Hotpoint Ariston ARL 105 User manual

GB
1
Contents
Installation, 2-3
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Description of the washing machine
and starting a wash cycle, 4-5
Control panel
Indicator lights
Starting a wash cycle
ash cycles, 6
Table of wash cycles
Personalisation, 7
Setting the temperature
Setting the spin speed
Functions
Detergents and laundry, 8
Detergent dispenser drawer
Bleach cycle
reparing the laundry
Garments requiring special care
Load balancing system
Precautions and tips, 9
General safety
Disposal
Opening the porthole door manually
Care and maintenance, 10
Cutting off the water or electricity supply
Cleaning the washing machine
Cleaning the detergent dispenser drawer
Caring for the door and drum of your appliance
Cleaning the pump
Checking the water inlet hose
Troubleshooting, 11
Service, 12
ARL 105
Instructions for use
ASHING MACHINE
English,1
GB CIS
Ðóññêèé,13
PT
Português,25
ÅËËÇÍÉÊÁ,37
GR HU
Magyar,49
DE
Deutsch,61

2
GB
Installation
 This instruction manual should be kept in a safe
place for future reference. If the washing machine is
sold, transferred or moved, make sure that the
instruction manual remains with the machine so that
the new owner is able to familiarise himself/herself
with its operation and features.
 Read these instructions carefully: they contain vital
information relating to the safe installation and
operation of the appliance.
Unpacking and levelling
Unpacking
1. Remove the washing machine from its packaging.
2. Make sure that the washing machine has not been
damaged during the transportation process. If it has
been damaged, contact the retailer and do not
proceed any further with the installation process.
3. Remove the 3
protective screws (used
during transportation) and
the rubber washer with
the corresponding
spacer, located on the
rear part of the appliance
(see figure).
4. Close off the holes using the plastic plugs provided.
5. Keep all the parts in a safe place: you will need
them again if the washing machine needs to be
moved to another location.
 ackaging materials should not be used as toys for
children.
Levelling
1. Install the washing machine on a flat sturdy floor,
without resting it up against walls, furniture cabinets
or anything else.
2. If the floor is not
perfectly level, compen-
sate for any unevenness
by tightening or loosening
the adjustable front feet
(see figure); the angle of
inclination, measured in
relation to the worktop,
must not exceed 2°.
Levelling the machine correctly will provide it with
stability, help to avoid vibrations and excessive noise
and prevent it from shifting while it is operating. If it is
placed on carpet or a rug, adjust the feet in such a
way as to allow a sufficient ventilation space
underneath the washing machine.
Connecting the electricity and water
supplies
Connecting the water inlet hose
1. Connect the supply
pipe by screwing it to a
cold water tab using a ¾
gas threaded connection
(see figure).
Before performing the
connection, allow the
water to run freely until it
is perfectly clear.
2. Connect the inlet hose
to the washing machine
by screwing it onto the
corresponding water inlet
of the appliance, which is
situated on the top right-
hand side of the rear part
of the appliance (see
figure).
3. Make sure that the hose is not folded over or bent.
 The water pressure at the tap must fall within the
values indicated in the Technical details table (see
next page).
 If the inlet hose is not long enough, contact a
specialised shop or an authorised technician.
 Never use second hand hose sets. Do not reuse
hose sets from any previously installed washing
machine.
 Use the ones supplied with the machine.

GB
3
Technical data
Model ARL 105
Dimensions
width 59.5 cm
height 85 cm
depth 52,5 cm
Capacity from 1 to 5 kg
Electrical
connections
please refer to the technical data
plate fixed to the machine
ater connections
maximum pressure 1 M a (10 bar)
minimum pressure 0.05 M a (0.5 bar)
drum capacity 46 litres
Spin speed up to 1000 rotations per minute
Energy rated
programmes
according to
regulation
EN 60456
programme 7; temperature 60°C;
using a load of 5 kg.
This appliance conforms to the
following EC Directives:
- 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility) and
subsequent modifications
- 2002/96/EC
- 2006/95/EC (Low Voltage)
65 - 100 cm
Connecting the drain hose
Connect the drain hose,
without bending it, to a
drainage duct or a wall
drain located at a height
between 65 and 100 cm
from the floor;
alternatively, rest it on
the side of a washbasin
or bathtub, fastening the
duct supplied to the tap
(see figure). The free end
of the hose should not
be underwater.
 We advise against the use of hose extensions; if it is
absolutely necessary, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Electrical connections
Before plugging the appliance into the electricity
socket, make sure that:
 the socket is earthed and complies with all
applicable laws;
 the socket is able to withstand the maximum power
load of the appliance as indicated in the Technical
data table (see opposite);
 the power supply voltage falls within the values
indicated in the Technical data table (see opposite);
 the socket is compatible with the plug of the
washing machine. If this is not the case, replace
the socket or the plug.
 The washing machine must not be installed
outdoors, even in covered areas. It is extremely
dangerous to leave the appliance exposed to rain,
storms and other weather conditions.
 When the washing machine has been installed, the
electricity socket must be within easy reach.
 Do not use extension cords or multiple sockets.
 The cable should not be bent or compressed.
 The power supply cable must only be replaced by
authorised technicians.
Warning! The company shall not be held responsible
in the event that these regulations are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, using the wash cycle 2.

4
GB
Detergent dispenser drawer: used to dispense
detergents and washing additives (see Detergents
and laundry).
There is a key which provides a summary of the
available wash cycles inside the detergent dispenser
drawer; this may be consulted at any time.
ON/OFF button: switches the washing machine on
and off.
ASH CYCLE knob: programmes the wash cycles.
During the wash cycle, the knob does not move.
FUNCTION buttons with indicator light: used to
select the available functions. The indicator light
corresponding to the selected function will remain lit.
TEMPERATURE knob: sets the temperature or the
cold wash cycle (see Personalisation).
SPIN SPEED knob: sets the spin speed or exclude
the spin cycle completely (see Personalisation).
ASH CYCLE PROGRESS/DELAY TIMER
indicator light s: used to monitor the progress of the
wash cycle.
The illuminated indicator light shows which phase is in
progress.
If the Delay Timer function has been set, the time
remaining until the wash cycle starts will be indicated
(see next page).
DOOR LOCKED indicator light: indicates whether
the door may be opened or not (see next page).
START/PAUSE button with indicator light: starts or
temporarily interrupts the wash cycles.
N.B. To pause the wash cycle in progress, press this
button; the corresponding indicator light will flash
orange, while the indicator light for the current wash
cycle phase will remain lit in a fixed manner. If the
DOOR LOCKED indicator light is switched off, the
door may be opened.
To start the wash cycle from the point at which it was
interrupted, press this button again.
Standby mode
This washing machine, in compliance with new
energy saving regulations, is fitted with an automatic
standby system which is enabled after about 30
minutes if no activity is detected. ress the ON-OFF
button briefly and wait for the machine to start up
again.
Description of the washing machine
and starting a wash cycle
TEMPERATURE
knob
Detergent dispenser drawer
ASH CYCLE PROGRESS/
DELAY TIMER
indicator lights
FUNCTION
buttons with
indicator lights
ON/OFF button
SPIN SPEED
knob
DOOR
LOCKED
indicator light
START/PAUSE
button with indicator
light
Control panel
ASH CYCLE
knob

GB
5
Indicator lights
The indicator lights provide important information.
This is what they can tell you:
Delayed start
If the DELAY TIMER function has been activated (see
Personalisation), after the wash cycle has been
started the indicator light corresponding to the
selected delay period will begin to flash:
As time passes, the remaining delay will be displayed
and the corresponding indicator light will flash:
Once the set delay has elapsed, the flashing indicator
light will switch off and the selected wash cycle will
begin.
ash cycle phase indicator lights
Once the desired wash cycle has been selected and has
begun, the indicator lights switch on one by one to
indicate which phase of the cycle is currently in progress.
Function buttons and corresponding indicator
lights
When a function is selected, the corresponding
indicator light will illuminate.
If the selected function is not compatible with the
programmed wash cycle, the corresponding indicator
light will flash and the function will not be activated.
If a function which is incompatible with another
function selected previously, only the most recent
selection will remain active.
Door locked indicator light
If this indicator light is on, the appliance door is locked
to prevent it from being opened accidentally; to avoid
any damage, wait for the indicator light to switch off
before you open the appliance door.
N.B. If the DELAY TIMER function is activated, the door
cannot be opened; pause the machine by pressing the
START/ AUSE button if you wish to open it.
 If the START/ AUSE indicator light (orange) flashes
rapidly at the same time as the function indicator
light, this indicates a problem has occurred (see
Troubleshooting).
Starting a wash cycle
1. Turn the washing machine on by pressing the ON/OFF button. All the indicator lights will turn on for a few
seconds, then only the indicator lights relative to the selected programme settings will remain lit and the START/
AUSE indicator light will flash.
2. Load the laundry and close the door.
3. Set the WASH CYCLE knob to the desired programme.
4. Set the washing temperature (see Personalisation).
5. Set the spin speed (see Personalisation).
6. Measure out the detergent and washing additives (see Detergents and laundry).
7. Select the desired functions.
8. Start the wash cycle by pressing the START/ AUSE button and the corresponding indicator light will remain lit
in a fixed manner, in green.
To cancel the set wash cycle, pause the machine by pressing the START/ AUSE button and select a new cycle.
9. At the end of the wash cycle the indicator light will switch on. The DOOR LOCKED indicator light will switch
off, indicating that the door may be opened. Take out your laundry and leave the appliance door ajar to make
sure the drum dries completely. Switch the washing machine off by pressing the ON/OFF button.
Wash
Rinse
Spin
Drain
End of wash cycle

6
GB
ash cycles
The information contained in the table is intended as a guide only.
For all Test Institutes:
1) Test wash cycle in co pliance with regulation EN 60456: set wash cycle 7 with a te perature of 60°C.
2) Long wash cycle for cottons: set wash cycle 2 with a te perature of 40°C.
3) Short wash cycle for cottons: set wash cycle 3 with a te perature of 40°C.
Wash cycles
Table of wash cycles
Description of the wash cycle
Max.
te p.
(°C)
Max.
speed
(rp )
Detergents Max.
load
(kg)
Cycle
duration
Bleach Wash Fabric
softener
Special cycles
7Sanitizing cycle 90°: Extremely soiled whites. 90° 1000 ll l 5165
7Sanitizing cycle 90° (1): Heavily soiled whites and resistant colours. 60° 1000 -ll 5 133
8Goodnigt cycle: Lightly soiled delicate colours. 40° 800 -ll 3288
9Baby cycle: Heavily soiled delicate colours. 40° 800 -ll 2 118
10 Shirts 40° 600 -ll 269
11 Silk/Curtains: For garments in silk and viscose, lingerie. 30° 0 -ll 155
12 Wool: For wool, cashmere, etc. 40° 600 -ll 155
Everyday wash cycles (Daily)
1Cotton + Prewash 90°: Extremely soiled whites. 90° 1000 -ll 5 155
2Cotton: Heavily soiled whites and resistant colours. 60° 1000 ll l 5 119
2Cotton (2): Heavily soiled whites and delicate colours. 40° 1000 ll l 5 115
3Coloured Cottons (3): Lightly soiled whites and delicate colours. 40° 1000 ll l 585
4Synthetics resistents: Heavily soiled resistant colours. 60° 800 -ll2,5 85
4Synthetics delicates: Lightly soiled resistant colours. 40° 800 -ll2,5 70
5Mix 30': To refresh lightly soiled garments quickly (not suitable for wool,
silk and clothes which require washing by hand). 30° 800 -ll 330
6Mix 15': To refresh lightly soiled garments quickly (not suitable for wool,
silk and clothes which require washing by hand). 30° 800 -ll1,5 15
Partials wash cycles
ARinse -1000 - - l536
BSpin -1000 - - - 516
CLight spin -800 - - - 2,5 12
DDrain no spin -0- - - 52
Specials wash cycles
Sanitizing cycle (wash cycle 7). A high-temperature hygienic wash cycle (over 60°C) which requires the use of bleach.
our the bleach, the detergent and the additives into the relevant compartments (see paragraph entitled
Detergent dispenser drawer).
Goodnigt cycle (wash cycle 8). This is a silent cycle which can be run at night, when the electricity prices are lower. The
wash cycle is designed for cottons and synthetics. At the end of the cycle the machine stops while there is still water in
the drum; to spin and drain the laundry press the START/ AUSE button; alternatively the machine will perform the spin
cycle and drain the water automatically after 8 hours.
Baby cycle (wash cycle 9). This wash cycle can be used to remove the soiling typically caused by babies, while ensuring
that all detergent is removed from nappies in order to prevent the delicate skin of babies from suffering allergies. The
cycle has been designed to reduce the amount of bacteria by using a greater quantity of water and optimising the effect
of special disinfecting additives added to the detergent.
At the end of the wash cycle, the machine will slowly rotate the drum to prevent the formation of creases; to end the cycle
press the START/ AUSE button.
Mix 30(wash cycle 5) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 30 minutes and
therefore saves both energy and time. By selecting this wash cycle (5 at 30°C), it is possible to wash different fabrics
together (except for wool and silk items), with a maximum load of 3 kg.
Mix 15(wash cycle 6) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 15 minutes and
therefore saves both energy and time. By selecting this wash cycle (6 at 30°C), it is possible to wash different fabrics
together (except for wool and silk items), with a maximum load of 1.5 kg.

GB
7
Setting the temperature
Turn the TEM ERATURE knob to set the wash temperature (see Table of wash cycles).
The temperature may be lowered, or even set to a cold wash ( ).
The washing machine will automatically prevent you from selecting a temperature which is higher than the
maximum value set for each wash cycle.
Setting the spin speed
Turn the S IN S EED knob to set the spin speed for the selected wash cycle.
The maximum spin speeds available for each wash cycle are as follows:
Wash cycles Maxi u spin speed
Cottons 1000 rpm
Synthetics 800 rpm
Wool 600 rpm
Silk drain only
The spin speed may be lowered, or the spin cycle can be excluded altogether by selecting the symbol .
The washing machine will automatically prevent you from selecting a spin speed which is higher than the
maximum speed set for each wash cycle.
Functions
The various wash functions available with this washing machine will help to achieve the desired results, every time.
To activate the functions:
1. ress the button corresponding to the desired function;
2. the function is enabled when the corresponding indicator light is illuminated.
Note: If the indicator light flashes rapidly, this signals that this particular function may not be selected in
conjunction with the selected wash cycle.
Delay timer
This timer delays the start time of the wash cycle by up to 12 hours.
ress the button repeatedly until the indicator light corresponding to the desired delay time switches on. The fifth time
the button is pressed, the function will be disabled.
N.B. Once you have pressed the START/ AUSE button, the delay time may only be decreased if you wish to modify it.
This option is enabled with all programmes.
Easy iron
By selecting this function, the wash and spin cycles will be modified in order to reduce the formation of creases. At
the end of the cycle the washing machine will perform slow rotations of the drum; the EASY IRON and START/
AUSE indicator lights will flash (orange) and the phase will remain lit in a fixed manner. To end the cycle, press
the START/ AUSE button or the EASY IRON button.
For the Silk wash cycle, the machine will end the cycle while the laundry is soaking, the EASY IRON and START/
AUSE indicator lights will flash (orange) and the RINSE phase will remain lit in a fixed manner. To drain the water
so that the laundry may be removed, press the START/ AUSE button or the EASY IRON button.
 This function may not be used in conjunction with wash cycles 5, 6, 7, 8, 9, 12, B, C, D.
Extra rinse
By selecting this function, the efficiency of the rinse is increased and optimal detergent removal is guaranteed. It is
particularly useful for sensitive skin.
 This function may not be used in conjunction with wash cycles 5, 6, B, C, D.
Super ash
Because a greater quantity of water is used in the initial phase of the cycle, and because of the increased cycle
duration, this function offers a high-performance wash.
 This function may not be used in conjunction with wash cycles 5, 6, 7, 11, 12, A, B, C, D.
Personalisation

8
GB
Detergents and laundry
Detergent dispenser drawer
Good washing results also depend on the correct
dose of detergent: adding too much detergent will not
necessarily result in a more efficient wash, and may in
fact cause build up on the inside of your appliance
and contribute to environmental pollution.
 Do not use hand washing detergents because these
create too much foam.
Open the detergent
dispenser drawer and
pour in the detergent or
washing additive, as
follows.
compartment 1: Pre-wash detergent (powder)
Before pouring in the detergent, make sure that extra
compartment 4 has been removed.
compartment 2: Detergent for the wash cycle
(powder or liquid)
Liquid detergent should only be poured in immediately
prior to the start of the wash cycle.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overflow the grid.
extra compartment 4: Bleach
Bleach cycle
Bleaching may only be performed in conjunction with
wash cycles 2, 3, 7.
our the bleach into extra compartment 4; pour the
detergent and softener into the corresponding
compartments, then select one of the
abovementioned wash cycles.
This option is recommended only for very soiled
cotton garments.
Preparing the laundry
 Divide the laundry according to:
- the type of fabric/the symbol on the label
- the colours: separate coloured garments from
whites.
 Empty all garment pockets and check the buttons.
 Do not exceed the listed values, which refer to the
weight of the laundry when dry:
Durable fabrics: max. 5 kg
Synthetic fabrics: max. 2,5 kg
Delicate fabrics: max. 2 kg
Wool: max. 1 kg
MAX
1
2
4
3
How much does your laundry weigh?
1 sheet 400-500 g
1 pillow case 150-200 g
1 tablecloth 400-500 g
1 bathrobe 900-1200 g
1 towel 150-250 g
Garments requiring special care
Shirts: use special wash cycle 10 to wash shirts in
various fabrics and colours.
It guarantees maximum care is taken of the garments
and minimises the formation of creases.
Silk: use special wash cycle 11 to wash all silk
garments. We recommend the use of special
detergent which has been designed to wash delicate
clothes.
Curtains: fold curtains and place them in a pillow
case or mesh bag. Use wash cycle 11.
ool: Hotpoint/Ariston is the only washing machine
manufacturer to have been awarded the prestigious
Woolmark latinum Care endorsement (M.0508) by
the Woolmark Company, which means that all
woollen garments may be washed in the washing
machine, even those which state hand wash only
on the label. Wash cycle 12 therefore offers
complete peace of mind when washing woollen
garments in the washing machine (max. load 1 kg)
and guarantees optimal performance.
Load balancing system
Before every spin cycle, to avoid excessive vibrations
and to distribute the load in a uniform manner, the drum
rotates continuously at a speed which is slightly greater
than the washing rotation speed. If, after several at-
tempts, the load is not balanced correctly, the machine
spins at a reduced spin speed. If the load is excessively
unbalanced, the washing machine performs the distri-
bution process instead of spinning. To encourage im-
proved load distribution and balance, we recommend
small and large garments are mixed in the load.

GB
9
Precautions and tips
 This washing machine was designed and
constructed in accordance with international safety
regulations. The following information is provided for
safety reasons and must therefore be read carefully.
General safety
 This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
 This appliance was designed for domestic use only.
 Do not touch the machine when barefoot or with
wet or damp hands or feet.
 Do not pull on the power supply cable when
unplugging the appliance from the electricity
socket. Hold the plug and pull.
 Do not open the detergent dispenser drawer while
the machine is in operation.
 Do not touch the drained water as it may reach
extremely high temperatures.
 Never force the porthole door. This could damage
the safety lock mechanism designed to prevent
accidental opening.
 If the appliance breaks down, do not under any
circumstances access the internal mechanisms in
an attempt to repair it yourself.
 Always keep children well away from the appliance
while it is operating.
 The door can become quite hot during the wash cycle.
 If the appliance has to be moved, work in a group
of two or three people and handle it with the utmost
care. Never try to do this alone, because the
appliance is very heavy.
 Before loading laundry into the washing machine,
make sure the drum is empty.
Disposal
 Disposing of the packaging materials: observe local
regulations so that the packaging may be re-used.
 The European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment, requires that
old household electrical appliances must not be
disposed of in the normal unsorted municipal waste
stream. Old appliances must be collected
separately in order to optimise the recovery and
recycling of the materials they contain and reduce
the impact on human health and the environment.
The crossed out "wheeled bin" symbol on the
Opening the porthole door manually
In the event that it is not possible to open the
porthole door due to a powercut, and if you wish to
remove the laundry, proceed as follows:
1. remove the plug from
the electrical socket.
2. make sure the water
level inside the machine is
lower than the door
opening; if it is not, remove
excess water using the
drain hose, collecting it in a
bucket as indicated in the
figure.
3. using a screwdriver,
remove the cover panel on
the lower front part of the
washing machine (see
figure).
4. pull outwards using the tab as indicated in the
figure, until the plastic tie-rod is freed from its stop
position; pull downwards and open the door at the
same time.
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
20
product reminds you of your obligation, that when
you dispose of the appliance it must be separately
collected.
Consumers should contact their local authority or
retailer for information concerning the correct
disposal of their old appliance.

10
GB
Care and maintenance
Cutting off the water and electricity
supplies
 Turn off the water tap after every wash cycle. This
will limit wear on the hydraulic system inside the
washing machine and help to prevent leaks.
 Unplug the washing machine when cleaning it and
during all maintenance work.
Cleaning the washing machine
The outer parts and rubber components of the
appliance can be cleaned using a soft cloth soaked
in lukewarm soapy water. Do not use solvents or
abrasives.
Cleaning the detergent dispenser
drawer
Remove the dispenser
by raising it and pulling it
out (see figure).
Wash it under running
water; this operation
should be repeated
frequently.
Caring for the door and drum of your
appliance
 Always leave the porthole door ajar in order to
prevent unpleasant odours from forming.
Cleaning the pump
The washing machine is fitted with a self-cleaning
pump which does not require any maintenance.
Sometimes, small items (such as coins or buttons)
may fall into the pre-chamber which protects the
pump, situated in its bottom part.
 Make sure the wash cycle has finished and unplug
the appliance.
To access the pre-chamber:
1. using a screwdriver,
remove the cover panel
on the lower front part of
the washing machine
(see figure);
2. unscrew the lid by
rotating it anti-clockwise
(see figure) a little water
may trickle out. This is
perfectly normal;
3. clean the inside thoroughly;
4. screw the lid back on;
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
Checking the water inlet hose
Check the inlet hose at least once a year. If there are
any cracks, it should be replaced immediately: during
the wash cycles, water pressure is very strong and a
cracked hose could easily split open.
 Never use second-hand hoses.
1
2

GB
11
Troubleshooting
Your washing machine could fail to work. Before contacting the Technical Assistance Centre (see Assistance),
make sure that the problem cannot be not solved easily using the following list.
Problem:
The washing machine does not
switch on.
The wash cycle does not start.
The washing machine does not
take in water (the indicator light
for the first wash cycle stage
flashes rapidly).
The washing machine
continuously takes in and drains
water.
The washing machine does not
drain or spin.
The washing machine vibrates a
lot during the spin cycle.
The washing machine leaks.
The START/PAUSE indicator light
(orange) and the function
indicator lights flash rapidly.
There is too much foam.
Possible causes / Solutions:
 The appliance is not plugged into the socket fully, or is not making contact.
 There is no power in the house.
 The washing machine door is not closed properly.
 The ON/OFF button has not been pressed.
 The START/ AUSE button has not been pressed.
 The water tap has not been opened.
 A delayed start has been set (see Personalisation).
 The water inlet hose is not connected to the tap.
 The hose is bent.
 The water tap has not been opened.
 There is no water supply in the house.
 The pressure is too low.
 The START/ AUSE button has not been pressed.
 The drain hose is not fitted at a height between 65 and 100 cm from
the floor (see Installation).
 The free end of the hose is under water (see Installation).
 The wall drainage system is not fitted with a breather pipe.
If the problem persists even after these checks, turn off the water tap,
switch the appliance off and contact the Assistance Service. If the
dwelling is on one of the upper floors of a building, there may be problems
relating to water drainage, causing the washing machine to fill with water
and drain continuously. Special anti-draining valves are available in shops
and help to avoid this inconvenience.
 The wash cycle does not include draining: some wash cycles require
the drain phase to be started manually.
 The EASY IRON function has been activated: To complete the wash
cycle, press the START/ AUSE button (Personalisation).
 The drain hose is bent (see Installation).
 The drainage duct is clogged.
 The drum was not unlocked correctly during installation (see Installation).
 The washing machine is not level (see Installation).
 The washing machine is trapped between cabinets and walls (see Installation).
 The water inlet hose is not screwed on properly (see Installation).
 The detergent dispenser drawer is blocked (for cleaning instructions, see
Care and maintenance).
 The drain hose is not fixed properly (see Installation).
 Switch off the machine and unplug it, wait for approximately 1 minute
and then switch it back on again.
If the problem persists, contact the Technical Assistance Service.
 The detergent is not suitable for machine washing (it should display the
text for washing machines or hand and machine wash, or the like).
 Too much detergent was used.

12
GB
Service
Before calling for Assistance:
Check whether you can solve the problem alone (see Troubleshooting);
 Restart the programme to check whether the problem has been solved;
 If this is not the case, contact an authorised Technical Assistance Centre using the telephone number
provided on the guarantee certificate.
Always request the assistance of authorised technicians.
Have the following information to hand:
 the type of problem;
 the appliance model (Mod.);
 the serial number (S/N).
This information can be found on the data plate applied to the rear of the washing machine, and can also
be found on the front of the appliance by opening the door.

CIS
13
Ðóññêèé
CIS
ARL 105
Ñîäåðæàíèå
Óñòàíîâêà, 14-15
Ðàñïàêîâêà è íèâåëèðîâêà
Ïîäêëþ÷åíèå ê âîäîïðîâîäó è ýëåêòðè÷åñòâó
Ïåðâûé öèêë ñòèðêè
Òåõíè÷åñêèå õàðàêòåðèñòèêè
Îïèñàíèå ñòèðàëüíîé àøèíû è
ïîðÿäêà çàïóñêà ïðîãðà û, 16-17
Ïàíåëü óïðàâëåíèÿ
Èíäèêàòîðû
Ïîðÿäîê çàïóñêà ïðîãðàììû
Ïðîãðà û, 18
Òà ëèöà ïðîãðàìì
Ïåðñîíàëèçèðîâàííûå íàñòðîéêè, 19
Ðåãóëèðîâêà òåìïåðàòóðû
Âû îð ñêîðîñòè îòæèìà
Äîïîëíèòåëüíûå ôóíêöèè
Ìîþùèå ñðåäñòâà è òèïû áåëüÿ, 20
Ðàñïðåäåëèòåëü ìîþùèõ ñðåäñòâ
Îò åëèâàíèå
Ïîäãîòîâêà åëüÿ
Èçäåëèÿ, òðå óþùèå äåëèêàòíîé ñòèðêè
Ñèñòåìà àëàíñèðîâêè åëüÿ
Ïðåäîñòîðîæíîñòè è ðåêî åíäàöèè, 21
Î ùèå òðå îâàíèÿ ê åçîïàñíîñòè
Óòèëèçàöèÿ
Àâàðèéíîå îòêðûòèå ëþêà
Òåõíè÷åñêîå îáñëóæèâàíèå è óõîä, 22
Îòêëþ÷åíèå âîäû è ýëåêòðè÷åñêîãî òîêà
Óõîä çà ñòèðàëüíîé ìàøèíîé
Óõîä çà ðàñïðåäåëèòåëåì ìîþùèõ ñðåäñòâ
Óõîä çà ëþêîì è àðà àíîì
Óõîä çà íàñîñîì
Ïðîâåðêà âîäîïðîâîäíîãî øëàíãà
Ïîèñê íåèñïðàâíîñòåé è åòîäû èõ
óñòðàíåíèÿ, 23
Ñåðâèñíîå îáñëóæèâàíèå, 24
Ðóêîâîäñòâî ïî
ýêñïëóàòàöèè ÑÒÈÐÀËÜÍÀß ÌÀØÈÍÀ

14
CIS
Óñòàíîâêà
! Âàæíî ñîõðàíèòü äàííîå ðóêîâîäñòâî äëÿ åãî
ïîñëåäóþùåãî èñïîëüçîâàíèÿ ñëó÷àå ïðîäàæè,
ïåðåäà÷è èëè ïåðååçäà íà íîâóþ êâàðòèðó íåî õîäèìî
ïðîâåðèòü, ÷òî û ðóêîâîäñòâî îñòàâàëîñü âìåñòå ñî
ñòèðàëüíîé ìàøèíîé, ÷òî û åå íîâûé âëàäåëåö ìîã
îçíàêîìèòüñÿ ñ ïîðÿäêîì åå ôóíêöèîíèðîâàíèÿ è
ñîîòâåòñòâóþùèìè ïðåäóïðåæäåíèÿìè.
! Âíèìàòåëüíî ïðî÷èòàéòå èíñòðóêöèè: â íèõ
ñîäåðæàòñÿ âàæíûå ñâåäåíèÿ î óñòàíîâêå èçäåëèÿ,
åãî ýêñïëóàòàöèè è åçîïàñíîñòè.
Ðàñïàêîâêà è íèâåëèðîâêà
Ñíÿòèå óïàêîâêè
1. Ñíèìèòå ñ ìàøèíû óïàêîâêó.
2. Ïðîâåðüòå, ÷òî û ñòèðàëüíàÿ ìàøèíà íå ûëà
ïîâðåæäåíà â ïðîöåññå ïåðåâîçêè.  ñëó÷àå
î íàðóæåíèÿ ïîâðåæäåíèé íåìåäëåííî î ðàòèòåñü ê
ïîñòàâùèêó, íå ïîäêëþ÷àÿ ìàøèíó.
3. Ñíèìèòå 3
òðàíñïîðòèðîâî÷íûõ
îëòà, ïðåäîõðàíÿþùèå
ìàøèíó â ïðîöåññå
ïåðåâîçêè, è ðåçèíîâóþ
çàãëóøêó ñ
ñîîòâåòñòâóþùåé
ðàñïîðíîé øàé îé,
ðàñïîëîæåííûå â çàäíåé
÷àñòè ñòèðàëüíîé
ìàøèíû (ñì. ñõåìó).
4. Çàêðîéòå îòâåðñòèÿ ïðèëàãàþùèìèñÿ
ïëàñòèêîâûìè çàãëóøêàìè.
5. Ñîõðàíèòå âñå äåòàëè: îíè äîëæíû ûòü
óñòàíîâëåíû íà ñòèðàëüíóþ ìàøèíó â ñëó÷àå åå
ïåðåâîçêè.
! Íå ðàçðåøàéòå äåòÿì èãðàòü ñ óïàêîâî÷íûìè
ìàòåðèàëàìè.
Íèâåëèðîâêà
1. Óñòàíîâèòå ñòèðàëüíóþ ìàøèíó íà ðîâíîì è
ïðî÷íîì ïîëó, íå ïðèñëîíÿÿ åå ê ñòåíàì, ìå åëè è
ïðî÷èì ïðåäìåòàì.
2. Åñëè ïîë íå ÿâëÿåòñÿ
èäåàëüíî
ãîðèçîíòàëüíûì,
íåî õîäèìî
êîìïåíñèðîâàòü
íåðîâíîñòü,
îòðåãóëèðîâàâ ïî âûñîòå
ïåðåäíèå íîæêè (ñì.
ñõåìó). Óêëîí,
èçìåðåííûé ïðè ïîìîùè
óðîâíÿ, óñòàíîâëåííîãî
íà ïîâåðõíîñòü ìàøèíû,
íå äîëæåí ïðåâûøàòü 2°.
Òî÷íàÿ íèâåëèðîâêà î åñïå÷èâàåò ñòà èëüíîñòü
ñòèðàëüíîé ìàøèíû, ïîìîãàåò èç åæàòü åå âè ðàöèé
è ñìåùåíèé â ïðîöåññå ôóíêöèîíèðîâàíèÿ.  ñëó÷àå
óñòàíîâêè ìàøèíû íà êîâåð èëè êîâðîëèí
îòðåãóëèðóéòå íîæêè òàêèì î ðàçîì, ÷òî û ïîä
ñòèðàëüíîé ìàøèíîé îñòàâàëñÿ äîñòàòî÷íûé çàçîð
äëÿ âåíòèëÿöèè.
Ïîäêëþ÷åíèå ê âîäîïðîâîäó è
ýëåêòðè÷åñòâó
Ïîðÿäîê ïîäêëþ÷åíèÿ ê âîäîïðîâîäíî ó øëàíãó
1. Ïðèêðóòèòå øëàíã
ïîäà÷è ê êðàíó õîëîäíîé
âîäû ñ ðåçü îâûì
îòâåðñòèåì 3/4 ãàç (ñì.
ñõåìó).
Ïåðåä ïîäñîåäèíåíèåì
îòêðîéòå âîäîïðîâîäíûé
êðàí äî òåõ ïîð, ïîêà èç
íåãî íå ïîòå÷åò ÷èñòàÿ
âîäà.
2. Ïîäñîåäèíèòå
âîäîïðîâîäíûé øëàíã ê
ìàøèíå, ïðèâèíòèâ åãî ê
ñïåöèàëüíîìó
âîäîïðîâîäíîìó êðàíó,
ðàñïîëîæåííîìó â
çàäíåé âåðõíåé ÷àñòè
ñïðàâà (ñì. ñõåìó).
3. Ïðîâåðüòå, ÷òî û âîäîïðîâîäíûé øëàíã íå ûë
çàëîìëåí èëè ñæàò.
! Äàâëåíèå âîäû â âîäîïðîâîäíîì êðàíå äîëæíî
ûòü â ïðåäåëàõ çíà÷åíèé, óêàçàííûõ â òà ëèöå
Òåõíè÷åñêèå äàííûå (ñì. ñòðàíèöó ðÿäîì).
! Åñëè äëèíà âîäîïðîâîäíîãî øëàíãà óäåò
íåäîñòàòî÷íîé, ñëåäóåò î ðàòèòüñÿ â
ñïåöèàëèçèðîâàííûé ìàãàçèí èëè â óïîëíîìî÷åííûé
ñåðâèñíûé öåíòð
! Íèêîãäà íå ïîëüçóéòåñü /ó øëàíãàìè.
! Èñïîëüçóéòå øëàíãè, ïðèëàãàþùèåñÿ ê ìàøèíå.

CIS
15
65 - 100 cm
Ïîäñîåäèíåíèå ñëèâíîãî øëàíãà
Ïîäñîåäèíèòå ñëèâíîé
øëàíã, íå ïåðåãè àÿ åãî,
ê ñëèâíîé òðó å èëè ê
íàñòåííîìó ñëèâíîìó
îòâåðñòèþ,
ðàñïëîæåííîìó íà
âûñîòå îò 65 äî 100 ñì îò
ïîëà,
èëè ïîìåñòèòå øëàíã â
ðàêîâèíó èëè â âàííó,
çàêðåïèâ
ïðèëàãàþùóþñÿ
íàïðàâëÿþùóþ ê êðàíó
(ñì. ñõåìó). Ñâî îäíûé
êîíåö ñëèâíîãî øëàíãà
íå äîëæåí ûòü ïîãðóæåí
â âîäó.
 Íå ðåêîìåíäóåòñÿ èñïîëüçîâàòü óäëèíèòåëüíûå
øëàíãè. Ïðè íåî õîäèìîñòè óäëèíåíèå äîëæíî èìåòü
òàêîé æå äèàìåòð, ÷òî è îðèãèíàëüíûé øëàíã, è åãî
äëèíà íå äîëæíà ïðåâûøàòü 150 ñì.
Ïîäêëþ÷åíèå ê ýëåêòðîñåòè
Ïåðåä âêëþ÷åíèåì èçäåëèÿ ê ðîçåòêå ýëåêòðîñåòè
íåîþõîäèìî ïðîâåðèòü ñëåäóþùåå:
 ðîçåòêà ýëåêòðîñåòè äîëæíà ûòü ñîåäèíåíà ñ
çàçåìëåíèåì è ñîîòâåòñòâîâàòü íîðìàòèâàì;
 ðîçåòêà ýëåêòðîñåòè äîëæíà ûòü ðàñ÷èòàíà íà
ìàêñèìàëüíóþ ìîùíîñòü ñòèðàëüíîé ìàøèíû,
óêàçàííóþ â òà ëèöå Òåõíè÷åñêèå äàííûå (ñì.
òàáëèöó ñáîêó);
 íàïðÿæåíèå ýëåêòðîñåòè äîëæíî ñîîòâåòñòâîâàòü
çíà÷åíèÿì, óêàçàííûì â òà ëèöå Òåõíè÷åñêèå
äàííûå (ñì. òàáëèöó ñáîêó);
 ýëåêòðè÷åñêàÿ ðîçåòêà äîëæíà ïîäõîäèòü ê
øòåïñåëüíîé âèëêå ñòèðàëüíîé ìàøèíû. Â
ïðîòèâíîì ñëó÷àå íåî õîäèìî çàìåíèòü ðîçåòêó.
 Çàïðåùàåòñÿ óñòàíàâëèâàòü ñòèðàëüíóþ ìàøèíó íà
óëèöå, äàæå ïîä íàâåñîì, òàê êàê îïàñíî ïîäâåðãàòü
åå âîçäåéñòâèþ äîæäÿ è ãðîçû.
 Ñòèðàëüíàÿ ìàøèíà äîëæíà ûòü ðàñïîëîæåíà
òàêèì î ðàçîì, ÷òî û äîñòóï ê ðîçåòêå ýëåêòðîñåòè
îñòàâàëñÿ ñâî îäíûì.
 Íå èñïîëüçóéòå óäëèíèòåëè è òðîéíèêè.
 Ñåòåâîé êà åëü èçäåëèÿ íå äîëæåí ûòü ñîãíóò
èëè ñæàò.
 Çàìåíà ñåòåâîãî êà åëÿ ìîæåò îñóùåñòâëÿòüñÿ
òîëüêî óïîëíîìî÷åííûìè ñåðâèñíûìè öåíòðàìè.
Âíèìàíèå! Ôèðìà ñíèìàåò ñ ñå ÿ âñÿêóþ
îòâåòñòâåííîñòü â ñëó÷àå íåñî ëþäåíèÿ
âûøåîïèñàííûõ ïðàâèë.
Ïåðâûé öèêë ñòèðêè
Ïî çàâåðøåíèè óñòàíîâêè, ïåðåä íà÷àëîì
ýêñïëóàòàöèè íåî õîäèìî ïðîèçâåñòè îäèí öèêë
ñòèðêè ñî ñòèðàëüíûì ïîðîøêîì, íî åç åëüÿ, ïî
ïðîãðàììå 2.
Òåõíè÷åñêèå õàðàêòåðèñòèêè
Ìîäåëü ARL 105
Ðàçìåðû
øèð è í à 59 , 5 ñ ì
âûñîòà 85 ñì
ãëóáèíà 52,5 ñì
Çàãðóçêà 1 - 5 êã
Ýëåêòðè÷åñêèå
ïàðàìåòðû
cìîòðèòå ïàñïîðòíó òàáëè÷êó ñ
òåõíè÷åñêèìè õàðàêòåðèñòèêàìè íà
ìàøèíå
Ãèäðàâëè÷åñêèå
ïàðàìåòðû
max äàâëåíèå 1 Ìïà (10 áàð)
min äàâëåíèå 0,05 Ìïà (0,5 áàð)
îáúåì áàðàáàíà 46 ë
Ñêîðîñòü
îòæèìà äî 1000 îá/ìèí
Kîíòðîëüíûå
ïðîãðàììû
ñîãëàñíî
íîðìàòèâó
N 604 56
ïðîãðàììà 7; òåìïåðàòóðà 60°Ñ;
ïðè çàãðóçêå äî 5 êã.
Ìàøèíà ñîîòâåòñòâóåò ñëåäó ùèì
Äèðåêòèâàì Åâðîïåéñêîãî
Ýêîíîìè÷åñêîãî ñîîáùåñòâà:
- 89/336 /ÅÅÑ îò 03.05.89 (ýëåêòðî-
ìàãíèòíîé ñîâìåñòèìîñòè) è
ïîñëåäó ùèå ìîäèôèêàöèè
- 2 00 2 / 96/ CE
- 2006/95/CE (íèçêîãî íàïðÿæåíèÿ)

16
CIS
Ðàñïðåäåëèòåëü ìîþùèõ ñðåäñòâ: äëÿ
çàãðóçêè ñòèðàëüíûõ âåùåñòâ è äî àâîê
(ñì. «Ìîþùèå ñðåäñòâà è òèïû áåëüÿ»).
Âíóòðè ðàñïðåäåëèòåëÿ ìîþùèõ ñðåäñòâ èìååòñÿ
êðàòêèé ïåðå÷åíü ïðîãðàìì.
Êíîïêà ÂÊË/ÂÛÊË: ñëóæèò äëÿ âêëþ÷åíèÿ è
âûêëþ÷åíèÿ ñòèðàëüíîé ìàøèíû.
Ðóêîÿòêà âû îðà ÏÐÎÃÐÀÌÌÀ: ñëóæèò äëÿ
âû îðà ïðîãðàìì. Â ïðîöåññå âûïîëíåíèÿ
ïðîãðàììû ðóêîÿòêà íå âðàùàåòñÿ.
Êíîïêè ñ èíäèêàòîðàìè äîïîëíèòåëüíûõ ÔÓÍÊÖÈÉ:
ñëóæàò äëÿ âû îðà èìåþùèõñÿ äîïîëíèòåëüíûõ
ôóíêöèé. Èíäèêàòîð, ñîîòâåòñòâóþùèé âû ðàííîé
ôóíêöèè, îñòàíåòñÿ âêëþ÷åííûì.
Ñêîðîñòè ÎÒÆÈÌÀ: ñëóæèò äëÿ âû îðà ñêîðîñòè
îòæèìà èëè äëÿ åãî èñêëþ÷åíèÿ
(ñì « åðñîíàëèçèðîâàííûå íàñòðîéêè»).
Ðåãóëÿòîð ÒÅÌÏÅÐÀÒÓÐÛ: ñëóæèò äëÿ íàñòðîéêè
òåìïåðàòóðû èëè äëÿ ñòèðêè â õîëîäíîé âîäå
(ñì. « åðñîíàëèçèðîâàííûå íàñòðîéêè»).
èíäèêàòîðû ÂÛÏÎËÍÅÍÈß ÔÀÇ ÖÈÊËÀ/ÇÀÏÓÑÊÀ
Ñ ÇÀÄÅÐÆÊÎÉ: ïîêàçûâàþò ïîñëåäîâàòåëüíîñòü
âûïîëíåíèåì ïðîãðàììû ñòèðêè. Âêëþ÷åííûé
èíäèêàòîð ñîîòâåòñòâóåò òåêóùåé ôàçå. Åñëè ûëà
âêëþ÷åíà ôóíêöèÿ Òàéìåð îòñðî÷êè, èíäèêàòîðû
óäóò ïîêàçûâàòü âðåìÿ, îñòàþùååñÿ äî çàïóñêà
ïðîãðàììû (ñì. ñòðàíèöó ñáîêó).
Èíäèêàòîð ÁËÎÊÈÐÎÂÊÈ ËÞÊA: ïîêàçûâàåò,
ìîæíî ëè îòêðûòü ëþê (ñì. ñòðàíèöó ñáîêó).
Êíîïêà ñ èíäèêàòîðîì ÏÓÑÊ/ÏÀÓÇÀ: ñëóæèò äëÿ
çàïóñêà èëè äëÿ âðåìåííîãî ïðåðûâàíèÿ
ïðîãðàììû.
ÏÐÈÌÅ×ÀÍÈÅ: äëÿ âðåìåííîãî ïðåðûâàíèÿ
òåêóùåãî öèêëà ñòèðêè íàæìèòå ýòó êíîïêó.
Ñîîòâåòñòâóþùèé èíäèêàòîð çàìèãàåò
îðàíæåâûìöâåòîì, à èíäèêàòîð òåêóùåé ôàçû
ñòèðêè óäåò ãîðåòü, íå ìèãàÿ. Åñëè èíäèêàòîð
ÁËÎÊÈÐÎÂÊÈ ËÞÊA ïîãàñ, ìîæíî îòêðûòü
ëþê.
Äëÿ âîçî íîâëåíèÿ öèêëà ñòèðêè ñ ìîìåíòà, êîãäà
îí ûë ïðåðâàí, âíîâü íàæìèòå ÏÓÑÊ/ÏÀÓÇÀ.
Ðåæè îæèäàíèÿ
Íàñòîÿùàÿ ñòèðàëüíàÿ ìàøèíà îòâå÷àåò
òðå îâàíèÿì íîâûõ íîðìàòèâîâ ïî ýêîíîìèè
ýëåêòðîýíåðãèè, óêîìïëåêòîâàíà ñèñòåìîé
àâòîìàòè÷åñêîãî îòêëþ÷åíèÿ (ðåæèì ñîõðàíåíèÿ
ýíåðãèè), âêëþ÷àþùåéñÿ ÷åðåç 30 ìèíóò ïðîñòîÿ
ìàøèíû. Íàæìèòå îäèí ðàç êíîïêó ÂÊË./ÂÛÊË è
ïîäîæäèòå, ïîêà ìàøèíà âíîâü âêëþ÷èòñÿ.
Îïèñàíèå ñòèðàëüíîé àøèíû è
ïîðÿäêà çàïóñêà ïðîãðà û
Ðåãóëÿòîð
ÒÅÌÏÅÐÀÒÓÐÛ
Ðàñïðåäåëèòåëü ìîþùèõ
ñðåäñòâ
Èíäèêàòîðû ÂÛÏÎËÍÅÍÈß ÔÀÇ
ÖÈÊËÀ/ÇÀÏÓÑÊÀ Ñ
ÇÀÄÅÐÆÊÎÉ
Êíîïêè ñ
èíäèêàòîðàìè
äîïîëíèòåëüíûõ
ÔÓÍÊÖÈÉ
Êíîïêà
ÂÊË/ÂÛÊË
Ñêîðîñòè
ÎÒÆÈÌÀ Èíäèêàòîð
ÁËÎÊÈÐÎÂÊÈ
ËÞÊA
Êíîïêà ñ
èíäèêàòîðîì
ÏÓÑÊ/ÏÀÓÇÀ
Ïàíåëü óïðàâëåíèÿ
Ðóêîÿòêà âû îðà
ÏÐÎÃÐÀÌÌÀ

CIS
17
Èíäèêàòîðû
Èíäèêàòîðû ñîî ùàþò ïîëüçîâàòåëþ âàæíûå
ñâåäåíèÿ. Çíà÷åíèå èíäèêàòîðîâ:
Òàé åð îòñðî÷êè
Åñëè ûëà âêëþ÷åíà ôóíêöèÿ Òàéìåð îòñðî÷êè
(ñì. « åðñîíàëèçèðîâàííûå íàñòðîéêè»), ïîñëå
çàïóñêà ïðîãðàììû íà÷íåò ìèãàòü èíäèêàòîð,
ñîîòâåòñòâóþùèé çàäàííîìó âðåìåíè çàäåðæêè:
Ïî ìåðå îòñ÷åòà âðåìåíè óäåò ïîêàçûâàòüñÿ
îñòàþùååñÿ âðåìÿ âìåñòå ñ ìèãàíèåì
ñîîòâåòñòâóþùåãî èíäèêàòîðà.
Ïî ïðîøåñòâèè çàäàííîãî âðåìåíè çàäåðæêè
ìèãàþùèé èíäèêàòîð ïîãàñíåò, è çàïóñòèòñÿ çàäàííàÿ
ïðîãðàììà.
Èíäèêàòîðû òåêóùåé ôàçû öèêëà:
Ïîñëå âû îðà è çàïóñêà öèêëà ñòèðêè èíäèêàòîðû
óäóò çàãîðàòüñÿ îäèí çà äðóãèì, ïîêàçûâàÿ
ïîñëåäîâàòåëüíîñòü âûïîëíåíèÿ ïðîãðàììû:
Êíîïêè äîïîëíèòåëüíûé ôóíêöèé è
ñîîòâåòñòâóþùèå èíäèêàòîðû
Ïðè âû îðå ôóíêöèè çàãîðàåòñÿ ñîîòâåòñòâóþùàÿ
êíîïêà.
Åñëè âû ðàííàÿ ôóíêöèÿ ÿâëÿåòñÿ íåñîâìåñòèìîé ñ
çàäàííîé ïðîãðàììîé, ñîîòâåòñòâóþùèé èíäèêàòîð
óäåò ìèãàòü, è òàêàÿ ôóíêöèÿ íå óäåò âêëþ÷åíà.
Åñëè óäåò âû ðàíà ôóíêöèÿ, íåñîâìåñòèìàÿ ñ
äðóãîé, ðàíåå âû ðàííîé ôóíêöèåé, îñòàíåòñÿ
âêëþ÷åííîé òîëüêî ïîñëåäíÿÿ âû ðàííàÿ ôóíêöèÿ.
Èíäèêàòîð áëîêèðîâêè ëþêà:
Âêëþ÷åííûé èíäèêàòîð îçíà÷àåò, ÷òî ëþê
çà ëîêèðîâàí âî èç åæàíèå åãî ñëó÷àéíîãî
îòêðûâàíèÿ. Âî èç åæàíèå åãî ïîâðåæäåíèÿ
íåî õîäèìî äîæäàòüñÿ, êîãäà èíäèêàòîð ïîãàñíåò,
ïåðåä òåì êàê îòêðûòü ëþê.
ÏÐÈÌÅ×ÀÍÈÅ: åñëè âêëþ÷åíà ôóíêöèÿ Òàéìåð
îòñðî÷êè, ëþê îòêðûòü íåëüçÿ. Äëÿ ýòîãî íåî õîäèìî
ïåðåêëþ÷èòü ìàøèíó â ðåæèì ïàóçû ïðè ïîìîùè
êíîïêè ÏÓÑÊ/ÏÀÓÇÀ.
 Áûñòðîå ìèãàíèå èíäèêàòîðà ÏÓÑÊ/ÏÀÓÇÀ
(îðàíæåâûé) îäíîâðåìåííî ñ èíäèêàòîðîì ôóíêöèé
îçíà÷àåò íåèñïðàâíîñòü (ñì. «Íåèñïðàâíîñòè è
ìåòîäû èõ óñòðàíåíèÿ»).
Ïîðÿäîê çàïóñêà ïðîãðà û
1. Âêëþ÷èòå ìàøèíó ïðè ïîìîùè êíîïêè ÂÊË./ÂÛÊË. Âñå èíäèêàòîðû çàãîðÿòñÿ íà íåñêîëüêî ñåêóíä,
çàòåì îñòàíóòñÿ âêëþ÷åííûìè èíäèêàòîðû íàñòðîåê âû ðàííîé ïðîãðàììû, è óäåò ìèãàòü èíäèêàòîð
ÏÓÑÊ/ÏÀÓÇÀ.
2. Çàãðóçèòå åëüå â àðà àí è çàêðîéòå ëþê.
3. Çàäàéòå ðóêîÿòêîé ÏÐÎÃÐÀÌÌÀ íóæíóþ ïðîãðàììó.
4. Çàäàéòå òåìïåðàòóðó ñòèðêè (ñì. « åðñîíàëèçèðîâàííûå íàñòðîéêè»).
5. Çàäàéòå ñêîðîñòü îòæèìà (ñì. « åðñîíàëèçèðîâàííûå íàñòðîéêè»).
6. Ïîìåñòèòå ìîþùèå ñðåäñòâà è äî àâêè (ñì. «Ñòèðàëüíûå âåùåñòâà è òèïû áåëüÿ»).
7. Âêëþ÷èòå íóæíûå äîïîëíèòåëüíûå ôóíêöèè.
8. Çàïóñòèòå ïðîãðàììó ïðè ïîìîùè êíîïêè ÏÓÑÊ/ÏÀÓÇÀ, ñîîòâåòñòâóþùèé èíäèêàòîð çàãîðèòñÿ çåëåíûì öâåòîì.
Äëÿ îòìåíû çàäàííîãî öèêëà ïåðåêëþ÷èòå ìàøèíó â ðåæèì ïàóçû ïðè ïîìîùè êíîïêè ÏÓÑÊ/ÏÀÓÇÀ è âû åðèòå íîâûé öèêë.
9. Ïî çàâåðøåíèè ïðîãðàììû çàãîðèòñÿ èíäèêàòîð . Èíäèêàòîð ÁËÎÊÈÐÎÂÊÈ ËÞÊA ïîãàñíåò, ïîêàçûâàÿ,
÷òî òåïåðü ìîæíî îòêðûòü ëþê. Âûíüòå åëüå è îñòàâèòü ëþê ïîëóîòêðûòûì äëÿ ñóøêè àðà àíà.
Âûêëþ÷èòå ñòèðàëüíóþ ìàøèíó, íàæàâ êíîïêó ÂÊË/ÂÛÊË.
Còèðêà
Ïîëîñêàíèå
Îòæèì
Ñëèâ
Êîíåö öèêëà

18
CIS
Îïèñàíèå ïðîãðàììû
Ìàêñ
òåìï.
(°C)
Ìàêñ.
ñêîðîñòü
(îá./ìèí.)
Ñòèðàëüíûå ñðåäñòâà Ìàêñ.
çàãðóçêà
(êã)
Ïðîäîë-
æèòòü
öèêëà
Îòáåë-
èâàòåëü
Ñòèðêà Îïîëàñêè-
âàòåëü
Ñïåöèàëüíûå ïðîãðàììû
7ÖÈKË ÀÍÒÈÁÀKÒÅÐÈß 90°: ñèëüíîçàãðÿçíåííîå áåëîå áåëüå. 90° 1000 ll l 5165
7ÖÈKË ÀÍÒÈÁÀKÒÅÐÈß 90° (1): ñèëüíîçàãðÿçíåííîå áåëîå è ïðî÷íîå
öâåòíîå áåëüå. 60° 1000 -ll 5133
8ÍÎ×ÍÎÉ ÖÈKË: ñëàáîçàãðÿçíåííîå äåëèêàòíîå öâåòíîå áåëüå. 40° 800 -ll 3288
9ÄÅÒÑKÎÅ ÁÅËÜÅ: ñèëüíîçàãðÿçíåííîå äåëèêàòíîå öâåòíîå áåëüå. 40° 800 -ll 2118
10 ÐÓÁÀØKÈ 40° 600 -ll 269
11 ØÅËK/ÇÀÍÀÂÅÑKÈ: äëÿ èçäåëèé èç øåëêà, âèñêîçû è íèæíåãî áåëüÿ. 30° 0 -ll 155
12 ØÅÐÑÒÜ: äë ÿ øå ðñ òè , êàøå ìèð à è ò. ä. 40° 600 -ll 155
Åæåäíåâíûå ïðîãðàììû
1ÏÐÅÄÂÀÐÈÒÅËÜÍÀß + ÕËÎÏÎK 90°: î÷åíü ñèëüíî çàãðÿçíåííîå áåëîå áåëüå. 90° 1000 -ll 5155
2ÕËÎÏÎK: ñèëüíîçàãðÿçíåííîå áåëîå è ïðî÷íîå öâåòíîå áåëüå. 60° 1000 ll l 5119
2ÕËÎÏÎK (2): ñèëüíîçàãðÿçíåííîå áåëîå è äåëèêàòíîå öâåòíîå áåëüå. 40° 1000 ll l 5115
3ÕËÎÏÎK (3): ñèëüíîçàãðÿçíåííîå áåëîå è öâåòíîå äåëèêàòíîå áåëüå. 40° 1000 ll l 585
4ÑÈÍÒÅÒÈKÀ: ñèëüíîçàÿãðÿçíåííîå áåëüå ïðî÷íîå öâåòíîå áåëüå. 60° 800 -ll 2,5 85
4ÑÈÍÒÅÒÈKÀ: ñëàáîçàãðÿçíåííîå ïðî÷íîå öâåòíîå áåëüå. 40° 800 -ll 2,5 70
5MÈKÑ 30': äëÿ áûñòðîãî îñâåæåíèÿ ìàëîãðÿçíîãî áåëüÿ (íå äëÿ øåðñòè,
øåëêà è èçäåëèÿ ðó÷íîé ñòèðêè). 30° 800 -ll 330
6MÈKÑ 15': äëÿ áûñòðîãî îñâåæåíèÿ ìàëîãðÿçíîãî áåëüÿ (íå äëÿ øåðñòè,
øåëêà è èçäåëèÿ ðó÷íîé ñòèðêè). 30° 800 -ll 1,5 15
Äoïîëíèòåëüíûå ïðîãðàììû
AÏîë îñ êàíèå -1000 - - l536
BÎòæèì -1000 - - - 516
CÄåëèêàòíûé îòæèì -800 - - - 2,5 12
DÑëèâ -0- - - 52
Ñïåöèàëüíûå ïðîãðà û
ÖÈKË ÀÍÒÈÁÀKÒÅÐÈß (ïðîãðàììà 7). Äåçèíôåöèðóþùàÿ ïðîãðàììà ñ âûñîêîé òåìïåðàòóðîé, ïðåäóñìàòðèâàþùàÿ
èñïîëüçîâàíèå îò åëèâàòåëÿ ïðè òåìïåðàòóðå âûøå 60°C.
Äëÿ îò åëèâàíèÿ çàëåéòå îò åëèâàòåëü, ìîþùåå ñðåäñòâî
è äî àâêè â ñîîòâåòñòâóþùèå ÿ÷åéêè (ñì ïàðàãðàô «Ðàñïðåäåëèòåëü ìîþùèõ ñðåäñòâ»).
ÍÎ×ÍÎÉ ÖÈKË (ïðîãðàììà 8). Ýòî åñøóìíûé öèêë, êîòîðûé ìîæíî âêëþ÷èòü íî÷üþ, ýêîíîìÿ ýëåêòðîýíåðãèþ.
Äàííàÿ ïðîãðàììà ðàñ÷èòàíà íà ñòèðêó ñèíòåòè÷åñêèõ è õ/ âåùåé. Ïî çàâåðøåíèè öèêëà ìàøèíà îñòàíàâëèâàåòñÿ ñ
âîäîé â àðà àíå; äëÿ ñëèâà è îòæèìà íàæìèòå êíîïêó ÏÓÑÊ/ÏÀÓÇÀ, â ïðîòèâíîì ñëó÷àå ïî ïðîøåñòâèè 8 ÷àñîâ
ìàøèíà àâòîìàòè÷åñêè ïðîèçâåäåò ñëèâ âîäû è îòæèì.
ÄÅÒÑKÎÅ ÁÅËÜÅ (ïðîãðàììà 9). Ïðîãðàììà óäàëÿåò òèïè÷íûå çàãðÿçíåíèÿ äåòñêîé îäåæäû, ãàðàíòèðóÿ óäàëåíèå
ìîþùåãî ñðåäñòâà èç òêàíè âî èç åæàíèå àëëåðãèè ÷óâñòâèòåëüíîé äåòñêîé êîæè. Äàííûé öèêë ðàñ÷èòàí íà
ñîêðàùåíèå êîëè÷åñòâà àêòåðèé ëàãîäàðÿ èñïîëüçîâàíèþ îëüøåãî î úåìà âîäû è îïòèìèçèðóÿ âîçäåéñòâèå
ñïåöèàëüíûõ äåçèíôèöèðóþùèõ äî àâîê ñòàðèëüíîãî âåùåñòâà.
Ïî çàâåðøåíèè ñòèðêè ìàøèíà ïðîäîëæèò ìåäëåííî âðàùàòü àðà àí âî èç åæàíèå ñìèíàíèÿ åëüÿ. Äëÿ îñòàíîâêè
öèêëà íàæìèòå êíîïêó ÏÓÑÊ/ÏÀÓÇÀ.
MÈKÑ 30' (ïðîãðàììà 5) ïðåäíàçíà÷åíà äëÿ ûñòðîé ñòèðêè ñëà îçàãðÿçíåííîãî åëüÿ öèêë äëèòñÿ âñåãî 30 ìèíóò,
÷òî ïîçâîëÿåò ñýêîíîìèòü âðåìÿ è ýëåêòðîýíåðãèþ. Ïî ýòîé ïðîãðàììå (5, 30°C) ìîæíî ñòèðàòü âìåñòå åëüå èç
ðàçíûõ òêàíåé (çà èñêëþ÷åíèåì øåðñòè è øåëêà) ñ ìàêñèìàëüíîé çàãðóçêîé 3 êã.
MÈKÑ 15' (ïðîãðàììà 6) ïðåäíàçíà÷åíà äëÿ ûñòðîé ñòèðêè ñëà îçàãðÿçíåííîãî åëüÿ öèêë äëèòñÿ âñåãî 15 ìèíóò,
÷òî ïîçâîëÿåò ñýêîíîìèòü âðåìÿ è ýëåêòðîýíåðãèþ. Ïî ýòîé ïðîãðàììå (6, 30°C) ìîæíî ñòèðàòü âìåñòå åëüå èç
ðàçíûõ òêàíåé (çà èñêëþ÷åíèåì øåðñòè è øåëêà) ñ ìàêñèìàëüíîé çàãðóçêîé 1,5 êã.
Ïðîãðà û
ðèâåäåííûå â òàáëèöå çíà÷åíèÿ ÿâëÿþòñÿ ïðèìåðíûìè.
Äëÿ âñåõ èíñòèòóòîâ òåñòèðîâàíèÿ:
1) Ïðîãðà û óïðàâëåíèÿ â ñîîòâåòñòâèè ñ Äèðåêòèâîé EN 60456: çàäàéòå ïðîãðà ó 7 ñ òå ïåðàòóðîé 60°C.
2) Äëèííàÿ ïðîãðà à äëÿ õ/á áåëüÿ: çàäàéòå ïðîãðà ó 2 ñ òå ïåðàòóðîé 40°C.
3) Êîðîòêàÿ ïðîãðà à äëÿ õ/á áåëüÿ: çàäàéòå ïðîãðà ó 3 ñ òå ïåðàòóðîé 40°C.
Ïðîãðà û
Òàáëèöà ïðîãðà

CIS
19
Ðåãóëèðîâêà òå ïåðàòóðû
Íàñòðîéêà òåìïåðàòóðû ñòèðêè ïðîèçâîäèòñÿ ïðè ïîìîùè ðåãóëÿòîðà ÒÅÌÏÅÐÀÒÓÐÛ (ñì.Òàáëèöó ïðîãðàìì).
Çíà÷åíèå òåìïåðàòóðû ìîæåò ûòü óìåíüøåíî âïëîòü äî ñòèðêè â õîëîäíîé âîäå ( ).
Ìàøèíà àâòîìàòè÷åñêè íå äîïóñêàåò âû îð òåìïåðàòóðû, ïðåâûøàþùèés ìàêñèìàëüíîå çíà÷åíèå,
ïðåäóñìîòðåííîå äëÿ êàæäîé ïðîðàììû.
Âûáîð ñêîðîñòè îòæè à
Âû îð ñêîðîñòè îòæèìà âû ðàííîé ïðîãðàììû ïðîèçâîäèòñÿ ïðè ïîìîùè ðåãóëÿòîðà ñêîðîñòè ÎÒÆÈÌ.
Äëÿ ðàçíûõ ïðîãðàìì ïðåäóñìàòðèâàåòñÿ ðàçíàÿ ìàêñèìàëüíàÿ ñêîðîñòü îòæèìà:
Ïðîãðà û Ìàêñè àëüíàÿ ñêîðîñòü îòæè à
Õëîïîê 1000 î îðîòîâ â ìèíóòó
Ñèíòåòè÷åñêèå òêàíè 800 î îðîòîâ â ìèíóòó
Øåðñòü 600 î îðîòîâ â ìèíóòó
Øåëê åç îòæèìà
Ñêîðîñòü îòæèìà ìîæåò ûòü óìåíüøåíà, èëè æå îòæèì ìîæåò ûòü ñîâñåì èñêëþ÷åí, ïîâåðíóâ ðåãóëÿòîð â
ïîëîæåíèå .
Ìàøèíà àâòîìàòè÷åñêè íå äîïóñêàåò âû îð ñêîðîñòè îòæèìà, ïðåâûøàþùèé ìàêñèìàëüíóþ ñêîðîñòü,
ïðåäóñìîòðåííóþ äëÿ êàæäîé ïðîðàììû.
Äîïîëíèòåëüíûå ôóíêöèè
Ðàçëè÷íûå ôóíêöèè ñòèðêè ìàøèíû ïîçâîëÿþò äîñòè÷ü æåëàåìîé ÷èñòîòû è åëèçíû âàøåãî åëüÿ.
Ïîðÿäîê âû îðà ôóíêöèé:
1. íàæìèòå êíîïêó íóæíîé âàì ôóíêöèè;
2. âêëþ÷åíèå ñîîòâåòñòâóþùåãî èíäèêàòîðà îçíà÷àåò, ÷òî ôóíêöèÿ âêëþ÷åíà.
Ïðèìå÷àíèå: ×àñòîå ìèãàíèå èíäèêàòîðà îçíà÷àåò, ÷òî äàííàÿ ôóíêöèÿ íå ìîæåò ûòü âû ðàíà äëÿ çàäàííîé
ïðîãðàììû.
Òàé åð îòñðî÷êè
Çàäåðæèâàåò çàïóñê öèêëà âïëîòü äî 12 ÷àñîâ.
Íàæìèòå êíîïêó íåñêîëüêî ðàç âïëîòü äî âêëþ÷åíèÿ èíäèêàòîðà, ñîîòâåòñòâóþùåãî íóæíîìó çíà÷åíèþ çàäåðæêè.
Ïðè ïÿòîì íàæàòèè êíîïêè ôóíêöèÿ îòêëþ÷àåòñÿ.
ÏÐÈÌÅ×ÀÍÈÅ: Ïîñëå íàæàòèÿ êíîïêè ÏÓÑÊ/ÏÀÓÇÀ, ìîæíî èçìåíèòü çíà÷åíèå çàäåðæêè òîëüêî â ñòîðîíó
óìåíüøåíèÿ.
 Ýòà ôóíêöèÿ ñîâìåñòèìà ñ ëþ îé ïðîãðàììîé.
Ëåãêàÿ ãëàæêà
Ïðè âû îðå ýòîé ôóíêöèè öèêëû ñòèðêè è îòæèìà èçìåíÿþòñÿ òàêèì î ðàçîì, ÷òî û ñîêðàòèòü ñêëàäêè íà
åëüå. Ïî çàâåðøåíèè öèêëà ìàøèíà ïðîèçâîäèò ìåäëåííîå âðàùåíèå àðà àíà. Èíäèêàòîð ôóíêöèè
ËÅÃÊÀß ÃËÀÆÊÀ è èíäèêàòîð ÏÓÑÊ/ÏÀÓÇÀ ìèãàþò (îðàíæåâûì öâåòîì), èíäèêàòîð ôàçû   ãîðèò, íå
ìèãàÿ. Äëÿ çàâåðøåíèÿ öèêëà íàæìèòå êíîïêó ÏÓÑÊ/ÏÀÓÇÀ èëè êíîïêó ËÅÃÊÀß ÃËÀÆÊÀ.
Ïðè âû îðå ïðîãðàììû Øåëê (11) ìàøèíà çàâåðøàåò öèêë åç ñëèâà âîäû, è Èíäèêàòîð ôóíêöèè ËÅÃÊÀß
ÃËÀÆÊÀ è èíäèêàòîð ÏÓÑÊ/ÏÀÓÇÀ ìèãàþò (îðàíæåâûì öâåòîì), èíäèêàòîð ôàçû Ïîëîñêàíèå ãîðèò, íå
ìèãàÿ. Äëÿ ñëèâà âîäû è âûãðóçêè åëüÿ íåî õîäèìî íàæàòü êíîïêó ÏÓÑÊ/ÏÀÓÇÀ èëè êíîïêó ËÅÃÊÀß
ÃËÀÆÊÀ.
 Ýòà ôóíêöèÿ íåñîâìåñòèìà ñ ïðîãðàììàìè 5, 6, 7, 8, 9, 12, B, C, D.
Äîïîëíèòåëüíîå Ïîëîñêàíèå
Ïðè âû îðå ýòîé ôóíêöèè ïîâûøàåòñÿ ýôôåêòèâíîñòü îïîëàñêèâàíèÿ, î åñïå÷èâàÿ ìàêñèìàëüíîå óäàëåíèå
ìîþùåãî âåùåñòâà. Ýòà ôóíêöèÿ îñî åííî óäî íà äëÿ ëþäåé ñ êîæåé, ÷óâñòâèòåëüíîé ê ñòèðàëüíûì âåùåñòâàì.
 Ýòà ôóíêöèÿ íåñîâìåñòèìà ñ ïðîãðàììàìè 5, 6, B, C, D.
Ñóïåðñòèðêà
Î åñïå÷èâàåò îïòèìàëüíóþ ñòèðêó ëàãîäàðÿ èñïîëüçîâàíèþ îëüøåãî î úåìà âîäû â íà÷àëå öèêëà è îëüøåé
ïðîäîëæèòåëüíîñòè öèêëà.
 Ýòà ôóíêöèÿ íåñîâìåñòèìà ñ ïðîãðàììàìè 5, 6, 7, 11, 12, A, B, C, D.
Ïåðñîíàëèçèðîâàííûå
íàñòðîéêè

20
CIS
Ìîþùèå ñðåäñòâà è
òèïû áåëüÿ
Ðàñïðåäåëèòåëü îþùèõ ñðåäñòâ
Õîðîøèé ðåçóëüòàò ñòèðêè çàâèñèò òàêæå îò
ïðàâèëüíîé äîçèðîâêè ñòèðàëüíîãî âåùåñòâà:
èç ûòîê ñòèðàëüíîãî âåùåñòâà íå ãàðàíòèðóåò îëåå
ýôôåêòèâíóþ ñòèðêó, íàïðîòèâ, ñïîñî ñòâóåò
î ðàçîâàíèþ íàëåòîâ âíóòðè ñòèðàëüíîé ìàøèíû è
çàãðÿçíåíèþ îêðóæàþùåé ñðåäû.
 Íå èñïîëüçóéòå ìîþùèå ñðåäñòâà äëÿ ðó÷íîé
ñòèðêè, òàê êàê îíè î ðàçóþò ñëèøêîì ìíîãî ïåíû.
Âûíüòå ðàñïðåäåëèòåëü è
ïîìåñòèòå â íåãî
ìîþùåå ñðåäñòâî èëè
äî àâêó â ñëåäóþùåì
ïîðÿäêå.
îòäåëåíèå 1: îþùåå ñðåäñòâî äëÿ
ïðåäâàðèòåëüíîé ñòèðêè (ïîðîøîê)
Ïåðåä çàñûïêîé ñòèðàëüíîãî ïîðîøêà íåî õîäèìî
ïðîâåðèòü, ÷òî û íå ûë óñòàíîâëåí äîïîëíèòåëüíûé
îòäåëåíèå 4.
îòäåëåíèå 2: Ìîþùåå ñðåäñòâî äëÿ ñòèðêè
(ïîðîøîê èëè æèäêîå)
Ìîþùåå ñðåäñòâî äëÿ ñòèðêè çàëèâàåòñÿ
íåïîñðåäñòâåííî ïåðåä çàïóñêîì ìàøèíû.
îòäåëåíèå 3: Äîáàâêè (îïîëàñêèâàòåëü è ò.ä.)
Íå íàëèâàéòå îïîëàñêèâàòåëü âûøå ðåøåòêè
îòäåëåíèÿ.
äîïîëíèòåëüíîå îòäåëåíèå 4: Îòáåëèâàòåëü
Îòáåëèâàíèå
Îò åëèâàíèå ïðîèçâîäèòñÿ òîëüêî ñ ïðîãðàììàìè
2, 3, 7.
Ïîìåñòèòå îò åëèâàòåëü â äîïîëíèòåëüíûé îòäåëåíèå
4, ìîþùåå ñðåäñòâî è îïîëàñêèâàòåëü â
ñîîòâåòñòâóþùèå îòäåëåíèÿ, çàòåì âû åðèòå îäíó èç
âûøåóêàçàííûõ ïðîãðàìì.
Ðåêîìåíäóåòñÿ òîëüêî äëÿ î÷åíü ãðÿçíîãî õ/ åëüÿ.
Ïîäãîòîâêà áåëüÿ
 Ðàçäåëèòå åëüå ïî ñëåäóþùèì ïðèçíàêàì:
- òèï òêàíè / î îçíà÷åíèÿ íà ýòèêåòêå.
- öâåò: îòäåëèòå öâåòíîå åëüå îò åëîãî.
 Âûíüòå èç êàðìàíîâ âñå ïðåäìåòû è ïðîâåðüòå ïóãîâèöû.
 Íå ïðåâûøàéòå ìàêñèìàëüíóþ çàãðóçêó àðà àíà,
óêàçàííóþ äëÿ ñóõîãî åëüÿ:
Ïðî÷íûå òêàíè: ìàêñ. 5 êã
Ñèíòåòè÷åñêèå òêàíè: ìàêñ. 2,5 êã
Äåëèêàòíûå òêàíè: ìàêñ. 2 êã
Øåðñòü: ìàêñ. 1 êã
MAX
1
2
4
3
Ñêîëüêî âåñèò áåëüå?
1 ïðîñòûíÿ 400-500 ãð.
1 íàâîëî÷êà 150-200 ãð.
1 ñêàòåðòü 400-500 ãð.
1 õàëàò 900-1200 ãð.
1 ïîëîòåíöå 150-250 ãð.
Èçäåëèÿ, òðåáóþùèå äåëèêàòíîé
ñòèðêè
Ðóáàøêè: èñïîëüçóéòå ñïåöèàëüíóþ ïðîãðàììó 10
äëÿ ñòèðêè ðó àøåê èç ðàçíûõ òêàíåé è ðàçíûõ
öâåòîâ.
Ýòî î åñïå÷èò ìàêñèìàëüíóþ ñîõðàííîñòü âåùåé è
ñäåëàåò èõ ìåíåå ìÿòûìè.
Øåëê: èñïîëüçóéòå ñïåöèàëüíóþ ïðîãðàììó 11 äëÿ
ñòèðêè âñåõ øåëêîâûõ âåùåé. Ðåêîìåíäóåòñÿ
èñïîëüçîâàòü ñïåöèàëüíîå ñòèðàëüíîå âåùåñòâî
äëÿ äåëèêàòíûõ òêàíåé.
Çàíàâåñêè: ñâåðíèòå è ïîëîæèòå â íàâîëî÷êó èëè â
ñåò÷àòûé ìåøî÷åê. Èñïîëüçóéòå ïðîãðàììó 11.
Øåðñòü: Ñòèðàëüíàÿ ìàøèíà ìàðêè Hotpoint/Ariston
åäèíñòâåííàÿ ïîëó÷èëà ïðåñòèæíûé çíàê Woolmark
Platinum Care (M.0508) îò Êîìïàíèè The Woolmark
Company, êîòîðûé ñåðòèôèöèðóåò ìàøèííóþ ñòèðêó
âñåõ øåðñòÿíûõ èçäåëèé, äàæå òåõ, íà ýòèêåòêàõ
êîòîðûõ óêàçàíî «òîëüêî ðó÷íàÿ ñòèðêà» . Ïðè
âû îðå ïðîãðàììû 12 âû ìîæåòå íàäåæíî è
ýôôåêòèâíî ñòèðàòü ëþ ûå øåðñòÿíûå èçäåëèÿ
(ìàêñ. 1 êã) ñ ãàðàíòèðîâàííûì ëó÷øèìè
ðåçóëüòàòàìè.
Ñèñòå à áàëàíñèðîâêè áåëüÿ
Ïåðåä êàæäûì îòæèìîì âî èç åæàíèå ÷ðåçìåðíûõ
âè ðàöèé è äëÿ ðàâíîìåðíîãî ðàñïðåäåëåíèÿ åëüÿ
â àðà àíå ìàøèíà ïðîèçâîäèò âðàùåíèÿ ñî
ñêîðîñòüþ, ñëåãêà ïðåâûøàþùåé ñêîðîñòü ñòèðêè.
Åñëè ïîñëå íåñêîëüêèõ ïîïûòîê åëüå íå óäåò
ïðàâèëüíî ñ àëàíñèðîâàíî, ìàøèíà ïðîèçâåäåò
îòæèì íà ìåíüøåé ñêîðîñòè ïî ñðàâíåíèþ ñ
ïðåäóñìîòðåííîé.
