Hoshizaki WOX-40WA-EW User manual

WOX-40WA-EW
WATER ELECTROLYZER
FOR END USER
INSTRUCTION MANUAL
L1X006112 (111520)
3-16 Minamiyakata, Sakae-cho, Toyoake, Aichi 470-1194 Japan

1
IMPORTANT SAFETY INFORMATION
Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage
to the unit.
WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE Indicates a hazardous situation which, if not avoided, could result in damage to the unit.
HYGIENE Indicates important precautions for hygiene and food safety.
IMPORTANT Indicates important information about the use and care of the unit.
IMPORTANT
This booklet is an integral and essential part of the product and should be kept and preserved by the user.
Please read carefully the guidelines and warnings contained herein as they are intended to provide the user with essential
information for the continued safe use and maintenance of the product. In addition, it provides GUIDANCE ONLY to the user
on the correct services and site location of the electrolyzer.
Please preserve this booklet for any further consultation that may be necessary.
WARNING
This is a water electrolyzer, and should be destined only to be used for the purpose for which it has been expressly designed.
Any other use should be considered improper and therefore dangerous. The manufacturer will not be held liable or responsible
for any damage caused by improper, incorrect and unreasonable use.
The installation, and relocation if necessary, must be carried out by qualied personnel, in accordance with current
regulations, according to the manufacturer’s instructions.
This electrolyzer is not intended for outdoor use (including under canopy). Exposure to rain may cause electric leak or shock.
Direct sunlight can damage the plastic tank exterior, resulting in cracks and water leaks.
Ensure adequate ventilation. Hydrogen gas or chlorine gas may cause health problems.
Do not mix electrolyzed water with other chemicals. Mixture with acidic or chlorine-based chemicals can cause chlorine gas,
resulting in health problems.
Do not use a large volume of sanitizing water only. Generation of a large amount of chlorine gas may cause health problems
or corrosion of surrounding equipment.
The use of any electrical appliance involves the observance of some fundamental rules. In particular:
* Instances of high humidity and moisture increase the risk of electrical short circuits and potential electrical shocks. If in
doubt, disconnect the electrolyzer.
* Do not damage the power cord or pull it in order to disconnect the electrolyzer from the electrical supply network.
* If the supply cord is damaged, it must be replaced by your local Hoshizaki service agent or similarly qualied persons in
order to avoid a hazard.
* Do not touch the electrical parts or operate the switches with damp hands.
* This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
* Children should be supervised to ensure that they do not play with the appliance.
* Do not attempt to modify the electrolyzer. Only qualied personnel may disassemble or repair the appliance.
CAUTION
Do not use a ame near a container or tank holding electrolyzed water. Hydrogen gas from cleaning water may cause ignition.

2
In the context of this manual, the term "sanitizing water" refers to
acidic water and "cleaning water" refers to alkaline water.
1. PRINCIPLE OF ELECTROLYSIS
2. CONSTRUCTION
[a] EXTERIOR
[8]
[7]
[9]
(Bottom)
[12]
[13]
To sink
[10]
[11]
4
Reactions at Anode
Chloride ions (Cl-) and hydroxide ions
emit electrons (e-) to the anode, which
become hypochlorous acid (HOCl).
Reactions at Cathode
Sodium ions (Na+) receive electrons (e-)
from the cathode and become sodium
metal (Na) which reacts with water (H2O)
and becomes sodium hydroxide (NaOH)
and hydrogen gas (H2).
DC Power Supply
Hypochlorous Acid
(
HOCl
)
Sodium Hydroxide
(NaOH)
Cathode
(
RED
)
Anode
(OX)
Positive ions drawn
to cathode
Cl-
Negative ions
drawn to anode
Salt Water (NaCl)
Diaphragm
Electrolytic Cell
Flow of electrons
Cl-H2O
H2O
Na Na
Na+
Na+
Na+
OH-
OH-
2e- 2e-
H2
HOCl
[3]
[1]
[2]
[4]
(Front)
[5]
[6]
水
Reactions at Anode
Chloride ions (Cl-) and hydroxide ions emit electrons (e-) to the anode,
which become hypochlorous acid (HOCl).
Reactions at Cathode
Sodium ions (Na+) receive electrons (e-) from the cathode and
become sodium metal (Na) which reacts with water (H2O) and
becomes sodium hydroxide (NaOH) and hydrogen gas (H2).
Salt water contains four kinds of ions; sodium ions (Na+), chlorine
ions (Cl-), hydrogen ions
(H+) and hydroxide ions (OH-).
NaCl + H2O → Na++ Cl-+ H++ OH-
(Mix water and salt) Salt water (4 kinds of ions)
When two electrodes are inserted into salt water and voltage is
applied:
Negative ions (Cl-) are drawn to the anode, and
Positive ions (Na+) are drawn to the cathode.
At the anode, hydrogen chloride (HCl) and hypochlorous acid (HOCl)
are generated.
2Cl-+ H2O → HCl + HOCl + 2e-
Electrons (2e-) are emitted to the anode, which means the acidic
water (HCl + HOCl) causes
oxidization. [As electrons are emitted, the oxidization/reduction
potential becomes positive (+mV).]
Chlorine ions also emit electrons and become chlorine gas (Cl2).
2Cl- → Cl2+ 2e-
(Cl2= chlorine gas)
At the cathode, sodium hydroxide (NaOH) and hydrogen gas (H2) are
generated.
Na++ H2O + H++ 2e- → NaOH + H2
Electrons (2e-) are received from the cathode, which means the
alkali water (NaOH) causes reduction. [As electrons are received, the
oxidization/reduction potential becomes negative (-mV).]
[1] Power switch (earth leakage circuit breaker)
[2] Water inlet (G3/4 male)
[3] Power cord (1 phase 220-240V)
[4] Dispensing sensor
Senses a hand or object to start and stop dispensing electrolyzed
water without using the dispense button (default setting: portion
control mode).
[5] Control panel
Contains buttons and lamps for electrolytic cell function settings. See
“[c] CONTROL PANEL”.
[6] Operation panel
Indicates the operating conditions of the unit.
[7] Drain outlet (left)
Drains sanitizing water in ush cycle.
[8] Salt water hose
[9] Salt water tank (accessory)
[10] Nozzle hose (accessory)
[11] Nozzle
[12] Sanitizing water outlet (G1/2 male)
[13] Drain outlet (right)
Drains cleaning water during dispensing action and sanitizing water in
ush cycle.

3
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[1] Display select button
Press this button to select the indication in the display on the
operation panel. The lamp (green) of the selected item (clock, cell run
time, current or voltage) illuminates.
[2] Sensor button
Press this button to use the dispensing sensor. Electrolyzed water is
dispensed and stopped by the sensor while the lamp is on.
[3] Flush circuit button
Press this button to ush the electrolyzed water circuit. The red lamp
ashes while the circuit is being ushed.
[4] Flush cell button
Press this button to ush the electrolytic cell. The red lamp ashes
while the cell is being ushed.
[5] Sensor lamp (blue)
Illuminates when the sensor detects a hand or object.
[6] Set button
Use this button to make various settings.
[7] Up/down button
Adjusts settings and present time.
[d] ACCESSORIES
Instruction manual 1 Nozzle hose 1
Installation manual 1 Shower nozzle 1
Measuring cup 1 Straight nozzle 1
Elbow 1 Reducing valve [0.15MPa] 1
Bracket B 1 Connection hose assembly 1
Nipple 2 Tube [4mmDIA x 6mmDIA x 2m] 2
Cap 1 Gasket 1
Salt water tank 1 O-ring [for shower nozzle] 1
Anchor bolt 4 pH test paper TB 1
Wood screw 4 Chlorine test paper 1
Suction hook 2 Rubber dropper 1
Dual check valve 1
3. CHECKS BEFORE OPERATION
[a] CHECKING AND SUPPLYING SALT WATER
IMPORTANT
Use sodium chloride (NaCl) or potassium chloride (KCl) with
more than 99% purity. Any other kind of salt may cause failure,
clogged pipes, or health problems.
1) Check the salt level in the salt water tank (accessory). If it is low,
follow steps 2) to 6) below.
2) Pull out the salt water hose, and put it into a plastic bucket. Uncap
the salt water tank.
[1] [2]
[3] [4] [5] [6] [7]
[b] OPERATION PANEL
Salt Water Hose
[1] Flush lamp (red)
The electrolytic cell and cleaning water circuit are being ushed while
this lamp is on. Starts ashing 5 minutes before ush cycle begins.
[2] Error lamp (red)
Flashes or illuminates in case of trouble.
[3] Add salt water lamp (red)
Flashes or illuminates when the salt water tank is running out of salt
water.
Flash: The electrolyzed water performance is insu󰀩cient. The unit is
going to stop due to the lack of salt water.
Illuminate: The electrolyzed water performance is insu󰀩cient. The unit
stops due to the lack of salt water.
[4] Reset button
After adding salt water in the salt water tank, press this button. The
add salt water lamp starts ashing, and salt water is supplied to the
unit.
[5] Flow rate select button
Adjusts the ow rate. The lamp of selected ow rate (HI or LO) comes
on.
HI: For utensils, LO: For foods
[6] Dispense button
Press this button to start or stop dispensing sanitizing water (default
setting: continuous dispensing mode).
[7] Display
Normally indicates present time. Also indicates the cell run time,
current, voltage, and error code in case of trouble.
[8] Ready lamp (blue)
Flashes or illuminates when electrolysis starts. See “5. DISPENSING”.
Flash: The electrolyzed water performance is insu󰀩cient.
Illuminate:The electrolyzed water performance is su󰀩cient.
[c] CONTROL PANEL
3) Use the measuring cup (accessory) to add two cups of salt into the
salt water tank.
4) Add water into the salt water tank up to the 4 L line.
5) Recap the salt water tank. Shake it well until salt grains completely
dissolve in the water.
IMPORTANT
If any salt grains remain in the salt water tank, the electrolyzer
may not operate properly.

4
6) Push the salt water hose into the salt water tank all the way to the
marked position. Put the salt water tank back in position.
IMPORTANT
1. If the salt water hose comes o󰀨 easily, use the mini cap to
hold the hose as shown below.
2. Install the salt water tank at the lower level than the nozzle
end to prevent leakage caused by siphoning.
IMPORTANT
If the power switch is turned o󰀨 during a ush cycle, the unit
cannot ush properly and may cause a clogged circuit.
* When the flush lamp on the operation panel stops flashing and
illuminates constantly, the unit starts a ush cycle. Sanitizing water
will not be available for 10 minutes (depending on the water quality).
* During a ush cycle, water may drip from the nozzle.
[b] ATTACHING NOZZLE (ACCESSORY)
The two types of nozzle (accessory) are available: straight nozzle and
shower nozzle. Choose according to your need.
Marked positionSalt Water Hose
Hold salt water
hose in position
①
②
③
Remove Straight nozzle (1) Straight nozzle
+
(2) O-ring
+
(3) Shower nozzle
✚
2 cups Shake well
4. START UP
1) Plug in the unit.
2) Turn on the power switch (earth leakage circuit breaker).
Note: A mechanical sound is heard three times immediately after the
power switch is turned on. This is not a sign of failure (initial
operation).
5. DISPENSING
The following two dispensing modes are available.
Continuous dispensing mode
Once the dispensing action is started, the unit dispenses electrolyzed
water continuously.
Portion control mode
The unit dispenses electrolyzed water for a preset time. The
dispensing time is adjustable from 5 to 1800 seconds (default setting:
15 seconds). The display shows countdown during dispensing action.
1) To dispense sanitizing water, press the dispense button or hold a
hand over the dispensing sensor.
Default setting - Dispense button: continuous dispensing mode
Dispensing sensor: portion control mode
The ready lamp stops ashing and stays on.
2) To stop dispensing sanitizing water, press the dispense button or
hold a hand over the dispensing sensor. The ready lamp goes o󰀨.
[a] WHEN FLUSH LAMP FLASHES
The flush lamp on the operation panel may flash while the unit is
dispensing water. This means sanitizing water has been dispensed
for 60 minutes in total and the unit is ready to start an automatic ush
cycle for the water circuit and electrolytic cell. If the dispensing action
is stopped right away or continued for 5 minutes after the ush lamp
starts ashing, the unit begins an automatic ush cycle.
6. ADJUSTMENT
[a] DISPENSING SENSOR
The dispensing sensor located at the bottom of the front panel
enables dispensing action by sensor detection.
1) To enable the dispensing sensor, press the sensor button on the
control panel. The sensor lamp comes on.
2) To disable the dispensing sensor, press the sensor button again.
The sensor lamp goes o󰀨.
[b] PRESENT TIME
1) To adjust the present time, press and hold the display select button
on the control panel until the display ashes the year.
2) Use the up/down button on the control panel to adjust the year [e.g.
“2011”].
3) Press the display select button. The display ashes the month.
4) Use the up/down button to adjust the month [e.g. “03.20” (March
20)].
5) Press the display select button. The display ashes the day.
6) Use the up/down button to adjust the day [e.g. “03.20” (March 20)].
7) Press the set button on the control panel. The display shows the
time.
8) Use the up/down button to adjust the time [e.g. “11.22” (11:22)].
The setting is stored after 3 seconds. The time is always adjustable
only by using the up/down button.
[c] CHECKING AND ADJUSTING CURRENT
The current of sanitizing water can be checked and adjusted. The pH
and available chlorine concentration are adjustable by changing the
electrolytic current.
* The electrolytic current is factory adjusted to 13A.
* Adjust the electrolytic current only when the raw water quality
causes the pH or available chlorine concentration go outside the
specied range.

5
1) To adjust the current, press and hold the set button on the control
panel until the display shows “Adj.”.
2) Press the set button. The display shows the latest adjustment
number “A - -”.
3) Use the up/down button on the control panel to indicate “A1” in the
display.
4) Press the set button. The display shows “13.0” (13.0A).
5) Use the up/down button to indicate the desired current in the
display [e.g. “15.0” for 15.0A].
6) Press the set button. The display shows the selected current [e.g.
“15.0”], then “A1”.
7) Press the up and down buttons at the same time. The display
shows “Adj.”.
8) Again, press the up and down buttons at the same time. The
display shows the present time.
[d] PORTION CONTROL DISPENSING TIME
The dispensing time in portion control mode is adjustable as follows
(default setting: 15 seconds).
1) Press and hold the set button on the control panel until the display
shows “Adj.”.
2) Press the set button. The display shows the latest adjustment
number “A - -”.
3) Use the up/down button on the control panel to indicate “A3” in the
display.
4) Press the set button. The display shows “15” (15 seconds).
5) Use the up/down button to indicate the desired dispensing time in
the display [e.g. “30” for 30 seconds].
6) Press the set button. The display shows the selected dispensing
time [e.g. “30.0”], then “A3”.
7) Press the up and down buttons at the same time. The display
shows “Adj.”.
8) Again, press the up and down buttons at the same time. The
display shows the present time.
[e] AUTOMATIC FLUSH CYCLE START TIME
The time to start automatic flush cycle for the water circuit and
electrolytic cell is adjustable.
When the flush lamp comes on, the unit starts flushing the water
circuit rst, then the electrolytic cell.
The present time should be adjusted before setting the automatic
ush cycle start time.
Note: The default setting is 0:00.
The automatic ush cycle takes about 10 minutes, depending
on water quality. Set the start time so that the ush cycle can
begin and end while no dispensing action is required.
No sanitizing water is available during the automatic ush cycle.
1) Press and hold the set button on the control panel until the display
shows “Adj.”.
2) Press the set button. The display shows the latest adjustment
number“A - -”.
3) Use the up/down button on the control panel to indicate “A8” in the
display.
4) Press the set button. The display shows “0.00” (0:00).
5) Use the up/down button to indicate the desired start time in the
display [e.g. “02.30” for 2:30 am].
6) Press the set button. The display shows the selected start time [e.g.
“02.30”], then “A8”.
7) Press the up and down buttons at the same time. The display
shows “Adj.”.
8) Again, press the up and down buttons at the same time. The
display shows the present time.
7. SHUT DOWN
It is not necessary to shut down the unit every day. Just press the
dispense button to stop dispensing electrolyzed water.
IMPORTANT
The unit starts automatic ush cycle at the preset time (see “6.
[e] AUTOMATIC FLUSH CYCLE START TIME”).
To start the ush cycle properly and prevent clogging the pipes:
* Do not turn o󰀨 the power switch.
* Do not close the water supply valve.
To ensure proper drainage from the sink and prevent overow:
* Do not close the drain valve for the sink.
8. PREPARING ELECTROLYZER FOR LONG STORAGE
[a] MORE THAN TWO DAYS
CAUTION
When shutting down the electrolyzer for more than two days,
drain out the unit to prevent foul water from causing bacterial
growth and health problems.
Purge the water circuit to prevent possible freeze-up.
1) Turn o󰀨 the power switch (earth leakage circuit breaker).
2) Unplug the unit or turn o󰀨 the main power supply.
3) Close the water supply line shut-o󰀨 valve and water supply valve.
Note: The water supply valve must be closed to prevent possible
water leaks in case of failure.
Each installation may have di󰀨erent water supply connections.
Locate the shut-o󰀨 valve, water supply valve and drain valve in
your site.
[b] MORE THAN A MONTH
WARNING
When shutting down the electrolyzer for more than a month,
turn o󰀨 the power switch (earth leakage circuit breaker), and
unplug the unit to prevent electric leak, heat generation, or
ignition.
1) Follow “[a] MORE THAN TWO DAYS” to shut down the unit.
2) Follow “9. MAINTENANCE” to clean the exterior and stainless steel
parts
3) Fill the salt water tank with tap water only. Follow “11. PURGING
SALT WATER PUMP” to purge the salt water pump and salt water
hose.
IMPORTANT
Be sure to drain salt water to prevent the salt water hose from
clogging with crystallized salt, resulting in failure.

6
9. MAINTENANCE
[a] EXTERIOR (AS REQUIRED)
The exterior is easily contaminated. Keep it clean.
Note: The exterior surface is painted. Do not use a commercial
stainless steel cleaner.
To prevent deformation or cracking, do not spray insecticide on
the plastic parts or allow them to contact oily materials.
1) Wipe the exterior with a cloth containing warm water and a neutral
cleaner.
2) Wipe clean with a damp cloth.
[b] STAINLESS STEEL (AS REQUIRED)
The stainless steel parts are easily damaged. Clean them as follows:
1) Wipe with a soft cloth containing a calcium chloride based liquid
cleanser, tap water, and cleaning water.
2) Wipe clean with a damp cloth.
IMPORTANT
1. Do not damage the stainless steel surfaces. Use of a
steal brush or steel wool may break oxide film to develop
corrosion inside.
2. Use a calcium chloride based liquid cleanser to remove
corrosion, dirt, and chlorides.
3. Clean the stainless steel surfaces along with their grains if
any.
10. INSPECTION
Use a copy of “15. DAILY INSPECTION SHEET” to keep records.
[a] pH, AVAILABLE CHLORINE CONCENTRATION (DAILY)
1) Sample sanitizing water from the nozzle into a container.
2) Use the pH and chlorine test papers to check that each value is
within the following range.
Water Test Paper pH Available Chlorine
Sanitizing pH test paper TB Acidic range —
Chlorine test paper — 20 mg/kg (ppm) or more
Note: See the instruction manual of each test paper for details of its
proper handling.
If any of the checked values exceeds the specified range,
contact an authorized Hoshizaki service company.
If water is not dispensed from its proper outlet, contact an
authorized Hoshizaki service company.
[b] SALT WATER LEVEL (DAILY)
Check the salt water level in the salt water tank (accessory) according
to “3. [a] CHECKING AND SUPPLYING SALT WATER”.
[c] CELL RUN TIME, CURRENT, VOLTAGE (DAILY)
Check the present time, cell run time, current, and voltage. Press
the display select button on the control panel until the desired item
appears in the display.
[d] WATER LEAKS (DAILY)
Check the unit and surrounding oor for water leaks. If any is found,
contact an authorized Hoshizaki service company.
[e] EARTH LEAKAGE CIRCUIT BREAKER (MONTHLY)
WARNING
Check the earth leakage circuit breaker for proper operation
once a month. If it is left inoperable, it could increase the risk of
electric shock in case of electric leak.
1) Press the test button of the power switch (earth
leakage circuit breaker).
2) Check that the switch turns off. If not,
immediately contact an authorized Hoshizaki
service company.
[f]
POWER CORD, EARTH WIRE, ATTACHMENT PLUG (ANNUALLY/
BIANNUALLY)
WARNING
Check periodically that the attachment plug blades and their
vicinity are free of dust and that the attachment plug is securely
plugged into the receptacle. Dusty blades or loose connection
may cause electric shock or re.
* Check for the following problems:
Problem Remedy
The earth wire is broken or loosely
connected.
Ask an authorized Hoshizaki
service company or licensed
electrician for repair.
The attachment plug or power cord is
too hot, damaged, weighed down, or
caught in.
Immediately ask an
authorized Hoshizaki service
company for repair.
The attachment plug blades, their
vicinity, and receptacle are dusty.
Clean.
The attachment plug is plugged into a
single receptacle with other equipment.
Plug into a separate
receptacle.
The unit shares a single power supply
with other equipment.
Use a separate power supply.
[g] CONSUMABLE/PERIODIC REPLACEMENT PARTS
Consumable parts:
pH test paper TB
Chlorine test paper
Periodic replacement parts:
Electrolytic cell (1000 hours including ush cycle time)
11. PURGING SALT WATER PUMP
This unit uses a pump to supply salt water. If the salt water pump
contains air, electrolyzed water cannot be dispensed properly. When
the add salt water lamp on the operation panel comes on and salt
water tank is relled, purge air from the salt water pump as follows:
1) Check that the salt water tank (accessory) is lled with salt water.
2) Check that the power switch (earth leakage circuit breaker) is on. If
not, turn it on.
3) Press and hold the reset button on the control panel until the add
salt water lamp flashes. After 90 seconds, the salt water pump
starts running and pumping up salt water to purge the salt water
hose.
Test Button
OFF

7
4) When the salt water pump has been purged, the pump stops, water
stops coming out of the nozzle, and the add salt water lamp goes
o󰀨.
12. BEFORE CALLING A SERVICE AGENT
If something seems wrong with the unit, check for possible causes
according to the following instructions.
If the problem still exists, turn off the power switch (earth leakage
circuit breaker), unplug the unit, and contact an authorized Hoshizaki
service company.
Only qualied personnel may repair the unit. Do not attempt to repair
it yourself.
[a] OPERATIONAL PROBLEMS
Problem Possible Cause Remedy
Abnormal
noise
Operating sounds
(water supply,
pump)
No problem.
Unstable
installation
Adjust installation.
Contact with other
objects
Keep them away from the unit.
Electrolyzed
water is not
available
Power failure Wait until power is resumed.
Unplugged Plug in.
Power switch
(earth leakage
circuit breaker) or
operation panel is
o󰀨
Turn on power switch. If it turns
o󰀨 automatically, there is a risk of
electric leak. Contact an authorized
Hoshizaki service company.
Add salt water
lamp (red) is on
Add salt water to the salt water
tank. See "3. [a] CHECKING AND
SUPPLYING SALT WATER".
Purge the salt water pump. See "11.
PURGING SALT WATER PUMP".
Wet oor Water leaks Contact an authorized Hoshizaki
service company.
[b] WHEN ERROR LAMP COMES ON OR FLASHES
When the error lamp (red) on the operation panel comes on or
ashes, check the error code in the display.
Lamp Code Problem Possible Cause Remedy
Flash E11 Inadequate
water
supply
Water failure Restart the unit after water
supply is resumed.
Water supply
valve is closed
Open.
* After the problem is resolved, press the ON/OFF switch on the
operation panel. The error lamp goes o󰀨. Press the ON/OFF switch
again to resume operation.
Lamp Code Problem Remedy
On E22 Water circuit clogged with
scale
Follow the steps below to
ush the water circuit.
* When the error lamp comes on, the display shows “E22”, and the
ush circuit lamp on the control panel ashes, manually ush the
water circuit.
Note: The manual water circuit flush cycle takes about 3 minutes,
depending on water quality.
No sanitizing water is available during the manual ush cycle.
1) Press and hold the ush circuit button on the control panel until the
ush circuit lamp on the control panel and the ush lamp on the
operation panel come on. The unit starts ushing the water circuit.
2) When the water circuit has been ushed, the ush lamp and ush
circuit lamp go o󰀨.
3) If the display shows “E22” again after operation is resumed, contact
an authorized Hoshizaki service company.
Lamp Code Problem Remedy
On E23 Electrolytic cell clogged
with scale
Follow the steps below to
ush the electrolytic cell.
* When the error lamp comes on, the display shows “E23”, and the
flush cell lamp on the control panel flashes, manually flush the
electrolytic cell.
Note: The manual electrolytic cell ush cycle takes about 10 minutes,
depending on water quality.
No sanitizing water is available during the manual ush cycle.
1) Press and hold the ush cell button on the control panel until the
flush cell lamp on the control panel and the flush lamp on the
operation panel come on. The unit starts ushing the electrolytic
cell.
2) When the electrolytic cell has been flushed, the flush lamp and
ush cell lamp go o󰀨.
3) If the display shows “E23” again after operation is resumed, contact
an authorized Hoshizaki service company.
When one of the following error codes appears, immediately contact
an authorized Hoshizaki service company.
Lamp Code Problem Possible Cause Remedy
Flash E13 Nozzle hose defective
Repair or replacement is
required.
Contact an authorized
Hoshizaki service
company.
E14 Water valve defective
E21 Electrolytic cell replacement
E53 Reversing relay defective
On E12 Flow control valve defective
E74 Thermistor defective
O󰀨 EE1 Control board defective
EF0
EF1
13. WARRANTY
Hoshizaki warrants to the original owner/user that all Hoshizaki
branded products shall be free of defects in material and/or
workmanship for the duration of the “warranty period”. The warranty
shall be e󰀨ective for one year from the date of installation.
Hoshizaki’s liability under the terms of the warranty are limited and
shall exclude routine servicing, cleaning, essential maintenance and/
or repairs occasioned by misuse and installations not in accordance
with Hoshizaki guidelines.
Warranty repairs should be completed by an approved Hoshizaki
dealer or service agency using genuine Hoshizaki components.
To obtain full details of your warranty and approved service agency,
please contact:
e-Water Systems Pty Ltd
TEL : 1300 EWATER
FAX : [phone]

8
14. SPECIFICATIONS
Model WOX-40WA-EW
Electrolysis System Membrane technology
Electrolyte Salt containing at least 99% sodium chloride
Power Supply 1 phase 220 - 240V, 50 - 60Hz
Electric Consumption 170W / 170W
Performance
(Standard) *
Sanitizing water: pH5.0 or less, available
chlorine 5 - 60mg/kg
Production Rate
(Standard) *
Sanitizing water: 4.0 L/min or less
Exterior ABS plastic
Dimensions Body: 285mm(W) x 145mm(D) x 335mm(H)
Weight 7kg (10kg)
Temperature Range Ambient: 5 - 35°C
Water supply: 5 - 30°C
Water Supply Comply with local water requirements
Pressure: 0.10 - 0.75MPa (with pressure
reducing valve)
* Reference
Production Rate Setting Hi Lo
Production Rate (L/min) 4.0 2.0
pH 3.0 3.0
Available Chlorine (mg/kg) 20 40

9
15. DAILY INSPECTION SHEET
Make copies of this page.
Date
Time
pH Sanitizing water
Sanitizing water available
chlorine concentration
Salt level
Water leaks around unit
Drain [drain outlet (right)]
Cell run time
Current (A)
Voltage (V)
Checked by
Date
Time
pH Sanitizing water
Sanitizing water available
chlorine concentration
Salt level
Water leaks around unit
Drain [drain outlet (right)]
Cell run time
Current (A)
Voltage (V)
Checked by
Date
Time
pH Sanitizing water
Sanitizing water available
chlorine concentration
Salt level
Water leaks around unit
Drain [drain outlet (right)]
Cell run time
Current (A)
Voltage (V)
Checked by
