holusion Iris 46 Installation and operation manual
Iris 46 User Booklet
Sommaire :
Delivery content 2
Usage precautions 2
Showcase installation 3
Content update 3
Tel : +33 (0)9 72 42 44 51 [email protected]
HOLUSION SAS -99A Boulevard Constantin Descat - Plaine Images - 59200 TOURCOING
Delivery content
- assembled Iris 46” ready to use
- one power supply to plug into a power outlet
- additional items
Usage precautions
During movement, please store the holographic showcase in the box provided,
packed as received. Do not lift the holographic showcase by the top screen,
instead lift it by metallic parts.
Please turn off the holographic showcase before cleaning it. To clean the
window, use a window cleaner product and a wipe. For the rest, you can also use
the same products.
Tel : +33 (0)9 72 42 44 51 [email protected]
HOLUSION SAS -99A Boulevard Constantin Descat - Plaine Images - 59200 TOURCOING
The terminal operates under normal conditions of use. Do not place the Iris in a
humid environment, at temperatures below 0°C and above 45°C. Do not put it in
contact with water.
Showcase installation
The product is delivered fully assembled and ready for operation.
To turn on the product, if you have a model that needs to manually start the
computer, you just have to press the power button on the box hanging above
the screen (it appears blue when the product is on). The content will play
automatically.
Hanging box of a working product
To turn off the product, cut the power, or press the same button if your model
has it. The screen turns white/blue and turns off after a few minutes.
Content update
Videos remain stored in the products from one startup to the next. A web
interface has been specially designed for this purpose. You access it by typing
the IP address of your machine in a web browser
To obtain the IP address you can connect (by RJ45 port) and find the product on
your online network or use a nano router (in option).
Connect the router (USB and ethernet) to the back of the terminal.
Connect your computer to the router wifi. To do this, go to the WiFi connections
and find the name of the router (it is noted under the router, to the right of "SSID").
Then, use the password to connect. The password is the sequence of numbers to
the right of "Wireless Password/PIN" on the bottom of the router.
Tel : +33 (0)9 72 42 44 51 [email protected]
HOLUSION SAS -99A Boulevard Constantin Descat - Plaine Images - 59200 TOURCOING
The picture is just an example. The data does not correspond to your router
The WIFI connection will be noted as limited. This is normal, you are connected
to the product and not to the internet.
To use the web interface with the nano router, type 192.168.0.1 in your browser,
and register with the password : holusion2014 or the one you have chosen. Click on
"DHCP Client" to find the IP address of your product (often 192.168.0.100, but
this can change). Enter it in your browser.
You are on the web interface. It should look like below, depending on your
version.
Now you can update the content by adding new videos or removing existing
ones. You can also activate or deactivate them. Or launch their reading on the
hologram by double clicking on it.
Tel : +33 (0)9 72 42 44 51 [email protected]
HOLUSION SAS -99A Boulevard Constantin Descat - Plaine Images - 59200 TOURCOING
We hope you will be satisfied with the use of the Iris 46. Feel free to contact us
for any questions or comments.
Do not hesitate to contact technical support (9am-5pm):
Sebastien DUMETZ
+33 (0)6.73.80.44.59
