Honeywell L-PHP15A User manual

L-PHP15A(581271)
Horn Loudspeaker
1
Technical Specifications
Electrical
Max power
Rated power
Power tapping
Sound pressure level
15W/1W(1m,350Hz~7kHz)
Frequency response
(-10 dB)
Dispersion angle
(1k Hz / -6 dB)
Rated input voltage
Rated impedance
Connection
at
Mechanical
Dimensions
Weight
Color
Material
25 W
15 W
15 W / 7.5 W
115 dB / 103 dB
350 Hz ~8k Hz
140°
100 V / 70 V
667 Ω/ 1.3 kΩ
Flexible wire
225 mm x 165 mm x240 mm
1.38 kg
White (Similar to RAL9003)
ABS
Installation/Configuration Notes
Mounting
Power setting
The horn loudspeakers are supplied complete with sturdy
adjustable mounting brackets, allowing the sound beam to
be accurately directed.
The horn loudspeakers include a 100 V transformer with
taps on the primary winding to allow different power
settings. Nominal full-power, half-power can easily be
selected by connecting the amplifier output to the
appropriate tap.
L-PHP15A is a 15W horn loudspeaker . Its low profile
appearance and white cover makes it blend easily into many
outdoor environments.
In addition to excellent voice reproduction and sound
transmission effect, the loudspeaker is water and dust
protected, making it ideal for noisy and spacious outdoor
applications, such as sports fields, parks, exhibition halls,
factories and train stations etc.
The horn loudspeaker is supplied with strong adjustable
mounting bracket, enabling the operator to complete the
installation at ease.
Low profile appearance
Superior voice reproduction effect
Water and dust proof , IP66 compliant
Easy for installation
International safety standards compliant
3 -Φ10 mm
unit: mm
Environmental
Operating temperature
Storage temperature
Relative humidity
-25℃to +55℃
-40℃to +70℃
<95%

2
Circuit Diagram
Frequency Response
Polar Diagram
Installation Instructions
1. Detach mounting bracket of product.
2. Fixing the installation racks to the position.
3. Tightly situating the speaker body on the installation
bracket.
4. Correct wiring.
