HomeAware Sonic Alert HA360WRB User manual

Complete Home Alerng Soluon
HA360WRB - Quick Reference Guide
Seng Up Your HomeAware™
1. Remove all contents of the box.
– HomeAware™ - Main Unit
–HomeAware Security Alert
–HomeAware Bes Shaker
–NOAA Weather Radio
2.
3.
4.
–3.5mm Connection Cable
–Plug the power supply into back of
the Main unit, 7.5V 2A DC IN.
Plug Main unit power supply into a
120V outlet.
Plug Vibrator / Bed Shaker into the
vibrator outlet on the back of the
Main unit. (Optional).
Seng Time of Day
1. Press the Time Set button. Blinking red dots
will show on the display.
2. Press the Hour and Minutes buttons up or
down to set desired time. When setting the
time make sure the PM indicator light reflects
the correct time.
3. Press the Enter button to complete.
For addtional information refer to your
HA360M2.1 User Guide.
Connecting the HA360SA2.1 to your NOAA Weather Radio
1. Remove the 3.5mm Double-Ended Connection Cable
2. Plug the 3.5mm cable into the External Alert outlet on the back of your NOAA Weather Radio.
3. Plug the other end of your 3.5mm cable into the outlet on side of the HA360SA Security Alert.
For addtional information refer to your HA360SA and NOAA Weather User Guides.
1
2
3
PM Indicator
SNOOZE
AL.2 Set Hour Minute Back
Enter
Tone
Volume
AL.1 Set
Time Set Alarm Off Set Up
Main
PM
A1
A2
7.5V 2A
DC IN
120V Outlet
7.5V 2A
DC IN
LAMP
SW.
EXT.
BATT.
USB CHARGE 5V
TEL.
TEL.
LINE CELL PHONE
DETECTOR
VIBRATOR
VIBRATOR/
BED SHAKER
HA360SA2.1 Switch Locations and Positions
1. There are three switch positions on the back of the HA360SA
–N / closed
–N / open
–Door chime
2. Using the HA360SA with the NOAA Weather Radio the switch.
should be in the N / open (Center location).
For addtional information refer to your HA360SA2.1 and NOAA
Weather User Guides.
4

LATCH TO OPEN
COMPARTMENT
DOOR
Installing the batteries into the HA360SA2.1 Security Alert
1. Install provided batteries into the bottom of the unit.
2. Once installed push the link button and the red LED light
will light. If the light does not show, you may have the
batteries in backwards.
3. Leave battery door opened to link the HA360SA to the
Main unit.
5
Linking the HA360SA2.1 to the Main Unit
6
BATTERIES
LINK BUTTON
BATTERY/LINK
COMPARTMENT
DOOR
Complete Home Alerng Soluon
7
LINK BUTTON
1. Press SET UP button on the Main unit and the word LINK
will be shown on the display, press ENTER. Link will be
blinking.
2. Press and release the link button. PICK DEVICE will
display on the screen, press the blue TONE
button until STORM is displayed. Press the
Enter button to complete.
NOAA Weather Radio Quick Setup
HA360WRB - Quick Reference Guide
1. Place 3 AA alkaline batteries (not supplied) into the compartment on the underside of radio.
(Note: Batteries provide approximately 5 hours of emergency power or 75 hours of standby power for the
radio in case of a power outage).
2. Plug the AC Adapter into a standard outlet. Plug the other end of the adapter into the DC jack on the back
of the radio.
3. Pull out antenna and extend to its full length.
4. Ensure ON/OFF switch is in the ON position
5. WELCOME will be displayed.
6. To SET LANGUAGE press the SELECT button then:
7. Choose your language by pressing ▲ or▼ then press the SELECT button.
8. To SET LOCATION press the SELECT button then:
9. Choose location type ANY then press SELECT.
(Note: see page 8 for more programming instructions).
10. To SET TIME press the SELECT button then:
11. Set the time by using ► ▲ ▼or then press SELECT.
12. To SET CHANNEL press the SELECT button then:
13. Tune the channel to the desired broadcast by using ▲or ▼.
14. Adjust the volume by using the VOLUME UP or VOLUME DOWN button.
15. To complete setup press the SELECT button.
NOTE: To reset the radio to the factory defaults, press and hold the WEATHER / SNOOZE button while
turning on the unit.
