Horizon Navigation NavMate NavMate 2.1 User manual

User Manual
NavMate®
Navigation
System
HORIZON
NAVIGATION

NavMate Navigation System
Copyright © 2002
All rights reserved.
NavMate Navigation System User Manual Ver. 1.1
This document and the software described in it are furnished under license and may be
used or copied only in accordance with such license. Except as permitted by such license,
the contents of this document may not be disclosed to third parties, copied, or duplicated
in any form, in whole or in part, without the prior written permission of Horizon
Navigation, Inc.
This document contains proprietary and confidential information of Horizon Navigation,
Inc. and its licensors. The contents of this document are for informational use only, and the
contents are subject to change without notice. Horizon Navigation, Inc. and its licensors
assume no responsibility or liability for any errors or inaccuracies that may appear in this
book.
Restricted Rights Legend. For defense agencies: Use, reproduction, or disclosure is
subject to restrictions set fort in subparagraph (c) (1) (ii) of the Rights in Technical Data
and Computer Software clause atDFARS 52.227-7013, and or similar successor clauses in
the FAR, or the DOD or NASA FAR Supplement.
Unpublished right reserved under the Copyright Laws of the United States.
NavMate Navigation System is a trademark of Horizon Navigation, Inc. All other
products or name brands are trademarks of their respective holders.
Printed in the USA.

i
User Manual
This page is intentionally blank.

ii
NavMate Navigation System
Preface
Your NavMate Navigation System provides turn-by-turn route guidance
while traveling to your destination. Before operating, take a few minutes to
review the safety and operating instructions in this manual so you can quickly
and safely become familiar with your navigation system’s many features.
This User Manual describes system components, explains the navigation
system’s functions, and provides details on:
• using the control buttons
• entering destinations
• understanding the different screens available on your navigation system
• adjusting user preferences
A handy Quick Reference Card is also included, which summarizes
important information in an easy-to-follow chart format.
Should you have additional questions about your NavMate Navigation
System, please call 1-86NAVMATE1 (1-866-286-2831) or visit
www.horizonnav.com.
Note. All users should read this manual prior to operating your navigation
system. Keep the User Manual in your vehicle for quick reference when
traveling. If you sell the vehicle, please leave this manual with the vehicle for
use by the new owner.

iii
User Manual
Safety Information and Precautions
WARNING! Please read and follow the following safety precautions.
Failure to follow the instructions below may increase your risk of
collision and personal injury.
The Please Drive Safely screen is displayed each time the NavMate
Navigation System is turned ON as a reminder to make use of the system’s
navigational aids in a safe manner.
Before using the NavMate Navigation System, read this entire manual. Make
sure that you are familiar with the system’s features and know how to operate
the system. Proper use of the NavMate Navigation System includes the
following guidelines:
• The NavMate Navigation System is not a substitute for your personal
judgment. The route suggestions should never supersede any local traffic
regulation or your personal judgment and/or knowledge of safe driving
practices. Prior to completing any maneuvers suggested by your navigation
system (for example, a U-turn or a left turn), verify that you can legally and
safely complete the maneuver. Do not follow route suggestions if they direct
you to perform an unsafe or illegal maneuver, would place you in an unsafe
situation, or would route you into an area that you consider unsafe.
• Glance at the screen only when necessary and safe to do so. Let the
computer voice guide you. If prolonged viewing is necessary, pull off the
road to a safe location.
• Do not use the NavMate Navigation System to locate emergency services
(such as police, fire stations, hospitals, and clinics). The database may not
include all emergency service providers. Use your own best judgment and
ask for directions in these situations.

iv
NavMate Navigation System
• When the vehicle is in motion, the NavMate Navigation System’s display
unit should only be programmed by the front seat passenger. The driver
should not program the system unless the vehicle is parked in a safe
location.
• The NavMate Navigation System’s map database provides information on
suggested routes without regard to factors that may affect your driving
experience or the time required to arrive at your destination. For example,
the system does not reflect road detours, closures or construction, some road
characteristics (e.g., road surface, slope or grade, weight or height
restrictions, etc.), temporary traffic congestion, weather conditions, and
similar factors. Use your personal judgment or the navigation system’s
“Detour” function as the situation warrants to calculate an alternate route.
• To use the system as effectively and safely as possible, obtain updated
system CD’s as they become available. For the latest CD’s Please call 1-
86NAVMATE1 (1-866-286-2831) or visit www.horizonnav.com.
• Do not position the display unit in a location that obstructs driver view of
the road, airbag deployment, instruments or controls to operate the vehicle.
• Adjust the display unit so the screen can be viewed with just a quick glance.
• Set the volume level of the display unit at a level that allows you to hear
outside traffic and emergency services.
• Do not disassemble or modify the system as this may lead to damage. If a
problem occurs, stop using the system immediately and contact your dealer.
Problems that require immediate attention include lack of sound or video,
noxious odors or smoke from the computer or display unit, or foreign
objects dropped inside the unit.
• Wear your seat belt at all times to avoid collisions with anything in the
vehicle’s interior, including the NavMate Navigation System.

v
User Manual
NavMate Navigation System Limited Warranty
The NavMate System Limited Warranty is provided by Horizon Navigation, Inc.
Horizon Navigation will provide at no cost for the repair or replacement of covered
components during the Limited Warranty Period in accordance with the following terms,
conditions, and limitations:
Eligibility
Original and subsequent purchasers of NavMate installed by an Authorized Horizon
Navigation, Inc. Distributor, Sales and Service Center or Sales Center are eligible to
enforce the conditions and terms of limited warranty for the duration of the applicable
Limited Warranty Period.
Limited Warranty Period
One (1) year from the date of purchase. End user must provide evidence in the form of
a receipt or an invoice to prove that the Product is within the Warranty Period to obtain
Warranty Service. Any alteration and removal of factory applied labels that include serial
numbers will result in termination of Warranty Agreement.
Parts and Services Covered/Parts and Services Not Covered
Except as follows, all NavMate parts (and applicable labor) are covered at no charge
when failure is due to a defect in a part, material or workmanship during normal use for
the duration of the applicable Limited Warranty Period.
Limitations and Exclusions
The Limited Warranty does not cover:
• Any hardware used to mount the display unit in the vehicle.
• Repairs and replacement due to recalls by vehicle manufacturer.
• Repairs caused by damage or unreasonable use, road hazard, accident, fire or other
casualty, misuse, negligence, or failures caused by modifications or parts not autho-
rized by or supplied by the vehicle manufacturer or NavMate manufacturer or war-
rantor.
• Damage from the environment (airborne fallout, acts of war, flood, chemicals, tree
sap, salt, hail, windstorm, lightning).
• Damage due to theft, vandalism or riot.
• Customer applied chemicals or accidental spills.
• Repairs needed to a covered part caused by a non-covered part.

vi
NavMate Navigation System
• To the extent allowed by laws, loss of use of vehicle, loss of time, inconvenience,
commercial loss, consequential damages and personal expenses.
• Repairs performed outside of the 50 states and Canada. Repairs required because of
operation outside of the 50 states and Canada.
• Any NavMate installed and repaired by any entity other than an Authorized Horizon
Navigation Distributor, Sales and Service Center or Sales Center.
• THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED ABOVE.
• THE WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSE-
QUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR
ARISING OUT OF ANY BREACH OF THISWARRANTY.
• ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRAN-
TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE, ARE LIMITED TO THE APPLICABLE LIMITED WARRANTY PERIOD
AND TERMS SET FORTH ABOVE.
• SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU.
• THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH MAY VARY FROM STATE TO STATE.
The NavMate Navigation Software Limited Warranty and End User License
Agreement are outlined in the User Manual provided with the NavMate CD.
Procedures for Obtaining Repair
During the applicable Limited Warranty Period, call the Horizon Navigation, Inc. at 1-
86NAVMATE1 (1-866-286-2831). Proof of the NavMate system purchase date is required
to obtain limited warranty repair. For further information on limited warranty performance
and coverage, contact the NavMate Warrantor, Horizon Navigation, Inc. at 1-
86NAVMATE1 (1-866-286-2831) or write to:
Warrantor:
Horizon Navigation, Inc.
4701 Patrick Henry Dr. #1301
Santa Clara, CA 95054

vii
User Manual
Portable NavMate Navigation System Limited Warranty
The NavMate System Limited Warranty is provided by Horizon Navigation, Inc.
Horizon Navigation, Inc. will provide at no cost for the repair or replacement of covered
components during the Limited Warranty Period in accordance with the following terms,
conditions, limitations, and exclusions:
Eligibility
Original and subsequent purchasers of Portable NavMate are eligible to enforce the
conditions and terms of this limited warranty for the duration of the applicable Limited
Warranty Period.
Limited Warranty Period
One (1) year from the date of purchase forall components except for Bag and Display
Mount. Bag is covered under warranty for 90 days from the date of purchase. Display
Mount is not covered under this warranty. End user must provide evidence in the form of a
receipt or an invoice to prove that the Product is within the Warranty Period to obtain
Warranty Service. Any alteration and removal of factory applied labels that include serial
numbers will result in termination of Warranty Agreement.
Parts and Services Covered/Parts and Services Not Covered
Except as follows, all Portable NavMate parts (and applicable labor) are covered at no
charge when failure is due to a defect in a part, material or workmanship during normal
use for the duration of the applicable Limited Warranty Period.
Limitations and Exclusions
The Limited Warranty does not cover:
• Any hardware used to mount the display unit in the vehicle.
• Repairs and replacement due to recalls by vehicle manufacturer.
• Repairs caused by damage or unreasonable use, road hazard, accident, fire or other
casualty, misuse, negligence, or failures caused by modifications or parts not autho-
rized by Portable NavMate manufacturer or warrantor.
• Damage from the environment (airborne fallout, acts of war, flood, chemicals, tree
sap, salt, hail, windstorm, lightning).
• Damage due to theft, vandalism or riot.
• Customer applied chemicals or accidental spills.
• Repairs needed to a covered part caused by a non-covered part.

viii
NavMate Navigation System
• To the extent allowed by law, loss of use of vehicle, loss of time, inconvenience,
commercial loss, consequential damages and personal expenses.
• Repairs performed outside of the 50 states and Canada. Repairs required because of
operation outside of the 50 states and Canada.
• Any Portable NavMate repaired by any entity other than an Authorized Horizon
Navigation Service Center.
• THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED ABOVE.
• THE WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSE-
QUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR
ARISING OUT OF ANY BREACH OF THISWARRANTY.
• ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRAN-
TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE, ARE LIMITED TO THE APPLICABLE LIMITED WARRANTY PERIOD
AND TERMS SET FORTH ABOVE.
• SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU.
• THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU
MAY ALSOHAVE OTHER RIGHTS, WHICH MAY VARY FROMSTATE
TO STATE.
The NavMate Navigation Software Limited Warranty and End User License
Agreement are outlined in the User Manual provided with the NavMate CD.
Procedures for Obtaining Repair
During the applicable limited warranty period, call the horizon navigation, inc. at 1-
86NAVMATE1 (1-866-286-2831). Proof of the navmate system purchase date is required
to obtain limited warranty repair. For further information on limited warranty performance
and coverage, contact the navmate warrantor, Horizon Navigation, Inc. at 1-
86NAVMATE1 (1-866-286-2831) or write to:
Warrantor:
Horizon Navigation, Inc.
4701 Patrick Henry Dr. #1301
Santa Clara, CA 95054

ix
User Manual
This page is intentionally blank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
Safety Information and Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
NavMate Navigation System Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . v
Eligibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v
Limited Warranty Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v
Parts and Services Covered/Parts and Services Not Covered . . . . . . . . v
Limitations and Exclusions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v
Procedures for Obtaining Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi
Portable NavMate Navigation System Limited Warranty . . . . . . . . . . . . . . . vii
Eligibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii
Limited Warranty Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Parts and Services Covered/Parts and Services Not Covered . . . . . . . vii
Limitations and Exclusions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Procedures for Obtaining Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii
1 Introduction to Your Navigation System 1
Vehicle Direction-Sensing Electronics . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Computerized Map and Information Database . . . . . . . . . . . . . . . . . . . .1
Metro Area Coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Intertown Coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Map and Information Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
NavMate Navigation System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Basic Mechanics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Portable NavMate Navigation System . . . . . . . . . . . . . . . . . . . . . . . . . .5
System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Basic Mechanics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2QuickStart 6
Step 1 — Start up/Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Step 2 — Select Destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Step 3 — Select Route Criteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Step 4 — Map/Guide along Route . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Step 5 — Arrive at Destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

x
NavMate Navigation System
3 Using Your Navigation System 8
What Are All These Buttons? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Controls and Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
System Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Core Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Function Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Navigation Process Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
List Mode vs. Spell Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
When to Use List Mode or Spell Mode . . . . . . . . . . . . . . . . . . . . . .14
Using List Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Using Spell Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
4 Selecting a Destination 17
Address/Intersection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Points of Interest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
By Category . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
By First Few Letters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
By Both Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Previous Destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Address Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Selecting an Address Book Entry as a Destination . . . . . . . . . . . .24
Adding, Deleting, or Editing in the Address Book . . . . . . . . . . . . . . 24
Freeway Entrance/Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
5 Selecting Route Criteria 27
6 Route Calculation and Guidance Screens 28
Route Calculation Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Please Proceed Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Planned Route Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Guide Display Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
True View (Intersection) Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Map Display Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Current Location Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Arrival Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
7 Detours, Off-Route and Interruptions 35
Detour Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

xi
User Manual
Off-Route Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Route Interruption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
8 Trail Mode 37
9 Portable Mode 40
10 Option Menu 41
Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Vehicle Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Portable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

xii
NavMate Navigation System

Vehicle Direction-Sensing Electronics 1
User Manual
1 Introduction to Your Navigation System
As you travel, your NavMate Navigation System functions as your co-pilot,
providing turn-by-turn visual and voice assistance to direct you to your selected
destination. Because the system knows where you are and where youwant to go,
it can quickly calculate step-by-step directions that provide the shortest time
route to any destination available on the included navigation map CD. The map
CD includes tens of thousands of roadway and mapping destinations, and
preprogrammed point of interest (POI) locations in over 40 categories. Simply
enter your desired destination into your NavMate Navigation System, and its
advanced intelligence does the rest.
With your NavMate Navigation System, if you deviate from the planned
route, the navigation system will automatically recalculate the route to
determine a new one from your current location. If you want to intentionally
avoid certain roads or freeways, your NavMate will do that too.
The NavMate Navigation System incorporates direction-sensing electronics,
Global Positioning System (GPS) satellites, and a roadway map database to
calculate and display travel directions. The system’s GPS antenna receives
signals from a constellation of 24 satellites orbiting the earth and uses the
strongest of signals, to determine your position to within 30 meters. The
navigation system’s sophisticated software and additional sensors are used to
provide the highly accurate positioning necessary to provide real-time, accurate,
turn-by-turn route guidance.
Vehicle Direction-Sensing Electronics
The NavMate Navigation System’s computer combines vehicle speed and
heading change, together with GPS information, to accurately determine vehicle
heading and position on a digital map. This information is relayed to you as you
proceed to your selected destination using voice guidance, the turn-by-turn
display and a digital map. When in Portable mode, the odometer signal in the
vehicle is not used.
Computerized Map and Information Database
The map used by your NavMate Navigation System was created from high-
resolution aerial photographs for most areas of the country and stored on Map
CD’s. This data is enhanced with a variety of useful travel information, such as

2 Introduction to Your Navigation System
NavMate Navigation System
freeway signage and over 500,000 point of interest locations in over 40
categories, ranging from tourist attractions, golf courses and government
buildings to gas stations, airports, restaurants, hotels, hospitals, and automated
teller machines (ATMs).
Metro Area Coverage
Metro Area Coverage includes all defined roads within a city as well as the
area’s entire road network (interstate highways, state and county roads). In a
metro area, a typical segment of a roadway may contain up to 150 pieces of
information, such as road type (freeway, ramp, city street, to name a few), one-
way restrictions, turning restrictions, and alternate street names. It is this vast
quantity of information in a metro area that allows your navigation system to
provide accurate route planning anddirectional guidance. Metro Area Coverage
is not yet complete for all metro areas, though ongoing digital mapping is
continually expanding the coverage.
Intertown Coverage
Intertown Coverage is provided for more rural areas of the country to
seamlessly connect the detailed areas. The “City Center” point of interest
category is useful for routing to cities where Metro Area Coverage is not
available. This information includes all roads in the American Automobile
Association’s (AAA) state road maps.
Map and Information Database
Your NavMate Navigation System’s map and information database is
constantly being updated for completeness and accuracy. While the database
was judged to be as accurate as possible at the time of its release, a map database
can never be 100% accurate. Roadway information thatis maintained in the map
databases, such as turning restrictions or road names, changes over time. In
addition, points of interests, such as restaurants, hotels, and gas stations, also
change over time. The complexity of keeping this directory current means that
some pieces of information may be missing or out-of-date at times.
Mapping and travel information for the USA is compressed into 9 Map CD’s,
together with navigation software to operate the system. Each Map CD comes
with the complete U.S. highway network called Route USA. They are:

Map and Information Database 3
User Manual
For information on obtaining additional Map CD’s or updates, call
1-86NAVMATE1 (1-866-286-2831) or visit www.horizonnav.com.
Map CD 8 Map CD 9
Map CD 6
Map CD 5
Map CD 4
Map CD 1 Map CD 2 Map CD 3
Map CD 7

4 Introduction to Your Navigation System
NavMate Navigation System
NavMate Navigation System
System Components
The following hardware components make up your NavMate:
• Wire Harness – connects system to the vehicle’s electrical system.
• Navigation System Computer – includes removable CD featuring
digital map, points of interest information database, and navigation
application software to operate the system.
• Display Cable – connects navigation computer to the display unit.
• GPS Antenna – installed on the vehicle roof, instrument panel, trunk
lid, or rear window shelf, this antenna must have a clear view of the sky
to receive the GPS satellite signals. For the best performance the GPS
antenna should be mounted on a metal surface.
• Computer Mounting Bracket – used to mount the computer in a safe
location, such as the cargo compartment or under a seat.
• Display Unit – typically mounted on or near the instrument panel, this
features a color LCD display screen, built-in speaker, and control
buttons.
• Map CD – One Map CD is included with this kit. To order additional
and updated Map CD’s, please call 1-86NAVMATE1 (1-866-286-
2831) or visit www.horizonnav.com.
Basic Mechanics
A special harness connects the navigation system to your vehicle’s electrical
system circuits. Connection locations vary depending on vehicle design. In
brief, however, this is how the navigation system is connected:
• Ignition ON provides power to wake up the navigation system.
• The battery circuit powers the navigation system’s computer. When the
Ignition is OFF, a minimal source of Battery power is needed to store
the vehicle’s last location/position, similar to the way the time on your
vehicle’s clock is stored while the car is OFF.
• Ground connection completes electrical circuits.
• Vehicle speed sensor circuit provides information on how fast the
vehicle is traveling.
• Reverse sensor circuit signals when the vehicle is backing up.
• A 3 amp fuse protects the navigation system from system fluctuations.
• A video display cable connects the computer to the display unit, and an
antenna wire connects the GPS antenna to the system.

Portable NavMate Navigation System 5
User Manual
Portable NavMate Navigation System
System Components
• Navigation System Computer – includes removable CD featuring digital
map, points of interest information database, and navigation application
software to operate the system.
• Display Cable – connects navigation computer to the display unit.
• GPS Antenna – installed on the vehicle roof, instrument panel, trunk lid, or
rear window shelf, this antenna must have a clear view of the sky to receive
the GPS satellite signals. For the best performance the GPS antenna should
be mounted on a metal surface.
• Display Unit – typically mounted on or near the instrument panel, this
features a color LCD display screen, built-in speaker, and control buttons.
• NavMate Bag - contains a foam insert to provide protection to NavMate
components contained in the bag. This uniquely designed bag has an upper
tray for stowing away the display unit and display cable. Both tray and bag
have air vents to allow for proper airflow.
• Display Mount – Typically mounted on or near the instrument panel of the
vehicle. For mounting instructions and care please carefully read Installation
Manual included with this kit.
• Map CD – One Map CD is included with this kit. To order additional and
updated Map CD’s, please call 1-86NAVMATE1 (1-866-286-2831) or visit
www.horizonnav.com.
Basic Mechanics
• Cigarette lighter adapter from the battery module is used to power the
system.
• Portable NavMate does not use a vehicle speed sensor. It is recommended
that the GPS antenna be mounted on the roof of the vehicle, in clear view of
the sky to receive a GPS signal.
• The system will take approximately seven minutes to initialize when it is
used for the first time or when battery has been drained.

6 Quick Start
NavMate Navigation System
2 Quick Start
Time to get you on the road with your NavMate Navigation System. Follow
these five easy steps and you are on your way.
WARNING! Before operating your NavMate, please carefully read
and follow the instructions provided in the “Safety Information and
Precautions” section of this manual.
Step 1 — Start up/Main Menu
With the ignition switch in the ‘run’ or ‘accessory’ position (or when the
cigarette lighter adapter is plugged into the vehicle - Portable NavMate), power
is supplied to NavMate. The system automatically turns on when you turn on
your vehicle, and turns off when you turn off your vehicle.
When your vehicle is started, your NavMate will automatically default to the
Please Drive Safely screen. Please read and follow the instructions on this
screen carefully.
Press to accept, and the Main Menu screen is displayed.
Note: If a key is not pressed within 10 seconds, the system goes into “sleep”
mode and the screen turns gray. The gray screen will turn on only when you are
on the Please Drive Safely screen. Press any key to return to the Please Drive
Safely screen.
Screen 1. Please Drive Safely Screen
Step 2 — Select Destination
At the Main Menu/Where do you want to go?screen, you have many ways to
ENTER
ENTER
