HomeMatic HM-TC-IT-WM-W-EU User manual

Installation and
operating manual (p. 43)
Wireless Room Thermostat
HM-TC-IT-WM-W-EU

43
1st English edition 11/2013
Documentation © 2013 eQ-3 Ltd., Hong Kong
All rights reserved. This manual may not be reproduced in any for-
mat, either in whole or in part, nor may it be duplicated or edited by
electronic, mechanical or chemical means, without the written con-
sent of the publisher.
Typographical and printing errors cannot be excluded. However, the
information contained in this manual is reviewed on a regular basis
and any necessary corrections will be implemented in the next edi-
tion. We accept no liability for technical or typographical errors or
the consequences thereof.
All trademarks and industrial property rights are acknowledged.
Printed in Hong Kong.
Changes may be made without prior notice as a result of technical
advances.
Translation from the original version in German.
132033/V 1.0

44
Table of Contents
1 Information about this manual ................45
2 Hazard information.........................45
3 Scope of supply ...........................46
4 Operation and display ......................47
5 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6 General information about the HomeMatic system 49
7 General information about radio operation.......50
8 Start-up..................................50
9 Teach-in:.................................57
10 Teach-out/Restore factory settings.............62
11 Operating modes (auto/manu/holiday)..........63
12 Comfort and eco temperature ................63
13 Setting the holiday function ..................64
14 Boost function.............................65
15 Congurationmenu ........................66
16 Child-proof lock/operating lock................74
17 Additional functions in connection with HomeMatic
Central Control Unit ........................75
18 Troubleshooting and maintenance .............76
19 Components that can be taught-in .............78
20 Technicalspecications .....................79

45
Information about this manual
1 Information about this manual
Read this manual carefully before beginning operation
with your HomeMatic components. Keep the manual handy
for later consultation!
If you hand over the device to other persons for use,
please hand over the operating manual as well.
Symbols used:
Attention! This indicates a hazard.
Note. This section contains important additional
information.
Note. This section contains additional important
information about using the device in connection
with the HomeMatic Central Control Unit.
2 Hazard information
The device may only be operated indoors and
must be protected from the effects of damp and
dust, as well as solar or heat radiation.
Using the room thermostat for any purpose other
than that described in this operating manual does
not fall within the scope of intended use and shall
invalidate any warranty or liability. This also applies
toanyconversionormodicationwork.Thisdevice
is intended for private use only.

46
Scope of supply
The device is not a toy; do not allow children to
play with it. Do not leave packaging material lying
around, as it can be dangerous in the hands of a
child.
Do not open the device: it does not contain any
components that need to be serviced by the user.
In the event of an error, please return the device to
our service department.
The system is only suitable for control of heaters
(radiators, convection heaters, heater bars) heated
by heat carriers. Any other use, e.g. on cooling
systems,in-oorheating,etc.,isnotpermittedand
can lead to severe damages.
3 Scope of supply
1 x HomeMatic Room Thermostat (HM-TC-IT-WM-W-EU)
2 x plugs
2 x adhesive strips
2 x screws 3.0 x 30 mm
2 x LR03/micro/AAA batteries
1 x Operating manual

47
Operation and display
4 Operation and display
A
B
C
D
E
FH
J
I
G
Display symbols and device buttons have the following
meaning and functions:
AAuto mode ( ) manu mode ( ), holiday mode ( ),
date/time ( )
BBoost function ( )
CComfort / eco temperature ( )
DOpen window function ( )
E Bar chart of programmed heating phases of current day
FAuto / manu button ( ): Switch between auto, manu
and holiday mode
GBoost button ( ): Activate the boost function; conrm,
start teach-in procedure
Handwheel: Temperature settings; select and set menu items
HComfort / eco button ( ): Switch between comfort
and eco temperature
IOperating lock ( ), antenna symbol (radio synchronic
ity) ( ), empty battery symbol ( )
J Display of setpoint or actual temperature and humidity

48
Operation and display
Controls:
K
L
M
(K) Mounting plate
(L) Clip-on frame
(M) Electronic unit

49
Function
5 Function
In connection with HomeMatic Wireless Radiator Ther-
mostats (HM-CC-RT-DN), the HomeMatic Wireless Room
Thermostat can conveniently regulate the room tempera-
ture according to individually tailored heating phases. The
room thermostat measures the temperature and humidity
and cyclically transmits the data to the radiator thermostat
to regulate the room temperature.
With the boost function, radiators can be heated up quick-
lyandbriey.Therewillbeapleasantroomtemperature
right away because of the radiated heat.
6 General information about the
HomeMatic system
This device is part of the HomeMatic home control system
and works with the bidirectional BidCoS® wireless proto-
col.Alldevicesaredeliveredinastandardconguration.
Thefunctionalityofthedevicecanalsobeconguredwith
a programming device and software. The additional func-
tions that can be made available in this way and the sup-
plementary functions provided by the HomeMatic system
when it is combined with other components are described
in the HomeMatic WebUI Manual.
Youcanndthelatestversionsofalltechnicaldocuments
and the latest updates at: www.homematic.com

50
General information about radio operation
7 General information about radio
operation
Radio transmission is performed on a non-exclusive trans-
mission path, which means that there is a possibility of
interference occurring. Interference can be caused by e.g.
switching operations, electrical motors or defective electri-
cal devices.
The range of transmission within buildings can
differ greatly from that available in the open air.
Besides the transmitting power and the reception
characteristics of the receiver, environmental
factors such as humidity in the vicinity have an
important role to play, as do on-site structural/
screening conditions.
Hereby, eQ-3 Entwicklung GmbH declares that this device
conforms with the essential requirements and other rel-
evant regulations of Directive 1999/5/EC.
The full declaration of conformity is provided under
www.homematic.com.
8 Start-up
8.1 Inserting (replacing) batteries
To insert or replace the batteries, proceed as follows:
• Once mounted, the electronic unit (M) can easily be
pulled out of the frame (L) and removed from the mount-
ing plate (K). To remove the electronic unit from the
frame, take hold of the sides of the electronic unit and

51
Start-up
pull it out. You do not need to open the device.
• Turn the electronic unit (M) over to remove or insert the
batteries.
• After removing the batteries you should wait approx. 10
seconds.
• Insert 2 LR03 (micro/AAA) batteries in the battery com-
partments (making sure that you insert them the right
way round).
• Put the electronic unit (M) back into the frame (L).
A battery symbol ( ) indicates that the batteries
need to be replaced.
The service life of new alkaline batteries is
approximately 1 year.
This device does not support operation with
rechargeable batteries.
Never recharge standard batteries. Do not throw the
batteriesintoare.Doingsowillpresentariskof
explosion. Do not short-circuit batteries.

52
Start-up
Caution! There is a risk of explosion if the battery is
not replaced correctly.
Used batteries should not be disposed of with
regular domestic waste! Instead, take them to
your local battery disposal point.
8.2 Set date and time
Afterinsertingorreplacingbatteriesthermwareversion
numberwillbeshownbriey.Accordingly,dateandtime
will be requested automatically.
• Set the year, month, day, hour and minute with the hand-
wheelandconrmwiththeboostbutton( ).
If the device has already been taught-in to a central
control unit or to another thermostat, the room
thermostat will be receiving date and time from one
of there devices. In this case, entering date and
time will not be requested.
8.3 Mounting
You can either use screws or adhesive strips to mount the
HomeMatic Room Thermostat to a wall. It can be mounted
in the frame (L) supplied or be integrated into an existing
switch (see sec. 8.4 for suitable switches).
8.3.1 Adhesive strip mounting
• Choose a site for installation. The surface on which you

53
Start-up
are mounting the room thermostat must be clean, dry
and free of grease.
• For mounting of the assembled room thermostat, attach
the adhesive strips to the back side of the mounting
plate (K). You should be able to read the letters on the
backside(accordingtogure).
<PA66>
• Removetheprotectivelmfromtheadhesivestrips.
• Press the assembled room thermostat with the back side
to the wall in the position where it should subsequently
be attached.
8.3.2 Screw mounting
• Choose a site for installation.
• Make sure that electrical lines in the wall will not be
damaged.
• Position the mounting plate (K) on the desired site on
the wall. Make sure that the arrow on the mounting plate
is pointing upwards.
• Use a pen to mark the positions of 2 bore holes 1(di-
agonally opposite) in the mounting plate (K) on the wall.
The bore holes 2can be used for installation with a
ush-mountingbox.

54
Start-up
2
2
1
1
2 2
• Now drill the bore holes. If you are working with a stone
wall, drill the marked two 5 mm holes and insert the
plugs supplied. If you are working with a wooden wall,
you can pre-drill 1.5 mm holes to make screws easier
to insert.
• Use the screws and plugs supplied to fasten the mount-
ing plate (K) to the wall.
• Next, attach the frame (L) to the mounting plate (K) and
attach the electronic unit (M).
• Make sure that the arrows on the back side of the elec-
tronic unit (M) point upwards and that the clips on the
mounting plate (K) latch into the openings on the elec-
tronic unit (M).
8.4 Installation in multiple combinations
You can mount the room thermostat with the attachment
frame (L) provided or use it with frames of other manu-
facturers as well as integrate the electronic unit (M) into a

55
Start-up
multi-gang frame. In both cases, mounting with adhesive
strips and screws is possible. For mounting with multiple
combinations, make sure that the mounting plate (K) of
the room thermostat is seamlessly aligned to the already
xedmountingplate/retainingring.
TheHomeMaticRoomThermostatisdesignedtotinto
frames supplied by the following manufacturers:
Manufac-
turer
Frame
Berker S.1, B.1, B.3, B.7 glass
ELSO Joy
GIRA System 55, Standard 55, E2, E22,
Event, Esprit
merten 1-M, Atelier-M, M-Smart, M-Arc, M-Star,
M-Plan
JUNG A 500, AS 500, A plus, A creation
If changes or works have to be made on the house
installation (e.g. extension, bypass of switch- or
socket inserts) or the low-voltage distribution for
mounting or installing the device, the following
safety instruction must be considered:
Only to be installed by persons with the
relevant electro-technical knowledge and
experience! (*1)

56
Start-up
Incorrect installation can put
• your own life at risk;
• and the lives of other users of the electrical system.
Incorrect installation also means that you are running the
riskofseriousdamagetoproperty,e.g.becauseofare.
You may be personally liable in the event of injuries or
damage to property.
Contact an electrical installer!
(*1) Specialist knowledge required for installation:
The following specialist knowledge is particularly important
during installation:
• The ‚5 safety rules‘ to be used: Disconnect from mains;
Safeguard from switching on again; Check that system
is deenergised; Earth and short circuit; Cover or cordon
off neighbouring live parts;
• Select suitable tool, measuring equipment and, if neces-
sary, personal safety equipment;
• Evaluation of measuring results;
• Selection of electrical installation material for safeguard-
ing shut-off conditions;
• IP protection types;
• Installation of electrical installation material;
• Type of supply network (TN system, IT system, TT sys-
tem) and the resulting connecting conditions (classical
zero balancing, protective earthing, required additional
measures etc.).

57
Teach-in:
9 Teach-in:
Please read this entire section before starting
the teach-in procedure.
To integrate the room thermostat into your HomeMatic
system and enable it to communicate with other Home-
Matic devices (e.g. HomeMatic Radiator Thermostat), you
mustteach-intheroomthermostatrst.Youcanteach-in
the room thermostat directly to other HomeMatic devices
or to the HomeMatic Central Control Unit.
9.1 Teaching-in to HomeMatic devices
If you would like to teach-in the room thermostat to one
or more HomeMatic devices, you must put the devices to
be connected into teach-in mode and select the required
teach-in channel. To do this, proceed as follows:
During teach-in, please make sure you maintain a
distance of at least 50 cm between the devices.
• Activate the teach-in mode of your room thermostat.
Therefore, press and hold the boost button ( ) for at
least 3 seconds until the display switches back to teach-
in mode..

58
Teach-in:
> 3 Sec.
• The antenna symbol ( ) is displayed, along with the
teach-in time remaining in seconds. The teach-in time is
30 seconds.
• Now put the device you wish to teach-in to the room
thermostat (e.g. HomeMatic Radiator Thermostat, see
thefollowingg.)intoteach-inmode.Pleasefollowthe
relevant operating manual instructions of the corre-
sponding device.
> 3 Sec.
• After teaching-in has been successful, “AC” appears and
the display returns back to normal display.

59
Teach-in:
IfyouhavealreadyconguredaHomeMatic
Radiator Thermostat and would like to teach-in the
device to the room thermostat, please put the
radiatorthermostatintoteach-inmoderst.Allyour
settings will be saved and transmitted to the room
thermostat.
The teach-in mode can be interrupted at any time
by pressing the boost button ( ) again shortly.
If “nAC” appears in the display, the teach-in
procedure has not been successful. In this case,
please try again.
Please repeat the teach-in procedure for all devices
that communicate with each other.
9.2 Teaching-in to a HomeMatic Central Con-
trol Unit
Your device can be conveniently
• controlledandcongured,
• connected directly to other devices or
• used in central control unit programs using a soft-
ware-based method.
For this purpose, it needs to be taught-in to the Home-
MaticCentralControlUnitrst.Newdevicesaretaught-in
to the central control unit using the HomeMatic “WebUI”
user interface.

60
Teach-in:
A soon as a component has been taught-in to a
central control unit, it can only be connected to
other components via this unit.
Each component can only be taught-in to one CCU.
During teach-in, please make sure you maintain a
distance of at least 50 cm between the HomeMatic
devices and the central control unit.
To teach-in your device to the central control unit, proceed
as follows:
• Open the “WebUI” user interface in your browser. Click
the “Teach in devices” button on the right-hand side of
the screen.
• To activate teach-in mode, click “BidCoS-RF teach-in
mode”.
• Teach-in mode remains activated for 60 seconds. An in-
formation box shows how much teach-in time remains.
• Meanwhile, please activate the teach-in mode of the
HomeMatic Room Thermostat to teach-in as well.

61
Teach-in:
• Therefore, press and hold the boost button ( ) for at
least 3 seconds until the display switches back to teach-
in mode.
> 3 Sec.
• The antenna symbol ( ) is displayed, along with the
teach-in time remaining in seconds. The teach-in time is
30 seconds.
• After a short time, the newly taught-in device will appear
in the inbox of your software interface. The button „Inbox
(x new devices)“ indicates how many new devices have
been taught-in successfully.
• If required, you can teach-in additional devices by re-
peating the steps described above for each device.
• Nowcongurethenewlytaught-indevicesintheinbox
asdescribedinthenextsection„Conguringnewly
taught-in devices:“.
Conguring newly taught-in devices:
Once you have taught-in your room thermostat to the
HomeMatic Central Control Unit, it will be moved to the
