Honeywell HW-T12332 User manual

Honeywell . ft 0ct6 5 25 Frances Cashmere Color
HW_T12332
User Manual
Read and save these instruction before use
CAUTION! ALWAYS UNPLUG YOUR TREE FROM ITS POWER
SOURCE BEFORE ASSEMBLING OR DISASSEMBLING.
Changing LED

THANK YOU
EN 2
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical products, basic precautions should always be followed
including the following:
Do not use this product outdoors.
This seasonal use product is not intended for permanent installation or use.
Do not mount or place near gas or electric heaters, fireplace, candles or other
Do not secure the wiring of the product with staples or nails, or place on sharp
Do not let lamps rest on the supply cord or on any wire.
Unplug the product when leaving the house, when retiring for the night, or if left
This is an electric product not a toy!—To avoid risk of fire, burns, personal injury
should not be played with or placed where small childrenand electric shock it
Do not use this product for other than its intended use.
Do not hang ornaments or other objects from cord, wire, or light string. Hang
Do not close doors or windows on the product or extension cords as this may
Do not cover the product with cloth, paper or any material not part of the product
ornaments only on the tree itself.
present and the product should be discarded.
This product employs overload protection (fuse). A blown fuse indicates an overload
or short-circuit situation. If the fuse blows, unplug the product from the outlet. Also
unplug any additional strings or products that may be attached to the product. Replace
rating) and check the product. If the replacement fuse blows, a short-circuit may be
Read and follow all instructions that are on the product or provided with the product.
SAVE THESE INSTRUCTIONS.
This product is equipped with push-in type lamps. Do not twist lamps.
This product has a polarized plug (one blade is wider than the other) as a feature to
reduce the risk of electric shock. This plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. Do not use with an extension cord unless plug can be fully inserted.
similar sources of heat.
hooks or nails.
unattended.
can reach it.
damage the wire insulation.
when in use.
the fuse as per the user servicing instructions (follow product marking for proper fuse
Do not alter or replace the plug.
Thank you for purchasing the 6.5ft Honeywell Frances Cashmere Color Changing LED
tree. This tree assembles in minutes and is decorated with LED light sets. This tree has
convenience, it is equipped with a foot pedal switch for easy illumination.
4 lighting options, Warm White Color Steady On, Multicolor Steady On, Color Changing
and off. These functions can be changed by using the control box. For your

PACKAGE CONTENT
OTHER COMPONENTS
G H
Replacement lamp
Fuse
G.
H.
(2 pieces)
(8 pieces)
EN 3
Installation kit:
Bottom Section
Middle Section
Tree Base
Top Section
A.
B.
C.
D.
E.
(1 set)
(1 set)
(1 set)
( piece)1
Screw
AB
D
E
C
F
F.
( piece)1
Power cord with foot
pedal switch
1)Warm White C olor1)Warm White Color
2)Multicolor Steady2)Multicolor Steady
4)OFF4)OFF
3)Color Changing 3)Color Changing
WL605-A-1B
SteadyO nSteadyOn
On
OPENOPEN
OPENOPEN
(1 set)

INSTALLATION
EN 4
Note: Before you start to assemble your tree, please choose a location near an
electrical wall outlet. Place the tree stand on a level surface.
Please remove protective covers from the base of the pole from each section.
1. Unfold the tree base to a 90 degree angle.
2. Carefully insert bottom section (C) of tree into tree base and tighten the screw (see Fig. 1).
3. Insert the middle section (B) of the tree into the bottom section (C) (see Fig. 2).
4. Insert the top section (A) into the middle section (B) (see Fig. 3).
Plug 1
On/off foot pedal
switch
On/off foot pedal
switch
A
B
C
Fig. 2
Fig. 3
Tree base
Fig. 1
side
view
side
view
Fig. 4
Fig. 5
D
Plug 2
Note: There is a tree top connector on the top section (A).
Tree top connector
6. Shape the branches. Starting with tips closest to the pole, shape one tip to the right,
one to the left and one along the centre of the main stem. Repeat pattern for each
5. Allow the branches to fall into place or gently pull branches up and out. When
adjusting branches be sure that all wires are free of branch hinges (see Fig. 4).
7. Plug the well-connected power supply cord plug 1 from the bottom section (C) into
electrical outlet. The plug 2 is for tree top lights. Plug the power supply cord plug 2
branch (see Fig. 5).
into electrical outlet.
F
Plug 3
Control
box
Control
box
8. Another way to light up the tree. Please note this tree comes with a power cord with
on/off foot pedal switch (F) for easy illumination. Plug the plug 1 and plug 2 into the
.9 Please note this tree comes with a control box for easy illumination and changing
power cord with on/off foot pedal switch (F). Plug the plug 3 into the electrical outlet.
This tree is Color Changing, the 4 lighting options available are : 1) Warmfunctions.
White Color Steady On, 2) Multicolor Steady On, 3) Color Changing and 4) Off.
1)Warm White Color1)Warm White Color
2)Multicolor Steady2)Multicolor Steady
4)OFF4)OFF
3)Color Changing3)Color Changing
WL605-A-1B
SteadyOn
On
OPEN
OPEN OPEN

TROUBLESHOOTHING
USER SERVICING INSTRUCTIONS
EN 5
3. If you are still experiencing problems with the tree, please contact us at 866-205-9854.
If any lights do not work on your pre-lit tree, please check the following before
1. If entire tree or a section of the tree does not light:
a) Make sure the end connector of the power cord is well connected to the
c) Check that there is power at the electrical outlet.
d) Check fuses in tree’s plugs and replace if necessary (see Replace the fuse below).
Loose branches
If a branch of the tree falls off, follow the steps below to reinstall it with a spare bolt.
1. Place the branch into the slot of the bracket.
pliers (not included) to crimp the bolt. (See Fig. A)
2. Insert a spare bolt through the hole and use diagonal
Fig. A
b) Check that each section of the tree is well connected.
calling customer service:
bottom section (C).
CAUTION! ALWAYS UNPLUG YOUR TREE FROM ITS POWER
SOURCE BEFORE ATTEMPTING EITHER FUSE OR LAMP REPLACEMENT.
Replace the fuse:
A) Replace the fuse of power cord with foot pedal switch (1 replaceable 5 A, 125 V
1. Grasp plug and remove from the receptacle or other outlet device. Do not
2. Open fuse cover. Slide open fuse access cover on top of attachment plug
Note: This plug will fit in a polarized outlet only one way. If the plug does not fit
fully in the outlet, reverse the plug.
fuse is located in the plug):
unplug by pulling on cord.
towards blades.
2. If a strand of lights still does not work:
replacement lamp (provided).replace lamp with a
a) Check that all lamps are tightly fitted inside the lampholders and that no lamps are
broken or missing. Replace any broken or missing lamps with replacement lamps
provided (see Replace the lamp below). If all lamps are firmly in the lampholders,
slightly twist the lamps from side to side to ensure proper connection.
b) If the lights still do not work, carefully remove each lamp one by one out of the
problem light string. Pull the lamp AND plastic base straight out of lampholder. Do
not twist lamps while removing from lampholders. Check the two wires at the bottom
of the lampholder. Each wire should be aligned properly on the lampholder to ensure
a proper connection in the lampholder. If one wire is missing or too short, please

USER SERVICING INSTRUCTIONS (CONTINUED)
EN 6
OPEN
OPEN
5. Close fuse cover. Slide closed the fuse access cover
3. Remove fuse carefully.
4. Risk of fire. Replace fuse only with 5 Amp, 125 Volt fuse (provided with product).
safety device (fuse) that should not be removed. Discard
6. Risk of fire. Do not replace attachment plug. Contains a
B) Replace the fuse of the power cord from the bottom section ( C) and plug 2:
1. Grasp plug and remove from the receptacle or other outlet device. Do not unplug
5. Close fuse cover. Slide closed the fuse access cover
2. Open fuse cover. Slide open fuse access cover on top of attachment plug towards
3. Remove fuse carefully.
4. Risk of fire. Replace fuse only with 3 Amp, 125 Volt fuse
that should not be removed. Discard product if the attachment plug is damaged.
6. Risk of fire. Do not replace attachment plug. Contains a safety device (fuse)
on top of attachment plug.
product if the attachment plug is damaged.
by pulling on cord.
blades.
(provided with product).
on top of attachment plug.
T
S
-
77
3A. MAX3A. MAX
USE ONLYUSE ONLY
125V FUSE125V FUSE
OPEN
Replace the lamp:
1. Grasp plug and remove from the receptacle or other outlet device. Do not unplug
2. Unlock the burned out LED lamp by lifting the hook.
4. Replace lamp with only 3.0 Volt, 0.06 Watt, LED type lamp (provided with
5. Lock the hook of lamp base by pushing lock down into the tab.
3. Pull lamp and plastic base straight out of lampholder.
product). Always match the hook to the tab.
CAUTION:
1. To reduce the risk of overheating, replace burned-out lamps promptly. Use
The LED lamp has polarity. Do not3.0 Volt, 0.06 Watt LED lamps only.
deliberately change the direction of the LED lamp in the lamp holder.
2. Risk of fire. This product does not contain lamp shunts, which allow the
product to operate if one lamp burns out. Replace lamps only with the
Hook
Tab
Unlock Lock
by pulling on cord.
spare lamps provided with this product.

USE CONTINUED)R SERVICING INSTRUCTIONS (
USE AND CARE INSTRUCTIONS
FCC STATEMENT
EN 7
If the new lamp base does not fit in lampholder, follow the steps below before step 4:
a) Pull the reflector out.
e) Insert the reflector into the base.
b) Remove the base of burned out lamp by straightening lamp leads and gently pull
c) Thread leads of new lamp through holes in old base with one lead in each
d) After lamp is fully inserted into base, bend each
lead up, like other lamps in the light set so that the
leads will touch the contacts inside the
lampholder (always match the long lead of new
CAUTION
a) To reduce the risk of electric shock, use only with the power-supply cord provided or
with a cord set intended for indoor use.
b) Do not use a cracked, frayed, or damaged cord. Inspect the cord periodically.
c) Do not abuse cord - Do not carry product by the cord or yank or pull it to disconnect
d) Disconnect the product from the outlet when not in use.
e) Do not overload. Connect other lighting strings or tree toppers end-to-end up to a
maximum of 216 watts (1.8 Amps) total. Do not interconnect low-voltage products.
from the outlet.
lamp out.
hole.
lamp to the hook of lamp base).
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Warning:Please note that changes or modifications of this product is not
expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment.
a) Before using or reusing, inspect product carefully. Discard any products that have cut,
damaged, or frayed wire insulation or cords, cracks in the lampholders or enclosures,
b) When storing the product, carefully remove the product from wherever it is placed
loose connections, or exposed copper wire.
to avoid any undue strain or stress on the product conductors, connections, and wires.
c) When not in use, store neatly in a cool, dry location protected from sunlight.

FCC STATEMENT CONTINUED)(
EN 8
Made in Cambodia
The Honeywell Trademark is used
under license from Honeywell
International Inc.
Honeywell International Inc. makes
no representations or warranties
with respect to this product.
This product is manufactured by
Dongguan Newone Trading Co.,Ltd.
Dongguan Newone Trading Co., Ltd.
1001 Room, No.273, Jinxiu Road,
Changan Town, Dongguan City,
Guangdong Prov., China
866-205-9854
NOTE:This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver
●Consult the dealer or an experienced radio/TV technician for help.
STORAGE: Disassembled tree can be stored in its original box. Store tree in a cool, dry place
where the temperature does not exceed 100°F (38°C).
MODEL NO. HW_T12332
ONE PLUG® U.S. Patents: US8,454,186, US8,454,187, US8,936,379, US9,044,056,
US 9,140,438, US 9,179,793, US9,222,656, US 9,243,788, US 10,194,764,
US 10,433,604, US 10,578,289, US 10,721,981, US 11,006,687, US 11,013,355,
US 11,419,374. Other Patents Pending.
See for a complete list of patents.https://www.williscorporation.com/about.html#p6
is connected.
TXUSA Corporation
1919 Akron Peninsula Road, Akron, Ohio 44313
866-205-9854
customersupport hw willis com tw_@ . .
