Host Liberator User manual

HOST®System Instruction Manual

Table of Contents
Getting Started
Plugging Machine into Electrical Outlet . . . . . . . . . . . . .3
Removing from Caddy . . . . . . . . . . . . . . . . . . . . . . . . . .3
How to Clean Carpet
Vacuuming & Pile Lifting . . . . . . . . . . . . . . . . . . . . . . . .4
Before Applying HOST Dry Carpet Cleaner . . . . . . . . .4
Filling the Applicator . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Replacing Lid on Bucket . . . . . . . . . . . . . . . . . . . . . . . .4
Applying with the Applicator . . . . . . . . . . . . . . . . . . . . . .5
Applying by Hand . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Brushing with the Liberator® . . . . . . . . . . . . . . . . . . . . .5
Removing HOST Dry Carpet Cleaner . . . . . . . . . . . . . .6
Emptying the Bagless Hopper . . . . . . . . . . . . . . . . . . . .6
Cleaning Very Dirty Carpet . . . . . . . . . . . . . . . . . . . . . .6
How to Remove Spots & Spills
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Brushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Vacuuming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Removing Spots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Upkeep & Clean-Up
Cleaning the Filters & Vacuum Cone . . . . . . . . . . . . . .9
Cleaning the Motor Vents & Filter . . . . . . . . . . . . . . . . .9
Checking the Hose for Clogs . . . . . . . . . . . . . . . . . . . .10
Cleaning & Rotating Brushes . . . . . . . . . . . . . . . . . . .10
Cleaning the Vacuum Shoe & Brush Guard . . . . . . . .10
Getting Started
Plugging Machine into Electrical Outlet . . . . . . . . . . . .11
Removing from Caddy . . . . . . . . . . . . . . . . . . . . . . . . .11
How to Clean Carpet
Vacuuming & Pile Lifting . . . . . . . . . . . . . . . . . . . . . . .12
Before Applying HOST Dry Carpet Cleaner . . . . . . . .12
Filling the Applicator . . . . . . . . . . . . . . . . . . . . . . . . . .13
Replacing Lid on Bucket . . . . . . . . . . . . . . . . . . . . . . .13
Applying with the Applicator . . . . . . . . . . . . . . . . . . . . .13
Applying by Hand . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Brushing with the Freestyle® . . . . . . . . . . . . . . . . . . . .14
Removing HOST Dry Carpet Cleaner . . . . . . . . . . . . .14
Cleaning Carpeted Stairs . . . . . . . . . . . . . . . . . . . . . .14
Emptying the Bagless Hopper . . . . . . . . . . . . . . . . . . .15
Cleaning Very Dirty Carpet . . . . . . . . . . . . . . . . . . . . .15
How to Remove Spots & Spills
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Brushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Vacuuming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Removing Spots . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Upkeep & Clean-Up
Cleaning the Filters & Vacuum Cone . . . . . . . . . . . . .18
Checking the Hose for Clogs . . . . . . . . . . . . . . . . . . . .18
Cleaning & Rotating Brushes . . . . . . . . . . . . . . . . . . .19
Cleaning the Vacuum Shoe & Brush Guard . . . . . . . .19
Cleaning the Motor Vents & Filter . . . . . . . . . . . . . . . .19
Getting Started
Plugging Machine into Electrical Outlet . . . . . . . . . . . .20
Removing from Caddy . . . . . . . . . . . . . . . . . . . . . . . . .20
How to Clean Carpet
Vacuuming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Before Applying HOST Dry Carpet Cleaner . . . . . . . .21
Filling the Applicator . . . . . . . . . . . . . . . . . . . . . . . . . .21
Replacing Lid on Bucket . . . . . . . . . . . . . . . . . . . . . . .21
Applying with the Applicator . . . . . . . . . . . . . . . . . . . . .22
Applying by Hand . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Brushing with the Reliant® . . . . . . . . . . . . . . . . . . . . . .22
Removing HOST Dry Carpet Cleaner . . . . . . . . . . . . .23
Cleaning Carpeted Stairs . . . . . . . . . . . . . . . . . . . . . .23
Cleaning Very Dirty Carpet . . . . . . . . . . . . . . . . . . . . .23
How to Remove Spots & Spills
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Brushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Vacuuming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Removing Spots . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Upkeep & Clean-Up
Cleaning the Motor Vents . . . . . . . . . . . . . . . . . . . . . .26
Cleaning & Rotating Brushes . . . . . . . . . . . . . . . . . . .26

3
The HOST® System
How to Get the Best Results
Using the HOST Liberator®
Be sure to read separate Safety & Maintenance
Instructions before using.
Plugging Liberator into Electrical Outlet
Plug the Liberator power cord into electrical outlet.
Do not use an extension cord.
Removing Liberator from Caddy
Lock Liberator handle in position by pointing red
arrowhead down. ote that there are 2 handle locks,
one on each side of machine.
Unlock locking bolts on front of caddy.
Blue/unlocked
Red/locked
Handle locking knob
Locking
bolts
Getting Started
1
a
b
Locate the switch control panel
on the back of the Liberator. Turn
on machine brushes by pressing
the black switch and drive the
Liberator off the caddy.
c
Black brush
switch
White vacuum
switch
Filter light
2

Vacuuming & Pile Lifting
Turn both ma hine brushes and va uum swit hes ON.
4
How to Clean Carpet with the Liberator
Lawnmower Vacuuming
Vacuum in 2 directions.
Before Applying HOST Dry Carpet Cleaner
Place bucket on its side for 10 minutes. This will help
to distribute the liquid ingredients evenly throughout
the cleaner.
CAUTION: onhazardous per OSHA and EU standards when used as directed. ontoxic via
ingestion, inhalation or skin absorption. ot a sensitizer. ot a skin or eye irritant. However,
persons with unusual skin sensitivity should protect skin from direct contact. In case of contact
with eyes, rinse with water to remove any particles. Improper use may contribute to increased
risk of health effects. OT A WHMIS CO TROL PRODUCT.
Replacing Lid on Bucket
Be sure to wipe off the edge of bucket before replacing the lid.
This will prevent leaking.
1
Vacuum the area with the Liberator in 2 directions:
north/south and east/west. The more vacuuming
the better to remove as much dry dirt as possible.
a
In hallways and open areas,
vacuum lawnmower style in
2 directions: north/south
and east/west.
b
2
Filling the Applicator
Fill the Applicator with up to 12 pounds (5.4 kilos)
of HOST. Do not overfill!
3
4
Fill here
Hole cover
Fill port cover
Note: Standard (white) and firm (zebra) brushes must be broken in before using for the first time.
To break in brushes, run the Liberator on smooth concrete surface for 15 minutes.
Visit www.hostdry.com to
view Instructional Videos.
Tip

5
How to Clean Carpet with the Liberator
Applying with the Applicator
Open hole covers for HOST application.
Choose:
• Light (1 cover open)
• Medium (2 covers open)
• Heavy (3 covers open)
Walk the Applicator over the area of dirty
carpet. DO OT apply to an area larger than
10 feet x 50 feet (approx. 50 sq. meters).
Keep Applicator 1 foot away from wall.
5
a
bc
a
b
1 Foot
Applying by Hand
Apply a handful of HOST to each square yard
(or square meter) of dirty carpet.
Do not apply to an area larger than 10 feet by 10 feet
(approx. 10 sq. meters) to keep HOST from drying out.
Begin brushing as soon as you have finished applying.
6
Brushing with the Liberator
Make sure the white va uum swit h is OFF.
Make three passes over the area. Use push-pull strokes just like when you vacuum.
2nd Pass1st Pass 3rd Pass
7
It is not necessary to apply HOST
next to the wall or to areas which
do not appear dirty. Apply only to
dirty areas of the carpet.
Path of Applicator
Dirty Area of Carpet

6
Vacuuming
Turn both ma hine brushes and va uum swit hes ON.
Vacuum the area you have just finished brushing in
2 directions: north/south and east/west.
Continue to vacuum in 2 directions until all visible
HOST is recovered.
The Liberator vacuums best if HOST is a bit damp.
If Carpet is Still Dirty
If carpet is still dirty, reapply HOST and brush again.
Vacuum in 2 directions.
For Very Dirty Carpet
If carpet is very dirty, PREP®Traffic Lane Booster may
be necessary.
To use PREP:
Mix 1 part PREP in 4 parts water
in a trigger spray bottle.
Mist PREP lightly on dirty carpet.
Apply HOST Dry Carpet Cleaner as before.
Brush with the Liberator.
Vacuum.
CAUTION: Improper use or dilution may cause damage to surfaces and increased risk of health effects.
Pre-Clean is
ready-to-use PREP.
How to Clean Carpet with the Liberator
8
a
b
c
d
e
Tip
Tip
Emptying the Bagless Hopper
Empty the bagless hopper often to avoid logging filters.
Pull out the hopper.
Empty into trash container.
Replace the hopper and insure that it is completely
closed to avoid vacuum power loss.
DISPOSAL INSTRUCTIONS: Wastes resulting from the use
of this product may be disposed of on site. Please recycle
empty plastic buckets and lids.
9
a
b
c

7
Preparation
For dry spots and spills, vacuum area first.
For wet spots and spills, blot or scrape up
area first.
Scatter HOST on the spot.
How to Remove Spots & Spills with the Liberator
1
Brushing
Concentrate the brushing over the spot.
Brush in a circle over the spot.
Brush an area slightly larger than the area
with the spot.
2
Removing HOST Dry
Carpet Cleaner
After brushing, vacuum up the HOST with
the Liberator.
3
a
b
a
b
c

8
Removing Spots with HOST PREP
For tough spots and spills, PREP Traffic Lane Booster may be necessary.
Lightly mist diluted PREP
on the spot.
Apply HOST to the area.
Brush again.
Vacuum up the HOST.
How to Remove Spots & Spills with the Liberator
a
b
c
d
Tip
Tip
Pre-Clean is
ready-to-use PREP.
Removing Spots with the HOST spot APPER®
Spots can also be removed using the HOST spotZAPPER:
1. Apply HOST Dry Carpet Cleaner.
3. The more brushing, the better.
2. Brush in many directions.
4. After brushing, let dry and
then vacuum.

9
Upkeep & Clean-up of the Liberator
Cleaning the Filters & Vacuum Cone
Turn Liberator off. Unlatch filter
housing and swing to the side.
Use a tank vacuum to vacuum both sides of the
black and burnt orange primary filters.
Remove the separator assembly
and wipe the inside with a cloth.
Replace the separator assembly
and push down firmly for a tight
seal.
Flip the filter housing over and vacuum both sides
of the 3-piece filters and replace. Refer to separate
Safety & Maintenance Instructions for HEPA filter
care.
Replace the burnt orange filter,
then the black filter. Close the filter
housing and close the latches.
Black
Burnt orange
a b
e
c d
1
Screws
Screws
Vacuum vents
Remove and
clean foam filter
2
Note: If you are cleaning
where IAQ is a concern
(i.e. healthcare facility),
clean filters elsewhere.
Cleaning the Motor Vents & Filter
Vacuum motor vents with the Liberator
hose after each use.
Remove the Velcro®skirt and screws
from side and back cover plates.
ab
Remove foam motor filter and
vacuum.
c

10
Upkeep & Clean-up of the Liberator
Checking the Hose for Clogs
Unplug the vacuum hose and check for any buildup of HOST or dirt.
If buildup exists, plug straight end of the vacuum hose into the vacuum connection.
With the vacuum motor on, loosen buildup from hose elbow.
3
4Cleaning & Rotating Brushes
Clean and rotate brushes each time you clean out the Liberator. The brush bristles
acquire a “set” in the direction they revolve unless switched regularly.
Unplug ma hine from power.
Remove the Velcro skirt.
Turn lock on brush cover plate
1/4 turn counter-clockwise until
it pops out. Pull up on ring to
remove brush cover plate.
Remove brushes and clean out
underside of machine.
Replace brushes on opposite hex brush shafts.
Liberator brushes can also be switched end-to-
end if desired.
Replace brush side plate. Press brush guard
against brushes while replacing side plate.
If brush plate does not engage, rotate hex shaft
slightly until brush side plate slips in place.
Lock the lock on side plate and replace Velcro skirt.
ad
e
f
g
b
c
Cleaning the Vacuum Shoe & Brush Guard
Remove lint and fuzz from the
vacuum shoe and brush guard.
5
Vacuum shoe
Brush guard
a
b
c

Removing Freestyle from Caddy
Unlock locking bolt on front of caddy.
Locate the brush motor switch on the back side of the
Freestyle base and turn machine brushes on.
Drive the Freestyle off the caddy.
a
b
c
2
Locking bolt
Caddy
11
Getting Started
The HOST® System
How to Get the Best Results
Using the HOST Freestyle®
Be sure to read separate Safety & Maintenance
Instructions before using.
1
Plugging Freestyle into Electrical Outlet
Plug the Freestyle power cord into electrical outlet.
Do not use an extension cord.

12
Vacuuming & Pile Lifting
Turn both ma hine brushes and va uum swit hes ON.
How to Clean Carpet with the Freestyle
1
2
Note: Standard (white) and firm (zebra) brushes must be broken in before using for the first time.
To break in brushes, run the Freestyle on smooth concrete surface for 15 minutes.
Before Applying HOST Dry Carpet Cleaner
Place bucket on its side for 10 minutes. This will help
to distribute the liquid ingredients evenly throughout
the cleaner.
CAUTION: onhazardous per OSHA and EU standards when used as directed. ontoxic via
ingestion, inhalation or skin absorption. ot a sensitizer. ot a skin or eye irritant. However,
persons with unusual skin sensitivity should protect skin from direct contact. In case of contact
with eyes, rinse with water to remove any particles. Improper use may contribute to increased
risk of health effects. OT A WHMIS CO TROL PRODUCT.
Vacuum in 2 directions.
Vacuum the area with the Liberator in
2 directions: north/south and east/west.
The more vacuuming the better to
remove as much dry dirt as possible.
a
To vacuum under a table or desk:
1. Unlock handle.
2. Tilt handle back and vacuum.
c
b
Lawnmower Vacuuming
In hallways and open areas, vacuum
lawnmower style in 2 directions:
north/south and east/west.
Visit www.hostdry.com to
view Instructional Videos.
Tip

13
How to Clean Carpet with the Freestyle
Replacing Lid on Bucket
Be sure to wipe off the edge of bucket before replacing the lid.
This will prevent leaking.
Filling the Applicator
Fill the Applicator with up to 12 pounds (5.4 kilos)
of HOST. Do not overfill!
3
4
Fill here
Hole cover
Fill port cover
Applying with the Applicator
Open hole covers for HOST application.
Choose:
• Light (1 cover open)
• Medium (2 covers open)
• Heavy (3 covers open)
Walk the Applicator over the area of dirty
carpet. DO OT apply to an area larger than
10 feet x 50 feet (approx. 50 sq. meters).
Keep Applicator 1 foot away from wall.
5
a
bc
1 Foot
It is not necessary to apply HOST
next to the wall or to areas which do
not appear dirty. Apply only to dirty
areas of the carpet.
Path of Applicator
Dirty Area of Carpet

14
a
b
a
b
c
Applying by Hand
Apply a handful of HOST to each square yard
(or square meter) of dirty carpet.
Do not apply to an area larger than 10 feet by 10 feet
(approx. 10 sq. meters) to keep HOST from drying out.
Begin brushing as soon as you have finished applying.
6
Brushing with the Freestyle
Make sure the white va uum swit h is OFF.
Make three passes over the area. Use push-pull strokes just like when you vacuum.
2nd Pass1st Pass 3rd Pass
7
How to Clean Carpet with the Freestyle
8
Cleaning Carpeted Stairs
Use the base of the Freestyle to clean carpeted stairs:
Remove the vacuum pod.
Remove the operating handle.
Use the base to clean stairs.
9
Unscrew handle
locking shaft
completely, lower
handle parallel to
floor and slide
handle out.
Lift and turn
handle release
knob 1/4 turn.
Vacuuming
Turn both ma hine brushes and va uum swit hes ON.
Vacuum the area you have just finished brushing in
2 directions: north/south and east/west.
Continue to vacuum in 2 directions until all visible
HOST is recovered.
The Freestyle vacuums best if HOST is a bit damp.
Vacuum in 2 directions.

15
If Carpet is Still Dirty
If carpet is still dirty, reapply HOST and brush again.
How to Clean Carpet with the Freestyle
Tip
Tip
10 Emptying the Bagless Hopper
Empty the bagless hopper often to avoid logging filters.
Pull out the hopper.
Empty into trash container.
Replace the hopper and insure that it is completely
closed to avoid vacuum power loss.
DISPOSAL INSTRUCTIONS: Wastes resulting from the use of this
product may be disposed of on site. Please recycle empty plastic
buckets and lids.
a
b
c
For Very Dirty Carpet
If carpet is very dirty, PREP®Traffic Lane Booster may be necessary.
To use PREP:
Mix 1 part PREP in 4 parts water
in a trigger spray bottle.
Mist PREP lightly on dirty carpet.
Apply HOST Dry Carpet Cleaner
as before.
Brush with the Freestyle.
Vacuum.
CAUTION: Improper use or dilution may cause damage to surfaces and increased risk of health effects.
Pre-Clean is
ready-to-use PREP.
a
b
c
d
e

16
How to Remove Spots & Spills with the Freestyle
1
Brushing
Concentrate the brushing over the spot.
Brush in a circle over the spot.
Brush an area slightly larger than the area
with the spot.
2
Removing HOST Dry
Carpet Cleaner
After brushing, vacuum up the HOST
with the Freestyle.
3
a
b
c
Preparation
For dry spots and spills, vacuum area first.
For wet spots and spills, blot or scrape up
area first.
Scatter HOST on the spot.
a
b

17
How to Remove Spots & Spills with the Freestyle
Removing Spots with HOST PREP
For tough spots and spills, PREP Traffic Lane Booster may be necessary.
Lightly mist diluted PREP
on the spot.
Apply HOST to the area.
Brush again.
Vacuum up the HOST.
a
b
c
d
Tip
Tip
Pre-Clean is
ready-to-use PREP.
Removing Spots with the HOST spot APPER®
Spots can also be removed using the HOST spotZAPPER:
1. Apply HOST Dry Carpet Cleaner.
3. The more brushing, the better.
2. Brush in many directions.
4. After brushing, let dry and
then vacuum.

18
Cleaning the Filters & Vacuum Cone
Turn Freestyle off. Unlatch filter
housing and swing to the side.
Use a tank vacuum to vacuum both sides of the
black and burnt orange primary filters.
Remove the separator assembly
and wipe the inside with a cloth.
Replace the separator assembly
and push down firmly for a tight
seal.
Note: If you are
cleaning where IAQ is
a concern (i.e.
healthcare facility),
clean filters elsewhere.
Flip the filter housing over and vacuum both sides
of the 3-piece filters and replace. Refer to separate
Safety & Maintenance Instructions for HEPA filter
care.
Replace the burnt orange filter,
then the black filter. Close the filter
housing and close the latches.
ab
e
cd
1
Upkeep & Clean-up of the Freestyle
2
Filter
housing
latches
Checking the Hose for Clogs
Unplug the vacuum hose and check for any buildup of HOST or dirt.
If buildup exists, plug straight end of the vacuum hose into the vacuum connection.
With the vacuum motor on, loosen buildup from hose elbow.
a
b
c

19
Upkeep & Clean-up of the Freestyle
3Cleaning & Rotating Brushes
Clean and rotate brushes each time you clean out the Freestyle. The brush bristles
acquire a “set” in the direction they revolve unless switched regularly.
Unplug ma hine from power.
Remove the Velcro skirt.
Press spring lock to release brush
guard/end cover.
Pull back on clip; lift out brushes.
Remove brushes and clean out
underside of machine.
Switch brushes to opposite drive
shafts. Brushes fit down over
shaft and engage on 3 pins near
bottom of shaft. Be sure brush
clip snaps into position.
Insert hinged bar of brush guard/end cover into
lower slot. Push all the way up, depress lock
button and slip brush guard into place.
Freestyle brushes can also be switched end-to-
end if desired. Remove screw holding brush clip
in place, reassemble at other end of brush and
replace.
ag
h
b
d
e
f
c
Cleaning the Vacuum Shoe
& Brush Guard
Remove lint and fuzz from the
vacuum shoe and brush guard.
4
Cleaning the Motor Vents & Filter
Remove the vacuum hose from machine base and
vacuum motor vents after each use.
5
Vacuum shoe
Brush guard

20
Getting Started
The HOST® System
How to Get the Best Results
Using the HOST Reliant®
Be sure to read separate Safety & Maintenance
Instructions before using.
Removing Reliant from Caddy
Unlock locking bolt on front of caddy.
Locate the brush motor switch on the back side of the
Reliant base and turn machine brushes on.
Drive the Reliant off the caddy.
a
b
c
2
Locking bolt
Caddy
1
Plugging Reliant into Electrical Outlet
Plug the Reliant power cord into electrical outlet.
Do not use an extension cord.
