Safety Precautions
Thank you for purchasing the Homezone zero-clearance adjustable bed.
HZ4150
AB05
Adjustable Bed
User Guide
Please read all directions before using the bed,and retain this guide for reference.
Input voltage: AC 100-240V. 50/60HZ, output: DC29V 2.0A.
Unplug the bed before cleaning it.
Keep the product wire, power supply,and control box away from heat.
Do not use the bed in a humid environment. The connector part of the wire and the gap
between the motor and the control box cannot be exposed to liquid or high humidity.
Never operate the bed if it has a damaged cord or plug, or is not working properly.
Unplug the power cord and remove the remote control battery when the bed is not being used
for a prolonged period of time.
Consult your physician if you have any health questions regarding the use of this product.
Do not let children play with or operate the bed..
Do not allow children or pets underneath the bed.
Product Specifications:
Product Size:
Twin XL: 38” x 80” (96.5 x 203 cm) Split Queen: 30” x 80” (76 x 203 cm)
Full:54” x 75” ( 137 x 190.5 cm) Queen:60” x 80”(152 x 203 cm)
Parts List
Bed platform X 1 pcs
Mattress rail X 1 pcs
Legs X 6 pcs
Remote controller
X 1 pcs
Power Supply Box
X 1pcs
Power Cable X 1pcs
AAA batteries X 2 pcs
User Guide X 1 pcs

Assembly
1. Lay the carton flat on the floor and carefully cut it open.
2. Lift the carton so that the open side faces down and slide it up and off the bed. Place the
bed upside-down flat on the floor.
3. Remove and discard the plastic bag. Put together the two pieces of the bed and align them
flat on the floor.
4. Cut the zip ties, take out all the part boxes and the mattress rail, and check that you have
all the necessary parts according to the parts list.
5. For leg assembly push the screw through the triangular brace.Screw in the leg and tighten,
Leg height adjustments: 6’’+3’’+3’’
6. Connect the wire (on the bed) to the jack of power supply box
Connect the AC power cable to the other jack on the power supply box.
Connect the AC power cable to your nearby power outlet.
7. Insert batteries into the remote control. Press the first circledbutton.
If the motor begins to run, unplug the power supply and turn the bed over to its right side-up position.
If the motor does not run, it needs to re-match itscode.
Matching code:
Method1:Cut off the power and waiting for 10 seconds. Then plug the power again.
You will see the arrow points to light up the blue light(like the circle shows in the first
picture). At the same time, the LED lights will flashes. Then press and hold the “PAIR”
button of the remote control(like the third picture). This step must be done in 10 seconds
when the LED lights flashes. Release them when white backlight flashes. Finally, if the
blue light in the controller turns to green and the LED lights go out, the code matches.
Method2:Press twice the controller button that the arrow points to light up the blue
light(like the circle shows in the first picture). At the same time, the LED lights will flashes.
Then press and hold the “PAIR” button of the remote control(like the third picture). Release
them when white backlight flashes. Finally, if the blue light in the controller turns to green
and the LED lights go out, the code matches.
8. Insert the mattress rail at the foot of the bed. Then the bed is ready for use.
OKIN
HEAD MO TOR FOOT MOT OR MASSA GE MFP

Remote Control and Functions:
Locking key Pairing Key
Position Memory Remote Flashlight
Head Up
Zero Gravity Position TV Position
Flat Position
Foot Up Foot Down
Head Down
Sleeping Position Reading Position
Massage Time lights
Timer Control
Backrest Massage Footrest Massage
Under Bed Light
Massage On/Off Massage Mode
Button Operation Button Operation
Click to match or re-match the control
Click to lock the remote box
Click to set a user-defined position Click to turn the LED flashlight on top
Of the remote on and off
Click to set a zero gravity position Click to set a TV position
Press and hold to raise the backrest Press and hold to raise the footrest
Let go when the desired position is Let go when the desired position is
reached reached
Click to flatten the bed Press and hold to lower the footrest
Let go when the desired position is
reached
Press and hold to lower the backrest
Let go when the desired position is Click to set a reading position
reached
Click to backrest massage and Set massage time,10 min,20 min stages.
successively increase the intensity Press 20 min again to delete
of the backrest massage in stages
Click to leg massage and successively
Increase the intensity of leg massage Click to open or close the massage
In stages
Click to turn the flashlight LED under Backrest/Leg massage frequency
bed on and off adjustment
Click to set sleep position
Memory Setting:
Setting a memory position if you’re not satisfied with the factory setting.
1.Press the FLAT button the flatten the bed.
2.Adjust the bed to your preferred position by pressing the head and foot up/down buttons
3,Press and hold button M and let go after you hear “didi” sound that indicates the setting has been
Successfully programmed
PAIR
M
ZG
TV
HEAD
HEAD
FOOT
ON/OFF
MODE

Bluetooth APP
1. IOS version 8.0 or above
2. Searching for OkinComfortableBed‖in App
Stores or scan the QR to download the APP
3. Open the APP and select the number of
Motors. 2M-2 motors/3M-3 motors/4M-4
motors.
This product is 2 motors, so select 2M
4. After selecting in, click the gear to select the
Bluetooth you want to connect.
Position:lift or lower different bed parts
Memory:ZG position;TV/PC position;Lounge
position;M position

Troubleshooting:
If you experience problems with your adjustable bed, please follow these steps:
1. Press any button on the remote controller to see whether the blue backlight is bright. If
it is dim or does not light,
check the batteries. Replace batteries when necessary
2. Check the green power indicator light on the power supply. If it is not lighted, check
the power outlet.
3. Check for loose wires and connectors.
4. Check if the adjustable bed is assembled according to above steps.
If your problems cannot be solved by above steps, please contact us.
