Hoshizaki PTR1SSB-FGFG User manual

Cabinet Const uction
•Stainless steel interior and exterior for long life, durability
and easy maintenance
•Ducted air distribution system achieves a uniform box
temperature elimnating “hot spots” even when full
•(3) heavy duty epoxy shelves per section are standard;
adjustable in 1" increments
•Cabinet door perimeter heater provides condensation
control and is equipped with a back-up heater. Manual
on/off switch allows for energy savings
•Cabinet walls are 2 3/8” thick, insulated with R-134A,
CFC free foamed in place polyurethane
•Interior fluorescent light manually activated
•Die cast legs and stainless steel feet offer increased
durability
Doo Const uction
•Two full height or half height glass doors are constructed of
double pane, heated glass with silver finish aluminum frame
•Door hinges are all metal with tension spring closure and
will not wear out like traditional cam-lift hinges; Doors stay
open at 90˚ and are self-closing at 85˚
•Snap in magnetic door gaskets are durable and easily removed
•Door hinging is reversible at time of order
•Cylinder door locks are standard
Ref ige ation System
•High efficiency refrigeration system is designed with a large capacity condenser and evaporator
resulting in lower overall power consumption
•TempGuard’s®EverCheck®controls monitor high and low temperatures, high pressure, high and low
voltage, clean filter and cabinet temperature functions.The controls are located on operators side of
the unit
•Refrigeration system is mounted on a fully insulated rotocast platform and is easily removable from
the main unit
•Evaporator coil is coated for extended life
•Refrigeration system is equipped with solid state digital controls
•Removable, cleanable air filter protects condenser and reduces cleaning requirements
•Hot gas condensate evaporator is standard
•115 volt units equipped with cord and plug
•Refrigerant: R-404A with expansion valve control
Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com
PPRR11SSSSBB--__GG__GG DDIIMMEENNSSIIOONNSS
W x D x H
P R1SSB-_G_G
5/08
Item # 13179
EMPGUARD®GLASS DOOR PASS HRU REFRIGERA ORS
Warranty
Valid in United States, Canada, Puerto Rico, & U.S. Territories. Contact factory for warranty in
other countries.
Two Yea - Parts & Labor on entire machine.
Five Yea - Parts on: Compressor.
PTR1SSB-_G_G
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
27.5 x 35.9 x 84.5*
*with 6" adj. legs
EMPGUARD®Self-Contained, Glass Door Pass hru Refrigerators with EverCheck®Audio Alert
PTR1SSB-HGHG
Shown
*AutoCad available on CL
PTR1SSB-FGFG

115/60/1
12.0
15.0
5 - 15P
18.5
2630
3610 (1/2HP)
104 - 126
45° - 100°F
36° to 50°F
R-404A
Hoshizaki
DDIIMMEENNSSIIOONNSS
W x D x H
PTR1SSB-_G_G
27.5 x 35.9 x 84.5*
* with 6" adj. legs
PAS S TH RU RE F RI G ER ATOR
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com Printed in U.S.A.
P R1SSB-_G_G
GLASS DOOR PASS HRU REFRIGERA OR
• 1 section pass thru refrigerator with half glass doors
• 1 section pass thru refrigerator with full glass doors
O P I O N S
• 4 Heavy duty casters • Universal tray/pan slides
• Additional epoxy shelves • Stainless steel shelves
• Foot pedal
DIMENSIONS/CAPACI Y
Mo el #
Interior Storage Capacity (CF)
Overall Wi th
Overall Depth
Height (including 6" dj. legs)
Depth with Door open at 90°
Door Opening Wi th
Door Opening Height
A justable Shelves
Shelf Dimensions (W x D)
Crate Shipping Weight
Crate Height
Crate Wi th
Crate Depth
One Section
PTR1SSB-HGHG
ELEC RICAL & REFRIGERA ION DA A
Mo el #
Voltage
Amperage
HACR Breaker
Electrical Connection(NEMA)
*Energy Consumption(kwh/d y)
* Heat Rejection(BTU/Hr.)
Approximate Nominal
Compressor BTU/Hr.(HP)
Voltage Range
Ambient Temp. Range
Control Setpoint Range
*Refrigerant
23.8 ft3
27.5"
35.9"
84.5"
84.7"
21.75"
26.75"
3
21.2" x 30.75"
475 lb
85"
32"
38"
* B sed on 100°F mbient cycling t setpoint (NSF)
One Section
PTR1SSB-HGHG
DOOR SWING
SIDE VIEW
PLAN VIEW
PTR1SSB-HGHG
(Operators Si e)
84.7"
25.0"
6.7"
35.9"
24.4"
St ys open t 105°
St ys open t 90°
35.9"
84.5"
78.5"
6"
26.75"
65.0"
27.5"
35.9"
84.5"
One Section
PTR1SSB-FGFG
23.8 ft3
27.5"
35.9"
84.5"
84.7"
21.75"
59.25"
3
21.2" x 30.75"
475 lb
85"
32"
38"
115/60/1
12.0
15.0
5 - 15P
18.5
2630
3610 (1/2HP)
104 - 126
45° - 100°F
36° to 50°F
R-404A
One Section
PTR1SSB-FGFG
84.5”
PTR1SSB-FGFG
(Operators Si e)
