HomLux MA04R24TD-OL User manual

1
Manual
LED Wall-mounted Mirror

LEDWall-mountedMirror
-1-
Instrucons & Installaon
Statement
Please read this instruction carefully before installation, and refer to it again during the installation to ensure a safe and
correct installation of the mirror.
Compliance
All the electrical components used in this product are ETL LISTED. This product passed ETL certification.
Electrical Safety Instructions
INSTALLATION should be made by a qualified / registered electrician. DO NOT attempt to install it by yourself, as
HOMLUX will not be responsible for any damage caused during installation.
According to IEEE regulations, this product is suitable for zone 2 and external zone, not zone 0 or zone 1. It is also not
suitable for installation in saunas, steam rooms or shower cubicles.
This product is only suitable for permanent installation, please do not plug in the power strip.
Please make sure to keep the electrical supply off during installation and maintenance. It is recommended to pull out the
fuse or switch off the circuit breaker before installation to disconnect the necessary circuits.
HOMLUX LED mirror adopts three-pin plug, power leads must be connected to ground wire.
DO NOT put hard and sharp materials directly against the mirror surface during operation, otherwise it may result in
current leakage and even personal injury accident.
Never forget to turn off the power supply in storm days, otherwise electric components of the product could be
damaged.
DO NOT switch off the power supply directly during normal operation, otherwise electric elements of the product may
be easily damaged.
Please turn off the power supply if the product is not used for a long time.
DO NOT remove protective film or corner protectors until the mirror is completely installed.
PLEASE KEEP THIS MANUAL BOOK FOR FUTURE REFERENCE.

LEDWall-mountedMirror
-2-
Speciaon
Product Name: LED LIGHTED MIRROR Cerates: ETL, CE, ROHS
Brand:HOMLUX Input Voltage: 110v
Design Style: Modern Power: 
Feature: Illuminated Lumen: 2500-3000lm
Mirror Shape: Round Input Frequency: 60Hz
Funcon: An-fog, memory funcon Color Temperature: 3000k-6000k oponal
Installaon: Wall mounted IP Rang: IP44
Glass Thickness: 5mm
Light Color Warm/White/Warm white changeable
Touch Sensor Yes
Material: Copper-free silvered glass
+ Aluminum frame
Dimming Funcon: Yes
Warranty: 1year
Hanging Way: Horizontal
Applicaon: Bathroom, makeup room
Operaon Instrucons
Light on/o
Power on, then press to turn on, that light will be warm light.



Wiring
Cleaning
When the mirror has to be cleaned, please switch off the power first.
DO NOT use abrasives or solvents when cleaning.
DO NOT let water get in the mirror and submerge mirror in water.
Wipe off all water spillages as soon as possible via a soft, damp cloth.
7
HOMLUX
can connect the cord to the wall and be controlled by a wall switch.

LEDWall-mountedMirror
-3-
Installaon
3x screws and white nylon screw type plug 4xspacer
Step 1
Sk spacers on mirror backside to keep the mirror at, and measure the distance of A(two hooks center distance).
Dimming instrucon
Power on, then press to turn on. Hold down and the brightness
PVC back board
Light strip
Drive power supply
Touch module
spacer
Measurement A
Measurement A(mm)
MA04R24TD-OL 82±5mm
388±5mm
388±5mm
82±5mm
388±5mm
MA04R32TD-OL
MA04R36TD-OL
MA05R24TD-OL
MA05R32TD-OL
Size
Model
F1A300494E
96FB004795
621A004796
A50E004797
692D004793
388±5mm
MA05R36TD-OL27D7004792
Ruler Spirit Level Electrical Drill Screwdriver Hammer

will change accordingly.
Fog-free instrucon
( For the led mirror with an-fog funcon)
Power on, press , the mirror can be defogging.

LEDWall-mountedMirror
-4-
Step 4
Hang the mirror to wall.
Wall
Wall
Mirror
★★★ About thewire connecon ★★★
There are two ways to connect the circuit for the mirror.
Connecon way : Plug the 3-pin plug in the socket on the wall.
Wall
Step 2
Mark two dots on the wall with the length of
A/B then drill holes into those marks.
Step 3
Place the white nylon plugs into the holes in the wall then
screw the screws into the plug.

LEDWall-mountedMirror
-5-
Connecon way ②: Connect the mirror wire with wall switch wire via connector.
Thanks for choosing HOMLUX.
Web: www.homluxproducts.com
Tel: [phone]
Any query please feel free to email service team : [email protected]
Scan the QR code to watch the video of installaon.
Field Wire
Neutral/ white
Earth/ Green
Earth/ Green
Neutral/ white
Live/ Black Live/ Black
Input Wire
of Mirror

CARE AND MAINTENANCE
If you have any problems, please feel free to contact us.
We enjoy hearing from our customers!

scratching the mirror.
• Please avoid harsh, corrosive, and abrasive cleaners.
• Keep dry and avoid damp environments.

wear and tear). 1 year warranty period shall not be extended
or renewed by the repair or replacement of the product/parts.
