Horwin Ranger-S User manual

1

2
Catalog
1 Means of representation...........................................................................................9
1.1 Symbols used.............................................................................................................................9
1.2 Formats used..............................................................................................................................9
2 Safety advice..............................................................................................................9
2.1 Use definition - intended use..................................................................................................9
2.2 Safety advice..........................................................................................................................9
2.3 Degrees of risk and symbols.................................................................................................10
2.4 Safe operation........................................................................................................................10
2.5 Protective clothing.................................................................................................................11
2.6 Work rules.............................................................................................................................11
2.7 Environment..........................................................................................................................11
2.8 User’ s manual.......................................................................................................................11
3 Important notes........................................................................................................................13
3.1 Manufacturer and implied warranty.....................................................................................13
3.2 Operating and auxiliary substances.......................................................................................13
3.3 Spare parts, accessories..........................................................................................................13
3.4 Service....................................................................................................................................13
3.5 Figures...................................................................................................................................14
3.6 Customer service...................................................................................................................14

3
4 View of motorcycle..................................................................................................................15
4.1 View of motorcycle, front left (example)..............................................................................15
4.2 View of motorcycle, top (example).......................................................................................16
5 Serial numbers..........................................................................................................................17
5.1 Chassis Number.....................................................................................................................17
5.2 Nameplate..............................................................................................................................17
5.3 Motor number........................................................................................................................17
6 Controls.......................................................................................................................................18
6.1 Front brake lever...................................................................................................................18
6.2 Rear brake lever....................................................................................................................18
6.3 Throttle grip..........................................................................................................................18
6.4 Key-Switch/Steering Lock....................................................................................................18
6.5 Remote controller..................................................................................................................19
6.6 Start/Stop button ...................................................................................................................19
6.7 Headlight Switch...................................................................................................................20
6.8 Driving mode Switch.............................................................................................................20
6.9 Emergency flasher switch......................................................................................................20
6.10 Headlight High/Low Beam Switch.....................................................................................21
6.11 Steering lamp switch...........................................................................................................21
6.12 Horn Button.........................................................................................................................21
6.13 Seat/helmet lock..................................................................................................................22

4
6.14 Charging dock.....................................................................................................................22
6.15 Side stand.............................................................................................................................23
7 Speedometer...............................................................................................................................23
7.1 Adjustment button.................................................................................................................23
7.2 Speed display.........................................................................................................................23
7.3 Driving mode display............................................................................................................24
7.4 Current display......................................................................................................................24
7.5 Odometer ..............................................................................................................................24
7.6 Temperature display..............................................................................................................24
7.7 Battery display.......................................................................................................................25
7.8 Charging indicator.................................................................................................................25
7.9 Steering indicator...................................................................................................................25
7.10 READY indicator................................................................................................................26
7.11 High beam indicator............................................................................................................26
7.12 Parking indicator.................................................................................................................26
7.13 Error code indicator............................................................................................................26
7.14 Time setting.........................................................................................................................27
7.15 Set the diameter of rear tire.................................................................................................27
7.16 Set the MM/INCH...............................................................................................................28
7.17 Service indicator..................................................................................................................28
8 How to drive this motorcycle...............................................................................................29

5
8.1 Checks and service when preparing for use..........................................................................29
8.2 Starting..................................................................................................................................30
8.3 Starting off.............................................................................................................................31
8.4 Braking..................................................................................................................................31
8.5 Stopping, parking..................................................................................................................32
8.6 Shutting down the motorcycle...............................................................................................33
8.7 Transporting the motorcycle...................................................................................................33
8.8 Transporting the battery........................................................................................................33
9 Service schedule........................................................................................................................34
9.1 Required work.......................................................................................................................34
9.2 Recommended inspection......................................................................................................35
10 Motorcycle adjustment operation....................................................................................36
10.1 Adjustment of rebound damping of front shock absorber...................................................36
10.2 Adjusting the spring preload of the rear shock absorber.....................................................37
10.3 Checking the chain tension..................................................................................................37
10.4 Adjusting the chain tension.................................................................................................38
10.5 Checking chain dirt accumulation.......................................................................................39
10.6 Clean the chain....................................................................................................................40
11 Braking system.......................................................................................................................40
11.1 Checking the brake disc.......................................................................................................40

6
11.2 Check the brake lining.........................................................................................................41
11.3 Checking the brake fluid.....................................................................................................41
12 Wheels, tires.............................................................................................................................42
12.1 Checking the status of wheels and tires ..............................................................................42
12.2 Checking the tire pressure...................................................................................................43
13 Battery.......................................................................................................................................44
13.1 Install the battery.................................................................................................................44
13.2 Removing the battery..........................................................................................................44
13.3 Battery charging..................................................................................................................44
14 Service for the Motor...........................................................................................................47
14.1 Checking the gear oil...........................................................................................................47
14.2 Changing the gear oil...........................................................................................................47
15 Cleaning and service................................................................................................................48
15.1 Cleaning the motorcycle.......................................................................................................48
15.2 Inspection and service for use during..................................................................................49
16 Storage..........................................................................................................................................51
16.1 Storage.................................................................................................................................51
16.2 Preparing for use after storage.............................................................................................51
17 Troubleshooting.....................................................................................................................53
18 Technical Data........................................................................................................................56

7
18.1 Motor...................................................................................................................................56
18.2 Complete motorcycle............................................................................................................56
18.3 Electrical System..................................................................................................................57

8
DEAR HORWIN Ranger CUSTOMER
Congratulations on your decision to purchase a HORWIN Ranger motorcycle. You are now the
owner of a state-of-the-art sports motorcycle that will give you enormous pleasure if you service
and maintain it properly.
Enter the serial numbers of your motorcycle below.
Chassis Number
Dealer’s stamp
Engine Number
The Owner's Manual contained the latest information for this model series at the time of going to
print. Slight deviations caused by continuing development and design of the motorcycles can,
however, not be completely excluded.
All specifications are non-binding. HORWIN Ranger specifically reserves the right to modify or
delete technical specifications, prices, colors, forms, materials, services, designs, equipment, etc.,
without prior notice and without specifying reasons, to adapt these to local conditions, as well as to
stop production of a particular model without prior notice. HORWIN Ranger accepts no liability for
delivery options, deviations from illustrations and descriptions, misprints, and other errors. The
models portrayed partly contain special equipment that does not belong to the regular scope of
supply.
If you have any questions about this motorcycle, please contact our customer service center.
Wish you a safe and happy riding experience!

9
1 Means of representation
1.1 Symbols used
The meaning of specific symbols is described below.
All work marked with this symbol requires specialist knowledge and technical
understanding. In the interest of your own safety, have these jobs performed by an
authorized HORWIN Ranger workshop. There, your motorcycle will be optimally serviced
for by specially trained experts using the specialist tools required.
Indicates information with more details or tips.
1.2 Formats used
The typographical formats used in this document are explained below.
Specific name
Identifies a proprietary name.
Underlined terms
Refer to technical details of the motorcycle or indicate technical terms that
are explained in
the glossary.
2 Safety advice
2.1 Use definition - intended use
HORWIN Ranger sport motorcycles are designed and made to withstand the normal stresses use.
Info
The motorcycle is authorized for public road traffic in the homologous (reduced) version
only.
In the derestricted version, the motorcycle must be used only on closed off property remote
from public road traffic.
2.2 Safety advice
A number of safety instructions need to be followed to operate the motorcycle safely. Therefore,
read this manual carefully. The safety instructions are highlighted in the text and are referred to at
the relevant passages.

10
Info
The motorcycle has various information and warning labels at prominent locations. Do not
remove information/warning labels. If they are missing, you or others may not recognize
dangers and may therefore be injured.
2.3 Degrees of risk and symbols
Danger
Indicates a danger that will immediately and invariably lead to fatal or serious permanent
injury if the appropriate measures are not taken.
Warning
Indicates a danger that is likely to lead to fatal or serious injury if the appropriate measures
are not taken.
Caution
Indicates a danger that may lead to minor injuries if the appropriate measures are not taken.
Note
Indicates a danger that will lead to considerable machine and material damage if the
appropriate measures are not taken.
Warning
Indicates a danger that will lead to environmental damage if the appropriate measures are not
taken.
2.4 Safe operation
Only operate the motorcycle when it is in perfect technical condition, in accordance with its
intended use, and in a safe and environmentally compatible manner.
An appropriate driver's license is needed to ride the motorcycle on public roads.
Have malfunctions that impair safety promptly eliminated by an authorized HORWIN Ranger
workshop.
Adhere to the information and warning labels on the motorcycle.
Danger
A rider who is not fit to ride poses a danger to him or herself and others.
Do not operate the motorcycle if you are not fit to ride due to alcohol, drugs or medication.
Warning

11
Some motorcycle components become very hot when the motorcycle is operated.
Do not touch any parts such as the motor, shock absorber, or braking system before the
motorcycle parts have cooled down.
2.5 Protective clothing
In the interest of your own safety, HORWIN Ranger recommends that you only operate the
motorcycle while wearing protective clothing.
Warning
Missing or poor protective clothing presents an increased safety risk.
Wear appropriate protective clothing such as helmet, boots, gloves as well as trousers
and a jacket with protectors on all rides.
Always wear protective clothing that is in good condition and meets the legal
regulations.
2.6 Work rules
Special tools are necessary for certain tasks. The tools are not contained in the motorcycle but can
be ordered under the number in parentheses.
During assembly, non-reusable parts (e.g. self-locking screws and nuts, seals and seal rings, O-rings,
pins, lock washers) must be replaced by new parts.
In some instances, a thread locker (e.g. Loctite ® ) is required. The manufacturer instructions for
use must be followed.
After disassembly, clean the parts that are to be reused and check them for damage and wear.
Change damaged or worn parts.
After you complete the repair or service work, check the operating safety of the motorcycle.
2.7 Environment
If you use your motorcycle responsibly, you can ensure that problems and conflicts do not occur. To
protect the future of the motorcycle sport, make sure that you use your motorcycle legally, display
environmental consciousness, and respect the rights of others.
When disposing of used oil, other operating and auxiliary fluids, and used components, comply
with the laws and regulations of the respective country.
Your authorized HORWIN Ranger dealer will be glad to advise you.
2.8 User’s manual
It is important that you read this Owner's Manual carefully and completely before making your first
trip. The Owner's Manual contains useful information and many tips on how to operate, handle, and

12
maintain your motorcycle. Only then will you find out how to customize the motorcycle ideally for
your own use and how you can protect yourself from injury.
Keep the Owner's Manual in an accessible place to enable you to refer to it as needed.
If you would like to know more about the motorcycle or have questions on the material you read,
please contact an authorized HORWIN Ranger dealer.
The Owner's Manual is an important component of the motorcycle and should be handed over to the
new owner if the motorcycle is sold.

13
3 Important notes
3.1 Manufacturer and implied warranty
The work specified in the service schedule may only be performed in an authorized HORWIN
Ranger workshop and must be recorded in both the Service & Warranty Booklet, otherwise any
warranty coverage will become void. Damage or secondary damage caused by tampering with
and/or conversions on the motorcycle is not covered by the warranty. Additional information on the
manufacturer or implied warranty and the procedures involved can be found in the Service &
Warranty Booklet.
3.2 Operating and auxiliary substances
Warning
Environmental hazard Improper handling of lubricating oil is a danger to the
environment.
Do not allow lubricating oil to enter the groundwater, the soil, or the sewage system.
Use operating and auxiliary substances (such as lubricants) as specified in the Owner's Manual.
3.3 Spare parts, accessories
For your own safety, only use spare parts and accessory products that are approved and/or
recommended by HORWIN Ranger and have them installed by an authorized HORWIN Ranger
workshop. HORWIN Ranger accepts no liability for other products and any resulting damage or
loss.
Certain spare parts and accessory products are specified in parentheses in the descriptions. Your
authorized HORWIN dealer will be glad to advise you.
The current HORWIN Ranger Power-Parts for your motorcycle can be found on the HORWIN
Ranger website.
International HORWIN Ranger Website: http://www.horwin.eu/
3.4 Service
A prerequisite for perfect operation and prevention of premature wear is that the service, motorcycle,
and tuning work on the engine and chassis is properly serviced out as described in the Owner's
Manual. Incorrect adjustment and tuning of the engine and chassis can lead to damage and breakage
of components.
Use of the motorcycle under difficult conditions, such as on sand or on wet and muddy surfaces,
can lead to considerably more rapid wear of components such as the drive train, braking system, or
suspension components. For this reason, it may be necessary to inspect or replace parts before the

14
next scheduled service.
It is imperative that you adhere to the stipulated run-in times and service intervals. If you observe
these exactly, you will ensure a much longer service life for your motorcycle.
3.5 Figures
The figures contained in the manual may depict special equipment.
In the interest of clarity, some components may be shown disassembled or may not be shown at all.
It is not always necessary to disassemble the component to perform the activity in question. Please
follow the instructions in the text.
3.6 Customer service
Authorized HORWIN dealer will be happy to answer any questions you may have on motorcycle
and HORWIN Ranger.
The list of authorized HORWIN dealers can be found on the HORWIN website.
International HORWIN Ranger Website: http://www.horwin.eu/

15
4 View of motorcycle
4.1 View of motorcycle, front left (example)
①
③
④
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
②
⑤
⑲
①Front shock absorber ②Front headlight ③Rearview ④Cushion ⑤Rear shock absorber
⑥Rear tail lamp ⑦Rear license plate lamp ⑧Rear reflector ⑨Seat lock ⑩Rear tire
⑪Rear chain sprocket⑫Chain guide ⑬Chain ⑭Side stand ⑮Motor ⑯Side reflector
⑰Front tire ⑱Front disc brake pump ⑲Front brake disc

16
4.2 View of motorcycle, top (example)
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
①Front switch light ②Front brake handle ③Accelerating handle ④Right handle switch
⑤Front foot rest ⑥Rear foot rest ⑦Rear steering lamp ⑧Start and stop button ⑨Left hand
handle switch ⑩Rear brake handle

17
5 Serial numbers
5.1 Chassis Number
The chassis number is stamped on the right side of the
steering head.
5.2 Nameplate
The nameplate is mounted on the chassis at the front
right.
5.3 Motor number
The engine number is stamped on the left side of the engine
under the engine sprocket.
A barcode label with the motor number is attached to the
right cover of the motor for easy viewing.




18
6 Controls
6.1 Front brake lever
The front brake handle is fitted on the right side of the
handlebar.
6.2 Rear brake lever
The rear brake lever is fitted on the left side of the
handlebar.
6.3 Throttle grip
The throttle grip is fitted on the right side of the handlebar.
6.4 Key-Switch/Steering Lock
The Key-Switch/Steering Lock is between the speedometer
and handlebar.
In this position, the motorcycle is started.
In this position, the motorcycle cannot be activated.
in this position, the steering is locked.
Info




19
The steering lock is used to lock the steering. Steering,
and therefore riding is no longer possible.
Using the steering lock when parked prevents
unauthorized use and helps prevent theft.
Lock the steering
1. Turn the handlebar all the way to the left.
2. With the key in the position, push the key down and
loose, then turn the key counter-clockwise to the position.
3. Remove the key.
Unlock the steering
1. Install the key and turn clockwise.
2. Remove the key.
6.5 Remote controller
We use the advanced smart remote controller which can be
easily locked or unlocked by pressing the button within 50
meters. The functions are as follows:
Unlock button: press this key, motorcycle unlocks,
start/stop button flashes.
Lock button: when the motorcycle is stopped, press
this key to lock the motorcycle.
Motorcycle search button：Press this button and the
motorcycle will ring.
Start button ：Double click this button to start the
motorcycle.
6.6 Start/Stop button
Start/stop button is used to start or stop the motorcycle.
After unlocking the motorcycle through the smart remote
controller, press the start button gentle. The motorcycle
enters the "start state". Press the button again to shut down
the motorcycle.
When start/stop button is always on, it’s the unlock state.
When start/stop button is flashing, it’s the locked state.






20
6.7 Headlight Switch
Flip the switch upward to , open the Headlight.
Flip the switch down to , open the Headlight.
6.8 Driving mode Switch
The driving mode switch is on the right handle switch.
Toggle between ECO, D(Dynamic), and S(Sport) modes.
The ECO selection reduces the acceleration and top speed of
the motorcycle but increases the amount of regeneration
when the throttle is released. It is an ideal mode for when you
want softer acceleration. This position is also good for newer
riders and for extending range.
The SPORT selection causes the motorcycle to accelerate at a
significantly faster rate but decreases the amount of
regeneration when the throttle is released. This position is
recommended for advanced riders.
The Dynamic selection has a dynamic performance between
the ECO and SPORT mode.
6.9 Emergency flasher switch
When the button is pressed, the turning lights flash to warn
other drivers of situations, which include stop or park under
emergency conditions.
Press the button again, and the hazard warning will turn off.



