Home Decorators HD-1199-LED User manual

THANK YOU
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this 1-LIGHT OUTDOOR POST MOUNT.
home improvement needs. Thank you for choosing Home Decorators Collection!
USE AND CARE GUIDE
1-LIGHT OUTDOOR POST MOUNT
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
Item #206968084
Model #HD-1199-LED

2
Table of Contents
Safety Information
NOTICE: Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
NOTICE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15B of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference to radio communicaions. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
NOTICE:
SUITABLE FOR WET LOCATIONS.
WARNING: Be sure the electricity to the wires you are
working on is shut off. Either remove the fuse or turn off the
circuit breaker.
WARNING: Carefully read and understand the information
given in this manual before beginning the assembly and installation
of the product. Failure to do so could lead to electric shock, re, or
other injuries which could be hazardous or even fatal.
Warranty
WHAT IS COVERED
WHAT IS NOT COVERED
The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship for a period of three (3) years from date
of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If this
product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at
the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications, alterations,
neglect, or mishandling.
Table of Contents..........................................................2
Safety Information.........................................................2
Warranty.........................................................................2
What is Covered.......................................................................2
What is Not Covered ................................................................2
Pre-installation ..............................................................3
Planning Installation ................................................................3
Tools Required .........................................................................3
Hardware Included...................................................................3
Package Contents ....................................................................4
Installation .....................................................................5
Care and Cleaning .........................................................7
Troubleshooting.............................................................7
This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in any way not in accordance with
the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse,
negligence, alteration, faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not apply to
the finish on any portion of the product, such as surface discoloration and/or weathering, as this is considered normal wear and tear.
The manufacturer does not warrant and specifically disclaims any warranty, whether express or implied, of fitness for a particular purpose,
other than the warranty contained herein. The manufacturer specifically disclaims any liability and shall not be liable for any consequential or
incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product.
Contact the Customer Service Team at 1-800-986-3460 or visit HOMEDEPOT.COM/HOMEDECORATORS.
□Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
□
□
□

3
Read all instructions before assembly. Before starting the installation of this xture or the removal of a previous xture, disconnect the power
by turning off the circuit breaker or by removing the fuse at the fuse box. To avoid damaging this product, assemble it on a soft, non-abrasive
surface such as carpet or cardboard.
Pre-Installation
HARDWARE INCLUDED
PLANNING INSTALLATION
HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
TOOLS REQUIRED
NOTE: Keep your receipt and these instructions for proof of
purchase.
NOTE: Hardware not shown to actual size.
Flathead
Screwdriver
Phillips
Screwdriver Ladder Wire Strippers
Pliers Safety GlassesWire CuttersElectrical
Tape
BB
AA
Part Description Quantity
AA Self-Tapping Screw 3
BB Wire Connector 3

4
Pre-Installation (continued)
PACKAGE CONTENTS
Part Description Quantity
A Fixture 1
B 1
Transparent Glass
B
A
D
C
F
E
C 1
D 1
Cup
Cylindrical Glass
E 1
Metal Cage
F 2
Ball Finial (preassembled to Fixture (A))

5HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
C
A
A
D
E
B
F
E
Installation
1Installing the xture
□Put the Cup (D) in the middle of the hole, parallel into the
Metal Cage (E) to the xed bolt, ensure that the open up
Cup (D).
□Thread the Cylindrical Glass (C) and Cup (D) into the Metal
Cage (E) with the thread pipe, ensure they are connected
rmly.
□Put the Transparent Glass (B) down into the Metal Cage (E).
Use the Metal Cage (E) on the hoop iron pin inside.
□Place the Fixture (A) and Metal Cage (E) t the hole for
connection.
□Attach the Ball Finial (F) to the Fixture (A) and Metal Cage (E)
and tighten.
2 Securing the glass

6
Installation (continued)
3Installing the xture
□Cover the three connections using the three Wire Conncetors (BB).
Wrap the three wire connections with electrical tape for a more
secure connection.
WHITE SUPPLY
BLACK SUPPLY
BARE, OR GREEN
BARE, OR GREEN
BARE, OR GREEN
GROUND WIRE
FROM SUPPLY
GROUND WIRE
FIXTURE GROUND
WIRE
GREEN GROUND
SCREW
PLAIN OR BLACK
WIRE
WIRE
FIXTURE WIRE
FIXTURE WIRE
UL LISTED
WIRE NUTS
WHITE OR IDENTIFIED
4Securing the fixture
□Please use the Self-Tapping Screw (AA) rotation the Metal Cage (E)
the installation hole cover cup, to ensure that they are closely linked.
E
E
AA
BB
CAUTION: DO NOT INSTALL ON POST OR ROLE THAT RESULTS
IN A VERTICAL RISE OF 25 FEET OR HIGHER.

7
Care and Cleaning
□Clean the xture with a soft, dry cloth.
□Do not use any cleaners with chemicals, solvents or harsh abrasives.
CAUTION: Before attempting to clean the xture, disconnect the
power to the xture by turning the breaker off or removing the fuse
from the fuse box.
HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Troubleshooting
The xture will not light.
Problem Possible cause Solution
The power is off.
The circuit breaker is off.
Ensure the power supply is On.
Ensure the circuit breaker is in the On position.
The fuse blows or the circuit breaker
trips when the light is turned on.
The wires are crossed or the power wire
is grounding out.
Check the wire connections. Contact a qualied
electrician or call the Customer Service Team at
1-800-986-3460.

Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
Retain this manual for future use.
