Hotpoint Ariston ARXXL105 User manual

GB
1
English,1
Contents
Installation, 2-3
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Description of the washing machine
and starting a wash cycle, 4-5
Control panel
Indicator lights
Starting a wash cycle
ash cycles, 6
Table of wash cycles
Personalisation, 7
Setting the temperature
Setting the spin speed
Functions
Detergents and laundry, 8
Detergent dispenser drawer
Bleach cycle
reparing the laundry
Garments requiring special care
Load balancing system
Precautions and tips, 9
General safety
Disposal
Opening the porthole door manually
Care and maintenance, 10
Cutting off the water or electricity supply
Cleaning the washing machine
Cleaning the detergent dispenser drawer
Caring for the door and drum of your appliance
Cleaning the pump
Checking the water inlet hose
Troubleshooting, 11
Service, 12
GB
ARXXL 105
Instructions for use
ASHING MACHINE
RO
Românã,25
GR
ÅËËÇÍÉÊÁ,13
ES
Español,37
PT
Português,49

2
GB
A
Installation
 This instruction manual should be kept in a safe
place for future reference. If the washing machine is
sold, transferred or moved, make sure that the
instruction manual remains with the machine so that
the new owner is able to familiarise himself/herself
with its operation and features.
 Read these instructions carefully: they contain vital
information relating to the safe installation and
operation of the appliance.
Unpacking and levelling
Unpacking
1. Remove the washing machine from its packaging.
2. Make sure that the washing machine has not been
damaged during the transportation process. If it has
been damaged, contact the retailer and do not
proceed any further with the installation process.
3. Remove the 3
protective screws (used
during transportation) and
the rubber washer with
the corresponding
spacer, located on the
rear part of the appliance
(see figure).
4. Close off the holes using the plastic plugs provided.
5. Keep all the parts in a safe place: you will need
them again if the washing machine needs to be
moved to another location.
 ackaging materials should not be used as toys for
children.
Levelling
1. Install the washing machine on a flat sturdy floor,
without resting it up against walls, furniture cabinets
or anything else.
2. If the floor is not
perfectly level, compen-
sate for any unevenness
by tightening or loosening
the adjustable front feet
(see figure); the angle of
inclination, measured in
relation to the worktop,
must not exceed 2°.
Levelling the machine correctly will provide it with
stability, help to avoid vibrations and excessive noise
and prevent it from shifting while it is operating. If it is
placed on carpet or a rug, adjust the feet in such a
way as to allow a sufficient ventilation space
underneath the washing machine.
Connecting the electricity and water
supplies
Connecting the water inlet hose
1. Insert seal A into the
end of the inlet hose and
screw the latter onto a
cold water tap with a 3/4
gas threaded opening
(see figure).
Before performing the
connection, allow the
water to run freely until it
is perfectly clear.
2. Connect the inlet hose
to the washing machine
by screwing it onto the
corresponding water inlet
of the appliance, which is
situated on the top right-
hand side of the rear part
of the appliance (see
figure).
3. Make sure that the hose is not folded over or bent.
 The water pressure at the tap must fall within the
values indicated in the Technical details table (see
next page).
 If the inlet hose is not long enough, contact a
specialised shop or an authorised technician.
 Never use second-hand hoses.
 Use the ones supplied with the machine.

GB
3
Technical data
Model ARXXL 105
Dimensions
width 59.5 cm
height 85 cm
depth 56,5 cm
Capacity from 1 to 7 kg
Electrical
connections
please refer to the technical data
plate fixed to the machine
ater connections
maximum pressure 1 M a (10 bar)
minimum pressure 0.05 M a (0.5 bar)
drum capacity 52 litres
Spin speed up to 1000 rotations per minute
Energy rated
programmes
according to
regulation
EN 60456
programme 6; temperature 60°C;
using a load of 7 kg.
This appliance conforms to the
following EC Directives:
- 72/23/EEC dated 19/02/73 (Low
Voltage) and subsequent modifications
- 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility) and
subsequent modifications
- 2002/96/EC
65 - 100 cm
Connecting the drain hose
Connect the drain hose,
without bending it, to a
drainage duct or a wall
drain located at a height
between 65 and 100 cm
from the floor;
alternatively, rest it on
the side of a washbasin
or bathtub, fastening the
duct supplied to the tap
(see figure). The free end
of the hose should not
be underwater.
 We advise against the use of hose extensions; if it is
absolutely necessary, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Electrical connections
Before plugging the appliance into the electricity
socket, make sure that:
 the socket is earthed and complies with all
applicable laws;
 the socket is able to withstand the maximum power
load of the appliance as indicated in the Technical
data table (see opposite);
 the power supply voltage falls within the values
indicated in the Technical data table (see opposite);
 the socket is compatible with the plug of the
washing machine. If this is not the case, replace
the socket or the plug.
 The washing machine must not be installed
outdoors, even in covered areas. It is extremely
dangerous to leave the appliance exposed to rain,
storms and other weather conditions.
 When the washing machine has been installed, the
electricity socket must be within easy reach.
 Do not use extension cords or multiple sockets.
 The cable should not be bent or compressed.
 The power supply cable must only be replaced by
authorised technicians.
Warning! The company shall not be held responsible
in the event that these regulations are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, using the wash cycle 1.

4
GB
Detergent dispenser drawer: used to dispense
detergents and washing additives (see Detergents
and laundry).
There is a key which provides a summary of the
available wash cycles inside the detergent dispenser
drawer; this may be consulted at any time.
ON/OFF button: switches the washing machine on
and off.
ASH CYCLE knob: programmes the wash cycles.
During the wash cycle, the knob does not move.
FUNCTION buttons with indicator light: used to
select the available functions. The indicator light
corresponding to the selected function will remain lit.
TEMPERATURE knob: sets the temperature or the
cold wash cycle (see Personalisation).
SPIN SPEED knob: sets the spin speed or exclude
the spin cycle completely (see Personalisation).
ASH CYCLE PROGRESS/DELAY TIMER
indicator light s: used to monitor the progress of the
wash cycle.
The illuminated indicator light shows which phase is in
progress.
If the Delay Timer function has been set, the time
remaining until the wash cycle starts will be indicated
(see next page).
DOOR LOCKED indicator light: indicates whether
the door may be opened or not (see next page).
START/PAUSE button with indicator light: starts or
temporarily interrupts the wash cycles.
N.B. To pause the wash cycle in progress, press this
button; the corresponding indicator light will flash
orange, while the indicator light for the current wash
cycle phase will remain lit in a fixed manner. If the
DOOR LOCKED indicator light is switched off, the
door may be opened.
To start the wash cycle from the point at which it was
interrupted, press this button again.
Description of the washing machine
and starting a wash cycle
TEMPERATURE
knob
Detergent dispenser drawer
ASH CYCLE PROGRESS/
DELAY TIMER
indicator lights
FUNCTION
buttons with
indicator lights
ON/OFF button
SPIN SPEED
knob
DOOR
LOCKED
indicator light
START/PAUSE
button with indicator
light
Control panel
ASH CYCLE
knob

GB
5
Indicator lights
The indicator lights provide important information.
This is what they can tell you:
Delayed start
If the DELAY TIMER function has been activated (see
Personalisation), after the wash cycle has been
started the indicator light corresponding to the
selected delay period will begin to flash:
As time passes, the remaining delay will be displayed
and the corresponding indicator light will flash:
Once the set delay has elapsed, the flashing indicator
light will switch off and the selected wash cycle will
begin.
ash cycle phase indicator lights
Once the desired wash cycle has been selected and has
begun, the indicator lights switch on one by one to
indicate which phase of the cycle is currently in progress.
Function buttons and corresponding indicator
lights
When a function is selected, the corresponding
indicator light will illuminate.
If the selected function is not compatible with the
programmed wash cycle, the corresponding indicator
light will flash and the function will not be activated.
If a function which is incompatible with another
function selected previously, only the most recent
selection will remain active.
Door locked indicator light
If this indicator light is on, the appliance door is locked
to prevent it from being opened accidentally; to avoid
any damage, wait for the indicator light to switch off
before you open the appliance door.
N.B. If the DELAY TIMER function is activated, the door
cannot be opened; pause the machine by pressing the
START/ AUSE button if you wish to open it.
 If the START/ AUSE indicator light (orange) flashes
rapidly at the same time as the function indicator
light, this indicates a problem has occurred (see
Troubleshooting).
Starting a wash cycle
1. Switch the washing machine on by pressing the ON/OFF button. All indicator lights will switch on for a few
seconds, then they will switch off and the START/ AUSE indicator light will pulse.
2. Load the laundry and close the door.
3. Set the WASH CYCLE knob to the desired programme.
4. Set the washing temperature (see Personalisation).
5. Set the spin speed (see Personalisation).
6. Measure out the detergent and washing additives (see Detergents and laundry).
7. Select the desired functions.
8. Start the wash cycle by pressing the START/ AUSE button and the corresponding indicator light will remain lit
in a fixed manner, in green.
To cancel the set wash cycle, pause the machine by pressing the START/ AUSE button and select a new cycle.
9. At the end of the wash cycle the indicator light will switch on. The DOOR LOCKED indicator light will switch
off, indicating that the door may be opened. Take out your laundry and leave the appliance door ajar to make
sure the drum dries completely.
Switch the washing machine off by pressing the ON/OFF button.
Wash
Rinse
Spin
Drain
End of wash cycle

6
GB
ash cycles
The information contained in the table is intended as a guide only.
For all Test Institutes:
1) Test wash cycle in co pliance with regulation EN 60456: set wash cycle 6 with a te perature of 60°C.
2) Long wash cycle for cottons: set wash cycle 1 with a te perature of 40°C.
3) Short wash cycle for cottons: set wash cycle 2 with a te perature of 40°C.
Wash cycles
Table of wash cycles
Description of the wash cycle
Max
te p.
(°C)
Max.
speed
(rp )
Detergents Max.
load
(kg)
Cycle
duration
Bleach Wash Fabric
softener
Special cycles
6Sanitizing cycle: Extremely soiled whites. 90° 1000 ll l 7165
6Sanitizing cycle (1): Heavily soiled whites and resistant colours. 60° 1000 -ll
7175
7Goodnigt cycle: Lightly soiled delicate colours. 40° 800 -ll
4290
8Baby cycle: Heavily soiled delicate colours. 40° 800 -ll
2 118
9Shirts 40° 600 -ll
270
10 Silk/Curtains: For garments in silk and viscose, lingerie. 30° 0 -ll
255
11 Wool: For wool, cashmere, etc. 40° 600 -ll
1,5 55
Everyday wash cycles (Daily)
1Cotton: Heavily soiled whites and resistant colours. 60° 1000 ll l 7 130
1Cotton (2): Heavily soiled whites and delicate colours. 40° 1000 ll l 7 115
2Coloured Cottons (3): Lightly soiled whites and delicate colours. 40° 1000 ll l 785
3Synthetics resistents: Heavily soiled resistant colours. 60° 800 -ll
385
3Synthetics delicates: Lightly soiled resistant colours. 40° 800 -ll
370
4Mix 30': To refresh lightly soiled garments quickly (not suitable
for wool, silk and clothes which require washing by hand). 30° 800 -ll
330
5Mix 15': To refresh lightly soiled garments quickly (not suitable
for wool, silk and clothes which require washing by hand). 30° 800 -ll
1,5 15
Partial wash cycles
ARinse -1000 - - l744
BLight rinse -800 - - l337
CSpin -1000 - - - 716
DLight spin -800 - - - 312
EDrain no spin -0- - - 72
Specials wash cycles
Sanitizing cycle (wash cycle 6). A high-temperature hygienic wash cycle (over 60°C) which requires the use of bleach.
our the bleach, the detergent and the additives into the relevant compartments (see paragraph entitled
Detergent dispenser drawer).
Goodnigt cycle (wash cycle 7). This is a silent cycle which can be run at night, when the electricity prices are lower. The
wash cycle is designed for cottons and synthetics. At the end of the cycle the machine stops while there is still water in
the drum; to spin and drain the laundry press the START/ AUSE button; alternatively the machine will perform the spin
cycle and drain the water automatically after 8 hours.
Baby cycle (wash cycle 8). This wash cycle can be used to remove the soiling typically caused by babies, while ensuring
that all detergent is removed from nappies in order to prevent the delicate skin of babies from suffering allergies. The
cycle has been designed to reduce the amount of bacteria by using a greater quantity of water and optimising the effect
of special disinfecting additives added to the detergent.
At the end of the wash cycle, the machine will slowly rotate the drum to prevent the formation of creases; to end the cycle
press the START/ AUSE button.
Mix 30(wash cycle 4) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 30 minutes and
therefore saves both energy and time. By selecting this wash cycle (4 at 30°C), it is possible to wash different fabrics
together (except for wool and silk items), with a maximum load of 3 kg.
Mix 15(wash cycle 5) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 15 minutes and
therefore saves both energy and time. By selecting this wash cycle (5 at 30°C), it is possible to wash different fabrics
together (except for wool and silk items), with a maximum load of 1.5 kg.

GB
7
Setting the temperature
Turn the TEM ERATURE knob to set the wash temperature (see Table of wash cycles).
The temperature may be lowered, or even set to a cold wash ( ).
The washing machine will automatically prevent you from selecting a temperature which is higher than the
maximum value set for each wash cycle.
Setting the spin speed
Turn the S IN S EED knob to set the spin speed for the selected wash cycle.
The maximum spin speeds available for each wash cycle are as follows:
Wash cycles Maxi u spin speed
Cottons 1000 rpm
Synthetics 800 rpm
Wool 600 rpm
Silk drain only
The spin speed may be lowered, or the spin cycle can be excluded altogether by selecting the symbol .
The washing machine will automatically prevent you from selecting a spin speed which is higher than the
maximum speed set for each wash cycle.
Functions
The various wash functions available with this washing machine will help to achieve the desired results, every time.
To activate the functions:
1. ress the button corresponding to the desired function;
2. the function is enabled when the corresponding indicator light is illuminated.
Note: If the indicator light flashes rapidly, this signals that this particular function may not be selected in
conjunction with the selected wash cycle.
Delay timer
This timer delays the start time of the wash cycle by up to 12 hours.
ress the button repeatedly until the indicator light corresponding to the desired delay time switches on. The fifth time
the button is pressed, the function will be disabled.
N.B. Once you have pressed the START/ AUSE button, the delay time may only be decreased if you wish to modify it.
This option is enabled with all programmes.
Easy iron
By selecting this function, the wash and spin cycles will be modified in order to reduce the formation of creases.
At the end of the cycle the washing machine will perform slow rotations of the drum; the EASY IRON and START/
AUSE indicator lights will flash (orange) and the RINSE phase will remain lit in a fixed manner. To end the cycle,
press the START/ AUSE button or the EASY IRON button.
For the Silk (10) wash cycle, the machine will end the cycle while the laundry is soaking and the EASY IRON
indicator light will flash. To drain the water so that the laundry may be removed, press the START/ AUSE button or
the EASY IRON button.
 This function may not be used in conjunction with wash cycles 4, 5, 6, 7, 8, 11, C, D, E.
Extra rinse
By selecting this function, the efficiency of the rinse is increased and optimal detergent removal is guaranteed. It is
particularly useful for sensitive skin.
 This function may not be used in conjunction with wash cycles 4, 5, C, D, E.
Super ash
Because a greater quantity of water is used in the initial phase of the cycle, and because of the increased cycle
duration, this function offers a high-performance wash.
 This function may not be used in conjunction with wash cycles 4, 5, 6, 10, 11, A, B, C, D, E.
Personalisation

8
GB
Detergents and laundry
Detergent dispenser drawer
Good washing results also depend on the correct
dose of detergent: adding too much detergent will not
necessarily result in a more efficient wash, and may in
fact cause build up on the inside of your appliance
and contribute to environmental pollution.
 Do not use hand washing detergents because these
create too much foam.
Open the detergent
dispenser drawer and
pour in the detergent or
washing additive, as
follows.
compartment 1: Pre-wash detergent (powder)
Before pouring in the detergent, make sure that extra
compartment 4 has been removed.
compartment 2: Detergent for the wash cycle
(powder or liquid)
Liquid detergent should only be poured in immediately
prior to the start of the wash cycle.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overflow the grid.
extra compartment 4: Bleach
Bleach cycle
Bleaching may only be performed in conjunction with
wash cycles 1, 2, 6.
our the bleach into extra compartment 4; pour the
detergent and softener into the corresponding
compartments, then select one of the
abovementioned wash cycles.
This option is recommended only for very soiled
cotton garments.
Preparing the laundry
 Divide the laundry according to:
- the type of fabric/the symbol on the label
- the colours: separate coloured garments from
whites.
 Empty all garment pockets and check the buttons.
 Do not exceed the listed values, which refer to the
weight of the laundry when dry:
Durable fabrics: max. 7 kg
Synthetic fabrics: max. 3 kg
Delicate fabrics: max. 2 kg
Wool: max. 1.5 kg
MAX
1
2
4
3
How much does your laundry weigh?
1 sheet 400-500 g
1 pillow case 150-200 g
1 tablecloth 400-500 g
1 bathrobe 900-1200 g
1 towel 150-250 g
Garments requiring special care
Shirts: use special wash cycle 9 to wash shirts in
various fabrics and colours.
It guarantees maximum care is taken of the garments
and minimises the formation of creases.
Silk: use special wash cycle 10 to wash all silk
garments. We recommend the use of special
detergent which has been designed to wash delicate
clothes.
Curtains: these should be folded and placed inside
the bag provided. Use wash cycle 10.
ool: Hotpoint/Ariston is the only washing machine
manufacturer to have been awarded the prestigious
Woolmark latinum Care endorsement (M.0508) by
the Woolmark Company, which means that all
woollen garments may be washed in the washing
machine, even those which state hand wash only
on the label. Wash cycle 11 therefore offers
complete peace of mind when washing woollen
garments in the washing machine (max. load 1.5 kg)
and guarantees optimal performance.
Load balancing system
Before every spin cycle, to avoid excessive vibrations
and to distribute the load in a uniform manner, the drum
rotates continuously at a speed which is slightly greater
than the washing rotation speed. If, after several at-
tempts, the load is not balanced correctly, the machine
spins at a reduced spin speed. If the load is excessively
unbalanced, the washing machine performs the distri-
bution process instead of spinning. To encourage im-
proved load distribution and balance, we recommend
small and large garments are mixed in the load.

GB
9
Precautions and tips
 This washing machine was designed and
constructed in accordance with international safety
regulations. The following information is provided for
safety reasons and must therefore be read carefully.
General safety
 This appliance was designed for domestic use only.
 The washing machine must only be used by adults, in
accordance with the instructions provided in this manual.
 Do not touch the machine when barefoot or with
wet or damp hands or feet.
 Do not pull on the power supply cable when
unplugging the appliance from the electricity
socket. Hold the plug and pull.
 Do not open the detergent dispenser drawer while
the machine is in operation.
 Do not touch the drained water as it may reach
extremely high temperatures.
 Never force the porthole door. This could damage
the safety lock mechanism designed to prevent
accidental opening.
 If the appliance breaks down, do not under any
circumstances access the internal mechanisms in
an attempt to repair it yourself.
 Always keep children well away from the appliance
while it is operating.
 The door can become quite hot during the wash cycle.
 If the appliance has to be moved, work in a group
of two or three people and handle it with the utmost
care. Never try to do this alone, because the
appliance is very heavy.
 Before loading laundry into the washing machine,
make sure the drum is empty.
Disposal
 Disposing of the packaging materials: observe local
regulations so that the packaging may be re-used.
 The European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment, requires that
old household electrical appliances must not be
disposed of in the normal unsorted municipal waste
stream. Old appliances must be collected
separately in order to optimise the recovery and
recycling of the materials they contain and reduce
the impact on human health and the environment.
The crossed out "wheeled bin" symbol on the
product reminds you of your obligation, that when
you dispose of the appliance it must be separately
collected.
Consumers should contact their local authority or
retailer for information concerning the correct
disposal of their old appliance.
Opening the porthole door manually
In the event that it is not possible to open the
porthole door due to a powercut, and if you wish to
remove the laundry, proceed as follows:
1. remove the plug from
the electrical socket.
2. make sure the water
level inside the machine is
lower than the door
opening; if it is not, remove
excess water using the
drain hose, collecting it in a
bucket as indicated in the
figure.
3. using a screwdriver,
remove the cover panel on
the lower front part of the
washing machine (see
figure).
4. pull outwards using the tab as indicated in the
figure, until the plastic tie-rod is freed from its stop
position; pull downwards and open the door at the
same time.
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
20

10
GB
Care and maintenance
Cutting off the water and electricity
supplies
 Turn off the water tap after every wash cycle. This
will limit wear on the hydraulic system inside the
washing machine and help to prevent leaks.
 Unplug the washing machine when cleaning it and
during all maintenance work.
Cleaning the washing machine
The outer parts and rubber components of the
appliance can be cleaned using a soft cloth soaked
in lukewarm soapy water. Do not use solvents or
abrasives.
Cleaning the detergent dispenser
drawer
Remove the dispenser
by raising it and pulling it
out (see figure).
Wash it under running
water; this operation
should be repeated
frequently.
Caring for the door and drum of your
appliance
 Always leave the porthole door ajar in order to
prevent unpleasant odours from forming.
Cleaning the pump
The washing machine is fitted with a self-cleaning
pump which does not require any maintenance.
Sometimes, small items (such as coins or buttons)
may fall into the pre-chamber which protects the
pump, situated in its bottom part.
 Make sure the wash cycle has finished and unplug
the appliance.
To access the pre-chamber:
1. using a screwdriver,
remove the cover panel
on the lower front part of
the washing machine
(see figure);
2. unscrew the lid by
rotating it anti-clockwise
(see figure) a little water
may trickle out. This is
perfectly normal;
3. clean the inside thoroughly;
4. screw the lid back on;
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
Checking the water inlet hose
Check the inlet hose at least once a year. If there are
any cracks, it should be replaced immediately: during
the wash cycles, water pressure is very strong and a
cracked hose could easily split open.
 Never use second-hand hoses.
1
2

GB
11
Troubleshooting
Your washing machine could fail to work. Before contacting the Technical Assistance Centre (see Assistance),
make sure that the problem cannot be not solved easily using the following list.
Problem:
The washing machine does not
switch on.
The wash cycle does not start.
The washing machine does not
take in water (the indicator light
for the first wash cycle stage
flashes rapidly).
The washing machine
continuously takes in and drains
water.
The washing machine does not
drain or spin.
The washing machine vibrates a
lot during the spin cycle.
The washing machine leaks.
The START/PAUSE indicator light
(orange) and the function
indicator lights flash rapidly.
There is too much foam.
Possible causes / Solutions:
 The appliance is not plugged into the socket fully, or is not making contact.
 There is no power in the house.
 The washing machine door is not closed properly.
 The ON/OFF button has not been pressed.
 The START/ AUSE button has not been pressed.
 The water tap has not been opened.
 A delayed start has been set (see Personalisation).
 The water inlet hose is not connected to the tap.
 The hose is bent.
 The water tap has not been opened.
 There is no water supply in the house.
 The pressure is too low.
 The START/ AUSE button has not been pressed.
 The drain hose is not fitted at a height between 65 and 100 cm from
the floor (see Installation).
 The free end of the hose is under water (see Installation).
 The wall drainage system is not fitted with a breather pipe.
If the problem persists even after these checks, turn off the water tap,
switch the appliance off and contact the Assistance Service. If the
dwelling is on one of the upper floors of a building, there may be problems
relating to water drainage, causing the washing machine to fill with water
and drain continuously. Special anti-draining valves are available in shops
and help to avoid this inconvenience.
 The wash cycle does not include draining: some wash cycles require
the drain phase to be started manually.
 The EASY IRON function has been activated: To complete the wash
cycle, press the START/ AUSE button (Personalisation).
 The drain hose is bent (see Installation).
 The drainage duct is clogged.
 The drum was not unlocked correctly during installation (see Installation).
 The washing machine is not level (see Installation).
 The washing machine is trapped between cabinets and walls (see Installation).
 The water inlet hose is not screwed on properly (see Installation).
 The detergent dispenser drawer is blocked (for cleaning instructions, see
Care and maintenance).
 The drain hose is not fixed properly (see Installation).
 Switch off the machine and unplug it, wait for approximately 1 minute
and then switch it back on again.
If the problem persists, contact the Technical Assistance Service.
 The detergent is not suitable for machine washing (it should display the
text for washing machines or hand and machine wash, or the like).
 Too much detergent was used.

12
GB
Service
Before calling for Assistance:
Check whether you can solve the problem alone (see Troubleshooting);
 Restart the programme to check whether the problem has been solved;
 If this is not the case, contact an authorised Technical Assistance Centre using the telephone number
provided on the guarantee certificate.
Always request the assistance of authorised technicians.
Have the following information to hand:
 the type of problem;
 the appliance model (Mod.);
 the serial number (S/N).
This information can be found on the data plate applied to the rear of the washing machine, and can also
be found on the front of the appliance by opening the door.

13
GR
ÅëëçíéêÜ
Ðåñéå÷üìåíá
ÅãêáôÜóôáóç, 14-15
Áðïóõóêåõáóßá êáé ïñéæïíôßùóç
ÕäñáõëéêÝò êáé çëåêôñéêÝò óõíäÝóåéò
Ðñþôïò êýêëïò ðëõóßìáôïò
Ôå÷íéêÜ óôïé÷åßá
ÐåñéãñáöÞ ôïõ ðëõíôçñßïõ êáé åêêßíçóç
åíü ðñïãñÜììáôï , 16-17
Ðßíáêáò åëÝã÷ïõ
ÅíäåéêôéêÜ ùôÜêéá
Åêêßíçóç åíüò ðñïãñÜììáôïò
ÐñïãñÜììáôá, 18
Ðßíáêáò ôùí ÐñïãñáììÜôùí
Åîáôïìéêåýóåé , 19
ÈÝóôå ôç èåñìïêñáóßá
ÈÝóôå ôï óôýøéìï
Ëåéôïõñãßåò
ÁðïññõðáíôéêÜ êáé ìðïõãÜäá, 20
ÈÞêç áðïññõðáíôéêþí
Êýêëïò ëåýêáíóçò
Ðñïåôïéìáóßá ôçò ìðïõãÜäáò
ÅéäéêÜ ñïý÷á
Óýóôçìá éóïóôÜèìéóçò ôïõ ïñôßïõ
ÐñïöõëÜîåé êáé óõìâïõëÝ , 21
ÃåíéêÞ áó Üëåéá
ÄéÜèåóç
×åéñïíáêôéêü Üíïéãìá ôçò ðüñôáò
ÓõíôÞñçóç êáé öñïíôßäá, 22
Áðïêëåéóìüò íåñïý êáé çëåêôñéêïý ñåýìáôïò
Êáèáñéóìüò ôïõ ðëõíôçñßïõ
Êáèáñéóìüò ôïõ óõñôáñéïý áðïññõðáíôéêþí
Öñïíôßäá ôçò ðüñôáò êáé ôïõ êÜäïõ
Êáèáñéóìüò ôçò áíôëßáò
¸ëåã÷ïò ôïõ óùëÞíá ôñï ïäïóßáò ôïõ íåñïý
Áíùìáëßå êáé ëýóåé , 23
ÕðïóôÞñéîç, 24
GR
ARXXL 105
Ïäçãßå ÷ñÞóç
ÐËÕÍÔÇÑÉÏ ÑÏÕ×ÙÍ

14
GR
A
ÅãêáôÜóôáóç
 Åßíáé óçìáíôéêü íá äéáôçñÞóåôå ôï åã÷åéñßäéï áõôü
ãéá íá ìðïñåßôå íá ôï óõìâïõëåýåóôå ïðïéáäÞðïôå
óôéãìÞ. Óå ðåñßðôùóç ðþëçóçò, ðáñá÷þñçóçò Þ
ìåôáêüìéóçò, âåâáéùèåßôå üôé ðáñáìÝíåé ìáæß ìå ôï
ðëõíôÞñéï ãéá íá ðëçñï ïñåß ôïí íÝï éäéïêôÞôç ãéá
ôç ëåéôïõñãßá êáé ôéò ó÷åôéêÝò ðñïåéäïðïéÞóåéò.
 ÄéáâÜóôå ðñïóåêôéêÜ ôéò ïäçãßåò: õðÜñ÷ïõí
óçìáíôéêÝò ðëçñï ïñßåò ãéá ôçí åãêáôÜóôáóç, ôç
÷ñÞóç êáé ôçí áó Üëåéá.
Áðïóõóêåõáóßá êáé ïñéæïíôßùóç
Áðïóõóêåõáóßá
1. ÁðïóõóêåõÜóôå ôï ðëõíôÞñéï.
2. ÅëÝãîôå áí ôï ðëõíôÞñéï Ý÷åé õðïóôåß æçìéÝò êáôÜ
ôç ìåôá ïñÜ. Áí Ý÷åé õðïóôåß æçìéÝò ìçí ôï
óõíäÝåôå êáé åðéêïéíùíÞóôå ìå ôïí ìåôáðùëçôÞ.
3. Á áéñÝóôå ôéò ! âßäåò
ðñïóôáóßáò ãéá ôç
ìåôá ïñÜ êáé ôï
ëáóôé÷Üêé ìå ôï ó÷åôéêü
äéá÷ùñéóôéêü, ðïõ
âñßóêïíôáé óôï ðßóù
ìÝñïò (âëÝðå åéêüíá).
4. Êëåßóôå ôéò ïðÝò ìå ôá ðëáóôéêÜ ðþìáôá ðïõ óáò
ðáñÝ÷ïíôáé.
5. Äéáôçñåßóôå êáé ôá ôñßá ôåìÜ÷éá: áí ôï ðëõíôÞñéï
÷ñåéáóôåß íá ìåôá åñèåß, èá ðñÝðåé íá
îáíáìïíôáñéóôïýí.
 Ïé óõóêåõáóßåò äåí åßíáé ðáé÷íßäéá ãéá ìéêñÜ
ðáéäéÜ.
ÅõèõãñÜììéóç
1. ÅãêáôáóôÞóôå ôï ðëõíôÞñéï óå Ýíá äÜðåäï
åðßðåäï êáé áíèåêôéêü, ÷ùñßò íá ôï áêïõìðÞóåôå óå
ôïß÷ïõò, Ýðéðëá Þ Üëëï.
2. Áí ôï äÜðåäï äåí åßíáé
áðüëõôá ïñéæïíôéùìÝíï,
áíôéóôáèìßóôå ôéò
áíùìáëßåò âéäþíïíôáò Þ
îåâéäþíïíôáò ôá ðñüóèéá
ðïäáñÜêéá (âëÝðå
åéêüíá). Ç ãùíßá êëßóçò,
ìåôñçìÝíç óôçí
åðé Üíåéá åñãáóßáò, äåí
ðñÝðåé íá îåðåñíÜåé ôéò
2°.
Ìéá ñïíôéóìÝíç ïñéæïíôßùóç ðñïóäßäåé óôáèåñüôçôá
óôç ìç÷áíÞ êáé áðïóïâåß äïíÞóåéò, èïñýâïõò êáé
ìåôáôïðßóåéò êáôÜ ôç ëåéôïõñãßá. Óå ðåñßðôùóç
ìïêÝôáò Þ ôÜðçôá, ñõèìßóôå ôá ðïäáñÜêéá Ýôóé þóôå
íá õ ßóôáôáé êÜôù áðü ôï ðëõíôÞñéï áñêåôüò ÷þñïò
ãéá ôïí áåñéóìü.
ÕäñáõëéêÝ êáé çëåêôñéêÝ óõíäÝóåé
Óýíäåóç ôïõ óùëÞíá ôñïöïäïóßá ôïõ íåñïý
1. ÅéóÜãåôå ôçí ôóéìïý÷á
A óôï Üêñï ôïõ óùëÞíá
ôñï ïäïóßáò êáé âéäþóôå
ôç óå Ýíá êñïõíü êñýïõ
íåñïý ìå óôüìéï
óðåéñþìáôïò 3/4 gas
(âëÝðå åéêüíá).
Ðñéí ôç óýíäåóç, á Þóôå
íá ôñÝîåé ôï íåñü ìÝ÷ñé
íá ãßíåé äéáõãÝò.
2. ÓõíäÝóôå ôï óùëÞíá
ôñï ïäïóßáò óôï
ðëõíôÞñéï âéäþíïíôÜò
ôïí óôçí áíôßóôïé÷ç
åßóïäï íåñïý, óôï ðßóù
ìÝñïò åðÜíù äåîéÜ
(âëÝðå åéêüíá).
3. ÐñïóÝîôå þóôå óôï óùëÞíá íá ìçí õðÜñ÷ïõí
ïýôå ðôõ÷þóåéò, ïýôå óôåíþóåéò.
 Ç ðßåóç íåñïý ôïõ êñïõíïý ðñÝðåé íá êõìáßíåôáé
ìåôáîý ôùí ôéìþí ôïõ ðßíáêá Ôå÷íéêÜ óôïé÷åßá
(âëÝðå óåëßäá äßðëá).
 Áí ôï ìÞêïò ôïõ óùëÞíá ôñï ïäïóßáò äåí
åðáñêåß, áðåõèõíèåßôå óå Ýíá åéäéêåõìÝíï
êáôÜóôçìá Þ óå Ýíá åîïõóéïäïôçìÝíï ôå÷íéêü.
 Ìç ÷ñçóéìïðïéåßôå ðïôÝ ÷ñçóéìïðïéçìÝíïõò
óùëÞíåò.
 ×ñçóéìïðïéåßôå åêåßíïõò ðïõ óáò ðáñÝ÷ïíôáé ìå
ôç ìç÷áíÞ.

15
GR
65 - 100 cm
Óýíäåóç ôïõ óùëÞíá áäåéÜóìáôï
ÓõíäÝóôå áäåéÜóìáôïò,
÷ùñßò íá ôïí äéðëþóåôå,
óå Ýíáí áãùãü
åêêÝíùóçò Þ óå ìéá
åðéôïß÷éá áðï÷Ýôåõóç óå
áðüóôáóç áðü 65 Ýùò
100 cm áðü ôï Ýäá ïò.
Äéá ïñåôéêÜ áðïèÝóôå
ôïí óôï ÷åßëïò åíüò
íéðôÞñá Þ ìéáò ëåêÜíçò,
äÝíïíôáò ôïí ïäçãü ðïõ
óáò ðáñÝ÷åôáé
óôïíêñïõíü (âëÝðå
åéêüíá). Ôï åëåýèåñï
Üêñï ôïõ óùëÞíá
áäåéÜóìáôïò äåí ðñÝðåé
íá ðáñáìÝíåé
âõèéóìÝíï óôï íåñü.
 Äåí óõíéóôÜôáé ç ÷ñÞóç ðñïåêôÜóåùí óùëÞíùí.
Áí áðáéôåßôáé, ç ðñïÝêôáóç ðñÝðåé íá Ý÷åé ôçí ßäéá
äéÜìåôñï ôïõ áñ÷éêïý óùëÞíá êáé íá ìçí îåðåñíÜåé
ôá 150 cm.
ÇëåêôñéêÞ óýíäåóç
Ðñéí åéóÜãåôå ôï âýóìá óôçí çëåêôñéêÞ ðñßæá,
âåâáéùèåßôå üôé:
 ç ðñßæá äéáèÝôåé ãåßùóç êáé ôçñåß ôéò åê ôïõ íüìïõ
ðñïäéáãñá Ýò.
 Ç ðñßæá íá åßíáé óå èÝóç íá õðï Ýñåé ôï ìÝãéóôï
ïñôßï éó÷ýïò ôçò ìç÷áíÞò, ðïõ áíá Ýñåôáé óôïí
ðßíáêá Ôå÷íéêþí óôïé÷åßùí (âëÝðå äßðëá).
 Ç ôÜóç ôñï ïäïóßáò íá êõìáßíåôáé ìåôáîý ôùí
ôéìþí ðïõ áíá Ýñïíôáé óôïí ðßíáêá Ôå÷íéêþí
óôïé÷åßùí (âëÝðå äßðëá).
 Ç ðñßæá íá åßíáé óõìâáôÞ ìå ôï âýóìá ôïõ
ðëõíôçñßïõ. Óå áíôßèåôç ðåñßðôùóç,
áíôéêáôáóôÞóôå ôçí ðñßæá Þ ôï âýóìá.
 Ôï ðëõíôÞñéï äåí åãêáèßóôáôáé óå áíïé÷ôü ÷þñï,
áêüìç êáé áí ï ÷þñïò åßíáé êáëõììÝíïò, äéüôé åßíáé
ðïëý åðéêßíäõíï íá ôï á Þíåôå åêôåèåéìÝíï óå
âñï÷Þ êáé êáêïêáéñßá.
 Ìå ôçí åãêáôÜóôáóç ôïõ ðëõíôçñßïõ, ç ðñßæá
ñåýìáôïò ðñÝðåé íá åßíáé åýêïëá ðñïóâÜóéìç.
 Ìç ÷ñçóéìïðïéåßôå ðñïåêôÜóåéò êáé ðïëýðñéæá.
 Ôï êáëþäéï äåí ðñÝðåé íá Ýñåé ðôõ÷Ýò Þ íá åßíáé
óõìðéåóìÝíï.
 Ôï êáëþäéï ôñï ïäïóßáò ðñÝðåé íá áíôéêáèßóôáôáé
ìüíï áðü åîïõóéïäïôçìÝíïõò ôå÷íéêïýò.
Ðñïóï÷Þ! Ç åðé÷åßñçóç áðïðïéåßôáé êÜèå åõèýíçò
óå ðåñßðôùóç ðïõ äåí ôçñïýíôáé áõôïß ïé êáíüíåò.
Ðñþôï êýêëï ðëõóßìáôï
ÌåôÜ ôçí åãêáôÜóôáóç, ðñéí ôç ÷ñÞóç, äéåíåñãÞóôå
Ýíá êýêëï ðëõóßìáôïò ìå áðïññõðáíôéêü êáé ÷ùñßò
ñïý÷á èÝôïíôáò ôï ðñüãñáììá 1.
Ôå÷íéêÜ óôïé÷åßá
ÌïíôÝëï ARXXL 105
ÄéáóôÜóåéò
ðëÜôïò cm 59,5
ýøïò cm 85
âÜèïò cm 56,5
×ùñçôéêüôçôá áðü 1 Ýùò 7 kg
ÇëåêôñéêÝò
óõíäÝóåéò
ëÝðå ôçí ðéíáêßäá
÷áñáêôçñéóôéêþí åðß ôçò ìç÷áíÞò
ÓõíäÝóåéò íåñïý
ìÝãéóôç ðßåóç 1 MPa (10 bar)
ÅëÜ÷éóôç ðßåóç 0,05 MPa (0,5 bar)
÷ùñçôéêüôçôá ôïõ êÜäïõ 52 ëßôñá
Ôá÷ýôçôá
óôõøßìáôïò ìÝ÷ñé 1000 óôñïöÝò ôï ëåðôü
Ðñï ñÜììáôá
åëÝ ÷ïõ óýìöùíá
ìå ôïí êáíïíéóìü
EN 60456
ðñüãñáììá 6; èåñìïêñáóßá 60°C;
åêôåëïýìåíï ìå 7 kg ìðïõãÜäáò.
Ç óõóêåõÞ áõôÞ åßíáé óýìöùíç
ìå ôéò áêüëïõèåò ïéíïôéêÝò
Ïäçãßåò:
- 73/23/CEE ôçò 19/02/73 (×áìçëÞ ÔÜóç)
êáé ìåôáãåíÝóôåñåò ôñïðïðïéÞóåéò
- 89/336/CEE ôçò 03/05/89
(ÇëåêôñïìáãíçôéêÞ Óõìâáôüôçôá)
êáé ìåôáãåíÝóôåñåò ôñïðïðïéÞóåéò
- 2002/96/CE

16
GR
ÈÞêç áðïññõðáíôéêþí: ãéá ôçí ðñïóèÞêç
áðïññõðáíôéêþí êáé ðñüóèåôùí (âëÝðå
«ÁðïññõðáíôéêÜ êáé ìðïõãÜäá»).
Óôï åóùôåñéêü ôçò èÞêçò áðïññõðáíôéêþí âñßóêåôáé
ôï áíáëüãéï, óôï ïðïßï ìðïñåßôå, áíÜ ðÜóá óôéãìÞ,
íá óõìâïõëåõôåßôå Ýíá óõíèåôéêü ó÷Ýäéï ôùí
ðñïãñáììÜôùí.
Êïõìðß ÁÍÁÌÌÁÔÏÓ/ÓÂÇÓÉÌÁÔÏÓ: Ãéá íá
áíÜøåôå Þ íá óâÞóåôå ôï ðëõíôÞñéï.
ÅðéëïãÝáò ÐÑÏÃÑÁÌÌÁÔÙÍ: ãéá íá èÝóåôå ôá
ðñïãñÜììáôá. ÊáôÜ ôç äéÜñêåéá ôïõ ðñïãñÜììáôïò ï
åðéëïãÝáò ðáñáìÝíåé áêßíçôïò.
Êïõìðé Ü ìå åíäåéêôéêÜ ùôÜêéá ËÅÉÔÏÕÑÃÉÁÓ:ãéá
íá åðéëÝîåôå ôéò äéáèÝóéìåò ëåéôïõñãßåò. Ôï ó÷åôéêü
ìå ôçí åðéëåãåßóá ëåéôïõñãßá åíäåéêôéêü ùôÜêé èá
ðáñáìåßíåé áíáììÝíï.
ÅðéëïãÝáò ÓÔÕØÉÌÁÔÏÓ: ãéá íá èÝóåôå ôï óôýøéìï
Þ íá ôï áðïêëåßóåôå (âëÝðå Åîáôïìéêåýóåé ).
ÅðéëïãÝá ÈÅÑÌÏÊÑÁÓÉÁ: ãéá íá èÝóåôå ôç
èåñìïêñáóßá Þ ôï ðëýóéìï óå êñýï íåñü (âëÝðå
«Åîáôïìéêåýóåé »).
ÅÍÄÅÉÊÔÉÊÁ ÖÙÔÁÊÉÁ ÐÑÏÙÈÇÓÇÓ ÊÕÊËÏÕ/
ÊÁÈÕÓÔÅÑÇÌÅÍÇÓ ÅÊÊÉÍÇÓÇÓ: ãéá íá
áêïëïõèåßôå ôçí êáôÜóôáóç ðñïüäïõ ôïõ
ðñïãñÜììáôïò ðëõóßìáôïò.
Ôï áíáììÝíï åíäåéêôéêü ùôÜêé äåß÷íåé ôçí óå
åîÝëéîç Üóç.
Áí ôÝèçêå ç ëåéôïõñãßá ÊáèõóôåñçìÝíç åêêßíçóç,
èá äåß÷íïõí ôïí ÷ñüíï ðïõ õðïëåßðåôáé ãéá ôçí
Ýíáñîç ôïõ ðñïãñÜììáôïò (âëÝðå óåëßäá äßðëá).
Åíäåéêôéêü ùôÜêé ÐÏÑÔÁ ÁÓÖÁËÉÓÌÅÍÇ: ãéá íá
êáôáëÜâåôå áí ç ðüñôá áíïßãåé (âëÝðå óåëßäá
äßðëá).
Êïõìðß ìå åíäåéêôéêü ùôÜêé ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ: ãéá
ôçí åêêßíçóç ôùí ðñïãñáììÜôùí Þ ôçí ðñïóùñéíÞ
äéáêïðÞ ôïõò.
ÓÇÌÅÉÙÓÇ: ãéá íá èÝóåôå óå ðáýóç ôï óå åîÝëéîç
ðëýóéìï, ðéÝóôå ôï êïõìðß áõôü, ôï ó÷åôéêü
åíäåéêôéêü ùôÜêé èá áíÜøåé ìå ðïñôïêáëß ÷ñþìá
åíþ åêåßíï ôçò óå åîÝëéîçò Üóçò èá åßíáé óõíå÷þò
áíáììÝíï. Áí ôï åíäåéêôéêü ùôÜêé ÐÏÑÔÁ
ÁÓÖÁËÉÓÌÅÍÇ óâÞóåé, ìðïñåßôå íá áíïßîåôå
ôçí ðüñôá.
Ãéá íá îåêéíÞóåé ðÜëé ôï ðëýóéìï áðü ôï óçìåßï
äéáêïðÞò, ðáôÞóôå åê íÝïõ ôï êïõìðß áõôü.
ÐåñéãñáöÞ ôïõ ðëõíôçñßïõ êáé
åêêßíçóç åíü ðñïãñÜììáôï
ÅðéëïãÝáò
ÈÅÑÌÏÊÑÁÓÉÁ
ÈÞêç áðïññõðáíôéêþí
ÅÍÄÅÉÊÔÉÊÁ ÖÙÔÁÊÉÁ
ÐÑÏÙÈÇÓÇÓ ÊÕÊËÏÕ/
ÊÁÈÕÓÔÅÑÇÌÅÍÇÓ
ÅÊÊÉÍÇÓÇÓ
Êïõìðé Ü ìå åíäåéêôéêÜ
ùôÜêéá
ËÅÉÔÏÕÑÃÉÁÓ
Êïõìðß
ÁÍÁÌÌÁÔÏÓ/
ÓÂÇÓÉÌÁÔÏÓ
ÅðéëïãÝáò
ÓÔÕØÉÌÁÔÏÓ
Åíäåéêôéêü ùôÜêé
ÐÏÑÔÁ
ÁÓÖÁËÉÓÌÅÍÇ
Êïõìðß ìå
åíäåéêôéêü ùôÜêé
ÅÊÊÉÍÇÓÇ/
ÐÁÕÓÇ
Ðßíáêá åëÝã÷ïõ
ÅðéëïãÝáò
ÐÑÏÃÑÁÌÌÁÔÙÍ

17
GR
ÅíäåéêôéêÜ öùôÜêéá
Ôá åíäåéêôéêÜ ùôÜêéá ðáñÝ÷ïõí óçìáíôéêÝò
ðëçñï ïñßåò.
Íá ôé ìáò ëÝíå:
ÊáèõóôåñçìÝíç åêêßíçóç
Áí åíåñãïðïéÞèçêå ç ëåéôïõñãßá ÊáèõóôåñçìÝíç
åêêßíçóç (âëÝðå Åîáôïìéêåýóåé ), á ïý åêêéíÞóåôå
ôï ðñüãñáììá, èá áñ÷ßóåé íá áíáâïóâÞíåé ôï
åíäåéêôéêü ùôÜêé ôï ó÷åôéêü ìå ôçí åðéëåãìÝíç
êáèõóôÝñçóç:
Ìå ôï ðÝñáóìá ôïõ ÷ñüíïõ èá áðåéêïíßæåôáé ç
õðïëåéðüìåíç êáèõóôÝñçóç, ìå ôï ó÷åôéêü
åíäåéêôéêü ùôÜêé íá áíáâïóâÞíåé.
Á ïý äéáíõèåß ç åðéëåãåßóá êáèõóôÝñçóç ôï
åíäåéêôéêü ùôÜêé ðïõ áíáâïóâÞíåé èá óâÞóåé êáé
èá áñ÷ßóåé ôï ôåèÝí ðñüãñáììá.
ÅíäåéêôéêÜ öùôÜêé öÜóç óå åîÝëéîç
ÊáôÜ ôïí åðéèõìçôü êýêëï ðëõóßìáôïò, ôá åíäåéêôéêÜ
ùôÜêéá èá áíÜøïõí ðñïïäåõôéêÜ ãéá íá äåßîïõí ôçí
êáôÜóôáóç ðñïþèçóçò:
ÊïõìðéÜ ëåéôïõñãßá êáé ó÷åôéêÜ åíäåéêôéêÜ öùôÜêéá
ÅðéëÝãïíôáò ìéá ëåéôïõñãßá ôï ó÷åôéêü åíäåéêôéêü ùôÜêé
èá ùôéóôåß.
Áí ç åðéëåãìÝíç ëåéôïõñãßá äåí åßíáé óõìâáôÞ ìå ôï
ôåèÝí ðñüãñáììá ôï ó÷åôéêü åíäåéêôéêü ùôÜêé èá
áíáâïóâÞíåé êáé ç ëåéôïõñãßá äåí èá åíåñãïðïéçèåß.
Óôçí ðåñßðôùóç ðïõ ôåèåß ìéá ëåéôïõñãßá ìç óõìâáôÞ
ìå ìéá Üëëç ðïõ åðéëÝ÷èçêå ðñïçãïõìÝíùò èá
ðáñáìåßíåé åíåñãÞ ìüíï ç ôåëåõôáßá åðéëïãÞ.
Åíäåéêôéêü öùôÜêé áóöáëéóìÝíç ðüñôá
Ôï áíáììÝíï åíäåéêôéêü ùôÜêé äåß÷íåé üôé ç ðüñôá
åßíáé áó áëéóìÝíç ãéá ôçí ðáñåìðüäéóç ôõ÷áßùí
áíïéãìÜôùí. Ãéá ôçí áðï õãÞ æçìéþí ðñÝðåé íá
ðåñéìÝíåôå íá óâÞóåé ôï åíäåéêôéêü ùôÜêé ðñéí ôï
Üíïéãìá ôçò ðüñôáò.
ÓÇÌÅÉÙÓÇ: áí åßíáé åíåñãÞ ç ëåéôïõñãßá
ÊáèõóôåñçìÝíç åêêßíçóç ç ðüñôá äåí ìðïñåß íá
áíïßîåé, ãéá íá ôçí áíïßîåôå èÝóôå ôç ìç÷áíÞ óå ðáýóç
ðéÝæïíôáò ôï êïõìðß ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ.
 Ôï ôá÷ý áíáâïóâÞóéìï ôïõ ùôüò ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ
(ðïñôïêáëß) ôáõôü÷ñïíá ìå åêåßíï ôùí ëåéôïõñãéþí
åðéóçìáßíåé ìéá áíùìáëßá (âëÝðå Áíùìáëßå êáé
ëýóåé ).
Åêêßíçóç åíü ðñïãñÜììáôï
1.ÁíÜøôå ôï ðëõíôÞñéï ðéÝæïíôáò ôï êïõìðß ÁÍÁÌÌÁ/ÓÂÇÓÉÌÏ. ¼ëá ôá åíäåéêôéêÜ ùôÜêé èá áíÜøïõí ìåñéêÜ
äåõôåñüëåðôá, ìåôÜ èá óâÞóïõí êáé èá ðÜëëåôáé ôï åíäåéêôéêü ùôÜêé ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ.
2. Öïñôþóôå ôç ìðïõãÜäá êáé êëåßóôå ôçí ðüñôá.
3. ÈÝóôå ìå ôïí åðéëïãÝá ÐÑÏÃÑÁÌÌÁÔÙÍ ôï åðéèõìçôü ðñüãñáììá.
4. ÈÝóôå ôç èåñìïêñáóßá ðëõóßìáôïò (âëÝðå «Åîáôïìéêåýóåé »).
5. ÈÝóôå ôçí ôá÷ýôçôá óôõøßìáôïò (âëÝðå «Åîáôïìéêåýóåé »).
6. ×ýóôå áðïññõðáíôéêü êáé ðñüóèåôá (âëÝðå «ÁðïññõðáíôéêÜ êáé ìðïõãÜäá»).
7. ÅðéëÝîåôå ôéò äéáèÝóéìåò ëåéôïõñãßåò.
8. ÅêêéíÞóôå ôï ðñüãñáììá ðéÝæïíôáò ôï êïõìðß ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ êáé ôï ó÷åôéêü åíäåéêôéêü ùôÜêé èá ðáñáìåßíåé
áíáììÝíï óõíå÷þò ìå ðñÜóéíï ÷ñþìá.
Ãéá íá áêõñþóåôå ôïí ôåèÝíôá êýêëï èÝóôå ôç ìç÷áíÞ óå ðáýóç ðéÝæïíôáò ôï êïõìðß ÅÊÊÉÍÇÓÇÓ/ÐÁÕÓÇÓ êáé åðéëÝîôå
Ýíá íÝï êýêëï.
9. Óôï ôÝëïò ôïõ ðñïãñÜììáôïò èá ùôéóôåß ôï åíäåéêôéêü ùôÜêé . Ôï åíäåéêôéêü ùôÜêé ÐÏÑÔÁ ÁÓÖÁËÉÓÌÅÍÇ èá
óâÞóåé äåß÷íïíôáò üôé ç ðüñôá ìðïñåß íá áíïßîåé. ÂãÜëôå ôç ìðïõãÜäá êáé á Þóôå ôçí ðüñôá ìéóüêëåéóôç ãéá íá
óôåãíþóåé ï êÜäïò.
ÓâÞóôå ôï ðëõíôÞñéï ðéÝæïíôáò ôï êïõìðß ÁÍÁÌÌÁ/ÓÂÇÓÉÌÏ.
Ðëýóéìï
ÎÝâãáëìá
Óôýøéìï
¢äåéáóìá
ÔÝëïò Ðëõóßìáôïò

18
GR
ÐñïãñÜììáôá
Ôá óôïé÷åßá ðïõ áíáöÝñïíôáé óôïí ðßíáêá åßíáé åíäåéêôéêÜ.
Ãéá üëá ôá Test Institutes:
1) Ðñüãñáììá åëÝã÷ïõ óýìöùíá ìå ôçí ðñïäéáãñáöÞ EN 60456: èÝóôå ôï ðñüãñáììá 6 óå ìéá èåñìïêñáóßá 60°C.
2) Ðñüãñáììá âáìâáêåñþí ìáêñý: èÝóôå ôï ðñüãñáììá 1 óå ìéá èåñìïêñáóßá 40°C.
3) Ðñüãñáììá âáìâáêåñþí óýíôïìï: èÝóôå ôï ðñüãñáììá 2 óå ìéá èåñìïêñáóßá 40°C.
Ðßíáêá ôùí ÐñïãñáììÜôùí
ÐñïãñÜììáôá
Ðåñé ñáöÞ ôïõ Ðñï ñܵµáôïò
ÌÝ éóôç
èåñµïêñ.
(°C)
ÌÝ éóôç
ôá÷ýôçôá
(óôñïöÝò
áíÜ
ëåðôü)
ÁðïññõðáíôéêÜ ÌÝ éóôï
Öïñôßï.
(Kg)
ÄéÜñêåéá
êýêëïõ
Ëåõêáí-
ôéêü Ðëýóéµï Ìáëáêôéêü
ÅéäéêÜ Ðñï ñܵµáôá
6KÕKËÏÓ ÁÐÏÓÔÅÉÑÙÓÇÓ: ËåõêÜ åîáéñåôéêÜ ëåñùµÝíá. 90° 1000 ll l 7 165
6KÕKËÏÓ ÁÐÏÓÔÅÉÑÙÓÇÓ (1): ËåõêÜ êáé ÷ñùµáôéóôÜ
áíèåêôéêÜ, ðïëý ëåñùµÝíá. 60° 1000 -ll 7 175
7ÁËÇÍÕ×ÔÁ: ×ñùµáôéóôÜ åõáßóèçôá ëßãï ëåñùµÝíá. 40° 800 -ll 4 290
8ÐAÕÓÇ ÃÉÁ ÌÙÑÁ: ×ñùµáôéóôÜ åõáßóèçôá ëßãï ëåñùµÝíá. 40° 800 -ll 2 118
9ÐÏÉKÁÌÉÓÁ 40° 600 -ll 270
10 ÌÅÔÁÎÙÔ¢/ ÏÕÑÔºÍÅÓ: Ãéá µåôáîùôÜ ñïý÷á, âéóêüæç, ëéíÜ. 30° 0 -ll 255
11 Ì¢ËËÉÍÁ: Ãéá µÜëëéíá, cachemire, êëð. 40° 600 -ll1,5 55
Ðñï ñܵµáôá éá üëåò ôéò µÝñåò
1ÂÁÌÂÁKÅÑ¢: ËåõêÜ êáé ÷ñùµáôéóôÜ áíèåêôéêÜ, ðïëý
ëåñùµÝíá. 60° 1000 ll l 7 130
1ÂÁÌÂÁKÅÑ¢: (2): ËåõêÜ êáé ÷ñùµáôéóôÜ åõáßóèçôá, ðïëý ëåñùµÝíá. 40° 1000 ll l 7 115
2ÂÁÌÂÁKÅÑ¢ ×ÑÙÌÁÔÉÓÔ¢ (3): ËåõêÜ ëßãï ëåñùµÝíá êáé
åõáßóèçôá ÷ñþµáôá. 40° 1000 ll l 785
3ÓÕÍÈÅÔÉKÁ: ×ñùµáôéóôÜ áíèåêôéêÜ, ðïëý ëåñùµÝíá. 60° 800 -ll 385
3ÓÕÍÈÅÔÉKÁ 40°: ×ñùµáôéóôÜ áíèåêôéêÜ, ëßãï ëåñùµÝíá. 40° 800 -ll 370
4ÖÑÅÓKÁÑÉÓÌÁ 30': Ãéá ôï ãñÞãïñï öñåóêÜñéóµá ñïý÷ùí
åëáöñÜ ëåñùµÝíùí (äåí åíäåßêíõôáé ãéá µÜëëéíá, µåôáîùôÜ
êáé ñïý÷á ðïõ ðëÝíïíôáé óôï ÷Ýñé).
30° 800 -ll 330
5ÖÑÅÓKÁÑÉÓÌÁ 15': Ãéá ôï ãñÞãïñï öñåóêÜñéóµá ñïý÷ùí
åëáöñÜ ëåñùµÝíùí (äåí åíäåßêíõôáé ãéá µÜëëéíá, µåôáîùôÜ
êáé ñïý÷á ðïõ ðëÝíïíôáé óôï ÷Ýñé).
30° 800 -ll1,5 15
Åðß µÝñïõò ðñï ñܵµáôá
AÎÅ ÃÁËÌÁ ÁÌ ÁKÅÑÁ -1000 -- l744
BÎÅ ÃÁËÌÁ ÅÕÁÉÓÈÇÔÁ -800 -- l337
CÓÔÕØÉÌÏ ÁÍÈÅKÔÉKÁ -1000 -- - 716
DÓÅÕØÉÌÏ ÅÕÁÉÓÈÇÔÁ -800 -- - 312
EÁÌÏ×ÅÔÅÕÓÇ ÍÅÑÏÕ -0-- - 72
ÅéäéêÜ ðñïãñÜììáôá
KÕKËÏÓ ÁÐÏÓÔÅÉÑÙÓÇÓ (ðñüãñáììá 6). ¸íá åîõãéáíôéêü ðñüãñáììá óå õøçëÝò èåñìïêñáóßåò ðïõ ðñïâëÝðåé ôç ÷ñÞóç
ëåõêáíôéêïý óå èåñìïêñáóßåò áíþôåñåò ôùí 60°C.
Ãéá ôç ëåýêáíóç ÷ýóôå ôï ëåõêáíôéêü, ôá áðïññõðáíôéêÜ êáé ôá ðñüóèåôá
óôá ó÷åôéêÜ äéáìåñßóìáôá (âëÝðå ðáñÜãñá ï ÓõñôÜñé ôùí áðïññõðáíôéêþí).
ÁËÇÍÕ ÔÁ (ðñüãñáììá 7). Åßíáé Ýíáò áèüñõâïò êýêëïò ðïõ ìðïñåß íá äïõëåýåé ôç íý÷ôá üôáí ôï ôéìïëüãéï ôïõ
çëåêôñéêïý åßíáé ìåéùìÝíï. Ôï ðñüãñáììá ìåëåôÞèçêå ãéá óõíèåôéêÜ êáé âáìâáêåñÜ ôïý÷á. Óôï ôÝëïò ôïõ êýêëïõ ç
ìç÷áíÞ óôáìáôÜåé ìå ôï íåñü óôç ëåêÜíç. Ãéá ôï óôýøéìï êáé ôï Üäåéáóìá ðéÝóôå ôï êïõìðß ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ,
äéá ïñåôéêÜ ìåôÜ áðü 8 þñåò ç ìç÷áíÞ èá êÜíåé áõôüìáôá ôï óôýøéìï êáé ôï Üäåéáóìá ôïõ íåñïý.
ÐAÕÓÇ ÃÉÁ ÌÙÑÁÖÑÅÓKÁÑÉÓÌÁ (ðñüãñáììá 8). Ðñüãñáììá éêáíü íá áðïìáêñýíåé ôïõò ëåêÝäåò ôõðéêïýò ôùí
ìùñþí, äéáó áëßæïíôáò ôçí áðïìÜêñõíóç ôïõ áðïññõðáíôéêïý áðü ôá ñïý÷á ãéá ôçí áðï õãÞ áëëåñãéþí óôï
åõáßóèçôï äÝñìá ôùí ìùñþí. Ï êýêëïò ìåëåôÞèçêå ãéá íá ìåéþíåé ôï âáêôçñéäéáêü ïñôßï ÷ñçóéìïðïéþíôáò ìéêñüôåñç
ðïóüôçôá íåñïý êáé âåëôéóôïðïéþíôáò ôçí åðßäñáóç ôùí åéäéêþí åîõãéáíôéêþí ðñüóèåôùí óôï áðïññõðáíôéêü.
Óôï ôÝëïò ôïõ ðëõóßìáôïò ç ìç÷áíÞ äéåíåñãåß áñãÝò ðåñéóôñï Ýò ôïõ êÜäïõ ãéá ôçí áðï õãÞ äçìéïõñãßáò ðôõ÷þóåùí.
Ãéá íá ôåëåéþóåé ï êýêëïò ðéÝóôå ôï êïõìðß ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ.
ÖÑÅÓKÁÑÉÓÌÁ 30' (ðñüãñáììá 4) ìåëåôÞèçêå ãéá ôï ðëýóéìï ñïý÷ùí åëá ñÜ ëåñùìÝíùí óå óýíôïìï ÷ñüíï: äéáñêåß
ìüíï 30 ëåðôÜ êáé óáò åîïéêïíïìåß ÷ñüíï êáé åíÝñãåéá. ÈÝôïíôáò ôï ðñüãñáììá (4 óå 30°C) ìðïñåßôå íá ðëýíåôå ìáæß
õ Üóìáôá äéá ïñåôéêÞò ýóçò (åêôüò ìÜëëéíùí êáé ìåôáîùôþí) ìå Ýíá ìÝãéóôï ïñôßï 3 kg.
ÖÑÅÓKÁÑÉÓÌÁ 15' (ðñüãñáììá 5) ìåëåôÞèçêå ãéá ôï ðëýóéìï ñïý÷ùí åëá ñÜ ëåñùìÝíùí óå óýíôïìï ÷ñüíï: äéáñêåß
ìüíï 15 ëåðôÜ êáé óáò åîïéêïíïìåß ÷ñüíï êáé åíÝñãåéá. ÈÝôïíôáò ôï ðñüãñáììá (5 óå 30°C) ìðïñåßôå íá ðëýíåôå ìáæß
õ Üóìáôá äéá ïñåôéêÞò ýóçò (åêôüò ìÜëëéíùí êáé ìåôáîùôþí) ìå Ýíá ìÝãéóôï ïñôßï 1,5 kg.

19
GR
ÈÝóôå ôç èåñìïêñáóßá
ÓôñÝ ïíôáò ôïí åðéëïãÝá ÈÅÑÌÏÊÑÁÓÉÁ ôßèåôáé ç èåñìïêñáóßá ðëõóßìáôïò (âëÝðå Ðßíáêá ðñïãñáììÜôùí).
Ç èåñìïêñáóßá ìðïñåß íá ìåéùèåß ìÝ÷ñé ôï ðëýóéìï óå êñýï íåñü ( ).
Ôï ìç÷Üíçìá èá ðáñåìðïäßóåé áõôüìáôá ôç èÝóç èåñìïêñáóßáò ìåãáëýôåñçò ôçò ìÝãéóôçò ðñïâëåðüìåíçò ãéá
êÜèå ðñüãñáììá.
ÈÝóôå ôï óôýøéìï
ÓôñÝ ïíôáò ôïí åðéëïãÝá ÓÔÕØÉÌÏ ôßèåôáé ç ôá÷ýôçôá óôõøßìáôïò ôïõ åðéëåãìÝíïõ ðñïãñÜììáôïò.
Ïé ìÝãéóôåò ðñïâëåðüìåíåò ôá÷ýôçôåò ãéá ôá ðñïãñÜììáôá åßíáé:
ÐñïãñÜììáôá ÌÝãéóôç ôá÷ýôçôá
ÂáìâáêåñÜ 1000 óôñï Ýò áíÜ ëåðôü
ÓõíèåôéêÜ 800 óôñï Ýò áíÜ ëåðôü
ÌÜëëéíá 600 óôñï Ýò áíÜ ëåðôü
ÌåôáîùôÜ ìüíï Üäåéáóìá
Ç ôá÷ýôçôá óôõøßìáôïò ìðïñåß íá åëáôôùèåß Þ íá áðïêëåéóôåß åðéëÝãïíôáò ôï óýìâïëï .
Ôï ìç÷Üíçìá èá ðáñåìðïäßóåé áõôüìáôá ôç äéåíÝñãåéá óôõøßìáôïò ìåãáëýôåñïõ ôïõ ìÝãéóôïõ ðñïâëåðüìåíïõ
ãéá êÜèå ðñüãñáììá.
Ëåéôïõñãßå
Ïé äéÜ ïñåò ëåéôïõñãßåò ðëõóßìáôïò ðïõ ðñïâëÝðïíôáé áðü ôï ðëõíôÞñéï åðéôñÝðïõí ôçí åðßôåõîç ôïõ
êáèáñéóìïý êáé ôïõ ëåõêïý ðïõ åðéèõìåßôå.
Ãéá ôçí åíåñãïðïßçóç ôùí ëåéôïõñãéþí:
1. ðéÝóôå ôï ðëÞêôñï ôï ó÷åôéêü ìå ôçí åðéëåãìÝíç ëåéôïõñãßá.
2. Ôï Üíáììá ôïõ åíäåéêôéêïý ùôüò åðéóçìáßíåé üôé ç ëåéôïõñãßá åßíáé åíåñãÞ.
ÐáñáôÞñçóç: Ôï ãñÞãïñï áíáâïóâÞóéìï ôïõ åíäåéêôéêïý ùôüò äåß÷íåé üôé ç ó÷åôéêÞ ëåéôïõñãßá äåí ìðïñåß íá
åðéëåãåß ãéá ôï ôåèÝí ðñüãñáììá.
ÊáèõóôåñçìÝíç åêêßíçóç
Êáèõóôåñåß ôçí åêêßíçóç ôïõ ìç÷áíÞìáôïò ìÝ÷ñé 24 þñåò.
ÐéÝóôå ðïëëÝò ïñÝò ôï ðëÞêôñï ìÝ÷ñé íá áíÜøåé ôï åíäåéêôéêü ùôÜêé ôï ó÷åôéêü ìå ôçí åðéèõìçôÞ êáèõóôÝñçóç. Óôçí
ðÝìðôç ïñÜ ðïõ èá ðéÝóåôå ôï êïõìðß ç ëåéôïõñãßá èá áðåíåñãïðïéçèåß.
ÓÇÌÅÉÙÓÇ: Á ïý ðáôçèåß ôï ðëÞêôñï ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ, ìðïñåßôå íá áëëÜîåôå ôçí ôéìÞ êáèõóôÝñçóçò ìüíï ìåéþíïíôÜò ôçí.
 Åßíáé åíåñãü ìå üëá ôá ðñïãñÜììáôá.
Åýêïëï óéäÝñùìá
ÅðéëÝãïíôáò ôç ëåéôïõñãßá áõôÞ, ôï ðëýóéìï êáé ôï óôýøéìï èá ôñïðïðïéçèïýí êáôÜëëçëá ãéá ôç ìåßùóç
ó÷çìáôéóìïý ôóáëáêùìÜôùí. Óôï ôÝëïò ôïõ êýêëïõ ðëýóçò èá ãßíïõí áñãÝò ðåñéóôñï Ýò ôïõ êÜäïõ. Ôï
åíäåéêôéêü ùôÜêé ôçò ëåéôïõñãßáò ÅÕÊÏËÏ ÓÉÄÅÑÙÌÁ êáé ôçò ÅÊÊÉÍÇÓÇÓ/ÐÁÕÓÇÓ èá áíáâïóâÞíïõí
(ðïñôïêáëß) êáé ç Üóç ÎÅÂÃÁËÌÁÔÏÓ èá ðáñáìåßíåé óõíå÷þò áíáììÝíç. Ãéá ôï ðÝñáò ôïõ êýêëïõ ðáôÞóôå ôï
êïõìðß ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ Þ ôï êïõìðß ÅÕÊÏËÏ ÓÉÄÅÑÙÌÁ.
Óôï ðñüãñáììá ÌåôáîùôÜ ç ìç÷áíÞ èá ôåëåéþóåé ôïí êýêëï ìå ôçí ìðïõãÜäá óå ìïýëéáóìá êáé ôï åíäåéêôéêü
ùôÜêé ÅÕÊÏËÏ ÓÉÄÅÑÙÌÁ èá áíáâïóâÞíåé. Ãéá íá áäåéÜóåôå ôï íåñü êáé íá ìðïñåßôå íá âãÜëåôå ôçí
ìðïõãÜäá ðñÝðåé íá ðáôÞóåôå ôï êïõìðß ÅÊÊÉÍÇÓÇ/ÐÁÕÓÇ Þ ôï êïõìðß ÅÕÊÏËÏ ÓÉÄÅÑÙÌÁ.
 Äåí åßíáé åíåñãü óôá ðñïãñÜììáôá 4, 5, 6, 7, 8, 11, C, D, E.
¸îôñá ÎÝâãáëìá
ÅðéëÝãïíôáò ôç äõíáôüôçôá áõôÞ áõîÜíåôáé ç áðïôåëåóìáôéêüôçôá ôïõ îåâãÜëìáôïò êáé åîáó áëßæåôáé ç
ìÝãéóôç áðïìÜêñõíóç ôïõ áðïññõðáíôéêïý. Åßíáé ÷ñÞóéìï ãéá åðéäåñìßäåò éäéáßôåñá åõáßóèçôåò.
 Äåí åßíáé åíåñãü óôá ðñïãñÜììáôá 4, 5, C, D, E.
Super Wash
×Üñç óôç ÷ñÞóç ìåãáëýôåñçò ðïóüôçôáò íåñïý óôçí áñ÷éêÞ Üóç ôïõ êýêëïõ êáé óôç ÷ñÞóç ðåñéóóüôåñïõ
÷ñüíï, ç äõíáôüôçôá áõôÞ åîáó áëßæåé Ýíá ðëýóéìï õøçëþí åðéäüóåùí.
 Äåí åßíáé åíåñãü óôá ðñïãñÜììáôá 4, 5, 6, 10, 11, A, B, C, D, E.
Åîáôïìéêåýóåé

20
GR
ÁðïññõðáíôéêÜ êáé ìðïõãÜäá
ÈÞêç áðïññõðáíôéêþí
Ôï êáëü áðïôÝëåóìá ôïõ ðëõóßìáôïò åîáñôÜôáé åðßóçò
êáé áðü ôç óùóôÞ äïóïëïãßá ôïõ áðïññõðáíôéêïý:
õðåñâÜëëïíôáò äåí ðëÝíïõìå áðïôåëåóìáôéêüôåñá êáé
óõíôåëïýìå óôç äçìéïõñãßá êñïýóôáò óôá åóùôåñéêÜ
ìÝñç ôïõ ðëõíôçñßïõ êáé óôç ìüëõíóç ôïõ
ðåñéâÜëëïíôïò.
 Ìç ÷ñçóéìïðïéåßôå áðïññõðáíôéêÜ ãéá ðëýóéìï óôï
÷Ýñé, äéüôé ðáñÜãïõí ðïëý á ñü.
ÂãÜëôå ôç èÞêç
áðïññõðáíôéêþí êáé
åéóÜãåôå ôï
áðïññõðáíôéêü Þ ôï
ðñüóèåôï ùò åîÞò.
èÞêç 1: Áðïññõðáíôéêü ãéá ðñüðëõóç
(óå óêüíç)
Ðñéí ÷ýóåôå ôï áðïññõðáíôéêü åëÝãîôå áí Ý÷åé
åéóá÷èåß ç ðñüóèåôç ëåêáíßôóá 4.
èÞêç 2: Áðïññõðáíôéêü ãéá ðëýóéìï
(óå óêüíç Þ õãñü)
Ôï õãñü áðïññõðáíôéêü ÷ýíåôáé ìüíï ðñéí ôçí
åêêßíçóç.
èÞêç 3: Ðñüóèåôá (ìáëáêôéêü, êëð.)
Ôï ìáëáêôéêü äåí ðñÝðåé íá äéá åýãåé áðü ôï ðëÝãìá.
èÞêç ðñüóèåôç 4: Ëåõêáíôéêü
Êýêëï ëåýêáíóç
Ç ëåýêáíóç ìðïñåß íá äéåíåñãçèåß ìüíï ìå ôá
ðñïãñÜììáôá 1,2,6.
×ýóôå ôï ëåõêáíôéêü óôçí ðñüóèåôç ëåêáíßôóá 4, ôï
áðïññõðáíôéêü êáé ôï ìáëáêôéêü óôéò ó÷åôéêÝò
ëåêáíßôóåò, êáôüðéí èÝóôå Ýíá áðü ôá
ðñïáíá åñèÝíôá ðñïãñÜììáôá.
Åíäåßêíõôáé ìüíï ãéá ñïý÷á âáìâáêåñÜ ðïëý
ëåñùìÝíá.
Ðñïåôïéìáóßá ôç ìðïõãÜäá
 ×ùñßóôå ôç ìðïõãÜäá áíÜëïãá:
- ìå ôï åßäïò ôïõ õ Üóìáôïò/ ôï óýìâïëï ôçò åôéêÝôáò.
- ôá ÷ñþìáôá: ÷ùñßóôå ôá ÷ñùìáôéóôÜ ñïý÷á áðü ôá
ëåõêÜ.
 Åêêåíþóôå ôéò ôóÝðåò êáé åëÝãîôå ôá êïõìðéÜ.
 Ìçí îåðåñíÜôå ôéò õðïäåéêíõüìåíåò ôéìÝò, óå ó÷Ýóç
ìå ôï âÜñïò ôçò óôåãíÞò ìðïõãÜäáò:
ÁíèåêôéêÜ õ Üóìáôá: max 7 kg
ÓõíèåôéêÜ õ Üóìáôá: max 3 kg
Åõáßóèçôá õ Üóìáôá: max 2 kg
ÌÜëëéíá: max 1,5 kg
MAX
1
2
4
3
Ðüóï æõãßæåé ç ìðïõãÜäá;
1 óåíôüíé 400-500 gr.
1 ìáîéëáñïèÞêç 150-200 gr.
1 ôñáðåæïìÜíôéëï 400-500 gr.
1 ìðïõñíïýæé 900-1.200 gr.
1 ðåôóÝôá 150-250 gr.
ÅéäéêÜ ñïý÷á
Ðïéêáìéóá: ÷ñçóéìïðïéÞóôå ôï áíôßóôïé÷ï ðñüãñáììá
9 ãéá íá ðëýíåôå ðïõêÜìéóá äéá üñùí åéäþí
õ Üóìáôïò êáé ÷ñþìáôïò.
Åîáó áëßæåé ôç ìÝãéóôç ñïíôßäá åëá÷éóôïðïéþíôáò ôï
ó÷çìáôéóìü ôóáëáêùìÜôùí.
ÌåôáîùôÜ: ÷ñçóéìïðïéÞóôå ôï áíôßóôïé÷ï ðñüãñáììá
10 ãéá íá ðëýíåôå üëá ôá ìåôáîùôÜ ñïý÷á. ÓõíéóôÜôáé
ç ÷ñÞóç åíüò åéäéêïý áðïññõðáíôéêïý ãéá åõáßóèçôá
ñïý÷á.
Êïõñôßíå : ðñïôåßíåôáé íá ôéò äéðëþíåôå êáé íá ôéò
âÜæåôå óôï ðáñå÷üìåíï óáêßäéï. ×ñçóéìïðïéÞóôå ôï
ðñüãñáììá 10.
ÌÜëëéíá: Ôï Hotpoint/Ariston åßíáé ôï ìïíáäéêü
ðëõíôÞñéï ðïõ êáôÝêôçóå ôç óçìáíôéêÞ áíáãíþñéóç
Woolmark Platinum Care (M.0508) åê ìÝñïõò ôçò The
Woolmark Company, ðïõ ðéóôïðïéåß ôï ðëýóéìï óôï
ðëõíôÞñéï üëùí ôùí ìÜëëéíùí ñïý÷ùí êáèþò êáé åêåßíùí
ðïõ Ýñïõí ôçí åôéêÝôá ìüíï ðëýóéìï óôï ÷Ýñé .
Ìå ôï ðñüãñáììá 11 Ý÷åôå óõíåðþò áðüëõôç
âåâáéüôçôá íá ðëÝíåôå óôï ðëõíôÞñéï üëá ôá ìÜëëéíá
ñïý÷á (max. 1,5 kg) ìå ôçí åããýçóç ôùí êáëýôåñùí
åðéäüóåùí.
Óýóôçìá éóïóôÜèìéóç ôïõ öïñôßïõ
Ðñéí áðü êÜèå óôýøéìï, ãéá íá áðï ýãåôå äïíÞóåéò
õðåñâïëéêÝò êáé ãéá íá êáôáíåßìåôå ïìïéüìïñ á ôï
ïñôßï, ï êÜäïò äéåíåñãåß ðåñéóôñï Ýò óå ìéá ôá÷ýôçôá
åëá ñÜ áíþôåñç åêåßíçò ôïõ ðëõóßìáôïò. Áí óôï ôÝëïò
ôùí äéáäï÷éêþí ðñïóðáèåéþí ôï ïñôßï äåí Ý÷åé áêüìç
åîéóïññïðçèåß óùóôÜ ç ìç÷áíÞ äéåíåñãåß ôï óôýøéìï óå
ìéá ôá÷ýôçôá ÷áìçëüôåñç ôçò ðñïâëåðüìåíçò.
Ðáñïõóßá õðåñâïëéêÞò áóôÜèåéáò, ôï ðëõíôÞñéï
äéåíåñãåß ôçí êáôáíïìÞ áíôß ôïõ óôõøßìáôïò. Ãéá íá
åõíïçèåß êáëýôåñç êáôáíïìÞ ôïõ ïñôßïõ êáé ôçò
óùóôÞò åîéóïññüðçóçò óõíéóôÜôáé ç áíÜìéîç ñïý÷ùí
ìåãÜëùí êáé ìéêñþí äéáóôÜóåùí.
