IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
USING INSTRUCTION

-1-
PRODUCT INTRODUCTION
Thank you for using the folding series washing
machine produced by our company. The washing
machine is made of flexible rubber material. The
barrel is foldable and convenient for storage and
carrying. According to different configuration,
It is designed for sterilization and washing of
intimate underwear, especially suitable for washing
baby clothes and women's underwear.

-2-
6
6
5
5
4
4
3
3
CONTENT
INTRODUCTION
FOLDING PATTERN&OPEN METHOD
PREPARATION BEFORE USE
OPERATION
ATTENTIONS
TROUBLESHOOTING
MAIN TECHNICAL PARAMETERS
HAZARDOUS SUBSTANCE CONTENT STATUS DESCRIPTION
AFTER-SALE SERVICE BACK COVER

-3-
INTRODUCTION
Upper cover Upper frame Pulsator Handle Adaptor
Buttons Base Water outlet Power outlet
FOLDING PATTERN & OPEN METHOD
1.Open: take out the washing machine from the package, press the
bottom of the barrel with one hand and pull the handle upward with
the other hand to open the washing machine.
2.Folding: hold the upper frame with both hands, press down
evenly, and the washing machine can be folded easily.

-4-
PREPARATION BEFORE USE
1.This machine uses 12V direct-current and
12V/2.5A or 3A adapter.
2.Turn on the folding washing machine and connect to
the power supply.
3.Put the clothes in, add water over the soft rubber barrel,
and put the detergent in.
OPERATION
Power Working
" button to pause
1.Plug in the power plug, hold the or 2 seconds, and the "power"
indicator on the left side will be on. Touch the button, the washing machine
starts to run, and the "power" indicator light flashes at the same time.
2. After the machine is turned on, if it is not started by pressing the button,
the washing machine will automatically shut down after 5 minutes.
3. During the washing process, you can press the "
or restart the machine.
4. The washing machine will shut down automatically after 10 minutes of pause
or washing.
5. During the washing process, the "Working" indicator light is always on,

-5-
13.This appliance is intended to be used in household and similar
applications such as:
– motorhome.
– by clients in hotels, motels and other residential type environments.
the washing machine shell with water, especially the base part,
washing machine with a wrung-out cloth.
1.This washing machine is not a toy. If not in use, please place in where
keep away from children.
2.The power adapter cannot be used in the bathroom.
3.Keep plastic bags away from children.
4.This washing machine is specially designed for small underwear or
similar light and light clothes. Do not put in too much clothes when
washing(less than or equal to 200g of clothes is recommended).
5.When cleaning the product, First turn it off and unplug, Secondly,
wipe the surface of the plastic shell with a wet towel. Do not rinse
otherwise it will damage the washing machine. Please wipe the
6.Make sure there are no sharp articles in the laundry before washing, so
as not to damage the soft rubber bucket.
7.Do not place the product on the unstable desktop to avoid product damage.
8.Do not use the product in high temperature or humidity.
9.When the product is not in use, please keep it in a dry and ventilated
place, away from the fire source.
10.The addition of water during washing shall not exceed the maximum
rated water level. The cover of the bucket shall be covered during washing
to prevent water splashing out of the bucket.
11.Do not wash clothes in more than 50℃of hot water.
12.Do not allow people(including children)with physical, sensory or mental
disabilities or lack of relevant experience and knowledge to use this product.
ATTENTIONS

-6-
(Hg ) (PBB ) (PBDE )
(Cd ) (C 6 r )
+
(Pb )
12V DC
273 273 250* *
2.0
2.5
4.5
10
273 273 110* *
MAIN TECHNICAL PARAMETERS
Voltage
Rated capacity (L)
Rated power (W)
Net weight (kg)
Gross weight (kg)
Dimension (mm)
Folding size (mm)
Description of harmful substance content in products
Harmful substances
Parts name Lead Mercury Cadmium Hexavalent
chromium
Polybrominated
biphenyls
polybrominated
diphenyl ethers
Plastic parts
Metal structural parts
Motor
Computer board
Other electrical parts
Packaging & Printing
This form is prepared in accordance with SJ/T 11364.
It means that the content of the harmful substance in all homogeneous materials
of the component is below the limit specified in GB/T 26572.
It means that the content of the harmful substance in at least one homogeneous material of the component
exceeds the limit requirement specified in GB/T 26572. However, it is within the scope of the application
exception list of restricted substances in the compliance management catalogue.
Notes: The "environmental protection service life" of the product is 10 years,
which is specified by the enterprise according to the design characteristics of
the product. The "environmental protection service life" is only valid when
the product is used under normal conditions as stated in the product manual.

Replace adaptor
No power on
Problem Cause Solution
Washing machine alarm
(The two lights flash at
the same time)
Too much clothings Take out some clothes and press the
power button to start again.
Do not mix clothes well
There is not enough water
The voltage is too low or current
too low
Add water and overflow the soft
rubber barrel
Replace the power supply that meets
the requirements
Automatic shutdown Automatic shutdown
No power connection
The adaptor is broken
Incorrect boot operation
Connect the power supply
Hold the power button for more than 2
seconds and start the machine normally
After 10 minutes of pause or washing,
and 5 minutes after power on, the
machine will shut down automatically.
COMMON TROUBLESHOOTING
-7-
Input voltage 100-240 V
Input AC frequency 50/60 Hz
Output voltage 12 V
Output current 2.5 A
Output power 30 W
Average active efficiency 86.95 %
Efficiency at low load (10 %) 76.95 %
