Hoshizaki Pass Thru Series PTR2SSB-HSHS User manual

Cabinet Const uction
•Stainless steel interior and exterior for long life, durability
and easy maintenance
•Ducted air distribution system achieves a uniform box
temperature eliminating “hot spots” even when full
•(3) heavy duty epoxy shelves per section are standard;
adjustable in 1" increments
•Cabinet door perimeter heater provides condensation
control and is equipped with a back-up heater; Manual
on/off switch allows for energy savings
•Cabinet walls are insulated with 2 3/8” of R-134A,
CFC free foamed in place polyurethane
•Interior incandescent light automatically activated
•Die cast legs and stainless steel feet offer increased
durability
Doo Const uction
•Full height and half height doors are constructed of
high grade 300 Series stainless steel inside and out
•Flush mount door handles maximize aisle space by
eliminating protruding parts
•Door hinges are all metal with tension spring closure;
Doors stay open at 105˚ and are self-closing at 85˚
•Step door design protects door gasket when product is
removed from the box; Snap-in magnetic door gaskets are durable and easily removed
•Door hinging is field reversible
•Cylinder door locks are standard
Ref ige ation System
•High efficiency refrigeration system is designed with a large capacity condenser and evaporator
resulting in lower overall power consumption
•TempGuard’s®EverCheck®controls monitor high and low temperatures, high pressure, high and low
voltage, clean filter and cabinet temperature functions.The controls are located on operators side of
the unit
•Refrigeration system is mounted on a fully insulated rotocast platform and is easily removable from
the main unit
•Evaporator coil is coated for extended life
•Refrigeration system is equipped with solid state digital controls
•Removable, cleanable air filter protects condenser and reduces cleaning requirements
•Hot gas condensate evaporator is standard
•115 volt units equipped with cord and plug
•Refrigerant: R-404A with expansion valve control
Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com
PPTTRR22SSSSBB--__SS__SS DDIIMMEENNSSIIOONNSS
W x D x H
PTR2SSB-_S_S
2/08
Item # 13205
TEMPG ARD®STAINLESS STEEL DOOR PASS THR REFRIGERATORS
Warranty
Valid in United States, Canada, Puerto Rico, & U.S. Territories. Contact factory for warranty in
other countries.
Two Yea - Parts & abor on entire machine.
Five Yea - Parts on: Compressor.
PTR2SSB-_S_S
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
55 x 35.9 x 84.5*
*with 6" adj. legs
TEMPG ARD®Self-Contained, Stainless Steel Door Pass Thru Refrigerators
with EverCheck®Audio Alert
PTR2SSB-HSHS
Shown
*AutoCad available on KC
PTR2SSB-FSFS

115/60/1
12.0
15.0
5 - 15P
16.6
2360
6226 (3/4HP)
104 - 126
45° - 100°F
36° to 50°F
R-404A
Hoshizaki
DDIIMMEENNSSIIOONNSS
W x D x H
PTR2SSB-_S_S
55 x 35.9 x 84.5*
* with 6" adj. legs
PAS S TH RU RE F RI G ER ATOR
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com Printed in U.S.A.
PTR2SSB-_S_S
STAINLESS STEEL DOOR PASS THR REFRIGERATOR
• 2 section pass thru refrigerator with half height stainless steel doors
• 2 section pass thru refrigerator with full height stainless steel doors
OPTIONS
• 4” Heavy duty casters • Universal tray/pan slides
• Additional epo y shelves • Stainless steel shelves
• Foot pedal • Reverse door hinging
• Padlock hasp
DIMENSIONS/CAPACITY
Mo el #
Interior Storage Capacity (CF)
Overall Wi th
Overall Depth
Height (including 6" dj. legs)
Depth with Door open at 90°
Door Opening Wi th
Door Opening Height
A justable Shelves
Shelf Dimensions (W x D)
Crate Shipping Weight
Crate Height
Crate Wi th
Crate Depth
Two Section
PTR2SSB-HSHS
ELECTRICAL & REFRIGERATION DATA
Mo el #
Voltage
Amperage
HACR Breaker
Electrical Connection(NEMA)
*Energy Consumption(kwh/d y)
* Heat Rejection(BTU/Hr.)
Approximate Nominal
Compressor BTU/Hr.(HP)
Voltage Range
Ambient Temp. Range
Control Setpoint Range
*Refrigerant
51.3 ft3
55"
35.9"
84.5"
85.9"
21.75"
26.75"
6
21.2" x 30.75"
700 lb
85"
59"
39"
* B sed on 100°F mbient cycling t setpoint (NSF)
Two Section
PTR2SSB-HSHS
DOOR SWING
SIDE VIEW
6.1"
67.1"
24.2"
84.3"
St ys open t 105°
35.9"
84.5"
78.5"
6"
26.75"
65.0"
Two Section
PTR2SSB-FSFS
51.3 ft3
55"
35.9"
84.5"
85.9"
21.75"
59.25"
6
21.2" x 30.75"
700 lb
85"
59"
39"
115/60/1
12.0
15.0
5 - 15P
16.6
2360
6226 (3/4HP)
104 - 126
45° - 100°F
36° to 50°F
R-404A
Two Section
PTR2SSB-FSFS
PLAN VIEW
55.0”
35.9”
84.5”
PTR2SSB-FSFS
84.5”
PTR2SSB-HSHS
