGS AND FLASHING CODES

Holland Marine Parts 5
D-010-04
E-307-00 (10m)
E-301-00 (10m)
E-304-00
(2m)
(5m) (10m) (10m)
Combi
Single
12V service baery
Series parallel switch
Pump unit
(use E-308-00 to extend cable)
Direconal 3-way valve(s)
(use E-309-00 to extend cable)
CONTROLLER UNIT: SINGLE & DUAL HELM SET UP
Always connect all
baery negaves to a
common ground.
D-010-06

6 Holland Marine Parts D-010-04
E-307-00
(10M)
E-301-00 (1m)
(5m) (10m) (10m)
E-304-00
(2m)
Transmier
Receiver
12V service baery
Series parallel switch
Pump unit
(use E-308-00 to extend cable)
Direconal 3-way valve(s)
(use E-309-00 to extend cable)
CONTROLLER UNIT: SINGLE & DUAL REMOTE SET UP
Always connect all
baery negaves to a
common ground.
D-010-06

Holland Marine Parts 7
D-010-04
CONTROLLER UNIT: BOW AND STERN DOUBLE SYSTEM & REMOTE SET UP
E-307-00
(10M)
E-301-00 (1m)
(5m) (5m)(10m) (10m)
E-304-00
(2m)
Transmier
Receiver
Series parallel switch Series parallel switch
Pump unit
(use E-308-00 to extend cable)
Pump unit
(use E-308-00 to extend cable)
Direconal 3-way valve(s)
(use E-309-00 to extend cable) Direconal 3-way valve(s)
(use E-309-00 to extend cable)
12V service baery
Always connect all baery negaves to a common ground.
D-010-06
ATTENTION! Both controllers dipswitch seng need to be on single. So pos 1 up all the rest down. Both valves need to be on valve one connecon

8 Holland Marine Parts D-010-04
1. Mulfunconal Thruster Controller
This controller is designed to control Jet Thrusters in single- and combi mode.
Also This controller can be used to operate Convenonal thrusters of any brand, also in combinaon with a Jet Thruster.
This controller is designed to be used in pleasure cras, to maneuver yachts sideways.
This controller comes with a two year factory guarantee.
Content:
1. Introducon and Contents.
2. Installaon and explanaon of the Controller.
3. Program funcons and sengs, Led ashing codes.
4. Declaraon of Conformity
E-307-00 Joysck extension cable
- 10m / 33
(also suitable as oponal second joysck connecon cable)
Use this cable if you need to extend the E-301-00 Controller
to Joysck cable.
E-308-00 Pump unit extension cable
- 5m / 16
Use this cable if you need to extend the Controller
to Pump power cable.
E-309-00 3-way direconal valve extension cable
- 5m / 16
Use this cable if you need to extend the Controller
to the Valve controller cable.
D-010-06

Holland Marine Parts 9
D-010-04
2. Installaon and Explanaon
Installaon and Explanaon
- The controller Should be mounted Ver�cally in an acessible loca�on.
- Use Washers under the moun�ng screws to avoid damage and ensure a proper fixa�on.
- The controller is (if the provided caps are used) splashproof. (IP53)
- Venlaton is not necessary. opera�ng temperature between 0°C (32°F) and 60°C (140°F)
- Power supply 12v DC (min. 10volt max. 20 volt) DO NOT EXTEND THE POWER CORD. OBSERVE POLARITY RED = +12V BLACK
= NEGATIVE/ GROUND - Never use the thrusterbaeries to power the controller, instead use the servicebaeries
- All cables connected to the controller should: 1. Have adeqate tension relief mounted. 2. Not go together in a bundle with
220v/110v cabling. (min. 10 cm (4”) distance) 3. Not go together in a bundle with VHF antenna cables. (min. 10 cm(4”)
distance) 4. Be passed through Carefully to avoid damaging the cables
Connecon order
Joysck
remote control
pump unit
Bow valve or
Bow thruster
Stern valve or
stern thruster
Behind the caps you’ll find:
- The power led lights if there is a 12v DC power supplied. If the fuse is broken this Led will not light.
- The status led provides the same informaon as on the joysckpanel. (see next page Flashing codes)
- The Dipswitsches allow you to set up the controller for your applicaon. (see next page )
- The Invert switches allow you to invert the valve or thruster operaon.
Power Led
Status Led
Dipswitches
Invert switches
Sengs Fuse 20A
12V power
D-010-06

10 Holland Marine Parts D-010-04
3. Program Funcons and Sengs
behind the Le cap you’ll find the dipswitches, Control Led’s and Invertswitches.
Below their funcon is described.
Dipswitches ((Firmware V04.001) dd 20-11-2018)
On is Up and Down is Off. (Between brackets is standard seng.)
- 1- Single (on) or Combi (off) (on)
- 2- Convenonal Bow thruster. (on) Jethruster (off) (off)
- 3- Convenonal stern thruster. (on) Jethruster (off) (off)
- 4- Future use (off)
- 5- Future use (off)
- 6- Future use (off)
- 7- Latching on /off (in case you don’t want to use the pushbuon)* (off)
- 8- disable power off mer (off)
*you can either use a latching switch or connect blue to brown ,to use the power supply on/off funcon.
(example: ign. switch) Never connect +12v to the control wires.
*you can either use a latching switch or connect blue to brown ,to use the power supply
on/off funcon.(example: ign. switch) Never connect +12v to the control wires.
In Case of electromechanical disturbance or stac discharge the controller will shut down.
Push the buon again to re-start the system.
Invert switches
Using these switches You can invert the valve- or thrusteroperaon, this simplifies installaon.
the le switch is for the stern and the right for the bow.
Warning: A wrong seng can cause damage or Injury!!
Keep your face and hands on a safe distance from thrusteropenings !!
Flashing Codes
- Green Led is o - No Power or defecve Fuse.
- Green Led is on - power present Controller is on and standby.
- Red Led is o - Controller is standby. ( automacally aer 10 minutes)
- Red Led is on - Controller is on and OK.
- Red Led Flashing fast - Engine overheated, (Let Cool Down, Auto reset)
- If system has never run, you need to create common ground (see page 12)
- Red Led Flashing code V - Valve not open or closed in me. (turn system o/on.
If malfuncon remains, one of the valves is stuck.
(Valve can be cleaned easely.)
If upon installaon the red led is ashing fast, make sure the Negave of ba�ery 1 (and pump) is connected to the ships
ground or the negave post of the baery powering the controller.
D-010-06

Holland Marine Parts 11
D-010-04
Electrical Installaon: Jet Thruster Single and Combi
JT-30 12V 1 x YT S 5.5L 75Ah
JT-50 24V 2 x YT S 5.5L 75Ah
JT-70 24V 4 x YT S 5.5L 75Ah
JT-90 24V 4 x YT S 5.5L 75Ah
Opma baery YT S 5.5L
Holland Marine Parts recomments Opma Baeries
If you decide not to use Opma Baeries: Apply baeries with at least 1000A CCA (Cold Crancking Amps.)
!
Visit our website
www.jehruster.com
for addional informaon.
D-010-06

12 Holland Marine Parts D-010-04
+ -
+ -
Common Grounding point
Red ashing code fast - During rst Test Run
Baery for Controller
Baery for Jet Thruster
If the controller indicated no
Common ground there will be a Green
light on and Red Flashing fast.
Please follow this schedule to resolve
this problem.
D-010-06

Holland Marine Parts 13
D-010-04
Jet Thruster pump units
JT-30 compact 66 thrust LBS 12V
Force
Voltage DC
E-motor capacity kW
Current
Master fuse
Recommended baery capacity 12V
Baery cable +/-
Water inlet
Water outlet
Pressure hose diameter
Weight pump
JT-50 compact 110 thrust LBS 24V
Force
Voltage DC
E-motor capacity kW
Current
Master fuse
Recommended baery capacity 12V
Baery cable +/-
Water inlet
Water outlet
Pressure hose diameter
Weight pump
JT-70 154 thrust LBS 24V
Force
Voltage DC
E-motor capacity kW
Current
Master fuse
Recommended baery capacity 12V
Baery cable +/-
Water inlet
Water outlet
Pressure hose diameter
Weight pump
70 Kgf
24V
11kW
800A
1000A (2x 500A)
4 x Opma Yellow Top 75Ah
1m -> 70mm2 / 3 -> 3/0 AWG
1 x Ø 4”
Nozzle Ø 50mm
3” / 76 mm
49 kg/95 LBS
JT-90 198 thrust LBS 24V
Force
Voltage DC
E-motor capacity kW
Current
Master fuse
Recommended baery capacity 12V
Baery cable +/-
Water inlet
Water outlet
Pressure hose diameter
Weight pump
90 Kgf
24V
15,5kW
1000A
1000A (2x 500A)
4 x Opma Yellow Top 75Ah
1m -> 95mm2 / 3 -> 4/0 AWG
1 x Ø 4”
Nozzle Ø 50mm
3” / 76 mm
61 kg/130 LBS
Installaon manual with product specicaons at:
www.hollandmarineparts.nl/download
30 Kgf
12V
3kW
480A
500A
1 x Opma Yellow Top 55Ah
1m -> 50mm2 / 3 -> 1/0 AWG
1 x Ø 90 mm
Nozzle Ø 36mm/1,26”
2” / 51 mm
19kg/42LBS
50 Kgf
24V
6kW
480A
500A
2 x Opma Yellow Top 75Ah
1m -> 50mm2 / 3 -> 1/0 AWG
1 x Ø 90 mm
Nozzle Ø 36mm/1,26”
2” / 51 mm
25 kg/55 LBS
D-010-06

14 Holland Marine Parts D-010-04
Please note: For a 12 Volts ship’s circuit you need to install a series-parallel switch to be able to charge the system on 12V
and use it on 24V. The JT-50, JT-70 and JT-90 come with a connecon wire F and G as a standard accessory
for this switch.
Recommended baery cabling: (at a total length of max. 1m/3)!
JT-30 (12V) 50 mm2 (1/0 AWG) for 1m/3
JT-50 (24V) 50 mm2 (1/0 AWG) for 1m/3
JT-70 (24V) 70 mm2 (2/0 AWG) for 1m/3
JT-90 (24V) 95 mm2 (3/0 AWG) for 1m/3
Posive cable total length max. 50cm./1.64 
Negave cable total length max. 50cm./1.64 
For opmum performance keep
baery cables as short as possible!!
Charging the baeries:
In order to keep the ship’s circuit separate from the Jet Thruster baery/baeries it is recommended to divide the charging
current with a diode bridge or MosFet baery separator from the alternator.
Please note: More electricity will be required as a result of the installaon of the Jet Thruster. That is why in some cases it is
recommended for the alternator to be converted to high yield or to place a separate alternator.
Please note: Place baeries directly next to the pump unit.
Keep baery cables as short as possible to avoid voltage drop and loss of energy.
The electric motor of the Jet Thruster generates a lot of power in a short period of me. It is necessary to
connect dedicated baeries to the system. It is necessary to make the connecon between this baery and the
system as short as possible. Use appropriate baery cables and connecng material for this at all mes.
The system must be equipped with the included main fuse, which must be installed in the baery posive cable.
For safety reasons, the Jet Thruster should be provided with a suitable main switch (not included).
The joysck operates on 12V. For vessels with a 24V installaon, a DC-DC converter must be applied.
To avoid long cable length:
Baeries must be placed directly next to pump unit!
D-010-06

Holland Marine Parts 15
D-010-04
JT-30 (12V) charged with 12V charger
D-010-06
Contactor
Main switch
Fuse
Opma baery
Controller
Service baeries
Start baery
Diode bridge
Charger 12V
Alternator

16 Holland Marine Parts D-010-04
D-010-06
JT-50 (24V) charged with 12V charger
Contactor
Main switch
Fuse
Opma baeries
Controller
Service baeries
Start baery
Diode bridge
Charger 12V
Alternator
Strips pre mounted
Series parallel switch

Holland Marine Parts 17
D-010-04
D-010-06
Contactor
Main switch
Fuse
Opma baeries
Controller
Service baeries
Start baery
Diode bridge
Charger 12V
Alternator
JT-50 (24V) charged with 12V Step up Charger
Mac Plus - Step up charger

18 Holland Marine Parts D-010-04
D-010-06
JT-70/JT-90 (24V) charged with 12V charger
Contactor
Main switch
Fuse
Opma baeries
Controller
Service baeries
Start baery
Diode bridge
Charger 12V
Alternator
Strips pre mounted
Series parallel switch

Holland Marine Parts 19
D-010-04
D-010-06
Contactor
Main switch
Fuse
Opma baeries
Controller
Service baeries
Start baery
Diode bridge
Charger 12V
Alternator
JT-70/JT-90 (24V) charged with 12V Step up
Mac Plus - Step up charger

20 Holland Marine Parts D-010-04
D-010-06
JT-70/JT-90 (24V) in a 24V board network
Contactor
Main switch
Fuse
Opma baeries
Controller
Service baeries
Start baery
Diode bridge
Charger 24V
Alternator
24V -> 12V converter
